INSPECTION AND ADJUSTMENTEXL-61
< BASIC INSPECTION > [XENON TYPE]
C
D
E
F
G H
I
J
K
M A
B
EXL
N
O P
INSPECTION AND ADJUSTMENT
ADDITIONAL SERVICE WHEN REPLAC ING CONTROL UNIT (AFS CONTROL
UNIT)
ADDITIONAL SERVICE WHEN REPLAC ING CONTROL UNIT (AFS CONTROL
UNIT) : Description
INFOID:0000000006213923
Perform “LEVELIZER ADJUSTMENT” with CONSUL T-III when replacing the AFS control unit.
ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT (AFS CONTROL
UNIT) : Special Repair Requirement
INFOID:0000000006213924
1.LEVELIZER ADJUSTMENT
Perform “LEVELIZER ADJUSTMENT”.
>> Refer to EXL-61, "
LEVELIZER ADJUSTMENT : Special Repair Requirement".
ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT (HEIGHT SEN-
SOR)
ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT (HEIGHT SENSOR) :
Description
INFOID:0000000006213925
Perform “LEVELIZER ADJUSTMENT” with CONS ULT-III when replacing the height sensor.
ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT (HEIGHT SENSOR) :
Special Repair Requirement
INFOID:0000000006213926
1.LEVELIZER ADJUSTMENT
Perform “LEVELIZER ADJUSTMENT”.
>> Refer to EXL-61, "
LEVELIZER ADJUSTMENT : Special Repair Requirement".
LEVELIZER ADJUSTMENT
LEVELIZER ADJUSTMENT : DescriptionINFOID:0000000006213927
Perform “LEVELIZER ADJUSTME NT” when installing, removing, and replacing the height sensor and the sus-
pension components.
LEVELIZER ADJUSTMENT : S pecial Repair RequirementINFOID:0000000006213928
CAUTION:
If perform aiming adjustment after the levelizer initia lization, be sure to start the engine running after
turning ignition switch OFF.
1.CHECK VEHICLE CONDITION
1. Park the vehicle in the straight-forward position.
2. Unload the vehicle (no passenger aboard).
>> GO TO 2.
2.LEVELIZER ADJUSTMENT
CONSULT-III WORK SUPPORT
1. Select “LEVELIZER ADJUSTMENT” of ADAPTIVE LIGHT work support item.
2. Select “START”.
3. When “ADJUSTMENT IS CO MPLETED”, select “END”.
CAUTION:
Revision: 2010 May2011 QX56

EXL-62
< BASIC INSPECTION >[XENON TYPE]
INSPECTION AND ADJUSTMENT
If “CAN NOT BE TESTED” is indi
cated, AFS control unit detects that the height sensor signal
changes. The levelizer adjustment is cancelled. In this case, turn the ignition switch OFF to pre-
vent the vehicle from the height change. Perform the levelizer adjustment again.
Is the levelizer adjustment completed?
YES >> GO TO 3.
NO >> Perform the levelizer adjustment again.
3.SELF-DIAGNOSIS RESULT CHECK
Perform self-diagnosis with CONSULT-III. Check that any DTC is not detected.
Is any DTC detected?
YES >> GO TO 2.
NO >> Levelizer adjustment completed
Revision: 2010 May2011 QX56

B2503, B2504 SWIVEL ACTUATOREXL-63
< DTC/CIRCUIT DIAGNOSIS > [XENON TYPE]
C
D
E
F
G H
I
J
K
M A
B
EXL
N
O P
DTC/CIRCUIT DIAGNOSIS
B2503, B2504 SWIVEL ACTUATOR
DTC LogicINFOID:0000000006213929
DTC DETECTION LOGIC
*: Initialization is not included.
DTC CONFIRMATION PROCEDURE
1.DTC ERASE
Erase the DTC memory of AFS with CONSULT-III.
>> GO TO 2.
2.CONFIRMATION DTC SELECTION
Select “B2503” or “B2504” for confirmation.
Which DTC is confirmation?
B2503 >> GO TO 3.
B2504 >> GO TO 4.
3.DTC CONFIRMATION (B2503)
1. Steer to the straight-forward position.
2. Start the engine.
3. Turn AFS switch ON.
4. Turn the headlamp ON.
5. Shift the selector lever to “N”.
6. Steer to the right. (Rotate it once or more.)
7. Perform the self-diagnosis with CONSULT-III.
Is DTC
“B2503” detected?
YES >> Refer to EXL-64, "Diagnosis Procedure".
NO >> Refer to GI-40, "
Intermittent Incident".
4.DTC CONFIRMATION (B2504)
1. Steer to the straight-forward position.
2. Start the engine.
3. Turn AFS switch ON.
4. Turn the headlamp ON.
5. Drive at 25 km/h (15.5 MPH) or more.
6. Steer to the left. (Rotate it once or more.)
DTC No. Trouble diagnosis name DTC detection condition Possible cause
B2503 Swivel actuator [RH] AFS control unit indicates an applicable DTC when detecting any of the following conditions continuous-
ly for 2 seconds or more.
 AFS control unit-recognized swivel position differs extremely from the swivel position sensor-input
value while the swivel operating.
*
 The swivel position sensor signal does not change even though AFS control unit transmits the swivel
motor driving signal while the swivel operating
*.
 The swivel motor short and open is detected while
the swivel operating
*.
 The swivel position sensor power supply is 6 V or more, or 4 V or less.
 The swivel position sensor signal is 0.25 V or less, or 4.75 V or more. Swivel position sensor
 Swivel position sensor
 Harness and connector
 AFS control unit
Swivel motor
Swivel motor
 Harness and connector
 AFS control unit
B2504 Swivel actuator [LH]
Revision: 2010 May2011 QX56

EXL-64
< DTC/CIRCUIT DIAGNOSIS >[XENON TYPE]
B2503, B2504 SWIVEL ACTUATOR
7. Stop the vehicle.
8. Perform the self-diagnosis with CONSULT-III.
Is DTC
“B2504” detected?
YES >> Refer to
EXL-64, "Diagnosis Procedure".
NO >> Refer to GI-40, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000006213930
1.CHECK SWIVEL POSITION SENSOR SIGNAL INPUT
1. Turn ignition switch ON.
2. Check voltage between AFS control unit harness connector and ground.
Is the measurement value within the standard value?
YES >> GO TO 2.
Less than the standard value >>GO TO 6.
Higher than the standard value>>GO TO 9.
2.CHECK SWIVEL MOTOR
Check swivel motor. EXL-67, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace front combination lamp.
3.CHECK SWIVEL MOTOR OPEN CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect AFS control unit connector and headlamp swivel actuator connector.
3. Check continuity between AFS control unit har ness connector and headlamp swivel actuator harness
connector.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace harnesses.
4.CHECK SWIVEL MOTOR SHORT CIRCUIT
Check continuity between AFS c ontrol unit harness connector and ground.
(+)
(− ) Vo l ta g e
(Approx.)
AFS control unit
Connector Terminal
RH M135 9
Ground 0.25 - 4.75 V
LH 29
AFS control unit Headlamp swivel
actuator Continuity
Connector Terminal Connector Terminal
RH M135 11
E123 8
Existed
13 7
32 3
34 4
LH 15
E122 3
17 4
36 8
38 7
Revision: 2010 May2011 QX56

B2503, B2504 SWIVEL ACTUATOREXL-65
< DTC/CIRCUIT DIAGNOSIS > [XENON TYPE]
C
D
E
F
G H
I
J
K
M A
B
EXL
N
O P
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace harnesses.
5.CHECK SWIVEL MOTOR CIRCUIT VOLTAGE OUTPUT
1. Connect AFS control unit connector.
2. Start the engine.
3. Turn the headlamp ON.
4. Select “LOW BEAM TEST RIGHT” or “LOW BEAM TEST LEFT” of ADAPTIVE LIGHT active test item.
5. With operating the test item, check voltage between AFS control unit harness connector and ground.
Is the inspection result normal?
YES >> Replace front combination lamp.
NO >> Replace AFS control unit. Refer to EXL-135, "
Removal and Installation"
6.CHECK SWIVEL POSITION SENSOR POWER SUPPLY CIRCUIT INPUT VOLTAGE
1. Turn ignition switch OFF.
2. Disconnect headlamp swivel actuator connector.
3. Turn ignition switch ON.
4. Check voltage between headlamp swivel actuator harness connector and ground.
AFS control unit
GroundContinuity
Connector Terminal
RH M135 11
Not existed
13
32
34
LH 15
17
36
38
(+)
(− ) Condition Vo l ta g e
(Approx.)
AFS control unit
Connector Terminal
RH
M135 11
Ground Swivel motor Active
8 - 12 V
32
LH 15
36
RH 13
Stop 9.5 - 11.5 V
34
LH 17
38
SKIB2408J
(+)
(− ) Vol tag e
(Approx.)
Headlamp swivel actuator
Connector Terminal
RH E123 2Ground5 V
LH E122
Revision: 2010 May2011 QX56

EXL-66
< DTC/CIRCUIT DIAGNOSIS >[XENON TYPE]
B2503, B2504 SWIVEL ACTUATOR
Is the inspection result normal?
YES >> GO TO 7.
NO >> GO TO 8.
7.CHECK SWIVEL POSITION SENSOR SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect AFS control unit connector.
3. Check continuity between AFS control unit har ness connector and headlamp swivel actuator harness
connector.
4. Check continuity between AFS control unit harness connector and ground.
Is the inspection result normal?
YES >> Replace front combination lamp.
NO >> Repair or replace harnesses.
8.CHECK SWIVEL POSITION SE NSOR POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect AFS control unit connector.
3. Check continuity between AFS control unit har ness connector and headlamp swivel actuator harness
connector.
4. Check continuity between AFS control unit harness connector and ground.
Is the inspection result normal?
YES >> Replace AFS control unit. Refer to EXL-135, "Removal and Installation"
NO >> Repair or replace harnesses.
9.CHECK SWIVEL POSITION SENSOR GROUND CIRCUIT VOLTAGE OUTPUT
Check voltage between AFS control unit harness connector and ground.
AFS control unit Headlamp swivel actuator Continuity
Connector Terminal Connector Terminal
RH M135 9E123
1 Existed
LH 29 E122
AFS control unit GroundContinuity
Connector Terminal
RH M135 9
Not existed
LH 29
AFS control unit Headlamp swivel actuator Continuity
Connector Terminal Connector Terminal
RH M135 4E123
2 Existed
LH 24 E122
AFS control unit GroundContinuity
Connector Terminal
RH M135 4
Not existed
LH 24
(+)
(− ) Vo l ta g e
(Approx.)
AFS control unit
Connector Terminal
RH M135 2
Ground 0 V
LH 27
Revision: 2010 May2011 QX56

B2503, B2504 SWIVEL ACTUATOREXL-67
< DTC/CIRCUIT DIAGNOSIS > [XENON TYPE]
C
D
E
F
G H
I
J
K
M A
B
EXL
N
O P
Is the inspection result normal?
YES >> GO TO 10.
NO >> Replace AFS control unit. Refer to EXL-135, "
Removal and Installation"
10.CHECK SWIVEL POSITION SENSOR GROUND OPEN CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect AFS control unit connector and headlamp swivel actuator connector.
3. Check continuity between AFS control unit har ness connector and headlamp swivel actuator harness
connector.
Is the inspection result normal?
YES >> Replace front combination lamp.
NO >> Repair or replace harnesses.
Component InspectionINFOID:0000000006213931
1.CHECK SWIVEL MOTOR SINGLE PART
1. Disconnect swivel actuator connector.
2. Check resistance among each swivel actuator connector terminals.
Is the inspection result normal?
YES >> Swivel actuator is normal.
NO >> Replace front combination lamp.
AFS control unit Headlamp swivel actuator Continuity
Connector Terminal Connector Terminal
RH M135 2E123
6 Existed
LH 27 E122
Swivel actuator Resistance
(Approx.)
Te r m i n a l Te r m i n a l
37 7.2 Ω
48
3410 M Ω or more
Revision: 2010 May2011 QX56

EXL-68
< DTC/CIRCUIT DIAGNOSIS >[XENON TYPE]
B2513 HEIGHT SENSOR UNUSUAL [FR]
B2513 HEIGHT SENSOR UNUSUAL [FR]
DTC LogicINFOID:0000000006213932
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC ERASE
Erase the DTC memory of AFS with CONSULT-III.
>> GO TO 2.
2.DTC CONFIRMATION
1. Start the engine.
2. Turn the headlamp ON.
3. Select the self-diagnosis with CONSULT-III.
4. Check the self-diagnosis result. Refer to EXL-39, "
DTC Index".
Is DTC
“B2513” detected?
YES >> Refer to EXL-68, "Diagnosis Procedure".
NO >> Refer to GI-40, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000006213933
1.CHECK HEIGHT SENSOR SIGNAL INPUT
1. Turn ignition switch ON.
2. Check voltage between AFS control unit harness connector and ground.
Is the measurement value within the standard value?
YES >> Replace AFS control unit. Refer to EXL-135, "Removal and Installation"
Less than the standard value >>GO TO 2.
Higher than the standard value>>GO TO 5.
2.CHECK HEIGHT SENSOR POWER SUPPLY CIRCUIT INPUT VOLTAGE
1. Turn ignition switch OFF.
2. Disconnect front height sensor connector.
3. Turn ignition switch ON.
4. Check voltage between front height sensor harness connector and ground.
DTC No. Trouble diagnosis name DTC detection condition Possible cause
B2513 Height sensor unusual [FR] An applicable DTC is indicated when any of the
following conditions is detected continuously
for 2 seconds or more.
 The front height sensor power supply is 6 V
or more, or 4 V or less.
 The front height sensor signal is 0.25 V or less, or 4.75 V or more. Front height sensor
 Front height sensor
 Harness and connector
 AFS control unit
(+)
(− ) Vo l ta g e
(Approx.)
AFS control unit
Connector Terminal M135 23 Ground 0.25 - 4.75 V
(+) (− ) Vo l ta g e
(Approx.)
Front height sensor
Connector Terminal E208 1 Ground 5 V
Revision: 2010 May2011 QX56

B2513 HEIGHT SENSOR UNUSUAL [FR]EXL-69
< DTC/CIRCUIT DIAGNOSIS > [XENON TYPE]
C
D
E
F
G H
I
J
K
M A
B
EXL
N
O P
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 4.
3.CHECK HEIGHT SENSOR SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect AFS control unit connector.
3. Check continuity between AFS control unit harnes s connector and front height sensor harness connector.
4. Check continuity between AFS control unit harness connector and ground.
Is the inspection result normal?
YES >> Replace front height sensor. Refer to EXL-136, "Removal and Installation".
NO >> Repair or replace harness.
4.CHECK HEIGHT SENSOR POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect AFS control unit connector.
3. Check continuity between AFS control unit harnes s connector and front height sensor harness connector.
4. Check continuity between AFS control unit harness connector and ground.
Is the inspection result normal?
YES >> Replace AFS control unit. Refer to EXL-135, "Removal and Installation"
NO >> Repair or replace harness.
5.CHECK HEIGHT SENSOR GROUND CIRCUIT VOLTAGE OUTPUT
Check voltage between AFS control unit harness connector and ground.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Replace AFS control unit. Refer to EXL-135, "
Removal and Installation"
6.CHECK HEIGHT SENSOR GROUND OPEN CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect AFS control unit connecto r and front height sensor connector.
3. Check continuity between AFS control unit harnes s connector and front height sensor harness connector.
AFS control unit Front height sensor
Continuity
Connector Terminal Connector Terminal
M135 23 E208 2 Existed
AFS control unit GroundContinuity
Connector Terminal
M135 23 Not existed
AFS control unit Front height sensor Continuity
Connector Terminal Connector Terminal
M135 5 E208 1 Existed
AFS control unit GroundContinuity
Connector Terminal
M135 5 Not existed
(+) (− ) Vol tag e
(Approx.)
AFS control unit
Connector Terminal M135 10 Ground 0 V
Revision: 2010 May2011 QX56

EXL-70
< DTC/CIRCUIT DIAGNOSIS >[XENON TYPE]
B2513 HEIGHT SENSOR UNUSUAL [FR]
Is the inspection result normal?
YES >> Replace front height sensor. Refer to
EXL-136, "Removal and Installation".
NO >> Repair or replace harness.
AFS control unit Front height sensor Continuity
Connector Terminal Connector Terminal
M135 10 E208 3 Existed
Revision: 2010 May2011 QX56
