Hyundai Coupe 2006 Owner's Manual

1CONTROLS AND EQUIPMENT
4
!
IMMOBILISER SYSTEM
B880B04A-EAT Keys All of the locks fitted to the vehicle are operated by the same key. However,since it is possible to lock the doors without the use of the key, care should be exercised to ensure that the keydoes not become locked inside the vehicle by mistake. OHD046100
5) Avoid rapid acceleration and maxi-
mum throttle openings.
6) Avoid harsh braking during the first 100 miles of urban motoring or 1,000 miles of motorway driving to allowthe friction facings of the brake pads and shoes to bed against the discs and drums properly.
7) No trailer towing should be under- taken during the running in period. B880A01A-EAT The immobiliser system is an anti-theft device, designed to deter automobile theft.
NOTE: A non-genuine duplicate key will not start the engine.
CAUTION:
When starting the engine, do not use the key with other immobiliser keysaround. Otherwise the engine may not start or may stop soon after it starts.Keep each key separate to prevent immobiliser malfunction, once you have received your new vehicle.
gkfluk-1a.p65 12/26/2006, 5:11 PM
4

1
CONTROLS AND EQUIPMENT
5
B880C02A-EAT Key Numbers The vehicle key number is recorded on a metal tag attached to the keys when the vehicle is first delivered to you.The key number should be recorded and kept in a safe place in case the need to order further keys arises. Newkeys are available from any Hyundai authorised repairer by quoting the rel- evant key number. In the interest of security, the metal tagattached to the keys which bears thekey number should be removed from the key ring after you receive your new vehicle. In addition, key numbers can-not be provided by Hyundai for secu- rity reasons. If you need additional keys or if youshould lose your keys, your Hyundai authorised repairer can make new keys.
OMC025002 B030C01E
YB030C2-E Illuminated Ignition Switch Whenever a door is opened, the ignition switch will be illuminated for your con- venience provided the ignition switch is not in the "ON" position. The light will gooff approximately 10 seconds after clos- ing the door or when the ignition switch is turned on.
gkfluk-1a.p65
12/26/2006, 5:11 PM
5

1CONTROLS AND EQUIPMENT
6
!
DOOR LOCKS
B040A01GK-EAT
WARNING:
o Unlocked doors can be danger- ous. Before you drive away (es- pecially if there are children in the car), be sure that all the doorsare securely closed and locked so that the doors cannot be inad- vertently opened from the inside.This helps ensure that doors will not be opened accidentally. Also, when combined with the properuse of seat belts, locking the doors helps keep occupants from being ejected from the car in caseof an accident.
o Before opening the door, always
look for and avoid oncoming traf-fic.
o A locked-up vehicle can become
extremely hot, causing death orsevere injury to unattended chil- dren, handicapped persons or animals who cannot escape thevehicle. Never leave children, handicapped persons or animals unattended in your vehicle.
o In case of accident the door is unlocked automatically (Not allmodels). B040B01A-AAT Locking and unlocking front doors with a key
o The door can be locked or unlocked
with a key.
o Lock the door by turning the key toward the front of the vehicle and unlock it by turning the key towardthe rear. OGK046002M
UNLOCK
LOCK B040C01O-AAT Locking From the Outside The doors can be locked without a key. To lock the doors, first push the inside lock switch to the "LOCK" position sothat the red mark on the switch is not visible, then close the door.
OGK046003R
gkfluk-1a.p65
12/26/2006, 5:11 PM
6

1
CONTROLS AND EQUIPMENT
7
B040G02GK-GAT Central Door Lock The central door locking is operated by pushing the driver's door lock switch toward the front or rear of the vehicle.If the passenger door is open when the switch is pushed, the door will remain locked when closed. OGK046003R
B040D01S-AAT Locking From the Inside To lock the doors from the inside, simply close the door and push the lock switch to the "LOCK" position.When this is done, neither the outside nor the inside door handle can be used. NOTE: When the door is locked, the red mark on the switch is not visible. LOCK
OGK046004R
UNLOCK
NOTE:
o If your vehicle is equipped with
central door locking system, the door will not lock if the key is leftin the ignition switch when the front doors are closed.
o When locking the door this way, be careful not to lock the door withthe ignition key left in the vehicle.
o To protect against theft, always remove the ignition key, close allwindows, and lock all doors when leaving your vehicle unattended.
gkfluk-1a.p65 12/26/2006, 5:11 PM
7

1CONTROLS AND EQUIPMENT
8
!
B070B02GK-EAT Armed Stage Park the car and stop the engine. Arm the system as described below.
1) Remove the ignition key from the
ignition switch.
2) Make sure that the engine bonnet,
doors and hatchback door are closed.
3) Lock the doors using the transmitter
of the keyless entry system.
After completion of the steps above, the turn signal lamp will blink once toindicate that the system is armed. CAUTION:
Do not arm the system until all passengers have left the car. If the system is armed while apassenger(s) remains in the car, the alarm may be activated when the remaining passenger(s) leavesthe car. NOTE:
1) If any door, hatchback door or
engine bonnet remains open, the system will not be armed.
2) If this happens, rearm the system as described above.
3) Once the system is armed, only the hatchback door may be un- locked using the key without dis- arming the system.
ANTI-THEFT ALARM SYS- TEM
B070A01A-EAT (Not all models) This system is designed to provide protection from unauthorised entry intothe car. This system is operated in three stages: the first is the "Armed" stage, the second is the "Alarm" stage,and the third is the "Disarmed" stage. If triggered, the system provides an audible alarm with blinking of the turnsignal light.
NOTE:
o When pushing the switch toward
the rear, all doors will unlock. When pushing the switch towardthe front, all doors will lock.
o When the door is unlocked, the
red mark on the switch is visible.
o The central door locking is oper- ated by turning the key (driver'sdoor only) toward the front orrear of the vehicle.
o If the door is locked/unlocked mul-
tiple times in rapid successionwith either the vehicle key or door lock switch, the system may stop operating temporarily in order toprotect the circuit and prevent damage to system components.
gkfluk-1a.p65 12/26/2006, 5:11 PM
8

1
CONTROLS AND EQUIPMENT
9
!
CAUTION:
Avoid trying to start the engine whilst the system is armed.
B070C02GK-EAT Alarm Stage The alarm will be activated if any of the following occur while the car is parkedand the system is armed.
1) A front door is unlocked and opened
without using the transmitter.
2) The hatchback door is opened with-
out using the key.
3) The engine bonnet is opened.The alarming horn will sound and the turn signal lights will blink continuously for approximately 27 seconds. To turn off the system, unlock the door with thetransmitter.
B070D04GK-EAT Disarmed Stage
UNLOCK
The system will be disarmed when either of the following steps are taken:
1) The driver's or passenger's door is unlocked by depressing the "UN- LOCK" button on the transmitter.
2) In the middle of alarming or after
alarming, it disarms after 30 sec-onds if the key is turned to and kept in the "ON" position.
After completing one of steps above,the turn signal lights will blink twice toindicate that the system is disarmed. OGK016102R
LOCK
B075E02O-AAT Alarm Warning
1. Push the "Alarm" button on the trans-mitter.
2. At the same time, the alarming horn will sound and the turn signal lights will blink for 30 seconds.
3. To turn off the system, push any button on the transmitter. OGK016102R
ALARMNOTE: If any door, hatchback door or en- gine bonnet is not opened within 30 seconds, the system will be re-armed.
gkfluk-1a.p65
12/26/2006, 5:11 PM
9

1CONTROLS AND EQUIPMENT
10
B070E03GK-GAT Replacing the battery When the transmitter's battery begins to get weak, it may take several pusheson the button to lock or unlock the doors, and the LED will not light. Re- place the battery as soon as possible. Battery type : CR2016 Replacement instructions:
Screwdriver
1. Carefully seperate the case with a blade screwdriver as shown in the illustration. OGK016122- Other vehicles or objects may be
blocking the signal.
- The weather is extremely cold.
- The transmitter is close to a radio transmitter such as a radio station or an airport which can interfere with normal operation of the trans- mitter.
When the transmitter does not work correctly, open and close the door with the ignition key. If you have aproblem with the transmitter, con- tact a Hyundai authorised repairer. NOTE: Keep the transmitter away from wa- ter or any liquid. If the keyless entry system is inoperative due to expo- sure to water or liquids, it will not becovered by your manufacturer ve- hicle warranty.
B070F02A-EAT KEYLESS ENTRY SYSTEM (Not all models) Locking doors
1. Close all doors.
2. Push the "LOCK" button on the trans-
mitter.
3. At the same time all doors lock, the
turn signal lights will blink once toindicate that the system is armed.
Unlocking doors
1. Push the "UNLOCK" button on the transmitter.
2. At the same time the driver's door
unlocks, the turn signal lights will blink twice to indicate that the sys- tem is disarmed.
NOTE: The transmitter will not work if any of following occur:
- The ignition key is in ignition switch.
- You exceed the operating distance
limit (10 m).
- The battery in the transmitter is weak.
gkfluk-1a.p65 12/26/2006, 5:11 PM
10

1
CONTROLS AND EQUIPMENT
11
2. Remove the old battery from the
case and note the polarity. Make sure the polarity of the new battery is the same(+side facing up), then insert it in the transmitter.
3. Installation is the reverse order of disassembly.
NOTE: Install a new battery within 30 sec- onds after remove the old one, if installing a new battery takes morethan 30 seconds, take the following steps.
1) Turn the ignition key to the "ACC" position.
2) Make sure that the turn signal lights blink once by pushing the "LOCK" or "UNLOCK" button on the transmitter. Battery
OGK016121
POWER WINDOWS
B050A03GK-EAT The power windows operate only when the ignition key is in the "ON" position. The main switches are located on thedriver's arm rest and control the front windows on the respective sides of the vehicle. The windows may be openedby depressing the front portion of the switch. To stop at the desired opening, release the switch. The window maybe closed by pulling the front portion of
the switch. To open the window on the driver's side, press the switch(1) half- way down. The window moves as long as the switch is operated. To fully open the driver's window auto- matically, press the switch fully down.In automatic operation, the window willfully open even if you let go of theswitch. To stop at the desired opening, pull up and release the switch. In order to prevent operation of the passenger front and rear windows, a window lock switch(2) is provided on the armrest of the driver's door. To disable the power windows, press the window lock switch. To revert to normal operation, press the window lock switch a second time.
HGK2015R
(2)
(1)
gkfluk-1a.p65
12/26/2006, 5:11 PM
11

1CONTROLS AND EQUIPMENT
12
!
SEATS
!
WARNING:
o Be careful that someone's head, hands and body are not trapped by a closing window.
o Never try to operate the main switch on the driver's door and theindividual door window switch in opposing directions at the sametime. If this is done, the window will stop and cannot be opened or closed.
o Always remove the ignition key prior to exiting the car.
o Do not leave children alone in the car. B080A01FC-EAT SEAT ADJUSTMENT
WARNING:
Front seat adjustments must not be undertaken whilst the vehicle is in motion. Loss of control of the ve-hicle may result if seat adjustments are made whilst the vehicle is in motion.
NOTE: The power windows can be operated for 30 seconds after the ignition key is turned to the "ACC" or "LOCK" positions, or removed from the igni- tion switch. If the front doors are opened during this 30 second period, the power windows can no longer be operated without the ignition key turned to the "ON" position. HGK2016-E
gkfluk-1a.p65
12/26/2006, 5:11 PM
12

1
CONTROLS AND EQUIPMENT
13
!WARNING:
o Seat adjustment should not be made whilst the vehicle is in mo- tion since loss of control of the vehicle may occur.
o To ensure the seat is locked se- curely, attempt to move the seatforward or rearward without using the lever.
B080B03FC-EAT FRONT SEATS Seat Rake Adjustment The front seat rake adjustment is per- formed by raising the lever at the front of the seat base and sliding the seat tothe desired position. At this position the lever should be released and the seat rocked to and fro to ensure thatthe mechanism has locked.
OGK036002M
SB070C1-E Front Seat Recline Adjustment
OGK036003M
The front seat back recline angle may be adjusted by leaning forward slightlyand raising the recline adjustment le- ver at the side of the seat. When the seatback is at the desired angle, thelever should be released. Ensure that the seatback is locked before driving the vehicle.
gkfluk-1a.p65 12/26/2006, 5:12 PM
13
