sensor INFINITI QX56 2011 Factory Service Manual

SRC-108
< DTC/CIRCUIT DIAGNOSIS >
B1120 SATELLITE SENSOR LH
B1120 SATELLITE SENSOR LH
DTC LogicINFOID:0000000006220046
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “Self Diagnostic Result” mode of “AIR BAG” using CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS does not enter the diagnosis mode if no malfunction is detected in the user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-108, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006220047
WARNING:
 Before servicing, turn ignition sw itch OFF, disconnect battery negative terminal, and wait at least 3
minutes or more. (To discharge backup capacitor.)
 Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE FRONT SATELLITE SENSOR
1. Replace front satellite sensor LH. Refer to SR-24, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-108, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-26, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-108, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
DTC Display contents of
CONSULT-III DTC detecting condition Possible cause
B1120 SATELLITE SENS LH
[COMM FAIL] Front satellite sensor LH is malfunctioning
or out of the specified specification  Disconnection of wiring harness
 Malfunction in front satellite sensor LH
 Malfunction in air bag diagnosis sensor unit
Revision: 2010 May2011 QX56

B1120 SATELLITE SENSOR LHSRC-109
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
NO >> INSPECTION END
Revision: 2010 May2011 QX56

SRC-110
< DTC/CIRCUIT DIAGNOSIS >
B1121 SATELLITE SENSOR LH
B1121 SATELLITE SENSOR LH
DTC LogicINFOID:0000000006220048
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “Self Diagnostic Result” mode of “AIR BAG” using CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS does not enter the diagnosis mode if no malfunction is detected in the user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-110, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006220049
WARNING:
 Before servicing, turn ignition sw itch OFF, disconnect battery negative terminal, and wait at least 3
minutes or more. (To discharge backup capacitor.)
 Never use unspecified tester or other measuring device.
1.REPLACE FRONT SATELLITE SENSOR
1. Replace front satellite sensor LH. Refer to SR-24, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-110, "
DTC Logic".
Is DTC detected?
YES >> GO TO 2.
NO >> INSPECTION END
2.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-26, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-110, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
NO >> INSPECTION END
DTC Display contents of
CONSULT-III DTC detecting condition Possible cause
B1121 SATELLITE SENS LH
[UNMATCH] Front satellite sensor LH is out of the spec-
ified specification Diagnosis front sensor unit or satellite sensor RH
is different from the part specified
Revision: 2010 May2011 QX56

B1122, B1123, B1124, B1125, B1126, B1127 DIAGNOSIS SENSOR UNIT
SRC-111
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G
I
J
K L
M A
B
SRC
N
O P
B1122, B1123, B1124, B1125, B1126, B1127 DIAGNOSIS SENSOR UNIT
DTC LogicINFOID:0000000006220050
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “Self Diagnostic Result” mode of “AIR BAG” using CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS does not enter the diagnosis mode if no malfunction is detected in the user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-111, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006220051
WARNING:
 Before servicing, turn ignition s witch OFF, disconnect battery negati ve terminal, and wait at least 3
minutes or more. (To discharge backup capacitor.)
 Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connectors.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-26, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-111, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
NO >> INSPECTION END
DTC Display contents of
CONSULT-III DTC detecting condition Possible cause
B1122
B1123
B1124
B1125
B1126
B1127 CONTROL UNIT Air bag diagnosis sensor unit is malfunctioning Malfunction in air bag diagnosis sensor unit
Revision: 2010 May2011 QX56

SRC-112
< DTC/CIRCUIT DIAGNOSIS >
B1129 SIDE AIR BAG MODULE RH
B1129 SIDE AIR BAG MODULE RH
DTC LogicINFOID:0000000006220052
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “Self Diagnostic Result” mode of “AIR BAG” using CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. SRC-14, "
On Board Diagnosis Function"
NOTE:
SRS does not enter the diagnosis mode if no malfunction is detected in the user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-112, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006220053
WARNING:
 Before servicing, turn ignition sw itch OFF, disconnect battery negative terminal, and wait at least 3
minutes or more. (To discharge backup capacitor.)
 Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-26, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-112, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE SIDE AIR BAG MODULE
1. Replace side air bag module RH. Refer to SE-114, "
SEATBACK : Disassembly and Assembly".
2. Perform DTC confirmation procedure. Refer to SRC-112, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
DTC Display contents of
CONSULT-III DTC detecting condition Possible cause
B1129 SIDE MODULE RH
[OPEN] Side air bag module RH circuit is open  Disconnection of wiring harness and open
 Malfunction in side air bag module RH
 Malfunction in air bag diagnosis sensor unit
Revision: 2010 May2011 QX56

SRC-114
< DTC/CIRCUIT DIAGNOSIS >
B1130 SIDE AIR BAG MODULE RH
B1130 SIDE AIR BAG MODULE RH
DTC LogicINFOID:0000000006220054
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “Self Diagnostic Result” mode of “AIR BAG” using CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS does not enter the diagnosis mode if no malfunction is detected in the user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-114, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006220055
WARNING:
 Before servicing, turn ignition sw itch OFF, disconnect battery negative terminal, and wait at least 3
minutes or more. (To discharge backup capacitor.)
 Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-26, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-114, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE SIDE AIR BAG MODULE
1. Replace side air bag module RH. Refer to SE-114, "
SEATBACK : Disassembly and Assembly".
2. Perform DTC confirmation procedure. Refer to SRC-114, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
DTC Display contents of
CONSULT-III DTC detecting condition Possible cause
B1130 SIDE MODULE RH
[VB-SHORT] Side air bag module RH circuit is shorted
to power supply circuit  Disconnection of wiring harness and short
 Malfunction in side air bag module RH
 Malfunction in air bag diagnosis sensor unit
Revision: 2010 May2011 QX56

SRC-116
< DTC/CIRCUIT DIAGNOSIS >
B1131 SIDE AIR BAG MODULE RH
B1131 SIDE AIR BAG MODULE RH
DTC LogicINFOID:0000000006220056
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “Self Diagnostic Result” mode of “AIR BAG” using CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS does not enter the diagnosis mode if no malfunction is detected in the user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-116, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006220057
WARNING:
 Before servicing, turn ignition sw itch OFF, disconnect battery negative terminal, and wait at least 3
minutes or more. (To discharge backup capacitor.)
 Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-26, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-116, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE SIDE AIR BAG MODULE
1. Replace side air bag module RH. Refer to SE-114, "
SEATBACK : Disassembly and Assembly".
2. Perform DTC confirmation procedure. Refer to SRC-116, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
DTC Display contents of
CONSULT-III DTC detecting condition Possible cause
B1131 SIDE MODULE RH
[GND-SHORT] Side air bag module RH circuit is shorted
to ground  Disconnection of wiring harness and short
 Malfunction in side air bag module RH
 Malfunction in air bag diagnosis sensor unit
Revision: 2010 May2011 QX56

SRC-118
< DTC/CIRCUIT DIAGNOSIS >
B1132 SIDE AIR BAG MODULE RH
B1132 SIDE AIR BAG MODULE RH
DTC LogicINFOID:0000000006220058
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “Self Diagnostic Result” mode of “AIR BAG” using CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS does not enter the diagnosis mode if no malfunction is detected in the user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-118, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006220059
WARNING:
 Before servicing, turn ignition sw itch OFF, disconnect battery negative terminal, and wait at least 3
minutes or more. (To discharge backup capacitor.)
 Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-26, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-118, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE SIDE AIR BAG MODULE
1. Replace side air bag module RH. Refer to SE-114, "
SEATBACK : Disassembly and Assembly".
2. Perform DTC confirmation procedure. Refer to SRC-118, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
DTC Display contents of
CONSULT-III DTC detecting condition Possible cause
B1132 SIDE MODULE RH
[SHORT] Side air bag module RH circuits are short-
ed to each other  Disconnection of wiring harness and short
 Malfunction in side air bag module RH
 Malfunction in air bag diagnosis sensor unit
Revision: 2010 May2011 QX56

SRC-120
< DTC/CIRCUIT DIAGNOSIS >
B1134 SIDE AIR BAG MODULE LH
B1134 SIDE AIR BAG MODULE LH
DTC LogicINFOID:0000000006220060
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “Self Diagnostic Result” mode of “AIR BAG” using CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS does not enter the diagnosis mode if no malfunction is detected in the user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-120, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006220061
WARNING:
 Before servicing, turn ignition sw itch OFF, disconnect battery negative terminal, and wait at least 3
minutes or more. (To discharge backup capacitor.)
 Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-26, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-120, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE SIDE AIR BAG MODULE
1. Replace side air bag module LH. Refer to SE-114, "
SEATBACK : Disassembly and Assembly".
2. Perform DTC confirmation procedure. Refer to SRC-120, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
DTC Display contents of CON-
SULT-III DTC detecting condition Possible cause
B1134 SIDE MODULE LH
[OPEN] Side air bag module LH circuit is open  Disconnection of wiring harness and open
 Malfunction in side air bag module LH
 Malfunction in air bag diagnosis sensor unit
Revision: 2010 May2011 QX56

SRC-122
< DTC/CIRCUIT DIAGNOSIS >
B1135 SIDE AIR BAG MODULE LH
B1135 SIDE AIR BAG MODULE LH
DTC LogicINFOID:0000000006220062
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “Self Diagnostic Result” mode of “AIR BAG” using CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS does not enter the diagnosis mode if no malfunction is detected in the user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-122, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006220063
WARNING:
 Before servicing, turn ignition sw itch OFF, disconnect battery negative terminal, and wait at least 3
minutes or more. (To discharge backup capacitor.)
 Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-26, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-122, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE SIDE AIR BAG MODULE
1. Replace side air bag module LH. Refer to SE-114, "
SEATBACK : Disassembly and Assembly".
2. Perform DTC confirmation procedure. Refer to SRC-122, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
DTC Display contents of
CONSULT-III DTC detecting condition Possible cause
B1135 SIDE MODULE LH
[VB-SHORT] Side air bag module LH circuit is shorted to
power supply circuit  Disconnection of wiring harness and short
 Malfunction in side air bag module LH
 Malfunction in air bag diagnosis sensor unit
Revision: 2010 May2011 QX56
