TROUBLE DIAGNOSIS — GENERAL DESCRIPTION
Revision: 2004 November 2004 FX35/FX45
DATA MONITOR
Operation Procedure
1. Touch “DATA MONITOR” on the selection screenACS-30,
"CONSULT-II INSPECTION PROCEDURE" .
2. Touch any of “ECU INPUT SIGNALS”, “MAIN SIGNALS”, and
“SELECTION FROM MENU” on selection screen.
3. Touch “SETTING”.
4. Display the data monitor.
5. If necessary, touch “COPY” in turn, and print data.
Monitored Item
×: Applicable
PKIA8868E
Monitored Item [unit]MAIN SIG-
NALSECU
INPUT
SIGNALSSELEC-
TION
FROM
MENUDescription
VHCL SPEED SE
[km/h] or [mph]×××Indicates vehicle speed calculated from wheel speed sen-
sor signal.
SET VHCL SPD
[km/h] or [mph]××Indicates set vehicle speed memorized in ICC unit.
THRTL OPENING
[%]×××Indicates throttle angle calculated from signal voltage of
throttle position sensor.
ENGINE RPM
[rpm]××Indicates engine speed read by ICC unit via CAN commu-
nication (ECM transmits engine speed via CAN communi-
cation).
DISTANCE ADJ
[SHOR/MID/LONG]×××Indicates set distance memorized in ICC unit.
WIPER SW
[OFF/LOW/HIGH]××Indicates wiper [OFF/LOW/HIGH] status.
MAIN SW
[ON/OFF]×××Indicates [ON/OFF] status as judged from control switch
signal.
SET/COAST SW
[ON/OFF]×××Indicates [ON/OFF] status as judged from control switch
signal.
CANCEL SW
[ON/OFF]×××Indicates [ON/OFF] status as judged from control switch
signal.
RESUME/ACC SW
[ON/OFF]×××Indicates [ON/OFF] status as judged from control switch
signal.
CRUISE OPE
[ON/OFF]××Indicates whether controlling or not (ON means “control-
ling”).
BRAKE SW
[ON/OFF]×××Indicates [ON/OFF] status as judged from ICC brake
switch signal.
STOP LAMP SW
[ON/OFF]×××Indicates [ON/OFF] status as judged from stop lamp
switch signal.
RELEASE SW NO
[ON/OFF]
××Indicates [ON/OFF] status as judged from release switch
signal.
ON when brake is depressed.
OFF when brake is not depressed.
RELEASE SW NC
[ON/OFF]
××Indicates [ON/OFF] status as judged from release switch
signal.
OFF when brake is depressed.
ON when brake is not depressed.

TROUBLE DIAGNOSIS — GENERAL DESCRIPTION
ACS-33
[ICC]
C
D
E
F
G
H
I
J
L
MA
B
ACS
Revision: 2004 November 2004 FX35/FX45
ACTIVE TEST
Caution

Do not perform the active test while driving.

Active test cannot be started while ICC system warning indicator illuminates.
1. Touch “ACTIVE TEST” on selection screenACS-30, "
CONSULT-II INSPECTION PROCEDURE" .
2. Touch any of “ICC BUZZER 1”, “METER LAMP”, “STOP LAMP”
and “BOOSTER SOL/V 3” on selection screen.
3. Touch necessary item and “START”.
4. Active test screen will be shown.
IDLE SW
[ON/OFF]××Indicates [ON/OFF] status of idle switch read by ICC unit
via CAN communication (ECM transmits ON/OFF status
via CAN communication).
GEAR
[1, 2, 3, 4, 5]××Indicates AT gear position read by ICC unit via CAN com-
munication (TCM transmits gear position via CAN commu-
nication).
BUZZER O/P
[ON/OFF] ×Indicates [ON/OFF] status of ICC war output.
ICC WARNING×NOTE:
This item is displayed, but cannot monitoring.
VHCL SPD AT
[km/h] or [mph]
×Indicates vehicle speed calculated from AT vehicle speed
sensor by ICC unit via CAN communication (TCM trans-
mits AT vehicle speed sensor signal via CAN communica-
tion).
PRESS SENS
[bar]×××Indicates brake fluid pressure value calculated from signal
voltage of pressure sensor.
PRESS SENS 2×NOTE:
This item is displayed, but cannot monitoring.
D RANGE SW
[ON/OFF]××Indicates [ON/OFF] status of “D” position read by ICC unit
via CAN communication (TCM transmits ON/OFF condi-
tion of “D” position via CAN communication).
AT OD OFF
[ON/OFF]×Indicates [ON/OFF] status of OD cancel output under con-
trol.
NP RANGE SW
[ON/OFF]××Indicates PNP switch signal read by ICC unit via CAN
communication. TCM transmits PNP switch signal via CAN
communication.
DISTANCE×NOTE:
This item is displayed, but cannot monitoring.
RELATIVE SPD×NOTE:
This item is displayed, but cannot monitoring.
STP LMP DRIVE
[ON/OFF]××Indicates [ON/OFF] status of brake hold relay drive output. Monitored Item [unit]MAIN SIG-
NALSECU
INPUT
SIGNALSSELEC-
TION
FROM
MENUDescription
SKIA6195E

ACS-34
[ICC]
TROUBLE DIAGNOSIS — GENERAL DESCRIPTION
Revision: 2004 November 2004 FX35/FX45
ICC BUZZER 1

Touch “ON” and “OFF” to check that ICC warning chime oper-
ates as in the following chart.
BUZZER O/P ON OFF
Buzzer sound Beep Not activated
SKIA1228E

TROUBLE DIAGNOSIS — GENERAL DESCRIPTION
ACS-35
[ICC]
C
D
E
F
G
H
I
J
L
MA
B
ACS
Revision: 2004 November 2004 FX35/FX45
METER LAMP

Start engine.

Touch “ON” and “OFF” to check that ICC system display oper-
ates as in the following chart.
STOP LAMP

Touch “ON” and “OFF” to check that stop lamp operates as in
the following chart.
BOOSTER SOL/V 3

Touch any of “MODE 1”, “MODE 2”, “MODE 3” to check that fol-
lowing operation condition is caused by operating monitor and
brake pedal.

“START” is displayed 10 seconds after operation start. (Active
test is completed.)
Self-Diagnostic FunctionAKS006YV
WITH CONSULT-II
1. Go to operation check after asking the customer for symptom information. Refer to ACS-9, "ACTION
TEST" .
2. Stop vehicle, turn ignition switch OFF, then connect CONSULT-II and CONSULT-II CONVERTER to data
link connector.
3. With engine started, touch “START”, “ICC”, “SELF-DIAG RESULTS” on CONSULT-II screen in this order.
METER LAMP ON OFF
ICC system display Full illumination OFF
SKIA1231E
STP LMP DRIVE ON OFF
Stop lamp Lamp ON Lamp OFF
SKIA1232E
SKIA1233E
PKIA0363J

ACS-36
[ICC]
TROUBLE DIAGNOSIS — GENERAL DESCRIPTION
Revision: 2004 November 2004 FX35/FX45
CAUTION:
If “ICC” cannot be shown after several attempts, the ICC unit may have had malfunction. Repair or
replace it. Refer to GI-40, "
CONSULT-II Data Link Connector (DLC) Circuit" .
4. Self-diagnostic result appears on screen. If “NO DTC ···” is shown, check ICC warning lamp. If any mal-
function is indicated, GO TO step 5.
5. According to ACS-40, "
Diagnostic Trouble Code (DTC) Chart" , perform appropriate check, and repair or
replace malfunctioning part as necessary.
6. Turn ignition switch OFF.
7. Start engine and touch “START”, “ICC”, “SELF-DIAG RESULT”, and “ERASE” on CONSULT-II display in
turn to erase the memory.
CAUTION:
If the memory does not erase, go to 5.
8. Perform ICC system running test (drive vehicle with ICC system ON), and make sure that ICC warning
lamp does not illuminate.
WITHOUT CONSULT-II
1. Go to operation check after asking the customer for symptom information. Refer to ACS-9, "ACTION
TEST" .
2. Stop the vehicle to start the self-diagnosis.
3. Turn ignition switch OFF.
4. Turn ignition switch ON, and within 5 to 10 seconds, press
ACCEL/RES switch 5 times. Then press COAST/SET switch 5
times to start self-diagnosis.
CAUTION:

Do not start the engine.

Do not turn the ON/OFF switch ON.

When operation above is not completed within 5 to 10 sec-
onds, start again from above go to 3.

If self-diagnosis mode cannot be started after several
attempts, the ICC unit may have had malfunction. Repair or
replace it. Refer to ACS-37, "
SELF-DIAGNOSIS BY ICC SYS-
TEM DISPLAY WILL NOT RUN." .
5. When self-diagnosis mode is started, DTC are shown on set vehicle speed indicator.
CAUTION:

DTC will disappear after 5 minutes.
SKIA7067E
SKIA1236E

TROUBLE DIAGNOSIS — GENERAL DESCRIPTION
ACS-37
[ICC]
C
D
E
F
G
H
I
J
L
MA
B
ACS
Revision: 2004 November 2004 FX35/FX45

When more than one malfunctions are detected, a maximum of 3 code numbers can be stored;
the latest malfunction will be displayed first.
6. Check ACS-40, "
Diagnostic Trouble Code (DTC) Chart" , and repair or replace if necessary.
7. After repair, erase DTC stored in the ICC unit.
8. DTC 55 will be shown.
9. Turn ignition switch OFF to exit the diagnosis.
10. Perform ICC system running test (drive vehicle with ICC system ON), and make sure that ICC warning
lamp does not illuminate.
Self-Diagnostic Erasing Method
1. Stop the vehicle and turn the ignition switch OFF.
2. Turn ignition switch ON and start self-diagnosis.
3. During self-diagnosis mode, press CANCEL switch 5 times, and DISTANCE switch 5 times in this order.
CAUTION:

Press them within 10 seconds after pressing CANCEL switch at first.

When operation is not completed within 10 seconds, start again from above go to 2.
4. DTC 55 will be shown.
CAUTION:
DTC of an existing malfunction will not be erased.
5. Turn ignition switch OFF to exit the diagnosis.
6. Perform ICC system running test (drive vehicle with ICC system ON), and make sure that ICC system
warning lamp (yellow) does not illuminate.
SELF-DIAGNOSIS BY ICC SYSTEM DISPLAY WILL NOT RUN.
Possible Irregular Condition
SKIA7068E
Open or short lines Trouble phenomenon Malfunction causes
ICC unit power supply malfunction No voltage supply from ignition switch Fuse blown
Harness open
Harness shorted
Ground cable not connected Harness open
Harness shorted
ICC steering switch malfunction No signal transmitted Harness open
Harness shorted
Spiral cable open
Spiral cable shorted
Switch or ECM malfunction
CAN communication system malfunction Signal not transmitted Harness open
Harness shorted
CAN communication outside the stan-
dard.

ACS-38
[ICC]
TROUBLE DIAGNOSIS — GENERAL DESCRIPTION
Revision: 2004 November 2004 FX35/FX45
1. CHECK ICC SYSTEM DISPLAY

When ignition switch is ON, do all displays illuminate?
YES or NO
YES >> GO TO 2.
NO >> GO TO 5.
2. CHECK ICC STEERING SWITCH

Check ICC steering switch. Refer to ACS-65, "ICC Steering Switch" .
OK or NG
OK >> GO TO 3.
NG >> Replace ICC steering switch.
3. CHECK HARNESS BETWEEN ECM AND ICC STEERING SWITCH

Check harness and spiral cable between ECM and ICC steering switch for open or short circuit.
OK or NG
OK >> GO TO 4.
NG >> Repair or replace harness or spiral cable between ECM and ICC steering switch.
4. CHECK SELF-DIAGNOSIS

Disconnect connector of ECM, and check terminals for bend and looseness. Securely connect it again.

Enter self-diagnosis mode for ICC system?
YES or NO
YES >> INSPECTION END
NO >> GO TO 5.
5. CHECK POWER SUPPLY FOR ICC UNIT

Check ICC unit power supply, and repair if necessary.

When ignition switch is ON, do all displays illuminate?
YES or NO
YES >> Perform self-diagnosis again.
NO >> GO TO 6.
6. CHECK CONNECTOR FOR ICC UNIT

Disconnect connector of ICC unit, and check terminals for bend and looseness. Securely connect it again.

When ignition switch is ON, do all displays illuminate?
YES or NO
YES >> Perform self-diagnosis again.
NO >> GO TO 7.
Combination meter system malfunction Indication not possible Indicator malfunction
Indicator segments disappear.
ICC unit malfunctionOpen or short lines Trouble phenomenon Malfunction causes

TROUBLE DIAGNOSIS — GENERAL DESCRIPTION
ACS-39
[ICC]
C
D
E
F
G
H
I
J
L
MA
B
ACS
Revision: 2004 November 2004 FX35/FX45
7. CHECK CAN COMMUNICATION

Perform self-diagnosis with CONSULT-II, and check CAN communication system for malfunction.
OK or NG
OK >> Replace combination meter.
NG >> CAN communication inspection. Refer to ACS-41, "
DTC 20 CAN COMM CIRCUIT" .

ACS-40
[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: 2004 November 2004 FX35/FX45
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMSPFP:00000
Diagnostic Trouble Code (DTC) ChartAKS006YW
×:Applicable
DTC
No.CONSULT-II screen termsICC sys-
tem
warning
lampFail-safe
Malfunctions detected where...Refer-
ence
page Ve h ic le -
to-vehi-
cle dis-
tance
control
modeConven-
tional
(fixed
speed)
cruise
control
modeBrake
assist
(with pre-
view
function)
11 CONTROL UNIT××××

ICC unit internal malfunctionACS-41
20 CAN COMM CIRCUIT××××
ICC unit detected CAN communi-
cation malfunction.ACS-41
31 POWER SUPPLY CIR××××
ICC unit power supply voltage is
excessively low. (less than 8V)ACS-42
34 POWER SUPPLY CIR2××××
ICC unit power supply voltage is
excessively high.ACS-42
41 VHCL SPEED SE CIRC××××

Wheel sensor malfunction.

ABS actuator and electric unit
(control unit) malfunction

AT vehicle speed sensor mal-
function

TCM malfunctionACS-42
43 ABS/TCS/VDC CIRC××××
VDC/TCS/ABS system malfunc-
tionACS-43
45 BRAKE SW/ STOP L SW××××

Brake and stop lamp switch har-
ness is open or shorted.

Brake and stop lamp switch is
ON or stuck to OFF.

Brake and stop lamp switch is
stuck to ON.ACS-43
46 OPERATION SW CIRC×××

ICC steering switch harness or
spiral cable is open or shorted.

ICC steering switch malfunctionACS-45
61 PRESS SEN CIRCUIT×× ×

Brake pressure sensor harness is
open or shorted.

Brake pressure sensor malfunc-
tion

Brake pressure sensor input cir-
cuit malfunctionACS-46
62 BOOSTER SOL/V CIRCUIT×× ×

Solenoid harness is open or
shorted.

Solenoid is open.

Solenoid drive circuit malfunctionACS-47
63 RELEASE SW CIRCUIT××××

Release switch harness is open
or shorted.

Release switch malfunction

Release switch input circuit mal-
functionACS-48
65 PRESSURE CONTROL×× ×
Booster malfunctionACS-49
74 LASER BEAM OFF CNTR×× ×
Laser beam of ICC sensor is off
the aiming point.ACS-49

TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
ACS-41
[ICC]
C
D
E
F
G
H
I
J
L
MA
B
ACS
Revision: 2004 November 2004 FX35/FX45
DTC 11 CONTROL UNITAKS006YX
1. DIAGNOSTIC CHECK
1. Are any items other than “DTC 11 CONTROL UNIT” indicated on self-diagnosis display?
YES or NO
YES >> Repair or replace applicable item. Erase DTC and perform ICC system running test. Then perform
self-diagnosis of ICC system again.
NO >> Replace ICC unit. Erase DTC and perform ICC system running test. Then perform self-diagnosis
of ICC system again.
DTC 20 CAN COMM CIRCUITAKS006YY
1. CHECK CAN COMMUNICATION
With CONSULT-II
1. Perform self-diagnosis.
2. Print self-diagnostic result.
>> After printing self-diagnostic result, go to “CAN system”. Refer to LAN-4, "
Precautions When
Using CONSULT-II" .
90 STOP LAMP RLY FIX×× ×
Normally open terminal of stop
lamp relay is stuck.ACS-50
92 ECM CIRCUIT××××

ECM malfunction

Accelerator pedal position sensor
malfunction

ICC unit malfunctionACS-54
96 NP RANGE×××

Park/neutral position switch har-
ness is open or shorted.

Park/neutral position switch mal-
function.

TCM malfunctionACS-55
97 AT CIRCUIT×××
TCM malfunctionACS-56
98 GEAR POSITION×××

TCM malfunction

AT turbine revolution sensor mal-
function

AT vehicle speed sensor mal-
functionACS-56
102 RADAR STAIN×× ×
ICC sensor body window has
contamination.ACS-57
103 LASER SENSOR FAIL×× ×
ICC sensor internal malfunctionACS-58
104 LASER AIMING INCMP×× ×
Laser beam aiming of ICC sensor
is not adjusted.ACS-58
107 LASER COMM FAIL×× ×

CAN data received by ICC sen-
sor is strange (from ICC unit,
combination meter or ECM).ACS-58
109 LASER HIGH TEMP×× ×
Temperature around ICC sensor
is excessively high.ACS-58
DTC
No.CONSULT-II screen termsICC sys-
tem
warning
lampFail-safe
Malfunctions detected where...Refer-
ence
page Vehicle-
to-vehi-
cle dis-
tance
control
modeConven-
tional
(fixed
speed)
cruise
control
modeBrake
assist
(with pre-
view
function)
