TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
ACS-49
[ICC]
C
D
E
F
G
H
I
J
L
MA
B
ACS
Revision: 2006 January2006 M35/M45
DTC 13 STOP LAMP RLY FIXNKS004D7
1. PERFORM ICC SENSOR INTEGRATED UNIT SELF-DIAGNOSIS
1. Perform self-diagnosis.
2. Check if “CAN COMM CIRCUIT [U1000]” (DTC 100) other than “STOP LAMP RLY FIX [C1A13]” (DTC 13)
is indicated in self-diagnosis item in the display.
Is it indicated?
YES >> 1. CAN communication inspection. Refer to ACS-60, "DTC 100 CAN COMM CIRCUIT" .
2. After repairing or replacing applicable item, erase DTC and perform ICC system running test.
Then perform self-diagnosis of ICC system again.
NO >> GO TO 2.
2. CHECK CONNECTOR FOR ECM
1. Turn ignition switch OFF.
2. Disconnect ECM connector, and connect it securely again.
3. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
4. Check if “STOP LAMP RLY FIX [C1A13]” (DTC 13) is indicated in self-diagnosis item in the display.
Is it indicated?
YES >> GO TO 3.
NO >> Poor connector connection
1. Check connector. (Check connector housing for disconnected, loose, bent, and collapsed ter-
minals. If any malfunction is detected, repair applicable part.)
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
3. CHECK STOP LAMP SWITCH WITH ICC DATA MONITOR
With CONSULT-II
With “ICC” “DATA MONITOR”, check if “STOP LAMP SW” operates normally.
OK or NG
OK >> GO TO 11.
NG >> GO TO 4.
4. CHECK STOP LAMP SWITCH INSTALLATION AND ADJUSTMENT
Check stop lamp switch for proper installation, and adjust the switch if necessary. Refer to BR-6, "
BRAKE
PEDAL" .
OK or NG
OK >> GO TO 5.
NG >> 1. Adjust stop lamp switch.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
5. CHECK STOP LAMP SWITCH
Check stop lamp switch. Refer to ACS-68, "
ICC Brake Switch and Stop Lamp Switch" .
OK or NG
OK >> GO TO 6.
NG >> 1. Replace stop lamp switch.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.

TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
ACS-55
[ICC]
C
D
E
F
G
H
I
J
L
MA
B
ACS
Revision: 2006 January2006 M35/M45
23. CHECK HARNESS BETWEEN STOP LAMP SWITCH AND ABS ACTUATOR AND ELECTRIC UNIT
(CONTROL UNIT)
1. Turn ignition switch OFF.
2. Disconnect ABS actuator and electric unit (control unit) connector.
3. Check continuity between stop lamp switch harness connector
(A) and ABS actuator and electric unit (control unit) harness
connector (B).
4. Check continuity between stop lamp switch harness connector
(A) and ground.
OK or NG
OK >> 1. Perform “ABS” self-diagnosis. Refer to BRC-22, "CONSULT-II Functions (ABS)" .
2. After repairing or replacing applicable item, erase DTC and perform ICC system running test.
Then perform self-diagnosis of ICC system again.
NG >> 1. Repair or replace harness between stop lamp switch and ABS actuator and electric unit (control
unit).
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
DTC 14 ECM CIRCUITNKS004D8
1. PERFORM ICC SENSOR INTEGRATED UNIT SELF-DIAGNOSIS
1. Perform self-diagnosis.
2. Check if “CAN COMM CIRCUIT [U1000]” (DTC 100) other than “ECM CIRCUIT [C1A14]” (DTC 14) is indi-
cated in self-diagnosis item in the display.
Is it indicated?
YES >> 1. CAN communication inspection. Refer to ACS-60, "DTC 100 CAN COMM CIRCUIT" .
2. After repairing or replacing applicable item, erase DTC and perform ICC system running test.
Then perform self-diagnosis of ICC system again.
NO >> GO TO 2.
2. PERFORM ECM SELF-DIAGNOSIS
With CONSULT-II
1. Perform “ENGINE” self-diagnosis. Refer to EC-133, "
CONSULT-II Function (ENGINE)" (for VQ35DE) or
EC-846, "
CONSULT-II Function (ENGINE)" (for VK45DE).
2. Check if malfunction is indicated.
Is malfunction indicated?
YES >> 1. Repair or replace applicable item.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
NO >> 1. Replace ICC sensor integrated unit, and adjust laser beam aiming.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
AB
Continuity
Connector Terminal Connector Terminal
E124 4 E30 30 Yes
A
GroundContinuity
Connector Terminal
E124 4 No
PKIC0834E
