3. Touch “IPDM E/R” on “SELECT SYSTEM” screen.
If “IPDM E/R” is not displayed, print “SELECT SYSTEM” screen,
then refer to GI-40, "
CONSULT-II Data Link Connector (DLC)
Circuit" .
4. Select the desired part to be diagnosed on the “SELECT DIAG
MODE” screen.
SELF-DIAGNOSTIC RESULTS
Refer to PG-21, "SELF-DIAG RESULTS" .
DATA MONITOR
Operation Procedure
1. Touch “DATA MONITOR” on “SELECT DIAG MODE ” screen.
2. Touch “ALL SIGNALS”, “MAIN SIGNALS” or “SELECTION FROM MENU” on the “DATA MONITOR”
screen.
3. Touch “START”.
4. Touch the required monitoring item on “SELECTION FROM MENU”. In “ALL SIGNALS”, all items are
monitored. In “MAIN SIGNALS”, predetermined items are monitored.
5. Touch “RECORD” while monitoring to record the status of the item being monitored. To stop recording,
touch “STOP”.
All Signals, Main Signals, Selection From Menu
NOTE:
Perform monitoring of IPDM E/R data with the ignition switch ON. When the ignition switch is at ACC, the dis-
play may not be correct.
PKIA5222E
PKIA6016E
ALL SIGNALS All items will be monitored.
MAIN SIGNALS Monitor the predetermined item.
SELECTION FROM MENU Select any item for monitoring.
Item nameCONSULT-II
screen displayDisplay or unitMonitor item selection
Description
ALL
SIGNALSMAIN
SIGNALSSELECTION
FROM MENU
FR wiper request FR WIP REQ STOP/1LO/LO/HI×× ×Signal status input from BCM
Wiper auto stop WIP AUTO STOP ACT P/STOP P×× ×Output status of IPDM E/R
Wiper protection WIP PROT OFF/LS/HS/Block×× ×Control status of IPDM E/R

FRONT WIPER AND WASHER SYSTEM
WW-21
C
D
E
F
G
H
I
J
L
MA
B
WW
Revision: 2004 November 2004 FX35/FX45
ACTIVE TEST
Operation Procedure
1. Touch “ACTIVE TEST” on “SELECT DIAG MODE” screen.
2. Touch item to be tested, and check operation.
3. Touch “START”.
4. Touch “STOP” while testing to stop the operation.
Front Wiper Does Not OperateAKS0079W
CAUTION:

During IPDM E/R fail-safe control, front wipers may not operate. Refer to PG-18, "CAN COMMUNI-
CATION LINE CONTROL" in “PG IPDM E/R” to make sure that it is not in fail-safe status.
1. CHECK IPDM E/R TO FRONT WIPERS (1)
With CONSULT-ll
1. Select “IPDM E/R” on CONSULT-II, and select “ACTIVE TEST”
on “SELECT DIAG MODE” screen.
2. Select “FRONT WIPER” on “SELECT TEST ITEM” screen.
Without CONSULT-ll
Start up auto active test. Refer to PG-24, "
Auto Active Test" .
Does the front wiper operate normally?
YES >> GO TO 6.
NO >> GO TO 2.
2. CHECK FUSE
1. Turn ignition switch OFF.
2. Check fuse No. 73 of IPDM E/R.
OK or NG
OK >> GO TO 3.
NG >> If fuse is blown, be sure to eliminate cause of malfunction before installing new fuse. Refer to PG-
3, "POWER SUPPLY ROUTING CIRCUIT" .
Test item CONSULT-II screen display Description
Front wiper (HI, LO) output FRONT WIPERWith a certain operation (OFF, HI ON, LO ON), the front wiper relay
(Lo, Hi) can be operated.
SKIA3486E

WW-22
FRONT WIPER AND WASHER SYSTEM
Revision: 2004 November 2004 FX35/FX45
3. CHECK IPDM E/R TO FRONT WIPERS (2)
1. Disconnect IPDM E/R connector and front wiper motor connec-
tor.
2. Check continuity between IPDM E/R harness connector and
front wiper motor harness connector terminal.
3. Check continuity between IPDM E/R harness connector terminal and Ground.
OK or NG
OK >> GO TO 4.
NG >> Repair harness or connector.
4. CHECK CIRCUITE BETWEEN FRONT WIPERS AND GROUND
Check continuity between front wiper motor harness connector E57
terminal 2 (B) and ground.
OK or NG
OK >> GO TO 5.
NG >> Repair harness or connector.
Terminals
Continuity IPDM E/R Front wiper motor
ConnectorTerminal
(Wire color)ConnectorTerminal
(Wire color)
E721 (P)
E571 (P)
Ye s 31 (PU) 4 (PU)
32 (L) 5 (L)
Terminals
Continuity IPDM E/R
Connector Terminal (Wire color)
E721 (P)
Ground No 31 (PU)
32 (L)
PKIA5192E
2 (B) - Ground : Continuity should exist.
PKIA5193E

FRONT WIPER AND WASHER SYSTEM
WW-23
C
D
E
F
G
H
I
J
L
MA
B
WW
Revision: 2004 November 2004 FX35/FX45
5. CHECK IPDM E/R
With CONSULT-ll
1. Connect IPDM E/R connector and front wiper motor connector.
2. Using active test, check voltage between IPDM E/R harness
connector terminal and ground while front wiper (HI, LO) is oper-
ating.
Without CONSULT-ll
1. Connect IPDM E/R connector and front wiper motor connector.
2. Start up auto active test, and check voltage between IPDM E/R
harness connector terminal and ground while front wiper (HI,
LO) is operating.
OK or NG
OK >> Replace front wiper motor.
NG >> Replace IPDM E/R.
6. CHECK CIRCUIT BETWEEN COMBINATION SWITCH AND BCM
With CONSULT-ll
Select “BCM” on CONSULT-II. With “WIPER” on “DATA MONITOR”,
confirm that “FRONT WIPER INT”, “FRONT WIPER LOW”, and
“FRONT WIPER HI” turn ON-OFF according to wiper switch opera-
tion.
Without CONSULT-ll
Refer to LT- 11 3 , "
Combination Switch Inspection" .
OK or NG
OK >> GO TO 7.
NG >> Check wiper Switch. Refer to LT- 11 3 , "
Combination
Switch Inspection" .
7. CHECK CIRCUIT BETWEEN IPDM E/R AND BCM
Select “BCM” on CONSULT-II, and perform self-diagnosis for
“BCM”.
Displayed self
-diagnosis results
NO DTC>>Replace BCM. Refer to BCS-15, "Removal and Installa-
tion of BCM" .
CAN COMM CIRCUIT>>Check CAN communication line of BCM.
GO TO BCS-14, "
CAN Communication Inspection Using
CONSULT-II (Self-Diagnosis)" .
Terminals
Condition Voltage IPDM E/R(+)
(-)
Connector Terminal (Wire color)
E721 (P)
GroundStopped Approx. 0V
LO operation Battery voltage
31 (PU)Stopped Approx. 0V
HI operation Battery voltagePKIA5194E
SKIA5300E
SKIA1039E

WW-24
FRONT WIPER AND WASHER SYSTEM
Revision: 2004 November 2004 FX35/FX45
Front Wiper Does Not Return to Stop PositionAKS0079X
1. CHECK CIRCUIT BETWEEN IPDM E/R AND WIPER MOTOR (1)
With CONSULT-ll
Select “IPDM E/R” on CONSULT-II. With data monitor, confirm that
“WIP AUTO STOP” turns “ACT P” - “STOP P” linked with wiper oper-
ation.
Without CONSULT-ll
GO TO 2.
OK or NG
OK >> Replace IPDM E/R.
NG >> GO TO 2.
2. CHECK CIRCUIT BETWEEN IPDM E/R AND WIPER MOTOR (2)
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R connector and front wiper motor connec-
tor.
3. Check continuity between IPDM E/R harness connector E7 ter-
minal 32 (L) and front wiper motor harness connector E57 termi-
nal 5 (L).
4. Check continuity between IPDM E/R harness connector E7 ter-
minal 32 (L) and Ground.
OK or NG
OK >> GO TO 3.
NG >> Repair harness or connector.
3. CHECK IPDM E/R
1. Connect IPDM E/R connector and front wiper motor connector.
2. Turn ignition switch ON.
3. Check voltage between IPDM E/R harness connector terminal
and ground while front wiper motor is stopped and while it is
operating.
OK or NG
OK >> Replace IPDM E/R.
NG >> Replace front wiper motor.
Only Front Wiper LO Does Not OperateAKS0079Y
Refer to LT- 11 3 , "Combination Switch Inspection" .
SKIA5301E
32 (L) - 5 (L) : Continuity should exist.
32 (L) - Ground : Continuity should not exist.
PKIA5195E
Terminals
Condition Voltage IPDM E/R(+)
(-)
ConnectorTe r m i n a l
(Wire color)
E7 32 (L) GroundWiper stopped Approx. 0V
Wiper operating Battery voltage
PKIA5196E

FRONT WIPER AND WASHER SYSTEM
WW-25
C
D
E
F
G
H
I
J
L
MA
B
WW
Revision: 2004 November 2004 FX35/FX45
Only Front Wiper HI Does Not OperateAKS0079Z
1. CHECK CIRCUIT BETWEEN IPDM E/R AND FRONT WIPERS (1)
With CONSULT-ll
1. Select “IPDM E/R” on CONSULT-II, and select “ACTIVE TEST”
on “SELECT DIAG MODE” screen.
2. Select “FRONT WIPER” on “SELECT TEST ITEM” screen.
Without CONSULT-ll
Start up auto active test. Refer to PG-24, "
Auto Active Test" .
Does the front wiper operate normally?
YES >> GO TO LT- 11 3 , "Combination Switch Inspection" .
NO >> GO TO 2.
2. CHECK CIRCUIT BETWEEN IPDM E/R AND FRONT WIPERS (2)
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R connector and front wiper motor connec-
tor.
3. Check continuity between IPDM E/R harness connector E7 ter-
minal 31 (PU) and front wiper motor harness E57 connector ter-
minal 4 (PU).
4. Check continuity between IPDM E/R harness connector E7 ter-
minal 31 (PU) and ground.
OK or NG
OK >> GO TO 3.
NG >> Repair harness or connector.
3. CHECK IPDM E/R
With CONSULT-ll
1. Connect IPDM E/R connector and front wiper motor connector.
2. Using active test, check voltage between IPDM E/R harness
connector E7 terminal 31 (PU) and ground while front wiper (HI)
is operating.
Without CONSULT-ll
1. Connect IPDM E/R connector and front wiper motor connector.
2. Start up auto active test, and check voltage between IPDM E/R
harness connector E7 terminal 31 (PU) and ground while front
wiper HI is operating.
OK or NG
OK >> Replace front wiper motor.
NG >> Replace IPDM E/R.
Only Front Wiper INT Does Not OperateAKS007A0
Refer to LT- 11 3 , "Combination Switch Inspection" .
SKIA3486E
31 (PU) - 4 (PU) : Continuity should exist.
31 (PU) - Ground : Continuity should not exist.
PKIA5197E
31 (PU) - Ground : Battery voltagePKIA5198E

WW-26
FRONT WIPER AND WASHER SYSTEM
Revision: 2004 November 2004 FX35/FX45
Front Wiper Interval Time Is Not Controlled by Vehicle SpeedAKS007A1
1. CHECK FUNCTION OF COMBINATION METER
Confirm that speedometer operates normally.
Does the front wiper operate normally?
YES >> GO TO 2.
NO >> Combination meter vehicle speed system malfunction. GO TO DI-17, "
Vehicle Speed Signal
Inspection" .
2. CHECK CAN COMMUNICATION BETWEEN BCM AND COMBINATION METER
Select “BCM” on CONSULT-II, and perform self-diagnosis for
“BCM”.
Displayed self
-diagnosis results
NO DTC>>Replace BCM. Refer to BCS-15, "Removal and Installa-
tion of BCM" .
CAN COMM CIRCUIT>>Check CAN communication line of BCM.
GO TO BCS-14, "
CAN Communication Inspection Using
CONSULT-II (Self-Diagnosis)" .
Front Wiper Intermittent Operation Switch Position Cannot Be AdjustedAKS007YW
1. CHECK COMBINATION SWITCH INPUT SIGNAL
Select “BCM” on CONSULT-II. With “WIPER” data monitor, make
sure “INT VOLUME” changes in order from 1 to 7 according to oper-
ation of the intermittent switch dial position.
OK or NG
OK >> Replace BCM. Refer to LT- 11 3 , "Combination Switch
Inspection" .
NG >> Replace wiper switch.
Wipers Do Not Wipe When Front Washer OperatesAKS00575
1. CHECK CIRCUIT BETWEEN COMBINATION SWITCH AND BCM
Select “BCM” on CONSULT-II. With “WIPER” on “DATA MONITOR”,
make sure “FR WASHER SW” turns ON-OFF according to operation
of front washer switch.
OK or NG
OK >> Replace BCM. Refer to BCS-15, "Removal and Installa-
tion of BCM" .
NG >> Replace wiper switch.
SKIA1039E
SKIA4234E
When front wiper switch
washer position: FR WASHER SW ON
SKIA5300E

FRONT WIPER AND WASHER SYSTEM
WW-27
C
D
E
F
G
H
I
J
L
MA
B
WW
Revision: 2004 November 2004 FX35/FX45
After Front Wipers Operate for 10 Seconds, They Stop for 20 Seconds, and after
repeating the operations five times, they become inoperative
AKS007A2
CAUTION:

When auto-stop signal has not varied for 10 seconds or longer while IPDM E/R is operating front
wipers, IPDM E/R considers that front wipers are locked, and stops wiper output. That causes this
symptom.

This status can be checked by “DATA MONITOR” of “IPDM E/R” on which “WIPER PROTECTION”
item shows “BLOCK”.
1. CHECK CIRCUIT BETWEEN IPDM E/R AND WIPER MOTOR (1)
With CONSULT-ll
Select “IPDM E/R” on CONSULT-II. With “DATA MONITOR”, confirm
that “WIP AUTO STOP” turns “ACT P” - “STOP P” linked with wiper
operation.
Without CONSULT-ll
GO TO 2.
OK or NG
OK >> Replace IPDM E/R.
NG >> GO TO 2.
2. CHECK CIRCUIT BETWEEN IPDM E/R AND WIPER MOTOR (2)
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R connector and front wiper motor connec-
tor.
3. Check continuity between IPDM E/R harness connector E7 ter-
minal 32 (L) and front wiper motor harness connector E57 termi-
nal 5 (L).
4. Check continuity between IPDM E/R harness connector E7 ter-
minal 32 (L) and ground.
OK or NG
OK >> GO TO 3.
NG >> Repair harness or connector.
SKIA5301E
32 (L) - 5 (L) : Continuity should exist.
32 (L) - Ground : Continuity should not exist.
PKIA5195E

WW-28
FRONT WIPER AND WASHER SYSTEM
Revision: 2004 November 2004 FX35/FX45
3. CHECK CIRCUIT BETWEEN IPDM E/R AND WIPER MOTOR (3)
1. Connect IPDM E/R connector and front wiper connector.
2. Turn ignition switch ON.
3. Check voltage between IPDM E/R harness connector E7 termi-
nal 32 (L) and ground while front wiper motor is stopped and
while it is operating.
OK or NG
OK >> Replace IPDM E/R.
NG >> Replace front wiper motor.
Front Wipers Do Not StopAKS007A3
1. CHECK CIRCUIT BETWEEN COMBINATION SWITCH AND BCM
With CONSULT-ll
Select “BCM” on CONSULT-II. With “WIPER” on “DATA MONITOR”,
confirm that “FRONT WIPER INT”, “FRONT WIPER LOW”, “FRONT
WIPER HI”, and “FRONT WASHER SW” turn ON-OFF according to
wiper switch operation.
Without CONSULT-ll
Refer to LT- 11 3 , "
Combination Switch Inspection" .
OK or NG
OK >> Replace IPDM E/R.
NG >> Check wiper Switch. Refer to LT- 11 3 , "
Combination
Switch Inspection" .
Removal and Installation of Front Wiper Arms, Adjustment of Wiper Arms Stop
Location
AKS00576
REMOVAL
1. Operate wiper motor, and stop it at the auto stop position.
2. Remove washer tube from washer tube joint.
3. Remove wiper arm mounting nuts and wiper arm from vehicle.
INSTALLATION
1. Clean up the pivot area as illustrated. This will reduce possibility
of wiper arm looseness.
Terminals
Condition Voltage IPDM E/R(+)
(-)
ConnectorTerminal
(Wire color)
E7 32 (L) GroundWiper stopped Approx. 0V
Wiper operating Battery voltage
PKIA5196E
SKIA5300E
SEL024J

FRONT WIPER AND WASHER SYSTEM
WW-29
C
D
E
F
G
H
I
J
L
MA
B
WW
Revision: 2004 November 2004 FX35/FX45
2. Prior to wiper arm installation, turn on wiper switch to operate
wiper motor and then turn it “OFF” (auto stop).
3. Push wiper arm onto pivot shaft, paying attention to blind spline.
4. Attach washer tube to washer tube joint.
5. Lift the blade up and then set it down onto glass surface to set
the blade center to clearance “L1” & “L2” immediately before
tightening nut.
6. Eject washer fluid. Turn on wiper switch to operate wiper motor
and then turn it “OFF”.
7. Ensure that wiper blades stop within clearance “L1” & “L2”.

Tighten wiper arm nuts to specified torque.
ADJUSTMENT
Refer to WW-28, "INSTALLATION" .
Removal and Installation of Front Wiper Motor and LinkageAKS00577
REMOVAL
1. Prior to wiper motor and linkage removal, turn ON wiper switch to operate wiper motor and then turn it
“OFF” (auto stop).
2. Remove wiper arm. Refer to WW-28, "
REMOVAL" .
3. Remove cowl top cover. Refer to EI-24, "
Removal and Installa-
tion" in “EI” section.
4. Remove washer tube.
5. Disconnect wiper motor connector.
6. Remove wiper motor and linkage mounting bolts, and remove
wiper motor and linkage.
INSTALLATION
1. Install wiper motor and linkage to the vehicle.
2. Connect wiper motor assembly to the connector. Turn wiper switch ON to operate wiper motor, then turn
wiper switch OFF (auto stop).
3. Attach washer tube to washer tube joint.
4. Install cowl top cover. Refer to EI-24, "
Removal and Installation" in “EI” section.
5. Install wiper arms. Refer to WW-28, "
Removal and Installation of Front Wiper Arms, Adjustment of Wiper
Arms Stop Location" .
6. Attach wiper arm washer tube.
CAUTION:

Do not drop the wiper motor or cause it to contact other parts.

Check grease conditions of the motor arm and wiper link joint (at retainer). Apply grease if nec-
essary.Clearance “L1” : 44.4 - 54.4 mm (1.75 - 2.14 in)
Clearance “L2” : 38 - 48 mm (1.50 - 1.89 in)
Front wiper arm nuts
: 23.6 N·m (2.4 kg-m, 17 ft-lb)
PKIA7843E
SKIA5070E
