ignition INFINITI QX56 2006 Factory Service Manual

TROUBLE DIAGNOSISATC-69
C
DE
F
G H
I
K L
M A
B
AT C
Revision: November 2009 2006 QX56
11 . CHECK PBR FEEDBACK SIGNAL CIRCUIT FOR SHORT TO GROUND
1. Turn ignition switch OFF.
2. Disconnect front air control harness connector.
3. Check continuity between front air control harness connector M49 terminal 16 and ground.
OK or NG
OK >> Replace front air control. Refer to ATC-144, "FRONT
AIR CONTROL" .
NG >> Repair or replace harness as necessary.
12. CHECK PBR FEEDBACK CIRCUIT FOR OPEN
1. Turn ignition switch OFF.
2. Disconnect the mode door motor harness connector and front air control harness connector.
3. Check continuity between mode door motor harness connector M142 terminal 2 and front air control harness connector M49 ter-
minal 16.
OK or NG
OK >> Replace mode door motor. Refer to ATC-161, "Removal
and Installation" .
NG >> Repair or replace harness as necessary. Continuity should not exist.
WJIA1733E
Continuity should exist.
LJIA0034E

ATC-72
TROUBLE DIAGNOSIS
Revision: November 20092006 QX56
COMPONENT DESCRIPTION
Air Mix Door Motors
The driver (1) and front passenger (2) air mix door motors are
attached to the front heater & cooling unit assembly. The rear air mix
door motor is attached to the rear heater & cooling unit. These
motors rotate so that the air mix door is opened or closed to a posi-
tion set by the front (or rear) air control. Motor rotation is then con-
veyed through a shaft and the air mix door position is then fed back
to the front air control by the PBR built into the air mix door motors.
DIAGNOSTIC PROCEDURE FOR AIR MIX DOOR MOTOR (DRIVER)
1. CHECK FRONT AIR CONTROL FOR POWER AND GROUND
1. Turn ignition switch ON.
2. Rotate temperature control dial (driver) to 32° C (90°F).
3. Check voltage between front air control harness connector M49 terminal 3 and terminal 4 while rotating temperature control dial
(driver) to 16 °C (60 °F).
OK or NG
OK >> GO TO 3.
NG >> GO TO 2.
2. CHECK AIR MIX DOOR MOTOR (DRIVER) CIRCUITS FOR SHORT TO GROUND
1. Turn ignition switch OFF.
2. Disconnect the front air control harness connector.
3. Check continuity between front air control harness connector M49 terminal 3, 4 and ground.
OK or NG
OK >> Replace front air control. Refer to ATC-144, "FRONT
AIR CONTROL" .
NG >> Repair or replace harness as necessary.
WJIA2309E
WJIA1245E
Connector Te r m i n a l s
Condition Voltage
(Approx.)
(+) (-)
Front air control: M49 3 4 Rotate temp
control dial Battery
voltage
WJIA1735E
3 - Ground : Continuity should not exist.
4 - Ground : Continuity should not exist.
WJIA1736E

TROUBLE DIAGNOSISATC-73
C
DE
F
G H
I
K L
M A
B
AT C
Revision: November 2009 2006 QX56
3. CHECK FRONT AIR CONTROL FOR POWER AND GROUND
1. Turn ignition switch ON.
2. Rotate temperature control dial (driver) to 32 °C (90 °F).
3. Check voltage between front air control harness connector M49 terminal 3 and terminal 4 while rotating temperature control dial
(driver) to 16 °C (60 °F).
OK or NG
OK >> GO TO 4.
NG >> Replace front air control. Refer to ATC-144, "
FRONT AIR CONTROL" .
4. CHECK AIR MIX DOOR MOTOR (DRIVER) CIRCUITS FOR OPEN
1. Turn ignition switch OFF.
2. Disconnect the front air control harness connector.
3. Check continuity between front air control harness connector M49 terminal 3 and terminal 4.
OK or NG
OK >> GO TO 6.
NG >> GO TO 5.
5. CHECK AIR MIX DOOR MOTOR (DRIVER) CIRCUITS FOR OPEN
1. Disconnect the air mix door motor (driver) harness connector.
2. Check continuity between front air control harness connector M49 terminal 3, 4 and the air mix door motor (driver) harness
connector M147 terminal 1, 6.
OK or NG
OK >> Replace air mix door motor (driver). Refer to ATC-163,
"FRONT AIR MIX DOOR MOTOR (PASSENGER)" .
NG >> Repair or replace harness as necessary.
Connector Terminals
Condition Voltage
(Approx.)
(+) (-)
Front air control: M49 4 3
Rotate temp
control dial Battery
voltage
WJIA1737E
Continuity should exist.
WJIA1738E
3 - 1 : Continuity should exist.
4 - 6 : Continuity should exist.
WJIA0588E

ATC-74
TROUBLE DIAGNOSIS
Revision: November 20092006 QX56
6. CHECK FRONT AIR CONTROL FOR PBR POWER AND GROUND
1. Reconnect front air control harness connector.
2. Turn ignition switch ON.
3. Check voltage between front air control harness connector M49 terminal 2 and terminal 15.
OK or NG
OK >> GO TO 8.
NG >> GO TO 7.
7. CHECK PBR REFERENCE VOLTAGE CIRCUIT FOR SHORT TO GROUND
1. Turn ignition switch OFF.
2. Disconnect the front air control harness connector.
3. Check continuity between front air control harness connector M49 terminal 2 and ground.
OK or NG
OK >> Replace front air control. Refer to ATC-144, "FRONT
AIR CONTROL" .
NG >> Repair or replace harness as necessary.
8. CHECK PBR REFERENCE VOLTAGE AND GROUND CIRCUITS
1. Turn ignition switch OFF.
2. Disconnect the front air control harness connector.
3. Check continuity between front air control harness connector M49 terminal 2 and terminal 15.
OK or NG
OK >> GO TO 10.
NG >> GO TO 9.
9. CHECK PBR REFERENCE VOLTAGE CIRCUIT FOR OPEN
1. Disconnect the air mix door motor (driver) harness connector.
2. Check continuity between air mix door motor (driver) harness connector M147 (B) terminal 3, 2 and front air control harness
connector M49 (A) terminal 2, 15.
OK or NG
OK >> Replace air mix door motor (driver). Refer to ATC-163,
"FRONT AIR MIX DOOR MOTOR (PASSENGER)" .
NG >> Repair or replace harness as necessary.
Connector Terminals
Voltage
(Approx.)
(+) (-)
Front air control: M49 2 15 5V
WJIA1729E
Continuity should not exist.
WJIA1730E
Continuity should exist.
WJIA1731E
2 - 3 : Continuity should exist.
15 - 2 : Continuity should exist.
WJIA1777E

TROUBLE DIAGNOSISATC-75
C
DE
F
G H
I
K L
M A
B
AT C
Revision: November 2009 2006 QX56
10. CHECK PBR FEEDBACK VOLTAGE
1. Reconnect the front air control harness connector.
2. Turn ignition switch ON.
3. Check voltage between front air control harness connector M49 terminal 18 and ground while rotating temperature control dial
from 32 °C (90 °F) to 16 °C (60 °F).
OK or NG
OK >> GO TO 12.
NG >> GO TO 11.
11 . CHECK PBR FEEDBACK SIGNAL CIRCUIT FOR SHORT TO GROUND
1. Turn ignition switch OFF.
2. Disconnect front air control harness connector.
3. Check continuity between front air control harness connector M49 terminal 18 and ground.
OK or NG
OK >> Replace front air control. Refer to ATC-144, "FRONT
AIR CONTROL" .
NG >> Repair or replace harness as necessary.
12. CHECK PBR FEEDBACK CIRCUIT FOR OPEN
1. Turn ignition switch OFF.
2. Disconnect the air mix door motor (driver) harness connector and front air control harness connector.
3. Check continuity between air mix door motor (driver) harness connector M147 terminal 4 and front air control harness connec-
tor M49 terminal 18.
OK or NG
OK >> Replace air mix door motor (driver). Refer to ATC-163,
"FRONT AIR MIX DOOR MOTOR (PASSENGER)" .
NG >> Repair or replace harness as necessary. Voltage
: Approx. .5V - 4.5V
LJIA0041E
Continuity should not exist.
WJIA1739E
Continuity should exist.
WJIA0590E

ATC-76
TROUBLE DIAGNOSIS
Revision: November 20092006 QX56
DIAGNOSTIC PROCEDURE FOR AIR MIX DOOR MOTOR (PASSENGER)
1. CHECK FRONT AIR CONTROL FOR POWER AND GROUND
1. Turn ignition switch ON.
2. Rotate temperature control dial (passenger) to 32 °C (90 °F).
3. Check voltage between front air control harness connector M50 terminal 36 and terminal 37 while rotating temperature control
dial (passenger) to 16 °C (60 °F).
OK or NG
OK >> GO TO 3.
NG >> GO TO 2.
2. CHECK AIR MIX DOOR MOTOR (PASSENGER) CIRCUITS FOR SHORT TO GROUND
1. Turn ignition switch OFF.
2. Disconnect the front air control harness connector.
3. Check continuity between front air control harness connector M50 terminal 36, 37 and ground.
OK or NG
OK >> Replace front air control. Refer to ATC-144, "FRONT
AIR CONTROL" .
NG >> Repair or replace harness as necessary.
3. CHECK FRONT AIR CONTROL FOR POWER AND GROUND
1. Turn ignition switch ON.
2. Rotate temperature control dial (passenger) to 16 °C (60 °F).
3. Check voltage between front air control harness connector M50 terminal 36 and terminal 37 while rotating temperature control
dial (passenger) to 32 °C (90 °F).
OK or NG
OK >> GO TO 4.
NG >> Replace front air control. Refer to ATC-144, "
FRONT AIR CONTROL" .
Connector Terminals
Condition Voltage
(Approx.)
(+) (-)
Front air control: M50 37 36 Rotate temp
control dial Battery
voltage
WJIA1740E
36 - Ground : Continuity should not exist.
37 - Ground : Continuity should not exist.
WJIA1741E
Connector Terminals
Condition Voltage
(Approx.)
(+) (-)
Front air control: M50 36 37 Rotate temp
control dial Battery
voltage
WJIA1778E

TROUBLE DIAGNOSISATC-77
C
DE
F
G H
I
K L
M A
B
AT C
Revision: November 2009 2006 QX56
4. CHECK AIR MIX DOOR MOTOR (PASSENGER) CIRCUITS FOR OPEN
1. Turn ignition switch OFF.
2. Disconnect the front air control harness connector.
3. Check continuity between front air control harness connector M50 terminal 36 and terminal 37.
OK or NG
OK >> GO TO 6.
NG >> GO TO 5.
5. CHECK AIR MIX DOOR MOTOR (PASSENGER) CIRCUITS FOR OPEN
1. Disconnect the air mix door motor (passenger) harness connec- tor.
2. Check continuity between front air control harness connector M50 terminal 36, 37 and the air mix door motor (passenger) har-
ness connector M143 terminal 1, 6.
OK or NG
OK >> Replace air mix door motor (passenger). Refer to AT C -
162, "FRONT AIR MIX DOOR MOTOR (DRIVER)" .
NG >> Repair or replace harness as necessary.
6. CHECK FRONT AIR CONTROL FOR PBR POWER AND GROUND
1. Reconnect front air control harness connector.
2. Turn ignition switch ON.
3. Check voltage between front air control harness connector M49 terminal 2 and terminal 15.
OK or NG
OK >> GO TO 8.
NG >> GO TO 7.
7. CHECK PBR REFERENCE VOLTAGE CIRCUIT FOR SHORT TO GROUND
1. Turn ignition switch OFF.
2. Disconnect the front air control harness connector.
3. Check continuity between front air control harness connector M49 terminal 2 and ground.
OK or NG
OK >> Replace front air control. Refer to ATC-144, "FRONT
AIR CONTROL" .
NG >> Repair or replace harness as necessary. Continuity should exist.
WJIA1779E
36 - 1
: Continuity should exist.
37 - 6 : Continuity should exist.
WJIA0548E
Connector Te r m i n a l s
Voltage
(Approx.)
(+) (-)
Front air control: M49 2 15 5V
WJIA1729E
Continuity should not exist.
WJIA1730E

ATC-78
TROUBLE DIAGNOSIS
Revision: November 20092006 QX56
8. CHECK PBR REFERENCE VOLTAGE AND GROUND CIRCUITS
1. Turn ignition switch OFF.
2. Disconnect the front air control harness connector.
3. Check continuity between front air control harness connector M49 terminal 2 and terminal 15.
OK or NG
OK >> GO TO 10.
NG >> GO TO 9.
9. CHECK PBR REFERENCE VOLTAGE CIRCUIT FOR OPEN
1. Disconnect the air mix door motor (passenger) harness connec- tor.
2. Check continuity between air mix door motor (passenger) har- ness connector M143 (B) terminal 3, 2 and front air control har-
ness connector M49 (A) terminal 2, 15.
OK or NG
OK >> Replace air mix door motor (passenger). Refer to AT C -
162, "FRONT AIR MIX DOOR MOTOR (DRIVER)" .
NG >> Repair or replace harness as necessary.
10. CHECK PBR FEEDBACK VOLTAGE
1. Reconnect the front air control harness connector.
2. Turn ignition switch ON.
3. Check voltage between front air control harness connector M50 terminal 41 and ground while rotating temperature control dial
(passenger) from 32 ° C (90 ° F) to 16 ° C (60 ° F). .
OK or NG
OK >> GO TO 12.
NG >> GO TO 11.
11 . CHECK PBR FEEDBACK SIGNAL CIRCUIT FOR SHORT TO GROUND
1. Turn ignition switch OFF.
2. Disconnect front air control harness connector.
3. Check continuity between front air control harness connector M50 terminal 41 and ground.
OK or NG
OK >> Replace front air control. Refer to ATC-144, "FRONT
AIR CONTROL" .
NG >> Repair or replace harness as necessary. Continuity should exist.
WJIA1731E
2 - 3
: Continuity should exist.
15 - 2 : Continuity should exist.
WJIA1732E
Voltage : Approx. .5V - 4.5V
LJIA0047E
Continuity should not exist.
WJIA1743E

TROUBLE DIAGNOSISATC-79
C
DE
F
G H
I
K L
M A
B
AT C
Revision: November 2009 2006 QX56
12. CHECK PBR FEEDBACK CIRCUIT FOR OPEN
1. Turn ignition switch OFF.
2. Disconnect the air mix door motor (passenger) harness connec- tor and front air control harness connector.
3. Check continuity between air mix door motor (passenger) har- ness connector M143 terminal 4 and front air control harness
connector M50 terminal 41.
OK or NG
OK >> Replace air mix door motor (passenger). Refer to AT C -
162, "FRONT AIR MIX DOOR MOTOR (DRIVER)" .
NG >> Repair or replace harness as necessary.
DIAGNOSTIC PROCEDURE FOR AIR MIX DOOR MOTOR (REAR)
1. CHECK FRONT AIR CONTROL FOR POWER AND GROUND
1. Turn ignition switch ON.
2. Rotate temperature control dial (rear) to maximum heat.
3. Check voltage between front air control harness connector M50 terminal 27 and terminal 28 while rotating temperature control
dial (rear) to maximum cold.
OK or NG
OK >> GO TO 3.
NG >> GO TO 2.
2. CHECK AIR MIX DOOR MOTOR (REAR) CIRCUITS FOR SHORT TO GROUND
1. Turn ignition switch OFF.
2. Disconnect the front air control harness connector.
3. Check continuity between front air control harness connector M50 terminal 27, 28 and ground.
OK or NG
OK >> Replace front air control. Refer to ATC-144, "FRONT
AIR CONTROL" .
NG >> Repair or replace harness as necessary. Continuity should exist.
WJIA0550E
Connector
Terminals
Condition Voltage
(Approx.)
(+) (-)
Front air control: M50 27 28
Rotate temp
control dial Battery
voltage
WJIA1744E
27 - Ground : Continuity should not exist.
28 - Ground : Continuity should not exist.
WJIA1745E

ATC-80
TROUBLE DIAGNOSIS
Revision: November 20092006 QX56
3. CHECK FRONT AIR CONTROL FOR POWER AND GROUND
1. Turn ignition switch ON.
2. Rotate temperature control dial (rear) to maximum cold.
3. Check voltage between front air control harness connector M50 terminal 27 and terminal 28 while rotating temperature control
dial (rear) to maximum heat.
OK or NG
OK >> GO TO 4.
NG >> Replace front air control. Refer to ATC-144, "
FRONT AIR CONTROL" .
4. CHECK AIR MIX DOOR MOTOR (REAR) CIRCUITS FOR OPEN
1. Turn ignition switch OFF.
2. Disconnect the front air control harness connector.
3. Check continuity between front air control harness connector M50 terminal 27 and terminal 28.
OK or NG
OK >> GO TO 6.
NG >> GO TO 5.
5. CHECK AIR MIX DOOR MOTOR (REAR) CIRCUITS FOR OPEN
1. Disconnect the air mix door motor (rear) harness connector.
2. Check continuity between front air control harness connector M50 terminal 27, 28 and the air mix door motor (rear) harness
connector B155 terminal 1, 6.
OK or NG
OK >> Replace air mix door motor (rear). Refer to ATC-163,
"REAR AIR MIX DOOR MOTOR" .
NG >> Repair or replace harness as necessary.
Connector Terminals
Condition Voltage
(Approx.)
(+) (-)
Front air control: M50 28 27
Rotate temp
control dial Battery
voltage
WJIA1746E
Continuity should exist.
WJIA1747E
27 - 1 : Continuity should exist.
28 - 6 : Continuity should exist.
LJIA0049E
