Hyundai Accent 2006 Owner's Manual

1CONTROLS AND EQUIPMENT
74
Face-Level
Selecting the "Face" mode will cause air to be discharged through the face level vents.
NOTE: It should be noted that prolonged operation of the heating system in " " mode will give rise to mistingof the windscreen and side windows and the air within the passenger com- partment will become stale. In addi-tion prolonged use of the air condi- tioning with the " " mode selected may result in the air within the pas-senger compartment becoming ex- cessively dry.
B670D03A-EAT Air Flow Control
This is used to direct the flow of air. Air can be directed to the floor, dashboard outlets, or windscreen. Five symbolsare used to represent Face, Bi-Level, Floor, Floor-Defrost and Defrost air po- sition.
HLC2091-D
HLC2082

75
1
CONTROLS AND EQUIPMENT
Bi-Level
Air is discharged through the face vents and the floor vents. This makes it possible to have cooler air from the dashboard vents and warmer air fromthe floor outlets at the same time. Floor-Level
Air is discharged through the floorvents, windscreen defroster nozzle, side defroster nozzle, side ventilator.
HLC2092-D
HLC2093-D
HLC2094-D
Floor-Defrost Level
Air is discharged through the windscreen defroster nozzle, the floor vents, side defroster nozzle, side ventilator. If the "Floor-Defrost" mode is selected,the air conditioning will be turned on automatically. And if you want to turn off the air conditioning, push the A/Cbutton.

1CONTROLS AND EQUIPMENT
76HEATING CONTROLS
B670E02A-AAT Temperature Control
Defrost-Level
Air is discharged through the windscreen defroster nozzle, side defroster nozzle, side ventilator.If the "Defrost" mode is selected, the air conditioning will be turned on automati- cally. And if you want to turn off the airconditioning, push the A/C button. This control is used to adjust the degree of heating or cooling desired.
Cool
Warm
HLC2095-D
HLC2086B690A02A-AAT
For normal heating operation, set the air intake control to the fresh air ( ) position and the air flow control to thefloor ( ) position. For faster heating, the air intake control should be set in the recirculate ( )position. If the windows fog up, set the air flow control to the defrost ( ) position (Theair conditioning will be turned on auto- matically) and the air intake control to the fresh air ( ) position.For maximum heat, move the tempera- ture control to "Warm". B690A01A-D

77
1
CONTROLS AND EQUIPMENT
DEFROSTING/DEFOGGINGVENTILATIONBI-LEVEL HEATING
B720A04A-EAT Use the heating/ventilation system to defrost or defog the windscreen: To remove interior fog on the windscreen:
o Set the air intake control to the fresh
air ( ) position.
o Set the air flow control to the defrost ( ) position. (The air conditioning will be turned on automatically)
o Set the temperature control to the desired position.
o Set the fan speed control between "1" and "4" position.B700A01A-AAT
Your Hyundai is equipped with bi-level heating controls. This makes it pos- sible to have cooler air from the dash- board vents and warmer air from thefloor outlets at the same time. To use this feature:
o Set the air intake control to the fresh air ( ) position.
o Set the air flow control at the bi-level
( ) position.
o Set the temperature control between "Cool" and "Warm". B670B01A-D
B710A01S-AATTo operate the ventilation system:
o Set the air intake control to "Fresh"
mode ( ).
o To direct all intake air to the dash- board vents, set the air flow control to "Face".
o Adjust the fan speed control to the desired speed.
o Set the temperature control between "Cool" and "Warm". B710A01A-D
B720B01A-D

1CONTROLS AND EQUIPMENT
78AIR CONDITIONING SYSTEM
B740A01A-EAT Air Conditioning Switch (Not all models)
B730A01FC-EAT Operation Tips
o To keep dust or unpleasant fumes from entering the car through the ventilation system, temporarily set the air intake control at "Recircula- tion". Be sure to return the control to"Fresh" when the irritation has passed to keep fresh air in the ve- hicle. This will help keep the driveralert and comfortable.
o Air for the heating/cooling system is
drawn in through the grilles justahead of the windscreen. Care should be taken that these are not blocked by leaves, snow, ice or other ob-structions.
o To prevent interior fog on the
windscreen, set the air intake controlto the fresh air ( ) position and fan speed to the desired position.
To remove the frost or exterior fog on the windscreen:
o Set the air intake control to the fresh
( ) position.
o Set the air flow control to the defrost ( ) position. (The air conditioning will be turned on automatically.)
o Set the temperature control to warm.
o Set the fan speed control to position "3" or "4".
NOTE: When the A/C is operated continu- ously on the floor-defrost level ( ) or defrost level ( ), it may causefog to form on the exterior windscreen. The air conditioning is turned on bypushing the A/C button on the heating/ air conditioning control panel.
HLC2090
B720B02A-D
If this occurs, set the air flow control to the face level position ( ) andfan speed control to the low posi- tion.

79
1
CONTROLS AND EQUIPMENT
B740B02A-EAT Air Conditioning Operation (Cooling)
B740C01A-AAT De-Humidified Heating
To use the air conditioning to cool the interior:
o Turn on the fan control switch (3).
o Turn on the air conditioning switch(4) by pushing in on the switch.The air conditioning indicator lightshould come on at the same time.
o Set the air intake control to the
position (5).
o Set the temperature control (1) to "Cool". ("Cool" provides maximumcooling. The temperature may bemoderated by moving the control toward "Warm".) o Adjust the fan control (3) to the de-
sired speed. For greater cooling, turn the fan control to one of the higher speeds or temporarily select the position on the air intake con-
trol. For dehumidified heating:
o Turn on the fan control switch (3).
o Turn on the air conditioning switch
(4). The air conditioning indicatorlight should come on at the sametime.
o Set the air intake control (5) to the
fresh air ( ) position.
o Set the air flow control (2) to the face ( ) position.
o Adjust the fan control (3) to the de- sired speed.
o For more rapid action, set the fan at
one of the higher speeds.
o Adjust the temperature control (1) to provide the desired amount ofwarmth.
B740B01A-D
(1)
(2)
(3)
(4) (5) B740C01A-D
(1)
(2)
(3)
(4) (5)

1CONTROLS AND EQUIPMENT
80POLLEN FILTER
B740D01A-AAT Operation Tips
o If the interior of the car is hot when you first get in, open the windows for a few minutes to expel the hot air.
o When you are using the air condi-
tioning system, keep all windowsclosed to keep hot air out.
o When moving slowly, as in heavy
traffic, shift to a lower gear. Thisincreases engine speed, which in turn increases the speed of the air conditioning compressor.
o On steep grades, turn the air condi- tioning off to avoid the possibility ofthe engine over-heating.
o During winter months or in periods when the air conditioning is not usedregularly, run the air conditioningonce every month for a few min- utes. This will help circulate the lubricants and keep your system inpeak operating condition.
!
B760A01Y
The pollen filter is located in front of the evaporator unit behind the glove box. It operates to decrease pollutants fromentering the car. To replace the pollen filter, refer to the page 6-20.
B760A05A-EAT
(For Evaporator and Blower Unit) (Not all models)
Inside of a vehicle
Evaporator core Filter
Blower Inside air CAUTION:
o Replace the filter every 10,000 miles or once a year. If the car is being driven in severe conditions such as dusty, rough roads, morefrequent pollen filter inspections and changes are required.
o When the air flow rate is suddenly
decreased, it must be checked atan authorized dealer.
Outside air

81
1
CONTROLS AND EQUIPMENT
STEREO SOUND SYSTEM
Ionosphere
B750A02L
AM reception
Mountains
Buildings Unobstructed
area
FM radio station
B750A03L
Ionosphere
FM reception
B750A01L Obstructed area
Iron bridges
FM broadcasts are transmitted at high frequencies and do not bend to follow the earth's surface. Because of this, FM broadcasts generally begin to fadeat short distances from the station. Also, FM signals are easily affected by buildings, mountains, or other obstruc-tions. These can result in certain listen- ing conditions which might lead you to believe a problem exists with your ra-dio. The following conditions are normal and do not indicate radio trouble:
AM broadcasts can be received atgreater distances than FM broadcasts. This is because AM radio waves aretransmitted at low frequencies. These long, low frequency radio waves can follow the curvature of the earth ratherthan travelling straight out into the at- mosphere. In addition, they curve around obstructions so that they canprovide better signal coverage.
B750A02A-AAT How Car Audio Works
AM and FM radio signals are broadcast from transmitter towers located around your city. They are intercepted by the radio antenna on your car. This signal isthen received by the radio and sent to your car speakers. When a strong radio signal has reachedyour vehicle, the precise engineering of your audio system ensures high quality reproduction. However, in some casesthe signal coming to your vehicle may not be strong and clear. This can be due to factors such as the distance from theradio station, closeness of other strong radio stations or the presence of build- ings, bridges or other large obstructions in the area.

1CONTROLS AND EQUIPMENT
82
!
B750A04L
B750A05L
o Station Swapping - As a FM signal weakens, another more powerful sig- nal near the same frequency may begin to play. This is because your radio is designed to lock onto theclearest signal. If this occurs, select another station with a stronger sig- nal.
o Multi-Path Cancellation - Radio sig- nals being received from several di-rections can cause distortion or flut-tering. This can be caused by a direct and reflected signal from the same station, or by signals from twostations with close frequencies. If this occurs, select another station until the condition has passed.
o Fading - As your car moves away
from the radio station, the signal willweaken and sound will begin to fade. When this occurs, we suggest that you select another stronger station.
o Flutter/Static - Weak FM signals or large obstructions between the trans-mitter and your radio can disturb thesignal causing static or fluttering noises to occur. Reducing the treble level may lessen this effect until thedisturbance clears. B750B02Y-AAT Using a cellular phone or a two- way radio When a cellular phone is used inside the vehicle, noise may be producedfrom the audio equipment. This does not mean that something is wrong with the audio equipment. In such a case,use the cellular phone at a place as far as possible from the audio equipment.
!
CAUTION:
When using a communication sys- tem such a cellular phone or a radioset inside the vehicle, a separate external antenna must be fitted. When a cellular phone or a radio set is usedwith an internal antenna alone, it may interfere with the vehicle's elec- trical system and adversely affectsafe operation of the vehicle.
WARNING:
Don't use a cellular phone when youare driving, you must stop at a safeplace to use a cellular phone.

83
1
CONTROLS AND EQUIPMENT
ANTENNA
B870C01A-GAT Manual Antenna Your car uses a manual stainless steel antenna to receive both AM and FMbroadcast signals. Pull up the antenna using your fingers, as shown in the drawing. NOTE: Before entering an automatic car wash or a place with a low height clearance, be sure that the antennais fully retracted. HLC2122B870B01Y-EAT Power Antenna (Not all models)
HLC2123
The antenna will automatically be ex- tended when the radio power switch is turned on while the ignition key is ineither the "ON" or "ACC" position. The antenna will automatically be retracted and stored when either the radio powerswitch is turned off or the ignition key is set to the "LOCK" position. NOTE:
o Before turning on the radio, make
sure that no one is near the an- tenna.
o Before entering an automatic car wash or a place with a low heightclearance, be sure that the an-tenna is retracted and stored.
o If the antenna is dirty, be sure to
clean it in order to avoid an opera-tion malfunction.
