INT-12
< ON-VEHICLE REPAIR >
DOOR FINISHER
• Disconnect the harness connector.
7. Remove the door finisher and disconnect the lock cable and handle cable from the inside door handle assembly. Refer to INT-11, "
Removal and Installation".
8. Remove the inside door handle assembly.
9. Remove door lock knob.
Installation
Installation is in the reverse order of removal.
REAR DOOR
Removal
1. Disconnect the battery negative terminal.
2. Remove the power window switch assembly. • Disconnect the harness connector.
3. Remove the pull handle cover. • Remove the screws behind the pull handle cover.
4. Remove the cap from the inside door handle escutcheon and the remove screw.
5. Remove the inside door handle escutcheon.
1. Rear door tweeter 2. Power window switch assembly 3. Rear door finisher LH
4. Pull handle cover 5. Cap6. Inside door handle escutcheon
7. Door lock knob 8. Step lamp9. Inside door handle assembly
AWJIA0005ZZ
Revision: March 2010 2008 QX56

DOOR FINISHERINT-13
< ON-VEHICLE REPAIR >
C
DE
F
G H
I
K L
M A
B
INT
N
O P
• Remove the screw behind inside door handle escutcheon.
6. Remove step lamp. • Disconnect the step lamp harness connector.
7. Remove the door finisher and disconnect lock c able and handle cable from inside door handle assembly.
Refer to INT-11, "
Removal and Installation".
8. Remove the inside door handle assembly.
9. Remove door lock knob.
10. Remove the rear door tweeter.
Installation
Installation is in the reverse order of removal.
Revision: March 2010 2008 QX56

INT-14
< ON-VEHICLE REPAIR >
BODY SIDE TRIM
BODY SIDE TRIM
Removal and InstallationINFOID:0000000001609872
CAUTION:
• Wrap the tip of flat-bladed screwdriver with a cloth when removing metal clips from finishers.
• When removing or installing body side welts, do not allow butyl seal to come in contact with pillar
finisher.
LOWER DASH SIDE FINISHER
Removal
1. Remove the push pin from the lower dash side finisher.
2. Remove the front kicking plate from the center pillar lower finisher. Refer to INT-16, "
Removal and Instal-
lation".
3. Remove the lower dash side finisher and the front kicking plate together.
4. Remove the lower dash side finisher from the front kicking plate.
Installation
Installation is in the reverse order of removal.
CENTER PILLAR LOWER FINISHER
1. Center pillar upper finisher LH 2. Center pillar assist grip 3. Rear door welt
4. Rear door bumper 5. Rear door parting seal 6. Clip CG104
7. Rear mudguard finisher 8. Rear kicking plate 9. Center pillar lower finisher LH
10. Metal clip 11. Front mudguard finisher 12. Metal clip
13. Clip CG103 14. Front kicking plate 15. Front door parting seal
16. Front door welt 17. Metal clip 18. Front door bumper
19. Lower dash side finisher LH 20. Front pillar finisher LH 21. Metal clip
22. Front pillar assist grip ⇐Vehicle front
WIIA0967E
Revision: March 2010 2008 QX56

BODY SIDE TRIMINT-15
< ON-VEHICLE REPAIR >
C
DE
F
G H
I
K L
M A
B
INT
N
O P
Removal
1. Remove the front and rear door welts.
2. Remove the seat belt anchor. Refer to
SB-14, "
Removal and Installation".
• On RH side, disconnect the seat belt tension sensor.
3. Remove the front and rear kicking plates. Refer to INT-14, "
Removal and Installation".
4. Remove the center pillar lower finisher.
Installation
Installation is in the reverse order of removal.
CENTER PILLAR UPPER FINISHER
Removal
1. Remove the center pillar lower finisher. Refer to INT-19, "Removal and Installation".
2. Remove the assist grip.
3. Remove the center pillar upper finisher.
Installation
Installation is in the reverse order of removal.
FRONT PILLAR FINISHER
Removal
1. Remove the assist grip.
2. Remove the front pillar finisher.
Installation
Installation is in the reverse order of removal.
KICKING PLATES
Removal
Release the clips and remove the front and/or rear kicking plates.
Installation
Installation is in the reverse order of removal.
MUDGUARD FINISHERS
Removal
Release the clips and remove the front and/or rear mudguard finishers.
Installation
Installation is in the reverse order of removal.
DOOR PARTING SEALS
Removal
1. Open front and/or rear doors fully.
2. Release clips and remove parting seals.
Installation
Installation is in the reverse order of removal.
Revision: March 2010 2008 QX56

INT-16
< ON-VEHICLE REPAIR >
FLOOR TRIM
FLOOR TRIM
Removal and InstallationINFOID:0000000001609873
REMOVAL
1. Remove the front seats. Refer to SE-49, "Removal and Installation".
• Remove the subwoofer. Refer to AV-172, "
Removal and Installation".
• Remove the navigation display control unit. Refer to AV-166, "
Removal and Installation".
2. Remove the second row seats. Refer to SE-54, "
Removal and Installation" and SE-50, "Exploded View", if
equipped.
3. Remove the third row rear seats. Refer to SE-79, "
Exploded View".
4. Remove the lower seat belt anchors. Refer to SB-14, "
Removal and Installation".
5. Remove the lower body side trim. Refer to INT-14
.
6. Remove the luggage lower side finishers (left / right). Refer to INT-19
.
7. Remove the kicking plates. Refer to INT-14
.
8. Remove the center console. Refer to IP-20, "
Removal and Installation".
9. Remove the rear console, if equipped. Refer to IP-21, "
Removal and Installation".
10. Remove the rear lower finisher. Refer to INT-19
.
11. Remove the carpet.
12. Remove the floor mat hooks from the front carpet.
INSTALLATION
Installation is in the reverse order of removal.
1. Carpet 2. Floor mat hooks
AWJIA0408ZZ
Revision: March 2010 2008 QX56

HEADLININGINT-17
< ON-VEHICLE REPAIR >
C
DE
F
G H
I
K L
M A
B
INT
N
O P
HEADLINING
Removal and InstallationINFOID:0000000001609874
1. Headlining 2. Assist grip bracket3. Assist grip
4. Sunvisor assembly LH 5. Cap LH 6. Sunvisor holder
7. Front roof console 8. Sunglass bin9. Sunroof welt
AWJIA0341GB
Revision: March 2010 2008 QX56

INT-18
< ON-VEHICLE REPAIR >
HEADLINING
CAUTION:
Disconnect both terminals from battery in advance.
REMOVAL
1. Remove the body side trim. Refer to INT-14.
2. Remove the luggage floor trim. Refer to INT-19
.
3. Remove the sunvisor assemblies.
4. Remove the sunvisor clips.
5. Remove the sunroof welt.
6. Remove the front roof console. • Disconnect the harnesses.
7. Remove the rear roof console. • Disconnect the harnesses.
8. Remove the assist grips.
9. Remove the lamp assembly and the rear roof finisher. • Disconnect the harness.
10. Remove the headlining. • Remove the clips from the rear of headlining.
• Disconnect the harnesses.
11. Remove the rear air control. • Disconnect the harness.
12. Remove the rear audio control assembly. • Disconnect the harness.
13. Remove the lamp assemblies. • Disconnect the harnesses.
14. Remove the air vents.
15. Remove the front roof console bracket.
16. Remove the rear roof console front bracket.
17. Remove the assist grip brackets from roof.
INSTALLATION
Installation is in the reverse order of removal.
10. Cap RH 11. Sunvisor assembly RH12. Rear roof console bracket
13. Rear storage bin or DVD display 14. Rear air control 15. Rear audio control assembly
16. Rear roof console 17. Rear roof console finisher18. Rear storage bin
19. Air vent 20. Lamp assembly21. Plastic clip
22. Rear lamp lens 23. Rear lamp24. Rear roof finisher
25. Plastic clip 26. Metal clip Vehicle front
Revision: March 2010 2008 QX56

LUGGAGE FLOOR TRIMINT-19
< ON-VEHICLE REPAIR >
C
DE
F
G H
I
K L
M A
B
INT
N
O P
LUGGAGE FLOOR TRIM
Removal and InstallationINFOID:0000000001609875
1. Rear lower finisher cap 2. Rear lower finisher3. Cap upper seat belt finisher RH
4. Luggage side finisher RH 5. Metal clip6. Plastic clip
7. Third row seat switches 8. Luggage side finisher lower RH 9. Luggage floor board
AWJIA0216ZZ
Revision: March 2010 2008 QX56

INT-20
< ON-VEHICLE REPAIR >
LUGGAGE FLOOR TRIM
REMOVAL
1. Remove the 2nd and 3rd row seat belts. Refer to SB-7, "Removal and Installation of Second Row Seat
Belt" and SB-9, "Removal and Installation of Third Row Seat Belt".
2. Remove the third row seat belt buckles.
3. Remove the third row seat assembly. Refer to SE-83, "
Exploded View".
4. Remove the back door weatherstrip. Refer to INT-21
.
5. Remove the rear luggage room lamp. Refer to INT-17
.
• Disconnect the harness from lamp.
6. Remove the rear upper finisher. Refer to INT-17
.
7. Remove the rear door kicking plates. Refer to INT-14
.
8. Remove the rear lower finisher.
9. Disconnect the door open/close link. Refer to INT-21, "
Removal and Installation".
10. Remove the cargo net hooks.
11. Remove the luggage side lower finishers LH/RH. • Disconnect the power point and the third row seat harness connectors RH side (if equipped).
12. Remove the coat hooks.
13. Remove the luggage side upper finishers LH/RH. • Disconnect the harness to door open/close switch, LH side.
14. Remove the tie down hooks LH/RH.
15. Remove the floor side finishers LH/RH.
16. Remove the luggage floor board.
17. Remove the storage box.
18. Remove the front luggage floor bracket.
19. Remove the rear luggage box bracket.
INSTALLATION
Installation is in the reverse order of removal.
10. Latch luggage floor board 11. Leak check cap 12. Cup holder
13. Third row seat switches 14. Tie down hook 15. Floor side finisher RH
16. Power point assembly 17. Cargo net hook 18. Rear luggage box bracket
19. Front luggage floor bracket 20. Storage box 21. Floor side finisher LH
22. Luggage side finisher upper LH 23. Luggage side finisher lower LH 24. Lid luggage side lower
25. Coat hook 26. Cap lower seat belt finisher 27. Back door open/close switch
28. Cap luggage side upper 29. Cap upper seat belt finisher LH
Revision: March 2010 2008 QX56

BACK DOOR TRIMINT-21
< ON-VEHICLE REPAIR >
C
DE
F
G H
I
K L
M A
B
INT
N
O P
BACK DOOR TRIM
Removal and InstallationINFOID:0000000001609876
REMOVAL
1. Disconnect the door open/close link. Refer to INT-21, "Removal and Installation".
2. Open the back door glass.
3. Remove the inside weatherstrip around back door glass.
4. Remove the assist handle.
5. Release the clips and remove back door lower finisher.
6. Release the clips and remove back door upper finisher.
7. Release the clips and remove back door side finishers LH and RH.
Installation
Installation is in the reverse order of removal.
1. Back door upper finisher 2. Back door glass weatherstrip 3. Back door side finisher RH
4. Back door lower finisher 5. Back door bumper6. Back door pull handle
7. Back door mask 8. Back door side finisher LH
AWJIA0022ZZ
