Hyundai Coupe 2006 Owner's Manual

1CONTROLS AND EQUIPMENT
14
!WARNING:
o For maximum effectiveness in case of an accident the head restraint should be adjusted so the middle of the head restraint is at the same height as the top of the occupant'seyes. For this reason, the use of a cushion that holds the body away from the seatback is not recom-mended. B080D01JM!
B080D02JM-EAT Adjustable Head Restraints Head restraints are designed to help reduce the risk of neck injuries. To raise the head restraint, pull it up. Tolower it, push it down whilst pressing the lock knob. To remove the head restraint, raise it as far as it can go thenpress the lock knob whilst pulling up- ward. This should only be done when the seat is not occupied.Lock Knob
HGK2032
WARNING:
To minimise risk of severe injury in the event of a collision or a sudden stop, both the driver's andpassenger's seatbacks should al- ways be in an upright position while the vehicle is in motion. The protec-tion provided by the seat belts and airbags in a frontal collision may be reduced significantly when the seatbacks are reclined. There is greater risk that the driver and passenger will slide under the seat belt which may result in serious injury if a crash occurs when the seatbacksare reclined. The seat belt cannot provide full protection to an occu- pant if the seat back is reclined.
gkfluk-1a.p65 12/26/2006, 5:12 PM
14

1
CONTROLS AND EQUIPMENT
15
SB070E1-E Lumbar Support Adjustment (Driver's seat only)(Not all models) Some models are fitted with adjustable driver seat lumbar support which maybe used to increase the amount of lumbar support offered by the seat back. Adjustment is performed bymoving the handle at the side of the backrest in a forward direction to in- crease the support. SOFT
o Do not operate vehicle with the
head restraints removed as injuryto the occupants may occur in the event of an accident. Head re- straints may provide protectionagainst neck injuries when prop- erly adjusted.
o Do not adjust the head restraint
height whilst the vehicle is inmotion.
OGK036005M
FIRMFB070F1-E Seat Cushion Height Adjustment (Driver's seat only)(Not all models) To raise or lower the front part of the seat cushion, turn the knob clockwiseor counter-clockwise. OGK036004M
gkfluk-1a.p65
12/26/2006, 5:12 PM
15

1CONTROLS AND EQUIPMENT
16
!
B130A01GK-DAT Rear Seat Entry (Walk in device) The driver and front passenger's seatback should be tilted to enter therear seat. By pulling up the walk in device lever (1) at the right-upper side of the driver sideseatback, the seatback will tilt forward. And then pull the lock release lever (2) up with moving the seat forward. OGK036007RB100A01GK-EAT Seat Warmer (Not all models) The seat warmer is provided to warm the front seats during cold weather. With the ignition key in the "ON" posi-tion, push either of the switches to warm the driver's seat or the passenger's seat.During mild weather or under condi- tions where the operation of the seat warmer is not needed, keep theswitches in the "OFF" position. OGK016033RNOTE:
o The seat warmer will not operate if
ambient temperature is warm enough.
o If the seat warmer doesn't work when ambient temperature islower than 24.5°C (76.1°F), it mustbe checked by a Hyundai authorised repairer.

WARNING:
The seat heater should not be oper-ated if you have occupants of the front seats who are children, elderly persons, people under medication or under the influence of alcohol.
gkfluk-1a.p65 12/26/2006, 5:12 PM
16

1
CONTROLS AND EQUIPMENT
17
By pulling up the walk in device lever (1) at the left-upper side of the passengerside seatback, the seatback will tilt forward. And then push the seat forward to enter the occupants. Recliner Memory By pulling up the walk in device lever (1) seatback is reclined and return to the memorised original position. OGK036008R
!WARNING:
Don't drive with reclining of the pas- senger side seatback. It is danger-ous to move it. Be sure the seatback is fix firmly or not before driving.
B129A01F-AAT Rear Seat Positions
!WARNING:
This vehicle contains two rear seat- ing positions only and a seat belt for each seating position. Thus, never permit more than two occu-pants to ride in the rear seat be- cause an unrestrained occupant could be seriously injured or killedin the event of a vehicle crash. B129A01GK
gkfluk-1a.p65
12/26/2006, 5:12 PM
17

1CONTROLS AND EQUIPMENT
18
SB480A1-E Folding Rear Seatbacks The rear seatbacks may be folded to facilitate the carriage of long items or to increase the luggage capacity of thevehicle.
o To unlock the seatback, release the
catch by operating the lock knob, pull the seatback forward and lower to the folded position.
o When the seatback is returned to the upright position, ensure that thelatching mechanism has engagedand that the seat may not move unintentionally.
B099A01GK-AAT Before Folding the Rear Seats In order to prevent the shoulder belt from being damaged while folding the rear seat, the shoulder belt must be passed through the hanger to keep itout of the way.
HGK2034
HGK2035
CAUTION:
o Seat belts must be removed from the hanger when in use.
!
o Before folding the seatback, insert the buckle in the pocket. This can prevent the buckle from being dam-aged by seatback.
OGK016606
gkfluk-1a.p65 12/26/2006, 5:12 PM
18

1
CONTROLS AND EQUIPMENT
19
SB090B1-E Babies/Small Children Babies and small children must be restrained using a restraint system specifically designed for this purpose. Under no circumstances should a childbe carried in the vehicle without the use of a suitable restraint which meets the regulations in force in the countrywhere the vehicle is in operation.
SEAT BELTS
!WARNING:
The folding rear seats are intended to allow the carriage of longer ob- jects than could otherwise be ac-commodated. Do not allow passen- gers to sit on top of the folded- down seatback whilst the car is inmotion since the folded seat does not provide a suitable sitting facil- ity and no seat belts are availablefor use. Objects carried on the folded seatback should not extend higher than the top of the frontseats and must be securely re- strained to prevent injury or dam- age during sudden deceleration. SB500A1-E REAR PARCEL SHELF Large or heavy items must not be placed upon the rear parcel shelf to prevent the possibility of injury arisingfrom such items in the event of impact.
SB090A1-E SEAT BELT PRECAUTIONS Seat belts should be worn at all times by all occupants front and rear. Thepossibility of injury or the severity of injuries suffered in the event of an accident will be greatly reduced by thewearing of seat belts. In addition the following recommenda- tions should be observed.
OGK016140
o Luggage which is carried within the
passenger compartment must besecurely restrained in order to pre- vent injury in the event of sudden deceleration.
gkfluk-1a.p65 12/26/2006, 5:12 PM
19

1CONTROLS AND EQUIPMENT
20
WARNING:
Sitting in a reclined position or ly- ing down when your vehicle is in motion can be dangerous. Even if you buckle up, your seat belts can'tdo their job when you're reclined. The shoulder belt can't do its job because it won't be against yourbody. Instead, it will be in front of you. In a crash you could go into it with great force, receiving seriousneck or other injuries. The lap belt can't do its job either. In a crash the belt could go up overyour abdomen. The belt forces would be applied there, not at your strong pelvic bones. This couldcause serious internal injuries. For proper protection when the ve- hicle is in motion, have the seatbackupright. Then sit back in the seat and wear your seat belt properly.
SB090C1-E Larger Children Larger children should occupy the rear seat and be restrained at all times. Therestraint may take the form of a special safety belt or the original factory fitted seat belt used in conjunction with anapproved booster cushion depending upon the size and weight of the child. Under no circumstances should chil-dren be allowed to travel standing, kneeling or lying on the seat. Never allow children to ride in the frontpassenger seat. SB090O1-E Pregnant Women The use of a seat belt is recommended for pregnant women. The seat belt should be worn as low and snugly as possible across the hips, not acrossthe abdomen. A qualified Medical Prac- titioner should be consulted for further information. SB090E1-E Injured Persons A seat belt should be used when an injured person is being transported.For specific recommendations, the advice of a qualified Medical Practioner should be sought. SB090F1-E Seat Belt Occupancy The seat belts are designed to be used by one seat occupant only. The use of a seat belt by more than one person increases the levels of injury which may be sustained in the event of anaccident.!
SE090G1-E Do Not Lie Down To ensure that the maximum level of protection may be afforded by the seatbelt system, all passengers should be sitting in an upright position throughout the journey. The seat belt will be un-able to afford maximum protection if the front seats are at or near the fully reclined position.
gkfluk-1a.p65
12/26/2006, 5:12 PM
20

1
CONTROLS AND EQUIPMENT
21
B170A04A-EAT Height Adjustable Front Seat Shoulder Belt
HGK2038
You can adjust the height of the shoul- der belt anchor to one of the 4 positions.If the height of the adjusting seat belt is too near your neck, you will not be getting the most effective protection.The shoulder portion should be ad- justed so that it lies across your chest and midway over your shoulder near-est the door and not your neck.
SB090H1-E CARE OF SEAT BELTS Seat belt assemblies must never be disassembled or modified in any way.In addition, care should be exercised to ensure that the belt assemblies do not become damaged by being trappedin seat mechanisms, door shuts etc. SB090I-E Periodic Inspection It is recommended that all seat belts be inspected periodically for wear or damage of any kind. Parts of the sys-tem that are damaged should be re- placed as soon as possible. Under no circumstances must any part of theseat belt assemblies be dismantled or repaired. SB090J1-E Keep Belts Clean and Dry Seat belts should be kept clean and dry. If belts become dirty, they can becleaned using a mild soap solution and warm water. Bleach, dye, strong de- tergents or abrasives should not beused since the fabric may become damaged and weakened. SB090K1-E Replacement of Seat Belts The entire seat belt assembly or as- semblies should be replaced if the vehicle has been involved in an acci-dent even if no damage is evident. Additional questions concerning seat belt operation should be directed to aHyundai authorised repairer.
!WARNING:
When you return the rear seatback to its upright position after the rear seatback was folded down, be care- ful not to damage the seat belt web-bing or buckle. Be sure that the web- bing or buckle does not get caught or pinched in the rear seat.
gkfluk-1a.p65 12/26/2006, 5:13 PM
21

1CONTROLS AND EQUIPMENT
22
B180A01A-EAT SEAT BELTS (3-Point Type) To Fasten The Seat Belt The seat belts are fastened by pulling the belt buckle towards the seat belt stalk and inserting the metal tongue ofthe buckle into the stalk. NOTE: When pulling the seat belt buckle towards the fastening position make sure the webbing is not twisted. B180A01NF-E
!
To adjust the height of the seat belt anchor, lower or raise the height ad-juster into an appropriate position. To raise the height adjuster, pull it up. To lower it, push it down whilst pressingthe height adjuster button. Release the button to lock the anchor into position. Try sliding the heightadjuster to make sure that it has locked into the position.
WARNING:
o The height adjuster must be in the locked position when the vehicle is moving.
o The misadjustment of height of the shoulder belt could reducethe effectiveness of the seat beltin a crash. The buckle should be firmly pressedinto the stalk until locked which will beindicated by an audible "click". The length of the seat belt webbing will be automatically adjusted by the seatbelt mechanism to allow the wearer maximum freedom of movement whilst the belt is being worn. However, in theevent of rapid deceleration or impact, the belt mechanism will automatically lock.The mechanism will also lock if the seat belt webbing is withdrawn too quickly when the belt is being fastenedor if attempts are made to withdraw the webbing whilst the vehicle is not on level ground. Should the seat belt lockunder these conditions, it will be pos- sible to release the mechanism by allowing a small amount of webbing tobe retracted and the belt withdrawn again.
gkfluk-1a.p65
12/26/2006, 5:13 PM
22

1
CONTROLS AND EQUIPMENT
23
B210A01A-AAT To Release the Seat Belt The seat belt is released by pressing the release button in the locking buckle. When it is released, the belt shouldautomatically draw back into the re- tractor. If this does not happen, check the beltto be sure it is not twisted, then try again.
CHILD RESTRAINT SYSTEM
B230A03P-EAT Children riding in the car should sit in the rear seat and must always be restrained to minimise the risk of injury in an accident, sudden stop or suddenmanoeuvre. According to accident sta- tistics, children are safer when prop- erly restrained in the rear seats than inthe front seat. Larger children should use one of the seat belts provided. You are required by law to use safetyrestraints for children. If small children ride in your vehicle you must put them in a child restraint system (safety seat).Children could be injured or killed in a crash if their restraints are not properly secured. For small children and ba-bies, a child seat or infant seat must be used. Before buying a particular child restraint system, make sure it fits yourcar seat and seat belts, and fits your child. Follow all the instructions pro- vided by the manufacturer when in-stalling the child restraint system.
B210A01NF-E
B200A01S-GAT Adjusting Your seat Belt You should place the belt as low as possible on your hips, not on your waist. If the belt is located too high onyour body, you could slide under it in case of accident or a sudden stop. This could result of death, seriousinjury or property damage. Both arms should not be under or over the belt. Rather, one should be over and theother under, as shown in the illustra- tion. Never wear the seat belt under the armnearest the door. B200A01NF-E
