FORD FIESTA 1989 Service Repair Manual

wiring passes through, as an aid to
reassembly.
Refitting
3Position the clock spring on the steering
wheel, routing the wiring as noted on removal,
and secure with the retaining screws.
4 The clock spring must now be centred as
follows.
5 Depress the locking pin, and rotate the
clock spring outer rotor fully anti-clockwise
until it is tight (see illustration) .
6 Now turn the outer rotor approximately
3.75 turns clockwise, then release the locking
pin. Ensure that the locking pin engages when
it is released.
7 Check that the relative position of the
direction indicator cancelling cam to the cable
connector on the clock spring assembly is as
shown (see illustration 31.5).
8 Refit the steering wheel as described in
Chapter 10.
12•18 Body electrical systems
31.5 Centring the air bag clock spring. Depress locking pin (A) and r\
otate outer rotor (B)
anti-clockwise (“X” indicates relative position of the direction \
indicator cancelling cam to the cable connector - see text)
1595Ford Fiesta Remakeprocarmanuals.com
http://vnx.su

Wiring diagrams 12•19
Notes, internal connection details, and key to symbols
12
1595Ford Fiesta Remakeprocarmanuals.com
http://vnx.su

12•20 Wiring diagrams
Diagram 1: Starting, charging, cooling fan, ABS, warning lamps and gauges
1595Ford Fiesta Remakeprocarmanuals.com
http://vnx.su

Wiring diagrams 12•21
Diagram 1a: Ignition system – carburettor models
12
1595Ford Fiesta Remakeprocarmanuals.com
http://vnx.su

12•22 Wiring diagrams
Diagram 1b: Ignition system – fuel-injected models
1595Ford Fiesta Remakeprocarmanuals.com
http://vnx.su

Wiring diagrams 12•23
Diagram 1c: Typical 1.1/1.3/1.4 CFi fuel injection
12
1595Ford Fiesta Remakeprocarmanuals.com
http://vnx.su

12•24 Wiring diagrams
Diagram 1d: 1.6 EFi fuel injection (including RS Turbo)
1595Ford Fiesta Remakeprocarmanuals.com
http://vnx.su

Wiring diagrams 12•25
Diagram 1e: DOHC 16-valve fuel injection
12
1595Ford Fiesta Remakeprocarmanuals.com
http://vnx.su

12•26 Wiring diagrams
Diagram 2: Exterior lighting – side and headlamps
1595Ford Fiesta Remakeprocarmanuals.com
http://vnx.su

Wiring diagrams 12•27
Diagram 2a: Exterior lighting – stop, reversing, fog and direction in\
dicator lamps
12
