Page 71 of 281
µµµ
µ
You can insert or
remove the key only in this position.
To turn the key, the shift lever must
be in Park, and you must push the
key in slightly. If the f ront wheels
are turned, the anti-thef t lock may
make it difficult to turn the key.
Firmly turn the steering wheel to the
left or to the right as you turn thekey.
The ignition switch has f our
positions: LOCK (0), ACCESSORY
(I), ON (II), START (III) You can
operate the audio system and the
accessory power sockets in this
position.
This is the normal key
position when driving. Several of the
lights on the instrument panel come
on as a test when you turn the
ignition switch f rom ACCESSORY
(I) to ON (II).
Use this position
only to start the engine. The switch
returns to the ON (II) position when
you let go of the key.
L OCK (0) A CCESSORY (I)
ON (II)
ST A RT (III)
Ignition Switch
76
— — y y
( y y
Page 72 of 281
You will hear a reminder beeper if
you leave the key in the ignition
switch in the LOCK (0) or
ACCESSORY (I) position and open
thedriver’sdoor.Removethekeyto
turn of f the beeper.
If your vehicle has an automatic
transmission, the shif t lever must be
in Park bef ore you can remove the
key f rom the ignition switch.Each f ront door has a power door
lock master switch. Either switch
locks and unlocks all doors. Push the
top of the switch to lock all doors;
push the bottom to unlock them.Each door has a lock tab on it. Push
down the tab to lock the door and
pull it up to unlock. When you push
down the tab on the driver’s door, all
the doors lock.
To lock any passenger’s door when
getting out of the vehicle, push the
lock tab down, and close the door.
All doors can be locked f rom the
outsidebyusingthekeyinthe
driver’s door. To unlock only the
driver’s door, insert the key, turn it
clockwise, and release it. The
remaining doors unlock when you
turn the key a second time within a
f ew seconds.
Door L ocks
Ignit ion Swit ch, Door L ocks
Inst rument s and Cont rols
77
top
bottom
POWER DOOR LOCK MASTER SWITCH
Removing the key from the
ignition switch while driving
locks the steering. This can
cause you to lose control of thevehicle.
Remove the key from the
ignition switch only whenparked.
— — y
y
( y y
Page 73 of 281
µ
With the driver’s door open and the
key in the ignition, both door lock
switches are disabled. They are not
disabled if the driver’s door is closed.
Pushing the switch down on the
open passenger’s door will lock all
doors.
The childproof door locks are
designed to prevent children seated
in the rear f rom accidentally opening
the rear doors. Each rear door has a
lock lever near the edge. With the
lever in the LOCK position, the door
cannot be opened f rom the inside
regardless of the position of the lock
tab. To open the door, pull the lock
tab up, and use the outside door
handle. Pressthisbuttononceto
lock all doors. Some exterior and
interior lights will f lash. The doors
do not lock if they are not f ully
closed or the key is in the ignition
switch.
Door L ocks
L ockout Prevent ionChildproof Door L ocks Remote T ransmitter
LOCK
78
LEVERPANIC
BUTTON
TRUNK
RELEASE
BUTTON LOCK
BUTTON
UNLOCK
BUTTON
— — y
y
( y
y
Page 74 of 281
µµ
µ
The ceiling light (if the ceiling light
switch is in the center position) will
come on when you press the
UNLOCK button. If you do not open
any door, the light stays on f or about
30 seconds, then f ades out. If you
relock the doors with the remote
transmitter before 30 seconds have
elapsed, the light will go of f
immediately. Press this button once
to unlock the driver’s door. Push it
twice to unlock the other doors.
When you push LOCK twice within 5
seconds, you will hear a beep to
verify that the security system is
active.
Pressthisbuttonfor
about 1 second to attract attention;
thehornwillsoundandtheexterior
lights will f lash f or about 30 seconds.
To cancel panic mode, press any
other button on the remote
transmitter, or turn the ignition
switch to the ON (II) position.
Pressthisbuttonfor
about 1 second to open the trunk.
You cannot open the trunk if the key
is in the ignition switch.
You cannot lock the doors with the
remote transmitter if they are not
f ully closed or the key is in the
ignition switch.
If you unlock the doors with the
remote transmitter, but do not open
any of the doors within 30 seconds,
the doors automatically relock.
Af ter the doors automatically relock,
the security system will be active.
U.S. EX, EX-L, LX-V6 and EX-V6
Canadian SE, EX-L, SE-V6 and EX-V6
U.S. EX, EX-L, LX-V6 and EX-V6Canadian SE, EX-L, SE-V6 and EX-V6
Childproof Door L ocks, Remot e T ransmit t er
UNL OCK PA NIC
TRUNK
Inst rument s and Cont rols
79
— — y y
( y y
Page 75 of 281
Avoid dropping or throwing the
transmitter.
Protect the transmitter from
extreme temperature.
Do not immerse the transmitter in
any liquid.
If you lose a transmitter, the
replacement needs to be
reprogrammed by your dealer.If it takes several pushes on the
button to lock or unlock the doors,
replace the battery as soon as
possible.
Battery type: CR1616
To replace the battery:Remove the screw at the base of
the transmitter with a small
Phillips-head screwdriver.
Separate the transmitter by prying
its middle seam with your
f ingernail.
1. 2.
Remote Transmitter
Remote Transmitter Care Replacing the Transmitter Battery
80
SCREW
— — y y
( y y
Page 76 of 281
´
Inside the transmitter, separate
the inner cover f rom the keypad
by releasing the two tabs on the
cover. Remove the old battery from the
back of the inner cover, and note
the polarity. Make sure the
polarity of the new battery is the
same ( side f acing down), then
insert it into the back of the cover.
Install the parts in reverse order.
3. 4. 5.
As required by the FCC:
This device complies with Part 15 of theFCC rules. Operation is subject to the
f ollowing two conditions: (1) This devicemay not cause harmf ul interf erence, and(2) this device must accept any
interf erence received, includinginterf erence that may cause undesiredoperation.
Changes or modif ications not expresslyapproved by the party responsible f or
compliance could void the user’sauthority to operate the equipment.
This device complies with IndustryCanada Standard RSS-210.Operation is subject to the f ollowing two
conditions: (1) this device may not causeinterf erence, and (2) this device mustaccept any interf erence that may cause
undesired operation of the device.
Remote Transmitter
Inst rument s and Cont rols
81
BATTERY
TAB
— — y y
( y y
Page 77 of 281
To protect items in the trunk when
you need to give the key to someone
else:Give the person the valet key.
Youcanopenthetrunkinanyof
three ways:
Pull up on the trunk release lever
located to the lef t of the driver’s
seat. Lockthetrunkreleaseleverwith
the master key. Also make sure
the trunk pass-through cover is
locked (see page ).
Press and hold the trunk release
button on the remote transmitter. To close the trunk, press down on
the trunk lid.
See page f or cargo loading and
weight limit inf ormation. Keep the
trunk lid closed at all times while
driving to avoid damaging the lid,
and to prevent exhaust gas from
getting into the interior. See
on page .
1. 2.
52
165
89
Trunk
Carbon
Monoxide Hazard
82
Pull
TRUNK RELEASE LEVER MASTER
KEY
— — y y
( y y
Page 78 of 281
As a saf ety f eature, your vehicle has
a release lever on the trunk latch so
the trunk can be opened f rom the
inside.To open the trunk, push the release
lever to the lef t.
For more inf ormation about child
saf ety, see page .
38
Emergency T runk Opener
Trunk
Inst rument s and Cont rols
83
— — y y
( y y
Page 79 of 281
After the seat reaches a comfortable
temperature, select LO by pushing
the back of the switch. This will keep
the seat warm.
In HI, the heater turns of f when the
seat gets warm, and turns back on
after the seat temperature drops.
In LO, the heater runs continuously.
It does not cycle with temperature
changes.Follow these precautions whenever
you use the seat heaters:
Use the HI setting only to heat the
seats quickly, because it draws
large amounts of current f rom the
battery.
If the engine is lef t idling f or an
extended period, do not use the
seat heaters even on the LO
setting. It can weaken the battery,
causing hard starting.
Both f ront seats are equipped with
seat heaters. Because of the sensors
f or the side airbag system, there is
no heater in the passenger’s seat-
back. The ignition switch must be
ON (II) to use the heaters.
U.S. EX-L and EX-V6 Canadian EX-L and EX-V6
Seat Heaters
84
— — y y
( y y
Page 80 of 281
µ
Raises or lowers the
seat.
Adjusts the seat-back
angle f orward or
backward.
Moves the f ront of the
seat up or down and
the rear of the seat up
or down.
Moves the seat
f orward and backward.
The controls f or the adjustable
driver’s power seat are on the
outside edge of the seat bottom. You
can adjust the power seat with the
ignition switch in any position. Make
all seat adjustments bef ore you start
driving.
To change the lumbar support, move
the lever on the right side of the
seat-back forward or backward.
Keep moving the lever f orward or
backward until you f ind a suitable
position.
The passenger’s seat has two
switches. One moves the seat
f orward and backward, and the other
raises and lowers the seat.
See pages f or important saf ety
inf ormation and warnings about how toproperly position seats and seat-backs.
U.S. EX, EX-L, LX-V6 and EX-V6
Canadian EX-L, SE-V6 and LX-V6
14
13
U.S. EX-V6 Canadian EX-V6 U.S. EX, EX-L and EX-V6
Canadian EX-L and EX-V6
Power Seat Adjustment Driver’s Lumbar Support
Seats
Inst rument s and Cont rols
85
