B2514 HEIGHT SENSOR UNUSUAL [RR]
DTC LogicINFOID:0000000006213934
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC ERASE
Erase the DTC memory of AFS with CONSULT-III.
>> GO TO 2.
2.DTC CONFIRMATION
1. Start the engine.
2. Turn the headlamp ON.
3. Select the self-diagnos is with CONSULT-III.
4. Check the self-diagnosis result. Refer to EXL-39, "
DTC Index".
Is DTC
“B2514” detected?
YES >> Refer to EXL-71, "Diagnosis Procedure".
NO >> Refer to GI-40, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000006213935
1.CHECK HEIGHT SENSOR SIGNAL INPUT
1. Turn ignition switch ON.
2. Check voltage between AFS cont rol unit harness connector and ground.
Is the measurement value within the standard value?
YES >> Replace AFS control unit. Refer to EXL-135, "Removal and Installation"
Less than the standard value >>GO TO 2.
Higher than the standard value>>GO TO 5.
2.CHECK HEIGHT SENSOR POWER SUPPLY CIRCUIT INPUT VOLTAGE
1. Turn ignition switch OFF.
2. Disconnect rear height sensor connector.
3. Turn ignition switch ON.
4. Check voltage between rear height sensor harness connector and ground.
DTC No. Trouble diagnosis name DTC detection condition Possible cause
B2514 Height sensor unusual [RR] An applicable DTC is indicated when any of the fol-
lowing conditions is detected continuously for 2
seconds or more.
 The rear height sensor power supply is 6 V or
more, or 4 V or less.
 The rear height sensor signal is 0.25 V or less, or 4.75 V or more. Rear height sensor
 Rear height sensor
 Harness and connector
 AFS control unit
(+)
(− ) Vol tag e
(Approx.)
AFS control unit
Connector Terminal M135 28 Ground 0.25 - 4.75 V
(+) (− ) Vol tag e
(Approx.)
Rear height sensor
Connector Terminal C15 1 Ground 5 V
Revision: 2010 May2011 QX56

EXL-72
< DTC/CIRCUIT DIAGNOSIS >[XENON TYPE]
B2514 HEIGHT SENSOR UNUSUAL [RR]
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 4.
3.CHECK HEIGHT SENSOR SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect AFS control unit connector.
3. Check continuity between AFS control unit harne ss connector and rear height sensor harness connector.
4. Check continuity between AFS control unit harness connector and ground.
Is the inspection result normal?
YES >> Replace rear height sensor. Refer to EXL-136, "Removal and Installation".
NO >> Repair or replace harness.
4.CHECK HEIGHT SENSOR POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect AFS control unit connector.
3. Check continuity between AFS control unit harne ss connector and rear height sensor harness connector.
4. Check continuity between AFS control unit harness connector and ground.
Is the inspection result normal?
YES >> Replace AFS control unit. Refer to EXL-135, "Removal and Installation"
NO >> Repair or replace harness.
5.CHECK HEIGHT SENSOR GROUND CIRCUIT VOLTAGE OUTPUT
Check voltage between AFS control unit harness connector and ground.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Replace AFS control unit. Refer to EXL-135, "
Removal and Installation"
6.CHECK HEIGHT SENSOR GROUND OPEN CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect AFS control unit connector and rear height sensor connector.
3. Check continuity between AFS control unit harne ss connector and rear height sensor harness connector.
AFS control unit Rear height sensor
Continuity
Connector Terminal Connector Terminal
M135 28 C15 2 Existed
AFS control unit GroundContinuity
Connector Terminal
M135 28 Not existed
AFS control unit Rear height sensor Continuity
Connector Terminal Connector Terminal
M135 6 C15 1 Existed
AFS control unit GroundContinuity
Connector Terminal
M135 6 Not existed
(+) (− ) Vo l ta g e
(Approx.)
AFS control unit
Connector Terminal M135 8 Ground 0 V
Revision: 2010 May2011 QX56

B2514 HEIGHT SENSOR UNUSUAL [RR]EXL-73
< DTC/CIRCUIT DIAGNOSIS > [XENON TYPE]
C
D
E
F
G H
I
J
K
M A
B
EXL
N
O P
Is the inspection result normal?
YES >> Replace rear height sensor. Refer to EXL-136, "Removal and Installation".
NO >> Repair or replace harness.
AFS control unit Rear height sensor Continuity
Connector Terminal Connector Terminal
M135 8 C15 3 Existed
Revision: 2010 May2011 QX56

EXL-74
< DTC/CIRCUIT DIAGNOSIS >[XENON TYPE]
B2516 SHIFT SIGNAL [P, R]
B2516 SHIFT SIGNAL [P, R]
DTC LogicINFOID:0000000006213936
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC ERASE
Erase the DTC memory of AFS with CONSULT-III.
>> GO TO 2.
2.DTC CONFIRMATION
1. Turn ignition ON.
2. Select the self-diagnosis with CONSULT-III.
3. Check the self-diagnosis result. Refer to EXL-39, "
DTC Index".
Is DTC
“B2516” detected?
YES >> Refer to EXL-74, "Diagnosis Procedure".
NO >> Refer to GI-40, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000006213937
1.TCM SELF-DIAGNOSIS
Check the self-diagnosis result with CONSULT-II I. Check that TCM does not detect any DTCs.
Is any DTC detected?
YES >> Check TCM. Refer to TM-78, "DTC Index".
NO >> GO TO 2.
2.DTC ERASE
Erase the DTC memory of AFS with CONSULT-III.
Is the memory erased?
YES >> INSPECTION END.
NO >> Replace AFS control unit. Refer to EXL-135, "
Removal and Installation"
DTC No. Trouble diagnosis name DTC detection condition Possible causes
B2516 Shift signal [P, R] The shift position signal is not received. TCM
 AFS control unit
Revision: 2010 May2011 QX56

B2517 VEHICLE SPEED SIGNALEXL-75
< DTC/CIRCUIT DIAGNOSIS > [XENON TYPE]
C
D
E
F
G H
I
J
K
M A
B
EXL
N
O P
B2517 VEHICLE SPEED SIGNAL
DTC LogicINFOID:0000000006213938
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC ERASE
Erase the DTC memory of AFS with CONSULT-III.
>> GO TO 2.
2.DTC CONFIRMATION
1. Turn ignition ON.
2. Select the self-diagnos is with CONSULT-III.
3. Check the self-diagnosis result. Refer to EXL-39, "
DTC Index".
Is DTC
“B2517” detected?
YES >> Refer to EXL-75, "Diagnosis Procedure".
NO >> Refer to GI-40, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000006213939
1.COMBINATION METER SELF-DIAGNOSIS
Check the self-diagnosis result wit h CONSULT-III. Check that the co mbination meter does not detect any
DTCs.
Is any DTC detected?
YES >> Check the combination meter Refer to MWI-43, "DTC Index".
NO >> GO TO 2.
2.DTC ERASE
Erase the DTC memory of AFS with CONSULT-III.
Is the memory erased?
YES >> INSPECTION END.
NO >> Replace AFS control unit. Refer to EXL-135, "
Removal and Installation"
DTC No. Trouble diagnosis name DTC detection condition Possible causes
B2517 Vehicle speed signal The vehicle speed signal is not re-
ceived. Combination meter
 AFS control unit
Revision: 2010 May2011 QX56

EXL-76
< DTC/CIRCUIT DIAGNOSIS >[XENON TYPE]
B2519 LEVELIZER CALIBRATION
B2519 LEVELIZER CALIBRATION
DTC LogicINFOID:0000000006213940
Diagnosis ProcedureINFOID:0000000006213941
1.LEVELIZER ADJUSTMENT
Perform the levelizer adjustment.
>> Refer to EXL-61, "
LEVELIZER ADJUSTMENT : Special Repair Requirement".
DTC No. Trouble diagnosis name DTC detection condition Possible causes
B2519 Levelizer calibration The height sensor adjustment position is not
recognized.AFS control unit
Revision: 2010 May2011 QX56

B2521 ECU CIRCUITEXL-77
< DTC/CIRCUIT DIAGNOSIS > [XENON TYPE]
C
D
E
F
G H
I
J
K
M A
B
EXL
N
O P
B2521 ECU CIRCUIT
DTC LogicINFOID:0000000006213942
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC ERASE
Erase the DTC memory of AFS with CONSULT-III.
>> GO TO 2.
2.DTC CONFIRMATION PROCEDURE
1. Turn ignition ON.
2. Select the self-diagnos is with CONSULT-III.
3. Check the self-diagnosis result. Refer to EXL-39, "
DTC Index".
Is DTC
“B2521” detected?
YES >> Refer to EXL-77, "Diagnosis Procedure".
NO >> Refer to GI-40, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000006213943
1.CHECK EACH SENSOR POWER SUPPLY
1. Turn ignition switch ON.
2. Check voltage between AFS cont rol unit harness connector and ground.
Is the measurement value within the standard value?
YES >> GO TO 2.
Less than the standard value >>GO TO 3.
Higher than the standard value>>GO TO 4.
2.CHECK EACH SENSOR SIGNAL
Check voltage between AFS control unit harness connector and ground.
DTC No. Trouble diagnosis name Error detection condition Possible cause
B2512 ECU circuit  AFS control unit indicates an applicable
DTC when detecting any of the following
conditions continuously for 2 seconds or
more.
- The swivel position sensor is shorted to
the power supply or the ground.
- The swivel position sensor signal is shorted to the ground.
- The height sensor power supply is short- ed to the power supply or the ground.
- The height sensor signal is shorted to
the ground.
 AFS control unit RAM/ROM error Swivel position sensor
 Swivel position sensor
 Harness and connector
 AFS control unit
Height sensor
 Height sensor
 Harness and connector
 AFS control unit
AFS control unit (RAM/
ROM)
 AFS control unit
(+)
(− ) Vol tag e
(Approx.)
AFS control unit
Connector Terminal
M135 4
Ground 5 V
5
6
24
Revision: 2010 May2011 QX56

EXL-78
< DTC/CIRCUIT DIAGNOSIS >[XENON TYPE]
B2521 ECU CIRCUIT
Is the measurement value within the standard value?
YES >> Replace AFS control unit. Refer to
EXL-135, "Removal and Installation"
Less than the standard value >>GO TO 5.
Higher than the standard value>>GO TO 6.
3.CHECK EACH SENSOR POWER SUPPLY SHORT CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect AFS control unit connector.
3. Check continuity between AFS control unit harness connector and ground.
Is the inspection result normal?
YES >> Replace AFS control unit. Refer to EXL-135, "Removal and Installation"
NO >> Repair or replace harness.
4.CHECK EACH SENSOR POWER SUPPLY SHORT CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect AFS control unit connector.
3. Check voltage between AFS control unit harness connector and ground.
Is the inspection result normal?
YES >> Replace AFS control unit. Refer to EXL-135, "Removal and Installation"
NO >> Repair or replace harness.
5.CHECK EACH SENSOR SIGNAL SHORT CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect AFS control unit connector.
3. Check continuity between AFS control unit harness connector and ground.
(+)
(− ) Vo l ta g e
(Approx.)
AFS control unit
Connector Terminal
M135 9
Ground 0.25 - 4.75 V
23
28
29
AFS control unit
GroundContinuity
Connector Terminal
M135 4
Not existed
5
6
24
(+) (− ) Vo l ta g e
(Approx.)
AFS control unit
Connector Terminal
M135 4
Ground 0 V
5
6
24
Revision: 2010 May2011 QX56

B2521 ECU CIRCUITEXL-79
< DTC/CIRCUIT DIAGNOSIS > [XENON TYPE]
C
D
E
F
G H
I
J
K
M A
B
EXL
N
O P
Is the inspection result normal?
YES >> Replace AFS control unit. Refer to EXL-135, "Removal and Installation"
NO >> Repair or replace harness.
6.CHECK EACH SENSOR SIGNAL SHORT CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect AFS control unit connector.
3. Turn ignition switch ON.
4. Check voltage between AFS cont rol unit harness connector and ground.
Is the inspection result normal?
YES >> Replace AFS control unit. Refer to EXL-135, "Removal and Installation"
NO >> Repair or replace harness.
AFS control unit
GroundContinuity
Connector Terminal
M135 9
Not existed
23
28
29
(+)
(− ) Vol tag e
(Approx.)
AFS control unit
Connector Terminal
M135 9
Ground 0 V
23
28
29
Revision: 2010 May2011 QX56

EXL-80
< DTC/CIRCUIT DIAGNOSIS >[XENON TYPE]
C0126 STEERING ANGLE SENSOR SIGNAL
C0126 STEERING ANGLE SENSOR SIGNAL
DTC LogicINFOID:0000000006213944
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC ERASE
Erase the DTC memory of AFS with CONSULT-III.
>> GO TO 2.
2.DTC CONFIRMATION
1. Start the engine.
2. Turn the steering wheel to the maximum right/left.
3. Select the self-diagnosis with CONSULT-III.
4. Check the self-diagnosis result. Refer to EXL-39, "
DTC Index".
Is DTC
“C0126” detected?
YES >> Refer to EXL-80, "Diagnosis Procedure".
NO >> Refer to GI-40, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000006213945
1.ABS ACTUATOR AND ELECTRICAL UNIT (CONTROL UNIT) SELF-DIAGNOSIS
Check the self-diagnosis result with CONSULT-III. C heck that ABS actuator and electrical unit (control unit)
does not detect any DTCs.
Is any DTC detected?
YES >> Check ABS actuator and electrical unit (control unit).Refer to BRC-51, "DTC Index".
NO >> GO TO 2.
2.DTC ERASE
Erase DTC memory of AFS with CONSULT-III.
Is the memory erased?
YES >> Inspection end.
NO >> Replace AFS control unit. Refer to EXL-135, "
Removal and Installation"
DTC No. Trouble diagnosis name DTC detection condition Possible causes
C0126 Steering angle sensor signal In any of the following conditions
 The steering angle sensor signal
is not received.
 The steering angle sensor signal error is received.
 Out-of-standard signal (-900 °-
+900 °) is received.  Steering angle sensor
 AFS control unit
Revision: 2010 May2011 QX56
