INFINITI QX56 2011 Factory Service Manual
Manufacturer: INFINITI, Model Year: 2011, Model line: QX56, Model: INFINITI QX56 2011Pages: 5598, PDF Size: 94.53 MB
Page 2381 of 5598
![INFINITI QX56 2011 Factory Service Manual
P0500 VSSEC-357
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O4. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Go to
EC-357, "Diagnosis Procedure".
NO >> INSPECTION END
4. INFINITI QX56 2011 Factory Service Manual
P0500 VSSEC-357
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O4. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Go to
EC-357, "Diagnosis Procedure".
NO >> INSPECTION END
4.](/img/42/57033/w960_57033-2380.png)
P0500 VSSEC-357
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O4. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Go to
EC-357, "Diagnosis Procedure".
NO >> INSPECTION END
4.PERFORM COMPONENT FUNCTION CHECK
WITH GST
Perform Component Function Check. Refer to EC-357, "
Component Function Check".
Use Component Function Check to check the overall func tion of the vehicle speed signal circuit. During this
check, a 1st trip DTC might not be confirmed.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Go to EC-357, "
Diagnosis Procedure".
Component Function CheckINFOID:0000000006217859
1.PERFORM COMPONENT FUNCTION CHECK
WITH GST
1. Lift up drive wheels.
2. Start engine.
3. Read vehicle speed signal in Service $01 with GST. The vehicle speed signal on GST should be able to ex ceed 10 km/h (6 MPH) when rotating wheels with
suitable gear position.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Go to EC-357, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000006217860
1.CHECK DTC WITH “ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)”
Refer to BRC-40, "
CONSULT-III Function".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace malfunctioning part.
2.CHECK DTC WITH “COMBINATION METER”
Refer to MWI-30, "
CONSULT-III Function".
>> INSPECTION END
B/FUEL SCHDL 5.5 - 31.8 msec
Selector lever Except P or N position
PW/ST SIGNAL OFF
Revision: 2010 May2011 QX56
Page 2382 of 5598
![INFINITI QX56 2011 Factory Service Manual
EC-358
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0506 ISC SYSTEM
P0506 ISC SYSTEM
DescriptionINFOID:0000000006217861
The ECM controls the engine idle speed to a specified leve
l through the fine adjustment INFINITI QX56 2011 Factory Service Manual
EC-358
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0506 ISC SYSTEM
P0506 ISC SYSTEM
DescriptionINFOID:0000000006217861
The ECM controls the engine idle speed to a specified leve
l through the fine adjustment](/img/42/57033/w960_57033-2381.png)
EC-358
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0506 ISC SYSTEM
P0506 ISC SYSTEM
DescriptionINFOID:0000000006217861
The ECM controls the engine idle speed to a specified leve
l through the fine adjustment of the air, which is let
into the intake manifold, by operating the electric thrott le control actuator. The operating of the throttle valve is
varied to allow for optimum control of the engine idli ng speed. The crankshaft position sensor detects the
actual engine speed and sends a signal to the ECM.
The ECM controls the electric throttle control actuator so that the engine speed coincides with the target value
memorized in the ECM. The target engine speed is t he lowest speed at which the engine can operate steadily.
The optimum value stored in the ECM is determined by taking into consideration various engine conditions,
such as during warming up, deceleration and engine load (air conditioner, power steering and cooling fan
operation, etc.).
DTC LogicINFOID:0000000006217862
DTC DETECTION LOGIC
NOTE:
If DTC P0506 is displayed with ot her DTC, first perform the trouble diagnosis for the other DTC.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
If the target idle speed is ou t of the specified value, perform EC-148, "
Work Procedure", before con-
ducting DTC Confirmation Procedure.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is 11 V or more at idle.
Always perform the test at a temperature above −10 °C (14 °F).
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and warm it up to normal operating temperature.
2. Turn ignition switch OFF and wait at least 10 seconds.
3. Turn ignition switch ON.
4. Turn ignition switch OFF and wait at least 10 seconds.
5. Restart engine and run it for at least 1 minute at idle speed.
6. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Go to EC-358, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006217863
1.CHECK INTAKE AIR LEAKAGE
1. Start engine and let it idle.
2. Listen for an intake air leakage after the mass air flow sensor.
Is intake air leakage detected?
YES >> Discover air leakage location and repair.
DTC No. Trouble diagnosis name
(Trouble diagnosis content) DTC detecting condition Possible cause
P0506 ISC SYSTEM
(Idle speed control system
RPM lower than expected) The idle speed is less than the target idle
speed by 100 rpm or more.
Electric throttle control actuator
Intake air leakage
Revision: 2010 May2011 QX56
Page 2383 of 5598
![INFINITI QX56 2011 Factory Service Manual
P0506 ISC SYSTEMEC-359
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
NO >> GO TO 2.
2.REPLACE ECM
1. Stop engine.
2. Replace ECM.
3. Perform additional service when replacing ECM INFINITI QX56 2011 Factory Service Manual
P0506 ISC SYSTEMEC-359
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
NO >> GO TO 2.
2.REPLACE ECM
1. Stop engine.
2. Replace ECM.
3. Perform additional service when replacing ECM](/img/42/57033/w960_57033-2382.png)
P0506 ISC SYSTEMEC-359
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
NO >> GO TO 2.
2.REPLACE ECM
1. Stop engine.
2. Replace ECM.
3. Perform additional service when replacing ECM. Refer to EC-143, "
Work Procedure".
>> INSPECTION END
Revision: 2010 May2011 QX56
Page 2384 of 5598
![INFINITI QX56 2011 Factory Service Manual
EC-360
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0507 ISC SYSTEM
P0507 ISC SYSTEM
DescriptionINFOID:0000000006217864
The ECM controls the engine idle speed to a specified leve
l through the fine adjustment INFINITI QX56 2011 Factory Service Manual
EC-360
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0507 ISC SYSTEM
P0507 ISC SYSTEM
DescriptionINFOID:0000000006217864
The ECM controls the engine idle speed to a specified leve
l through the fine adjustment](/img/42/57033/w960_57033-2383.png)
EC-360
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0507 ISC SYSTEM
P0507 ISC SYSTEM
DescriptionINFOID:0000000006217864
The ECM controls the engine idle speed to a specified leve
l through the fine adjustment of the air, which is let
into the intake manifold, by operating the electric thrott le control actuator. The operating of the throttle valve is
varied to allow for optimum control of the engine idli ng speed. The crankshaft position sensor detects the
actual engine speed and sends a signal to the ECM.
The ECM controls the electric throttle control actuator so that the engine speed coincides with the target value
memorized in the ECM. The target engine speed is t he lowest speed at which the engine can operate steadily.
The optimum value stored in the ECM is determined by taking into consideration various engine conditions,
such as during warming up, deceleration and engine load (air conditioner, power steering and cooling fan
operation, etc.).
DTC LogicINFOID:0000000006217865
DTC DETECTION LOGIC
NOTE:
If DTC P0507 is displayed with ot her DTC, first perform the trouble diagnosis for the other DTC.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
If the target idle speed is ou t of the specified value, perform EC-148, "
Work Procedure", before con-
ducting DTC Confirmation Procedure.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is 11 V or more at idle.
Always perform the test at a temperature above −10 °C (14 °F).
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and warm it up to normal operating temperature.
2. Turn ignition switch OFF and wait at least 10 seconds.
3. Turn ignition switch ON.
4. Turn ignition switch OFF and wait at least 10 seconds.
5. Start engine and run it for at least 1 minute at idle speed.
6. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Go to EC-360, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006217866
1.CHECK PCV HOSE CONNECTION
Confirm that PCV hose is connected correctly.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace malfunctioning part.
DTC No. Trouble diagnosis name
(Trouble diagnosis content) DTC detecting condition Possible cause
P0507 ISC SYSTEM
(Idle speed control system
RPM higher than expected) The idle speed is more than the target idle
speed by 200 rpm or more. Electric throttle control actuator
Intake air leakage
PCV system
Revision: 2010 May2011 QX56
Page 2385 of 5598
![INFINITI QX56 2011 Factory Service Manual
P0507 ISC SYSTEMEC-361
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
2.CHECK INTAKE AIR LEAKAGE
1. Start engine and let it idle.
2. Listen for an intake air leakage after the mas INFINITI QX56 2011 Factory Service Manual
P0507 ISC SYSTEMEC-361
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
2.CHECK INTAKE AIR LEAKAGE
1. Start engine and let it idle.
2. Listen for an intake air leakage after the mas](/img/42/57033/w960_57033-2384.png)
P0507 ISC SYSTEMEC-361
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
2.CHECK INTAKE AIR LEAKAGE
1. Start engine and let it idle.
2. Listen for an intake air leakage after the mass air flow sensor.
Is intake air leakage detected?
YES >> Discover air leakage location and repair.
NO >> GO TO 3.
3.REPLACE ECM
1. Stop engine.
2. Replace ECM.
3. Perform additional service when replacing ECM. Refer to EC-143, "
Work Procedure".
>> INSPECTION END
Revision: 2010 May2011 QX56
Page 2386 of 5598
![INFINITI QX56 2011 Factory Service Manual
EC-362
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P050E COLD START CONTROL
P050E COLD START CONTROL
DescriptionINFOID:0000000006288336
ECM controls ignition timing and engine idle speed when engine is started INFINITI QX56 2011 Factory Service Manual
EC-362
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P050E COLD START CONTROL
P050E COLD START CONTROL
DescriptionINFOID:0000000006288336
ECM controls ignition timing and engine idle speed when engine is started](/img/42/57033/w960_57033-2385.png)
EC-362
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P050E COLD START CONTROL
P050E COLD START CONTROL
DescriptionINFOID:0000000006288336
ECM controls ignition timing and engine idle speed when engine is started with pre-warming up condition.
This control promotes the activation of three way ca
talyst by heating the catalyst and reduces emissions.
DTC LogicINFOID:0000000006288337
DTC DETECTION LOGIC
NOTE:
If DTC P050E is displayed with other DTC, first perform the trouble diagnosis for other DTC.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is 11 V or more at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE-I
WITH CONSULT-III
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Select “DATA MONITOR” mode with CONSULT-III.
4. Check the indication of “COOLAN TEMP/S”.
WITH GST
Follow the procedure “With CONSULT-III” above.
Is the value of
“COOLAN TEMP/S” between 5°C (41°F) and 36°C (97°F)?
YES >> GO TO 3.
NO-1 [If it is below 5 °C (41 °F)]>>Warm up the engine until the val ue of “COOLAN TEMP/S” reaches 5°C
(41 °F) or more. Retry from step 1.
NO-2 [If it is above 36 °C (97 °F)]>>Cool engine down to less than 36 °C (97 °F). Retry from step 1.
3.PERFORM DTC CONFIRMATION PROCEDURE-II
WITH CONSULT-III
1. Set the select lever in N range.
2. Start the engine and warm up in idle with the value of “COOLAN TEMP/S” between 5 °C (41 °F) and 40 °C
(104 °F) for more than 15 seconds.
3. Check 1st trip DTC.
WITH GST
Follow the procedure “With CONSULT-III” above.
Is 1st trip DTC detected?
YES >> Proceed to EC-362, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006288338
1.PERFORM IDLE AIR VOLUME LEARNING
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P050E Cold start engine exhaust temper-
ature too low The temperature of the catalyst inlet does not
rise to the proper temperature when the engine
is started with pre-warming up condition. Lack of intake air volume
Fuel injection system
ECM
Revision: 2010 May2011 QX56
Page 2387 of 5598
![INFINITI QX56 2011 Factory Service Manual
P050E COLD START CONTROLEC-363
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Perform
EC-148, "Work Procedure".
Is Idle Air Volume Learning carried out successfully?
YES >> GO TO INFINITI QX56 2011 Factory Service Manual
P050E COLD START CONTROLEC-363
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Perform
EC-148, "Work Procedure".
Is Idle Air Volume Learning carried out successfully?
YES >> GO TO](/img/42/57033/w960_57033-2386.png)
P050E COLD START CONTROLEC-363
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Perform
EC-148, "Work Procedure".
Is Idle Air Volume Learning carried out successfully?
YES >> GO TO 2.
NO >> Follow the instruction of Idle Air Volume Learning.
2.CHECK INTAKE SYSTEM
Check for the cause of intake air volume lacking. Refer to the following.
Crushed intake air passage
Intake air passage clogging
Clogging of throttle body
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace malfunctioning part
3.CHECK FUEL INJECTION SYSTEM FUNCTION
Perform DTC Confirmation Procedure for DTC P0171, P0174. Refer to EC-263, "
DTC Logic".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Proceed to EC-264, "
Diagnosis Procedure" for DTC P0171, P0174.
4.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Erase DTC.
3. Perform DTC Confirmation Procedure. See EC-362, "
DTC Logic".
Is the 1st trip DTC P050E displayed again?
YES >> GO TO 5.
NO >> INSPECTION END
5.REPLACE ECM
Replace ECM. Refer to EC-535, "
Removal and Installation".
>> INSPECTION END
Revision: 2010 May2011 QX56
Page 2388 of 5598
![INFINITI QX56 2011 Factory Service Manual
EC-364
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0524 ENGINE OIL PRESSURE
P0524 ENGINE OIL PRESSURE
DTC LogicINFOID:0000000006288342
DTC DETECTION LOGIC
NOTE:
If DTC P0524 is displayed with DTC P0075 or P00 INFINITI QX56 2011 Factory Service Manual
EC-364
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0524 ENGINE OIL PRESSURE
P0524 ENGINE OIL PRESSURE
DTC LogicINFOID:0000000006288342
DTC DETECTION LOGIC
NOTE:
If DTC P0524 is displayed with DTC P0075 or P00](/img/42/57033/w960_57033-2387.png)
EC-364
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0524 ENGINE OIL PRESSURE
P0524 ENGINE OIL PRESSURE
DTC LogicINFOID:0000000006288342
DTC DETECTION LOGIC
NOTE:
If DTC P0524 is displayed with DTC P0075 or P0081,
perform trouble diagnosis for DTC P0075 or P0081
first. Refer to EC-193, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING-I
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confi rm that battery voltage is between 10 V and 16 V at
idle.
>> GO TO 2.
2.PRECONDITIONING-II
Check oil level and oil pressure. Refer to LU-7, "
Inspection".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Proceed to LU-7, "
Inspection".
3.PERFORM DTC CONFIRMATION PROCEDURE
WITH CONSULT-III
1. Select “DATA MONITOR” mode with CONSULT-III.
2. Maintain the following conditions for at least 20 consecutive seconds.
CAUTION:
Always drive at a safe speed.
3. Check 1st trip DTC.
WITH GST
Follow the procedure “With CONSULT-III” above.
Is 1st trip DTC detected?
YES >> Proceed to EC-365, "Diagnosis Procedure"
DTC No.Trouble diagnosis name
(Trouble diagnosis content) Detecting condition Possible cause
P0524 ENGINE OIL PRESSURE
(Engine oil pressure too low) Engine oil pressure is low because
there is a gap between angle of target
and phase-control angle. Engine oil pressure or level too low
Crankshaft position sensor
Camshaft position sensor
Intake valve timing control solenoid valve
Accumulation of debris to the signal pick-up por-
tion of the camshaft
Timing chain installation
Foreign matter caught in the oil groove for intake valve timing control
ENG SPEED More than 1,700 rpm
COOLAN TEMP/S More than 70 °C (158 °F)
Selector lever 1st or 2nd position
Driving location uphill Driving vehicle uphill
(Increased engine load will help maintain the driving
conditions required for this test.)
Revision: 2010 May2011 QX56
Page 2389 of 5598
![INFINITI QX56 2011 Factory Service Manual
P0524 ENGINE OIL PRESSUREEC-365
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006288343
1.CHECK OIL PRESSURE WARNING LAMP
1. INFINITI QX56 2011 Factory Service Manual
P0524 ENGINE OIL PRESSUREEC-365
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006288343
1.CHECK OIL PRESSURE WARNING LAMP
1.](/img/42/57033/w960_57033-2388.png)
P0524 ENGINE OIL PRESSUREEC-365
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006288343
1.CHECK OIL PRESSURE WARNING LAMP
1. Start engine.
2. Check oil pressure warning lamp and confirm it is not illumi- nated.
Is oil pressure warning lamp illuminated?
YES >> Proceed to LU-7, "Inspection".
NO >> GO TO 2.
2.CHECK INTAKE VALVE TIMING CONTROL SOLENOID VALVE
Refer to EC-179, "
Component Inspection (Intake Valve Timing Control Solenoid Valve)".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace malfunctioning intake valve timing control solenoid valve.
3.CHECK CRANKSHAFT POSITION SENSOR
Refer to EC-301, "
Component Inspection (Crankshaft Position Sensor)".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Replace crankshaft position sensor.
4.CHECK CAMSHAFT PO SITION SENSOR
Refer to EC-306, "
Component Inspection (Camshaft Position Sensor)".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Replace malfunctioning camshaft position sensor.
5.CHECK CAMSHAFT SPROCKET (SIGNAL PLATE)
Check the following.
Accumulation of debris to the signal plate of camshaft sprocket (INT)
Chipping signal plate of camshaft sprocket (INT)
Is the inspection result normal?
YES >> GO TO 6.
NO >> Remove debris and clean the signal plate of camshaft sprocket (INT) or replace camshaft sprocket (INT).
Refer to EM-61, "
Exploded View".
6.CHECK TIMING CHAIN INSTALLATION
Check service records for any recent repairs that may cause timing chain misaligned.
Are there any service records that may cause timing chain misaligned?
YES >> Check timing chain installation. Refer to EM-61, "Exploded View".
NO >> GO TO 7.
7.CHECK LUBRICATION CIRCUIT
Perform “Inspection of Camshaft Sprocket (INT) Oil Groove”. Refer to LU-7, "
Inspection".
PBIA8559J
JMBIA0962ZZ
Revision: 2010 May2011 QX56
Page 2390 of 5598
![INFINITI QX56 2011 Factory Service Manual
EC-366
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0524 ENGINE OIL PRESSURE
Is the inspection result normal?
YES >> GO TO 8.
NO >> Clean lubrication line.
8.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Inte INFINITI QX56 2011 Factory Service Manual
EC-366
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0524 ENGINE OIL PRESSURE
Is the inspection result normal?
YES >> GO TO 8.
NO >> Clean lubrication line.
8.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Inte](/img/42/57033/w960_57033-2389.png)
EC-366
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0524 ENGINE OIL PRESSURE
Is the inspection result normal?
YES >> GO TO 8.
NO >> Clean lubrication line.
8.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
>> INSPECTION END
Revision: 2010 May2011 QX56
