Hyundai Santa Fe 2009 - RHD (UK, Australia) User Guide

F11
AUSTRALIAN DESIGN RULES
The compliance plate shows that your vehicle has been tested and found to comply with all relevant Australian Design Rules (ADR's) applicable at its date of manufac- ture. Any part, that is subject to these ADR's, must not be removed or altered and is to bemaintained in good order at all times for the vehicle to be roadworthy and re- registerable by all registerable authorities. Consult an Authorised Hyundai Motors Dealer before conducting any repairs thatmay affect these areas or if requiring further classification on design rules or safety features. Failure to observe the above warning may render the vehicle compliance invalid and result in personal injury which may have otherwise been avoided.
A100A01JM-DAT
CM-aust-00.p65
5/19/2008, 6:25 PM
11

Fuel Recommendations ................................................ 1-2
Running In Your New Hyundai ..................................... 1-4
Immobiliser System ...................................................... 1-4
Door Locks ................................................................... 1-6
Theft-Alarm System ...................................................... 1-9Power Windows........................................................... 1-14
Seats ........................................................................... 1-15
Seat Belts .................................................................... 1-24
Child Restraint System ................................................ 1-28
Supplemental Restraint (AIRBAG ) System................. 1-35
Instrument Cluster and Indicator Lights .......................1-44
Warning and Indicator Lights....................................... 1-48
Trip Computer .............................................................. 1-57
Multi-function Light Switch ........................................... 1-60
Windshield Wiper/Washer Switch ................................1-63
Sunroof ........................................................................ 1-73
Mirror ........................................................................... 1-79
Bonnet Release ........................................................... 1-90
Cruise Co ntrol.............................................................. 1-94
Heating and Cooling Control .......... ..............................1-99
Antenna ..................................................................... 1-118
Stereo Sound System ............................................... 1-119
Audio System ............................................................ 1-122
FEATURES OF YOUR HYUNDAI
1
1
CM-aust-1a.p65
5/21/2008, 2:04 PM
1

1FEATURES OF YOUR HYUNDAI
2
OCM051001R
Unleaded petrol with a Pump Octane Rating of 87 (Research Octane Num-ber 91) or higher must be used in your Hyundai. If leaded petrol is used, it will cause the catalytic converter to become ineffec- tive and the emission control system tomalfunction. This can also result in increased maintenance expense. To avoid accidental use of leaded fuel,the larger nozzle used with leaded petrol at service stations cannot be inserted into the fuel tank opening of your Hyundai.
B010A02CM-DAT Use Unleaded Petrol
FUEL RECOMMENDATIONS
UNLEADED FUEL ONLY
!
Use Diesel Diesel fuel Diesel engine must be operated only on commercially available diesel fuel that complies with EN 590 or comparablestandard. (EN stands for "European Norm"). Do not use marine diesel fuel, heating oils, or non-approved fuel addi-tives, as this will increase wear and cause damage to the engine and fuel system. The use of non-approved fuelsand / or fuel additives will result in a limitation of your warranty rights. Diesel fuel of 52 to 54 cetane is thecorrect rating to use in your Hyundai. If two types of diesel fuel are available, use summer or winter fuel properlyaccording to the following temperature conditions.
o Above -5°C (23°F) ... Summer type
diesel fuel.
o Below -5°C (23°F) ... Winter type diesel fuel.
Watch the fuel level in the tank very carefully : If the engine stops through fuel failure, the circuits must be com- pletely purged to permit restarting. CAUTION:
o Do not let any petrol or water enter the tank. This would make it nec- essary to drain it out and to bleed the lines to avoid jamming theinjection pump and damaging the engine.
o In winter, in order to cut down
incidents due to freezing, paraffinoil may be added to the fuel if the temperature drops to below -10°C.Never use more than 20% paraffin oil.
Biodiesel Commercially supplied biodiesel blends of no more than 5% biodiesel, com- monly known as "B5 biodiesel" may be used in your vehicle if it meets EN14214 or equivalent specifications. (EN stands for "European Norm"). The use of biofuels made from rapeseed methylester (RME), fatty acid methyl ester (FAME), vegetable oil methyl ester (VME) etc. or mixing diesel withbiodiesel will cause increased wear or damage to the engine and fuel system.
CM-aust-1a.p65 5/21/2008, 2:04 PM
2

1
FEATURES OF YOUR HYUNDAI
3
B010E01A-DAT Petrol for Cleaner Air To help contribute to cleaner air, Hyundai recommends that you use petrol treatedwith detergent additives, which help prevent deposit formation in the engine. This petrol will help the engine runcleaner and enhance performance of the Emission Control System.
B010D01A-DAT Do not Use Methanol Fuels containing methanol (wood alco- hol) should not be used in your Hyundai.This type of fuel can reduce vehicle performance and damage components of the fuel system.
! B010F01A-AAT Operation in Foreign Countries If you are going to drive your Hyundai in another country, be sure to:
o Observe all regulations regarding
registration and insurance.
o Determine that acceptable fuel is
available.
CAUTION:
Hyundai Warranty Policy will not cover the damage of the fuel system and performance problems that are caused by the use of methanol orfuels containing methanol. B010B01A-DAT What About Gasohol [E-10]? Gasohol (a mixture of 90% unleaded gasoline and 10% ethanol or grain alco-hol) may be used in your Hyundai. However, if your engine develops drive ability problems, the use of 100% un-leaded petrol is recommended. Fuels with unspecified quantities of alcohol, or alcohols other than ethanol, shouldnot be used.
Repair or replacement of worn or dam-aged components due to the use of nonapproved fuels will not be covered by the manufactures warranty.
CAUTION:
o Never use any fuel, whether diesel or B5 biodiesel that fails to meet the latest petroleum industry speci-fication.
o Never use any fuel additives or
treatments that are not recom- mended or approved by the ve- hicle manufacturer.
!
CM-aust-1a.p65 5/21/2008, 2:04 PM
3

1FEATURES OF YOUR HYUNDAI
4IMMOBILISER SYSTEM
B880A01A-DAT The immobiliser system is an anti-theft device, designed to deter automobile theft. B880B03MC-DAT Keys All of the locks fitted to the vehicle are operated by the same key. However,since it is possible to lock the doors without the use of the key, care should be exercised to ensure that the keydoes not become locked inside the vehicle by mistake. NOTE: If you make your own duplicate key, you will not be able to cancel the system or start the engine.
B885B01JM
B020A01FC-DAT During the First 1,000 km (Diesel Engine) No formal running in period is required with your new Hyundai. However, youcan contribute to the economical opera- tion and durability of your Hyundai by observing the following recommenda-tions during the first 1000 km.
o While driving, keep your engine speed
or revolutions per minute within 3000 rpm.
o While driving, keep under three quar- ters of maximum speed.
o Use moderate acceleration. Don't use
full-throttle starts.
o For the first 300 km, try to avoid hard braking.
o Don't labouring the engine (in other words, don't drive so slowly in toohigh a gear that the engine hesitates: shift to a lower gear).
o Whether going fast or slow, vary your speed from time to time.
o Don't let the engine idle longer than 3
minutes at one time.
o Do not tow a trailer during the first
1000 km of operation.
RUNNING IN YOUR NEW HYUNDAI
B020A01S-DAT During the First 2,000 km (Petrol Engine) No formal running in period is required with your new Hyundai. However, youcan contribute to the economical opera- tion and durability of your Hyundai by observing the following recommenda-tions during the first 2000 km.
o Don't drive faster than 88 km/h.
o While driving, keep your engine speed
or revolutions per minute between2000 and 4000 rpm.
o Use moderate acceleration. Don't use full-throttle starts.
o For the first 300 km, try to avoid hard stops.
o Don't labour the engine (in other
words, don't drive so slowly in toohigh a gear that the engine jumps: shift to a lower gear).
o Whether going fast or slow, vary your speed from time to time.
o Don't let the engine idle longer than 3
minutes.
o Do not tow a trailer during the first 2000 km of operation.
CM-aust-1a.p65 5/21/2008, 2:04 PM
4

1
FEATURES OF YOUR HYUNDAI
5
B880C01NF-DAT Key Numbers The vehicle key number is recorded upon a number tag attached to the keyswhen the vehicle is first delivered to you. The key number should be recordedand kept in a safe place in case the need to order further keys arises. New keys are available from any Hyundaidealer by quoting the relevant key num- ber. In the interest of security, the numbertag attached to the keys which bears the key number should be removed from the key string after you receiveyour new vehicle. In addition, key num- bers cannot be provided by Hyundai for security reasons. If you need additional keys or if youshould lose your keys, your authorisedHyundai dealer can make new keys if you can supply the key number and master key.
B885D01CM-DAT Limp home procedures In case the immobiliser warning indica- tor blinks for five seconds when the ignition key is turned to "ON" position,this indicates that the immobiliser sys- tem is out of order. Should the immobiliser system be out of order,your vehicle will need to be towed to a Hyundai dealer for rectification.
HNF2011
Immobiliser warning indicator
OMC025002
!
CAUTION:
o When starting the engine, do not use the key with other immobiliser keys around. Otherwise the en-gine may not start or may stop soon after it starts. Keep each keys separately not tohave any malfunction after you receive your new vehicle.
o Do not install the metal accesso-
ries near the key or ignition switch.The engine may not start for the metal accessories may interruptthe transponder signal from nor- mally transmitting.
!WARNING:
In order to prevent theft of your ve- hicle, do not leave spare keys any-where in your vehicle. Your immobi- lizer password is a customer unique password and should be kept confi-dential. Do not leave this number anywhere in your vehicle.
CM-aust-1a.p65 5/21/2008, 2:04 PM
5

1FEATURES OF YOUR HYUNDAI
6
B030C01CM-AAT ILLUMINATED IGNITION SWITCH (If installed) Whenever a door is opened, the ignition switch will be illuminated for your con-venience, provided the ignition switch is not in the "ON" position. The light will go off approximately 30 seconds afterclosing the door or when the ignition switch is turned on.
B030C01E
DOOR LOCKS
!
B040A01NF-DAT
WARNING:
o Unlocked doors can be danger- ous. Before you drive away (espe- cially if there are children in the car), be sure that all the doors aresecurely closed and locked so that the doors cannot be inadvertently opened from the inside. This helpsensure that doors will not be opened accidentally. Also, when combined with the proper use of seat belts, locking the doors helps keep occupants from being ejectedfrom the car in case of an accident.
o Before opening the door, always
look for and avoid oncoming traf-fic.
o In case of an accident, all doors
will unlock automatically (If In-stalled). o Do not lock the door using the key
or the transmitter until all passen-gers have left the car because once the doors have been locked using the key or transmitter, it is impos-sible to unlock the door manually by hand (If Installed). Leaving children, helpless adults,or pets in an enclosed vehicle is dangerous. They can be overcome by the extreme heat and sufferpermanent injuries or even death from heat stroke.
CM-aust-1a.p65 5/21/2008, 2:04 PM
6

1
FEATURES OF YOUR HYUNDAI
7
!
B040C01O-AAT Locking from the Outside The doors can be locked without a key. To lock the doors, first push the insidelock switch to the "LOCK" position so that the red mark on the switch is not visible, then close the door. NOTE:
o The door will not lock if the key is
left in the ignition switch when the front doors are closed.
o When locking the door this way,
be careful not to lock the door withthe ignition key left in the vehicle.
WARNING:
Do not lock the door using the key or the transmitter until all passengers have left the car because once thedoors have been locked using the key or transmitter, it is impossible to unlock the door manually by hand (IfInstalled). Leaving children, help- less adults, or pets in an enclosed vehicle is dangerous. They can beovercome by the extreme heat and suffer permanent injuries or even death from heat stroke.
OCM051002R
OCM052005R
LOCK
UNLOCK
B040B01TG-AAT Locking and unlocking front doors with a key
o The door can be locked or unlocked
with a key.
o Lock the door by turning the key toward the front of the vehicle and unlock it by turning the key towardthe rear.
CM-aust-1a.p65 5/21/2008, 2:04 PM
7

1FEATURES OF YOUR HYUNDAI
8
B040E04A-DAT Child-protector Rear Door Lock Your Hyundai is equipped with a "child- protector" rear door lock assembly. When the lock mechanism is engaged, the rear door cannot be opened from theinside. Its use is recommended when- ever there are small children in the rear seat. To engage the child-protector fea-ture so that the door cannot be opened from inside, move the child-protector lever to the "
" position and close the
door. Move the lever to the "
" posi-
tion when normal door operation is de- sired. The outside door handle will func-tion normally, regardless of the position of the child protector door lock.
OCM052009
!
o To reduce the chances of theft, always remove the ignition key, close all windows, and lock all doors and tail gate when leaving your vehicle unattended.
OCM052006R
B040D01NF-AAT Locking from the Inside To lock the doors from the inside, sim- ply close the door and push the lock switch to the "LOCK" position.
UNLOCKLOCK
WARNING:
Be careful not to pull the inside door handle while driving. If you pull theinside door handle, the door can be opened and you may be ejected from the vehicle and can be injured orkilled.
NOTE:
o When the door is locked, the red
mark on the switch is not visible.
o The driver's and front passenger's doors can be opened by pulling the inside door handle even if the inside lock switch is pushed to the"LOCK" position.
CM-aust-1a.p65 5/21/2008, 2:04 PM
8

1
FEATURES OF YOUR HYUNDAI
9
o The driver's and front passenger's doors can be opened by pulling the inside door handle even if the front portion of the driver's or front passenger's (if installed) centraldoor locking switch has been de- pressed to lock the doors.
o If the door is locked/unlocked mul- tiple times in rapid successionwith either the vehicle key or door lock switch, the system may stopoperating temporarily in order to protect the circuit and prevent damage to system components.
B040G02NF-AAT Central Door Locks (If Installed) The central door locking switch is lo- cated on the driver's and frontpassenger's (if installed) armrest. It is operated by depressing the door lock switch. If any door is open when theswitch is depressed to the "LOCK" position, the door will remain locked when closed. NOTE:
o When pushing the front portion of
the driver's or front passenger's (if installed) door lock switch, all vehicle doors will lock.
o When pushing the rear portion of these switches, all vehicle doorswill unlock.
OCM052007R
LOCKUNLOCK
LOCKUNLOCK
!
OCM052002R
THEFT-ALARM SYSTEM
UNLOCK
LOCK
B070A01A-DAT (If Installed) This system is designed to provide protection from unauthorised entry intothe car. This system is operated in three stages: the first is the "Armed" stage, the second is the "Alarm" stage,and the third is the "Disarmed" stage. If triggered, the system provides an au- dible alarm with blinking of the turnsignal lights. B070B01CM-DAT Armed Stage Park the car and stop the engine. Arm the system as described below.
WARNING:
Be careful not to pull the inside doorhandle while driving. If you pull theinside door handle, the door can be opened and you may be ejected from the vehicle and can be injured orkilled.
Passenger's door (If Installed)
Driver's door
CM-aust-1a.p65 5/21/2008, 2:04 PM
9
