Hyundai Accent 2006 Owner's Manual

SA040A1-E SA050A1-E
TWO WAY RADIO INSTALLATION
This vehicle is fitted with electronically controlled fuel injection or other micro processor controlled equipment. It is possible for incorrectly installed two way radio equipment including mobiletelephones to adversely affect these systems. Before radio equipment of this kind is installed, please contact your Hyundai dealer for recommendation regarding the suitability of the particular radio equipmentconcerned and the recommended method of installation and equipment location. Incorrectly installed or unsuitable equipment which gives rise to incorrect functioning of or damage to electronic vehicle components will not fall within the scope of thevehicle manufacturers warranty.
CAUTION: MODIFICATIONS TO ORIGINAL VEHICLE SPECIFICATION
Modification to the original vehicle specification may invalidate the manufacturers warranty and may adversely affect the safety and durability of the vehicle. Components which are subject to modification or are added to the original vehiclespecification without the express approval of the manufacturer and result in conse- quential loss or damage are not covered by the vehicle manufacturers warranty.!

CONTROLS AND EQUIPMENTDRIVING YOUR HYUNDAI
IN CASE OF EMERGENCY
APPEARANCE CARE
VEHICLE MAINTENANCE REQUIREMENTS OWNER MAINTENANCE
EMISSION CONTROL SYSTEMS CONSUMER INFORMATIONVEHICLE SPECIFICATIONS
INDEX
TABLE OF CONTENTS
SECTION
5
1 2 3 4 6 7 8 9
10

!
SAFETY AND VEHICLE DAMAGE WARNING
This manual includes information titled as WARNING, CAUTION and NOTE. These titles indicate the following:
WARNING:
This indicates that a condition may result in harm, serious injury or death to you or other persons if the warning is not heeded. Follow the advice provided with the warning.
CAUTION:
This indicates that a condition may result in damage to your vehicle or its equipment if the caution is not heeded. Follow the advice provided with the caution. NOTE: This indicates that interesting or helpful information is being provided.
A090A01A-AAT
!

A100A01L-EAT GUIDE TO HYUNDAI GENUINE PARTS
1. What are Hyundai GenuineParts?
Hyundai Genuine Parts are the same parts used by Hyundai Motor Com- pany to manufacture vehicles. Theyare designed and tested for the opti- mum safety, performance, and reli- ability to our customers.
2. Why should you use genuine parts?
Hyundai Genuine Parts are engineered and built to meet rigid manufacturing requirements. Using imitation, coun- terfeit or used salvage parts is not covered under the Hyundai New Ve-hicle Limited Warranty or any other Hyundai warranty. In addition, any damage to or failure of GenuineHyundai Parts caused by the installa- tion or failure of an imitation, counter- feit or used salvage part is not coveredby Hyundai Motor Company.
3. How can you tell if you are
purchasing Hyundai Genuine Parts?
Look for the Hyundai Genuine Parts Logo on the package (see below). A100A03L
The export specifications are written inEnglish only. Hyundai Genuine Parts are only soldthrough authorized Hyundai Dealerships.
A100A04L
A100A02L
A100A01L

HLC003-D
B250B01A-EAT
INSTRUMENTS AND CONTROLS

CAUTION:
When installing a container of liquid air freshener inside the vehicle, do not place it near the instrument cluster nor on the instrument panel pad surface. If there is any leakage from the air freshener onto these areas (Instrument cluster, instrument panel pad or air ventilator), it may damage these parts. If the liquid from air freshener does leak onto these areas, wash themwith water immediately.!
1. Passenger's Airbag (Not all models)
2. Glove Box
3. Heating/Air Conditioning Control Panel
(Not all models)
4. Rear Fog Light Switch
5. Rear Window Defogger Switch (Not all models)
6. Hazard Warning Light Switch
7. Front Fog Light Switch (Not all models)
8. Digital Clock 9. Windscreen Wiper/Washer Switch
10. Horn and Driver's Airbag
11. Instrument Cluster
12. Multi-Function Light Switch 13. Headlight Leveling Switch
14. Rear Wiper/Washer Switch (Not all models)
15. Rear Drink Holder
16. Parking Brake Lever
17. Shift Lever (Not all models)
18. Front Drink Holder
19. Ashtray
20. Cigar Lighter
21. Bonnet Release Lever

YOUR VEHICLE AT A GLANCE
B255A01A-EAT INDICATOR SYMBOLS ON THE INSTRUMENT PANEL * More detailed explanations of these items will be found begining on page 1-40.Turn Signal Indicator Lights
SRS (Airbag) Service Reminder Indicator O/D OFF Indicator Light (Automatic transaxle only) High Beam Indicator Light
Low Oil Pressure Warning Light
ABS Service Reminder Indicator (Not all models)
Door Ajar Warning Light
Parking Brake/Low Brake Fluid Level Warning Light Charging System Warning Light
Fuel Filter Warning Light (Diesel only)
Low Fuel Level Warning Light Diesel Pre-heat Indicator Light (Diesel only)
Malfunction Indicator Light
Immobilizer Indicator

Fuel Recommendations ................................................ 1-2
Running In Your New Hyundai ..................................... 1-4
Immobilizer System ...................................................... 1-5
Door .............................................................................. 1-6Power Windows........................................................... 1-11
Seat ............................... .............................................. 1-12
Seat Belt ...................................................................... 1-18
Child Restraint System ................................................ 1-22
Supplemental Restraint (AIRBAG) System .................1-31
Instrument Cluster and Indicator Lights .......................1-38
Warning and Indicator Lights....................................... 1-42
Trip Computer .............................................................. 1-48
Multi-Function Switch .................................................. 1-51
Windscreen Wiper/Washer Switch ..............................1-52
Sunroof ........................................................................ 1-59
Mirror ........................................................................... 1-64
Bonnet Release ........................................................... 1-67
Heating and Cooling Control .......... ..............................1-72
Stereo Sound System ................................................. 1-81
Antenna ....................................................................... 1-83
CONTROLS AND EQUIPMENT
1
1

1CONTROLS AND EQUIPMENT
2FUEL RECOMMENDATIONS
B010A02A-EAT Petrol Engines THIS VEHICLE MUST ONLY BE OP- ERATED WITH UNLEADED FUEL.SERIOUS DAMAGE WILL RESULT FROM THE USE OF LEADED FUEL. However, care must be exercised when filling the vehicle tank from jerry cans orby means of a funnel that the fuel being used is unleaded. The use of leaded fuel in this vehicle willresult in irreversible pollution of the catalyst element. Such pollution will prevent correct operation of the cata-lyst and give rise to increased operating temperatures leading to the catalyst element melting and restricting the ex-haust flow along with an increase in exhaust emission levels.
Unleaded fuel with a Research Octane Number (RON) of 91 or higher must beused in this vehicle. To prevent accidental filling of the fuel tank with leaded fuel, a small diameterfiller neck along with a restrictor flap are fitted to ensure that only unleaded fuel pump nozzles may enter the filler neck.
!
CAUTION:
The vehicle warranty will not extend to damage arising from the use of incorrect fuels.
! Diesel Engines Diesel fuel of 52 to 54 cetane is the correct rating to use in your HyundaiAccent. If two types of diesel fuel are available, use summer or winter fuel properly according to the following tem-perature conditions.
o Above 23°F (-5°C) ... Summer type
diesel fuel.
o Below 23°F (-5°C) ... Winter type
diesel fuel.
Watch the fuel level in the tank very carefully : If the engine stops due to fuel failure, the circuits must be completelypurged to permit restarting.
CAUTION:
Do not let any petrol or water enterthe tank. If this happens, the tankshould be completely drained and the fuel lines should all be cleaned out. This will stop the fuel pumpfrom becoming contaminated.
B010A04A
UNLEADED FUEL ONLY

3
1
CONTROLS AND EQUIPMENT
ZB010C1-E "Alternative fuels" Fuels which contain methanol or etha- nol must not be used. ZB010D1-E Operation in Foreign Countries Drivers of vehicles which are to be operated in foreign countries must sat-isfy themselves that:
o The vehicle meets all local regula-
tions with respect to insurance, speci- fications etc..
o The correct types and grades of fuel are available for satisfactory opera-tion of the vehicle.
BEFORE ENTERING THE VEHICLE
YB020A1-E
o Ensure that all windows, mirrors and
lamps are clean.
o Check condition of all tyres.
o Ensure that no fluid leaks are evi- dent.
o Ensure that the area around the ve-
hicle is clear before driving off.
SB010E1-E FUELS FOR CLEANER AIR To help contribute to cleaner air, Hyundai recommends that you use fuels treatedwith detergent additives, which help to prevent deposit formation in the engine. These fuels will help the engines runcleaner and the Emission Control Sys- tem performance.
