EXTERIOR LAMP FUSEEXL-85
< DTC/CIRCUIT DIAGNOSIS > [XENON TYPE]
C
D
E
F
G H
I
J
K
M A
B
EXL
N
O P
EXTERIOR LAMP FUSE
Diagnosis ProcedureINFOID:0000000006213954
1.CHECK FUSE
Check that the following fuses are not fusing.
Is the inspection result normal?
YES >> The fuse is normal.
NO >> Repair the applicable circuit. And then replace the fuse.
Unit Location Fuse No. Capacity
Headlamp HI (LH) IPDM E/R #52 10 A
Headlamp HI (RH) IPDM E/R #51 10 A
Headlamp LO (LH) IPDM E/R #53 15 A
Headlamp LO (RH) IPDM E/R #54 15 A
Front fog lamp IPDM E/R #50 15 A
Parking lamp (LH)
 Front side marker lamp (LH) IPDM E/R #46 10 A
 Parking lamp (RH)
 Front side marker lamp (RH) IPDM E/R #47 10 A
 Tail lamp (Back door side LH/RH)
 Tail lamp (Body side LH)
 License plate lamp
 Rear side mark er lamp (LH) IPDM E/R #46 10 A
 Tail lamp (Body side RH)
 Rear side mark er lamp (RH) IPDM E/R #47 10 A
Stop lamp FUSE BLOCK (J/B) #7 10 A
Back-up lamp IPDM E/R #55 10 A
Revision: 2010 May2011 QX56

EXL-86
< DTC/CIRCUIT DIAGNOSIS >[XENON TYPE]
HEADLAMP (HI) CIRCUIT
HEADLAMP (HI) CIRCUIT
Component Function CheckINFOID:0000000006213955
1.CHECK HEADLAMP (HI) OPERATION
CONSULT-III ACTIVE TEST
1. Select “EXTERNAL LAMPS” of IPDM E/R active test item.
2. With operating the test items, che ck that the headlamp (HI) is turned ON.
NOTE:
ON/OFF is repeated 1 second each.
Is the inspection result normal?
YES >> Headlamp (HI) circuit is normal.
NO >> Refer to EXL-86, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000006213956
1.CHECK HEADLAMP (HI) OUTPUT VOLTAGE
CONSULT-III ACTIVE TEST
1. Turn ignition switch OFF.
2. Disconnect front combination lamp connector.
3. Turn ignition switch ON.
4. Select “EXTERNAL LAMPS” of IPDM E/R active test item.
5. With operating the test items, check vo ltage between IPDM E/R harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> GO TO 3.
2.CHECK HEADLAMP (HI) OPEN CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R connector.
3. Check continuity between IPDM E/R harness connec tor and front combination lamp harness connector.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace harness.
3.CHECK HEADLAMP (HI) FUSE
1. Turn ignition switch OFF. Hi : Headlamp (HI) ON
Off : Headlamp (HI) OFF
(+)
(− ) Test item Vo l ta g e
(Approx.)
IPDM E/R
Connector Terminal
RH E1549
GroundEXTERNAL
LAMPS Hi Battery voltage
Off 0 V
LH 50 Hi Battery voltage
Off 0 V
IPDM E/R Front combination lamp Continuity
Connector Terminal Connector Terminal
RH E1549 E119
6 Existed
LH 50 E118
Revision: 2010 May2011 QX56

HEADLAMP (HI) CIRCUITEXL-87
< DTC/CIRCUIT DIAGNOSIS > [XENON TYPE]
C
D
E
F
G H
I
J
K
M A
B
EXL
N
O P
2. Check that the following fuses are not fusing.
Is the inspection result normal?
YES >> Replace IPDM E/R.
NO >> GO TO 4.
4.CHECK HEADLAMP HIGH (HI) SHORT CIRCUIT
1. Disconnect IPDM E/R connector.
2. Check continuity between IPDM E/R harness connector and ground.
Is the inspection result normal?
YES >> Replace fuse. (Replace IPDM E/R if the fuse is fusing again.)
NO >> Repair or replace harness. And then replace the fuse.
5.CHECK HEADLAMP (HI) GROUND OPEN CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect front combination lamp connector.
3. Check continuity between front combination lamp harness connector and ground.
Is the inspection result normal?
YES >> Replace front combination lamp.
NO >> Repair or replace harness.
Unit Location Fuse No. Capacity
Headlamp HI (RH) IPDM E/R #51
10 A
Headlamp HI (LH) #52
IPDM E/R
GroundContinuity
Connector Terminal
RH E1549
Not existed
LH 50
Front combination lamp
GroundContinuity
Connector Terminal
RH E119 2Existed
LH E118
Revision: 2010 May2011 QX56

EXL-88
< DTC/CIRCUIT DIAGNOSIS >[XENON TYPE]
HEADLAMP (LO) CIRCUIT
HEADLAMP (LO) CIRCUIT
Component Function CheckINFOID:0000000006213957
1.CHECK HEADLAMP (LO) OPERATION
CONSULT-III ACTIVE TEST
1. Select “EXTERNAL LAMPS” of IPDM E/R active test item.
2. With operating the test items, che ck that the headlamp (LO) is turned ON.
Is the inspection result normal?
YES >> Headlamp (LO) is normal.
NO >> Refer to EXL-88, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000006213958
1.CHECK HEADLAMP (LO) OUTPUT VOLTAGE
CONSULT-III ACTIVE TEST
1. Turn ignition switch OFF.
2. Disconnect front combination lamp connector.
3. Turn ignition switch ON.
4. Select “EXTERNAL LAMPS” of IPDM E/R active test item.
5. With operating the test items, check vo ltage between IPDM E/R harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> GO TO 3.
2.CHECK HEADLAMP (LO) OPEN CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R connector.
3. Check continuity between IPDM E/R harness connec tor and front combination lamp harness connector.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace harness.
3.CHECK HEADLAMP (LO) FUSE
1. Turn ignition switch OFF.
2. Check that the following fuses are not fusing. Lo : Headlamp (LO) ON
Off : Headlamp (LO) OFF
(+)
(− ) Test item Vo l ta g e
(Approx.)
IPDM E/R
Connector Terminal
RH E1552
GroundEXTERNAL
LAMPS Lo Battery voltage
Off 0 V
LH 51 Lo Battery voltage
Off 0 V
IPDM E/R Front combination lamp Continuity
Connector Terminal Connector Terminal
RH E1552 E119
5 Existed
LH 51 E118
Revision: 2010 May2011 QX56

HEADLAMP (LO) CIRCUITEXL-89
< DTC/CIRCUIT DIAGNOSIS > [XENON TYPE]
C
D
E
F
G H
I
J
K
M A
B
EXL
N
O P
Is the inspection result normal?
YES >> Replace IPDM E/R.
NO >> GO TO 4.
4.CHECK HEADLAMP (LO) SHORT CIRCUIT
1. Disconnect IPDM E/R connector.
2. Check continuity between IPDM E/R harness connector and ground.
Is the inspection result normal?
YES >> Replace fuse. (Replace IPDM E/R if the fuse is fusing again.)
NO >> Repair or replace harness. And then replace the fuse.
5.CHECK HEADLAMP (LO) GROUND OPEN CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect front combination lamp connector.
3. Check continuity between front combination lamp harness connector and ground.
Is the inspection result normal?
YES >> Perform the xenon headl amp diagnosis. Refer to EXL-90, "Diagnosis Procedure".
NO >> Repair or replace harness.
Unit Lotion Fuse No. Capacity
Headlamp LO (RH) IPDM E/R #54
15 A
Headlamp LO (LH) #53
IPDM E/R
GroundContinuity
Connector Terminal
RH E1552
Not existed
LH 51
Front combination lamp
GroundContinuity
Connector Terminal
RH E119 1Existed
LH E118
Revision: 2010 May2011 QX56

EXL-90
< DTC/CIRCUIT DIAGNOSIS >[XENON TYPE]
XENON HEADLAMP
XENON HEADLAMP
Diagnosis ProcedureINFOID:0000000006213959
1.CHECK XENON BULB
Install the normal bulb to the applicable headlamp. Turn the lighting switch ON.
Is the headlamp turned ON?
YES >> Replace xenon bulb.
NO >> GO TO 2.
2.CHECK HID CONTROL UNIT
Install the normal HID control unit to the applicable headlamp. Turn the lighting switch ON
Is the headlamp turned ON?
YES >> Replace HID control unit.
NO >> Xenon headlamp is normal. Check headlamp control system.
Revision: 2010 May2011 QX56

HEADLAMP LEVELIZER CIRCUITEXL-91
< DTC/CIRCUIT DIAGNOSIS > [XENON TYPE]
C
D
E
F
G H
I
J
K
M A
B
EXL
N
O P
HEADLAMP LEVELIZER CIRCUIT
Component Function CheckINFOID:0000000006213960
1.CHECK AIMING MOTOR OPERATION
CONSULT-III ACTIVE TEST
1. Start the engine.
2. Turn the lighting switch 2ND.
3. Select “LEVELIZER TEST” of ADAP TIVE LIGHT active test item.
4. With operating the test item, check the operation.
Is the operation normal?
YES >> Headlamp levelizer circuit is normal.
NO >> Refer to EXL-91, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000006213961
1.CHECK AIMING MOTOR DRIVE SIGNAL OUTPUT
CONSULT-III ACTIVE TEST
1. Start the engine.
2. Turn light switch 2ND.
3. Select “LEVELIZER TEST” of ADAP TIVE LIGHT active test item.
4. With operating the test item, check voltage between AFS control unit harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> GO TO 3.
2.CHECK AIMING MOTOR DRIVE SIGNAL OPEN CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect AFS control unit connector and headlamp aiming motor connector.
3. Check continuity between AFS control unit har ness connector and head lamp aiming motor harness con-
nector.
Is the inspection result normal?
YES >> Replace front combination lamp.
NO >> Repair or replace harness.
Te s t i t e m Optical axis
LEVELIZER TEST
Origin Standard positonPeak Lowest position
(+) (− ) Test item Voltag e
(Approx.)
AFS control unit
Connector Terminal
RH M13519
Ground LEVELIZER TEST Origin 7.5 V
Peak 7.3 V
LH 40 Origin 7.5 V
Peak 7.3 V
AFS control unit Headlamp aiming motor
Continuity
Connector Terminal Connector Terminal
RH M13519 E121
1 Existed
LH 40 E120
Revision: 2010 May2011 QX56

EXL-92
< DTC/CIRCUIT DIAGNOSIS >[XENON TYPE]
HEADLAMP LEVELIZER CIRCUIT
3.CHECK AIMING MOTOR DRIVE
SIGNAL SHORT CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect AFS control unit connector and headlamp aiming motor connector.
3. Check continuity between AFS control unit harness connector and ground.
Is the inspection result normal?
YES >> Replace AFS control unit. Refer to EXL-135, "Removal and Installation"
NO >> Repair or replace harness.
AFS control unit
GroundContinuity
Connector Terminal
RH M13519
Not existed
LH 40
Revision: 2010 May2011 QX56

HEADLAMP AIMING SYSTEM (MANUAL)EXL-93
< DTC/CIRCUIT DIAGNOSIS > [XENON TYPE]
C
D
E
F
G H
I
J
K
M A
B
EXL
N
O P
HEADLAMP AIMING SYSTEM (MANUAL)
Component InspectionINFOID:0000000006216752
1.CHECK HEADLAMP AIMING SWITCH
1. Remove headlamp aiming switch.
2. Check resistance among each headlamp aiming switch terminal.
Is the inspection result normal?
YES >> Headlamp aiming switch is normal.
NO >> Replace the headlamp aiming switch.
Headlamp aiming switch Condition Resistance
(Approx.)
Terminal Switch position
1 20 A: 910
Ω
1 B: 680 Ω
2 C: 510 Ω
3 D: 390 Ω
3 — E: 390 Ω
JSLIA0084ZZ
Revision: 2010 May2011 QX56

EXL-102
< DTC/CIRCUIT DIAGNOSIS >[XENON TYPE]
OPTICAL SENSOR
OPTICAL SENSOR
Component Function CheckINFOID:0000000006213969
1.CHECK OPTICAL SENSOR SI
GNAL BY CONSULT-III
CONSULT-III DATA MONITOR
1. Turn ignition switch ON.
2. Select “OPTISEN (DTCT)” of BCM (HEADLAMP) data monitor item.
3. Turn lighting switch AUTO.
4. With the optical sensor illuminating, check the monitor status.
*: Illuminates the optical sensor. The value may be less than the standard value if brightness is weak.
Is the inspection result normal?
YES >> Optical sensor is normal.
NO >> Refer to EXL-102, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000006213970
1.CHECK OPTICAL SENSOR POWER SUPPLY INPUT
1. Turn ignition switch ON.
2. Turn lighting switch AUTO.
3. Check voltage between optical sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> GO TO 4.
2.CHECK OPTICAL SENSOR GROUND INPUT
Check voltage between optical sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 6.
3.CHECK OPTICAL SENSOR SIGNAL OUTPUT
With illuminating the optical sensor, check vo ltage between optical sensor harness connector and ground.
Monitor item Condition Voltage (Approx.)
OPTISEN (DTCT) Optical sensor When illuminating 3.1 V or more *
When shutting off light 0.6 V or less
(+)
(− ) Vo l ta g e
(Approx.)
Optical sensor
Connector Terminal M17 1 Ground 5 V
(+) (− ) Vo l ta g e
(Approx.)
Optical sensor
Connector Terminal M17 3 Ground 0 V
Revision: 2010 May2011 QX56
