Hyundai Accent 2006 Owner's Manual

1CONTROLS AND EQUIPMENT
54
3. When the " " position is depre-
ssed, the interval between wipes operates every five seconds inter- mittently.
Do not operate the washer continuouslyfor more than 15 seconds or when the fluid reservoir is empty; this could dam-age the system. Do not operate the wiper when the window is dry; this can result in scratch-ing as well as premature wiper blade wear. For the reason stated above,do notoperate the washer when the washer fluid reservoir is empty.B390A02A-EAT REAR WINDOW WIPER AND WASHER (Not all models)
B390A01A-E
The rear window wiper and washer are turned on by depressing the button. Washer fluid is sprayed onto the glass
as long as the " " is depressed.
1. When the " " position is depre- ssed, the rear window wiper starts to operate continuously.
2. When the " " position is depr- essed, the rear window wiper startsto operate three times after the washer fluid sprays onto the rearwindow.
HEADLIGHT LEVELING DEVICE SYSTEM
B340G01S-EAT
To adjust the headlight beam level ac- cording to the number of the passen- gers and the loading weight in the lug- gage area, turn the beam leveling switch.The higher the number of the switch position, the lower the headlight beam level. Always keep the headlight beamat the proper leveling position, or head- lights may dazzle other road users. Listed below are the examples of rec-ommended switch settings. For loading conditions other than those listed be- low, adjust the switch position so thatthe beam level may be the nearest as the condition obtained according to the list. B340G01A-E

55
1
CONTROLS AND EQUIPMENT
HEATED REAR WINDOWHAZARD WARNING SYSTEM
SB250A1-E (Not all models) To operate the heated rear window de- press the switch shown. The heated rear window will automatically turn off after 20 minutes or when the ignition isturned off. The system may be turned off manually by depressing the switch again. B370A01A-D
SB240A1-E The hazard warning system should be used whenever it becomes necessary to stop the car in a hazardous location. The hazard warning system is operatedby depressing the switch at which time all turn signal lights will flash simulta- neously and the turn signal warninglights located within the instrument clus- ter will flash simultaneously. The hazard warning system may beturned off by depressing the switch again.
B370B01A-D
Loading condition
Switch
position
Driver only Driver + front passengerFull passengers (including driver) Full passengers(including driver) + full boot loading (or light trailer loading) Driver + full boot loading(or maximum trailer loading) 0
1 2
3 0

1CONTROLS AND EQUIPMENT
56
B360A01Y-GAT Rear Fog Light Switch To turn on the rear fog lights, push the switch. They will come on when theheadlight switch is in the second posi- tion and the key is in the "ON" position. B360A01A-D
CAUTION:
The inside of the rear windscreen should never be cleaned with a hard or sharp implement since damage to the heating element may occur. Theglass should only be cleaned with a soft cloth or chamois leather with the use only of a mild detergent or pro-prietary glass cleaner where neces- sary. Only horizontal movement of the cloth should be made when clean-ing the glass and care should be exercised to ensure that the heating elements are not damaged by ringsor jewellery whilst the glass is being cleaned. NOTE: The ignition must be in the "ON" position for the heated rear window to operate.
!
FOG LIGHT SWITCH
B360B01FC-EAT Front Fog Light Switch (Not all models) To turn on the front fog lights, push the switch in the "ON" position. They will come on when the headlight switch is inthe first or second position. B360B01A-D

57
1
CONTROLS AND EQUIPMENT
CIGAR LIGHTER
!
CAUTION:
Do not use electric accessories or equipment other than the Hyundaigenuine parts in the socket.
B420A02A-EAT
For the cigar lighter to work, the keymust be in the "ACC" or the "ON" position. To use the cigar lighter, push the lighterall the way into its socket. When the element is heated, the lighter will pop out into the "ready" position.Do not hold the cigar lighter at the depressed position which may result in damage to the vehicle wiring or anelectrical fire. If it is necessary to replace the cigarette lighter, use only a genuine Hyundaireplacement part.
B400A01A-EAT
HLC2100
There are three control buttons for thedigital clock. Their functions are: HOUR - Push "H" to advance the hour
indicated.
MIN - Push "M" to advance the
minute indicated.
RESET - Push "R" to reset minutes to
":00" to facilitate resetting the clock to the correct time. When this is done:
Pressing "R" between 10 : 30 and 11 :29 changes the readout to 11 : 00.Pressing "R" between 11 : 30 and 12 : 29 changes the readout to 12 : 00. HLC2104-D
DIGLTAL CLOCK

1CONTROLS AND EQUIPMENT
58DRINK HOLDER
B450A04A-EAT Front Drink Holder The front drink holder is located on the centre facia panel for holding cups orcans in its holes. The drink holder can be used by pushing it.
CAUTION:
Place the drink holder in its closed position when not in use.
! HLC2116-D
ASHTRAY
B430A01A-GAT Front Ashtray
The front ashtray may be opened by pulling it out by its grip. To remove the ashtray to empty or clean it, press downon the spring-loaded tab inside the ash- tray and pull it all the way out. The ashtray light will only illuminate whenthe external lights are on.
HLC2107-D
B440A01E-EAT Rear Ashtray (Not all models) HLC2108-D
The rear ashtray may be opened by pulling it out by its top edge. To remove the ashtray to empty or clean it, pressdown on the spring-loaded tab inside the ashtray and lift the ashtray upward and pull it all the way out.

59
1
CONTROLS AND EQUIPMENT
SUNROOF
!
!
B450B01A-AAT Rear Drink Holder
The rear drink holder is located on the rear main console and may be used forholding cups or cans. HLC2117
WARNING:
Do not place anything except drinks in the drink holder. Such objects can be thrown out, possibly injuring per-sons in the vehicle during sudden braking or in the event of an acci- dent.
WARNING:
Do not place anything except drinksin the drink holder. Such objects can be thrown out, possibly injuring per- sons in the vehicle during suddenbraking or in the event of an acci- dent. B470A01A-EAT SUNSHADE (Not all models) To remove the sunshade
1. Pull the sunshade knob toward the front of the sunshade then pull down the rear of the sunshade.
2. Then, you can easily remove the sunshade.
To install the sunshade
1. Install the hook into the holder at- tached on the front of the sunroof.
2. Slide and lock the sunshade into the
catch. HLC2022

1CONTROLS AND EQUIPMENT
60
HLC2024
B460B02A-AAT To Close the Sunroof
1. Pull the handle toward you.
2. After the sunroof has been closed,
lock the handle back into position.
3. Be sure that the sunroof and handle
are securely closed.
!
B460A01A-EAT SUNROOF (Not all models) To Tilt Up the Sunroof The sunroof can be manually opened or closed.
1. Pull the handle down and then for-ward and up as indicated by the arrows in the illustration.
2. Push the handle at the centre to lock the sunroof in the open position.
3. After tilting up the sunroof, make
sure the handle is secure in place. HLC2023
WARNING:
Never install or remove the sunshade whilst driving.
CAUTION:
o Installation or removal of the sun- shade should be done with the sunroof closed.
o Before driving, make sure the sun-
shade is securely installed.
!

61
1
CONTROLS AND EQUIPMENT
!
B460C01A-EAT To Remove the Sunroof
HLC2025
1. Remove the sunshade before re- moving the sunroof.
2. Pull the handle all the way down- ward.
3. Depress the handles of the base
plate to release them from their holes.
4. Raise the sunroof glass from outside
of the vehicle until it is perpendicular to the roof panel.
WARNING:
Do not close the sunroof if anyone’shands, arms or other body parts arebetween the sunroof and the sunroof sash as this may cause an injury.
CAUTION:
o Do not open the sunroof in se- verely cold temperatures or when it is covered with ice or snow.
o Remove water drops, snow, ice or sand from the sunroof before open-ing.
!
!
5. Now, you can easily remove thesunroof from the roof panel. HLC2025B
WARNING:
o Do not stand up or extend any portion of your body out of the opening whilst the vehicle is mov-ing.
o Do not sit on top of the vehicle
around the opening.

1CONTROLS AND EQUIPMENT
62INTERIOR LIGHT
B480A01E-EAT Map Light (Not all models)
The two map lights are located at each side of the interior light.The lights may be operated by depress- ing the switch to turn on the light and pressing again to turn off the light. Thislight produces a spot beam for conve- nient use as a map light at night or as a personal light for the driver or the pas-senger. HLC2081
!
B460D01A-EAT To Install the Sunroof
1. Insert the flat hinges into the cut-
outs. Then supporting the sunroof with your hands, slowly lower it.
2. Make sure both of the flat hinges are
securely inserted into their cutouts.
3. Depress the handles of the base plate and insert into the holes. B460E01A-AAT Storing the Sunroof and the Sun- shade There is a storage bag in the trunk. Place the sunroof or sunshade into thestorage bag and store it in the trunk.
CAUTION:
o Be careful not to place heavy ob- jects on the bag, otherwise thesunshade or sunroof may be de- formed or broken.
o When storing the sunroof and sun- shade into the storage bag, put thesunshade on top of the sunroof.
!
WARNING:
o Never install or remove the sunroof whilst driving.
o Never put your hands between the sunroof and the car's body.
o Do not drive the vehicle without being certain that the sunroof is securely locked in place.

63
1
CONTROLS AND EQUIPMENT
GLOVE BOX
!WARNING:
To avoid the possibility of injury, the glove box lid must be kept closed whilst the vehicle is in motion.
o To open the glove box, pull the glove box release lever.
B500A01A-EAT
B490A02A-GAT Interior Light The interior courtesy light has a switch of three positions. The three positions are:
o "DR" or "ˆ" In the "DR" or "ˆ" position, the interior courtesy light comes on when any dooris opened regardless of the ignition key position. The light goes out when the door is closed. HLC2080
With Sunroof Without Sunroof
HLC2110-D
NOTE: If your vehicle is equipped with the delay-out interior light, the light goes out gradually within 6 seconds afterthe door is closed.
o "ON" In the "ON" position, the light stays on at all times.
o "OFF" In the "OFF" position, the light stays off at all times even though a door is open.
