P0451 EVAP CONTROL SYSTEM PRESSURE SENSOREC-333
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P0451 EVAP CONTROL SYSTEM
PRESSURE SENSOR
DTC LogicINFOID:0000000006288316
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and wait at least 40 seconds. NOTE:
Do not depress accelerator pedal even slightly.
2. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-333, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006288317
1.CHECK EVAP CONTRO L SYSTEM PRESSURE SENSOR CONNECTOR
1. Disconnect EVAP control system pressure sensor harness connector.
2. Check that water is not inside connectors.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace harness connector.
2.CHECK EVAP CONTROL SYS TEM PRESSURE SENSOR POWER SUPPLY CIRCUIT
1. Turn ignition switch ON.
2. Check the voltage between EVAP control system pressure sensor harness connector and ground.
DTC No. Trouble diagnosis name
(Trouble diagnosis con- tent) DTC detecting condition Possible cause
P0451 EVAP SYS PRES SEN
(EVAP control system
pressure sensor perfor-
mance) ECM detects a sloshing signal
from the EVAP control system
pressure sensor  (EVAP control system pressure sensor circuit is shorted.)
Harness or connectors
(Battery current sensor circuit is open or shorted.)
(Accelerator pedal position sensor 2 circuit is shorted.)
[Camshaft position sensor (bank 1) circuit is shorted.]
(Crankshaft position sensor circuit is shorted.)
(Refrigerant pressure sensor circuit is shorted.)
 EVAP control system pressure sensor
 Battery current sensor
 Accelerator pedal position sensor
 Camshaft position sensor (bank 1)
 Crankshaft position sensor
 Refrigerant pressure sensor
EVAP control system
pressure sensor Ground Voltage (V)
Connector Terminal
C17 3 Ground Approx. 5 V
Revision: 2010 May2011 QX56

EC-334
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0451 EVAP CONTROL S
YSTEM PRESSURE SENSOR
Is the inspection result normal?
YES >> GO TO 7.
NO >> GO TO 3.
3.CHECK SENSOR POWER SUPPLY CIRCUIT
Check harness for short to power and short to ground, between the following terminals.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair short to ground or short to power in harness or connectors.
4.CHECK COMPONENTS
Check the following.
 Crankshaft position sensor (Refer to EC-301, "
Component Inspection (Crankshaft Position Sensor)".)
 Camshaft position sensor (bank 1) (Refer to EC-306, "
Component Inspection (Camshaft Position Sensor)".)
 Battery current sensor (Refer to EC-427, "
Component Inspection (Battery Current Sensor)".)
 Refrigerant pressure sensor (Refer to EC-520, "
Component Function Check".)
Is the inspection result normal?
YES >> GO TO 5.
NO >> Replace malfunctioning component.
5.CHECK APP SENSOR
Refer to EC-470, "
Component Inspection (Accelerator Pedal Position Sensor)".
Is the inspection result normal?
YES >> GO TO 8.
NO >> GO TO 6.
6.REPLACE ACCELERATOR PEDAL ASSEMBLY
Replace accelerator pedal assembly.
Refer to ACC-3, "
MODELS WITHOUT DISTANCE CONTROL ASS IST SYSTEM : Removal and Installation"
(Without distance control assist system)
Refer to ACC-4, "
MODELS WITH DISTANCE CONTROL ASSI ST SYSTEM : Removal and Installation" (With
distance control assist system).
>> INSPECTION END
7.CHECK EVAP CONTROL SY STEM PRESSURE SENSOR
Refer to EC-335, "
Component Inspection (EVAP Control System Pressure Sensor)".
Is the inspection result normal?
YES >> GO TO 8.
NO >> Replace EVAP control system pressure sensor.
8.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
ECM Sensor
Connector Terminal Name Connector Terminal
F110 76 Crankshaft position sensor F74 1
77 Camshaft position sensor (bank 1) F84 1
E80 133EVAP control system pressure sen-
sor
C17 3
Battery current sensor E63 2
Refrigerant pressure sensor E77 1
131 APP sensor 2 (Without ICC) E110 1
APP sensor 2 (with ICC) E67 9
Revision: 2010 May2011 QX56

EC-336
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0452 EVAP CONTROL S
YSTEM PRESSURE SENSOR
P0452 EVAP CONTROL SYSTEM PRESSURE SENSOR
DTC LogicINFOID:0000000006288319
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Always perform test at a temperature of 5 °C (41 °F) or more.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
WITH CONSULT-III
1. Start engine and warm it up to normal operating temperature.
2. Turn ignition switch OFF and wait at least 10 seconds.
3. Turn ignition switch ON.
4. Turn ignition switch OFF and wait at least 10 seconds.
5. Turn ignition switch ON.
6. Select “DATA MONITOR” mode with CONSULT-III.
7. Check that “FUEL T/TM P SE” is more than 0°C (32 °F).
8. Start engine and wait at least 20 seconds.
9. Check 1st trip DTC.
WITH GST
1. Start engine and warm it up to normal operating temperature.
2. Set voltmeter probes to ECM harness connector terminals under the following conditions.
3. Check that the voltage is less than 4.2 V.
4. Turn ignition switch OFF and wait at least 10 seconds.
5. Turn ignition switch ON.
6. Turn ignition switch OFF and wait at least 10 seconds.
7. Start engine and wait at least 20 seconds.
DTC No. Trouble diagnosis name
(Trouble diagnosis content) DTC detecting condition Possible cause
P0452 EVAP SYS PRES SEN
(EVAP control system pres-
sure sensor low input) An excessively low voltage from
the sensor is sent to ECM.  (EVAP control system pressure sensor circuit is short-
ed.)
Harness or connectors
(Battery current sensor circuit is open or shorted.)
(Accelerator pedal position sensor 2 circuit is shorted.)
[Camshaft position sensor (bank 1) circuit is shorted.]
(Crankshaft position sensor circuit is shorted.)
(Refrigerant pressure sensor circuit is shorted.)
 EVAP control system pressure sensor
 Battery current sensor
 Accelerator pedal position sensor
 Camshaft position sensor (bank 1)
 Crankshaft position sensor
 Refrigerant pressure sensor
ECM
Connector +–
Terminal Terminal
E80 134
(Fuel tank temperature sensor signal) 175
Revision: 2010 May2011 QX56

P0452 EVAP CONTROL SYSTEM PRESSURE SENSOREC-337
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
8. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to
EC-337, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006288320
1.CHECK EVAP CONTRO L SYSTEM PRESSURE SENSOR CONNECTOR
1. Disconnect EVAP control system pressure sensor harness connector.
2. Check that water is not inside connectors.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace harness connector.
2.CHECK EVAP CONTROL SYS TEM PRESSURE SENSOR POWER SUPPLY CIRCUIT-I
1. Turn ignition switch ON.
2. Check the voltage between EVAP control system pressure sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 9.
NO >> GO TO 3.
3.CHECK EVAP CONTROL SYS TEM PRESSURE SENSOR POWER SUPPLY CIRCUIT-II
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between EVAP control syst em pressure sensor harness connector and ECM har-
ness connector.
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 4.
4.DETECT MALFUNCTIONING PART
Check the following.
 Harness for open between ECM and EVAP control system pressure sensor
 Loose or poor connection for each connector and harness
>> Repair open circuit.
5.CHECK SENSOR POWER SUPPLY CIRCUIT
Check harness for short to power and short to ground, between the following terminals.
EVAP control system
pressure sensor Ground Voltage (V)
Connector Terminal
C17 3 Ground Approx. 5
EVAP control system pressure sensor ECM
Continuity
Connector Terminal Connector Terminal
C17 3 E80 133 Existed
ECM Sensor
Connector Terminal Name Connector Terminal
F110 76 Crankshaft position sensor F74 1
77 Camshaft position sensor (bank 1) F84 1
Revision: 2010 May2011 QX56

EC-338
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0452 EVAP CONTROL S
YSTEM PRESSURE SENSOR
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair short to ground or short to power in harness or connectors.
6.CHECK COMPONENTS
Check the following.
 Crankshaft position sensor (Refer to EC-301, "
Component Inspection (Crankshaft Position Sensor)".)
 Camshaft position sensor (bank 1) (Refer to EC-306, "
Component Inspection (Camshaft Position Sensor)".)
 Battery current sensor (Refer to EC-414, "
Component Inspection (Battery Current Sensor)".)
 Refrigerant pressure sensor (Refer to EC-520, "
Component Function Check".)
Is the inspection result normal?
YES >> GO TO 7.
NO >> Replace malfunctioning component.
7.CHECK APP SENSOR
Refer to EC-470, "
Component Inspection (Accelerator Pedal Position Sensor)".
Is the inspection result normal?
YES >> GO TO 14.
NO >> GO TO 8.
8.REPLACE ACCELERATOR PEDAL ASSEMBLY
Replace accelerator pedal assembly.
Refer to ACC-3, "
MODELS WITHOUT DISTANCE CONTROL ASS IST SYSTEM : Removal and Installation"
(Without distance control assist system)
Refer to ACC-4, "
MODELS WITH DISTANCE CONTROL ASSI ST SYSTEM : Removal and Installation" (With
distance control assist system).
>> INSPECTION END
9.CHECK EVAP CONTROL SYSTEM PRESSURE SENSOR GROUND CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between EVAP control system pressure sensor harness connector and ECM har-
ness connector.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 11.
NO >> GO TO 10.
10.DETECT MALFUNCTIONING PART
Check the following.
 Harness for open or short between EVAP control system pressure sensor and ECM
E80 133EVAP control system pressure sen-
sor
C17 3
Battery current sensor E63 2
Refrigerant pressure sensor E77 1
131 APP sensor 2 (Without ICC) E110 1
APP sensor 2 (with ICC) E67 9
ECM Sensor
Connector Terminal Name Connector Terminal
EVAP control system pressure sensor ECM
Continuity
Connector Terminal Connector Terminal
C17 1 E80 150 Existed
Revision: 2010 May2011 QX56

P0453 EVAP CONTROL SYSTEM PRESSURE SENSOREC-341
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P0453 EVAP CONTROL SYSTEM
PRESSURE SENSOR
DTC LogicINFOID:0000000006288322
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Always perform test at a temperature of 5 °C (41 °F) or more.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
WITH CONSULT-III
1. Start engine and warm it up to normal operating temperature.
2. Turn ignition switch OFF and wait at least 10 seconds.
3. Turn ignition switch ON.
4. Turn ignition switch OFF and wait at least 10 seconds.
5. Turn ignition switch ON.
6. Select “DATA MONITOR” mode with CONSULT-III.
7. Check that “FUEL T/TM P SE” is more than 0°C (32 °F).
8. Start engine and wait at least 20 seconds.
9. Check 1st trip DTC.
WITH GST
1. Start engine and warm it up to normal operating temperature.
2. Set voltmeter probes to ECM harness connector terminals under the following conditions.
3. Check that the voltage is less than 4.2 V.
DTC No. Trouble diagnosis name
(Trouble diagnosis content) DTC detecting condition Possible cause
P0453 EVAP SYS PRES SEN
(EVAP control system pres-
sure sensor high input) An excessively high voltage
from the sensor is sent to
ECM.  Harness or connectors
(EVAP control system pressure sensor circuit is short-
ed.)
(Crankshaft position sensor circuit is open or shorted.)
[Camshaft position sensor (bank 1) circuit is shorted.]
(Accelerator pedal position sensor 2 circuit is shorted.)
(Battery current sensor circuit is shorted.)
(Refrigerant pressure sensor circuit is shorted.)
 EVAP control system pressure sensor
 Crankshaft position sensor
 Camshaft position sensor (bank 1)
 Accelerator pedal position sensor 2
 Battery current sensor
 Refrigerant pressure sensor
 EVAP canister vent control valve
 EVAP canister
 Rubber hose from EVAP canister vent control valve to
vehicle frame
ECM Ground
Connector +–
Terminal Terminal
E80 134
(Fuel tank temperature sensor signal) 175
Revision: 2010 May2011 QX56

P0453 EVAP CONTROL SYSTEM PRESSURE SENSOREC-343
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair short to ground or short to power in harness or connectors.
6.CHECK COMPONENTS
Check the following.
 Crankshaft position sensor (Refer to EC-301, "
Component Inspection (Crankshaft Position Sensor)".)
 Camshaft position sensor (bank 1) (Refer to EC-306, "
Component Inspection (Camshaft Position Sensor)".)
 Battery current sensor (Refer to EC-427, "
Component Inspection (Battery Current Sensor)".)
 Refrigerant pressure sensor (Refer to EC-520, "
Component Function Check".)
Is the inspection result normal?
YES >> GO TO 7.
NO >> Replace malfunctioning component.
7.CHECK APP SENSOR
Refer to EC-470, "
Component Inspection (Accelerator Pedal Position Sensor)".
Is the inspection result normal?
YES >> GO TO 19.
NO >> GO TO 8.
8.REPLACE ACCELERATOR PEDAL ASSEMBLY
Replace accelerator pedal assembly.
Refer to ACC-3, "
MODELS WITHOUT DISTANCE CONTROL ASSI ST SYSTEM : Removal and Installation"
(Without distance control assist system)
Refer to ACC-4, "
MODELS WITH DISTANCE CONTROL ASSI ST SYSTEM : Removal and Installation" (With
distance control assist system).
>> INSPECTION END
9.CHECK EVAP CONTROL SYSTEM PRESSURE SENSOR GROUND CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between EVAP control syst em pressure sensor harness connector and ECM har-
ness connector.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 11.
NO >> GO TO 10.
ECM Sensor
Connector Terminal Name Connector Terminal
F110 76 Crankshaft position sensor F74 1
77 Camshaft position sensor (bank 1) F84 1
E80 133EVAP control system pressure sen-
sor
C17 3
Battery current sensor E63 2
Refrigerant pressure sensor E77 1
131 APP sensor 2 (Without ICC) E110 1
APP sensor 2 (with ICC) E67 9
EVAP control system
pressure sensor ECM
Continuity
Connector Terminal Connector Terminal
C17 1 E80 150 Existed
Revision: 2010 May2011 QX56

EC-364
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0524 ENGINE OIL PRESSURE
P0524 ENGINE OIL PRESSURE
DTC LogicINFOID:0000000006288342
DTC DETECTION LOGIC
NOTE:
If DTC P0524 is displayed with DTC P0075 or P0081,
perform trouble diagnosis for DTC P0075 or P0081
first. Refer to EC-193, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING-I
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confi rm that battery voltage is between 10 V and 16 V at
idle.
>> GO TO 2.
2.PRECONDITIONING-II
Check oil level and oil pressure. Refer to LU-7, "
Inspection".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Proceed to LU-7, "
Inspection".
3.PERFORM DTC CONFIRMATION PROCEDURE
WITH CONSULT-III
1. Select “DATA MONITOR” mode with CONSULT-III.
2. Maintain the following conditions for at least 20 consecutive seconds.
CAUTION:
Always drive at a safe speed.
3. Check 1st trip DTC.
WITH GST
Follow the procedure “With CONSULT-III” above.
Is 1st trip DTC detected?
YES >> Proceed to EC-365, "Diagnosis Procedure"
DTC No.Trouble diagnosis name
(Trouble diagnosis content) Detecting condition Possible cause
P0524 ENGINE OIL PRESSURE
(Engine oil pressure too low) Engine oil pressure is low because
there is a gap between angle of target
and phase-control angle.  Engine oil pressure or level too low
 Crankshaft position sensor
 Camshaft position sensor
 Intake valve timing control solenoid valve
 Accumulation of debris to the signal pick-up por-
tion of the camshaft
 Timing chain installation
 Foreign matter caught in the oil groove for intake valve timing control
ENG SPEED More than 1,700 rpm
COOLAN TEMP/S More than 70 °C (158 °F)
Selector lever 1st or 2nd position
Driving location uphill Driving vehicle uphill
(Increased engine load will help maintain the driving
conditions required for this test.)
Revision: 2010 May2011 QX56

P0524 ENGINE OIL PRESSUREEC-365
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006288343
1.CHECK OIL PRESSURE WARNING LAMP
1. Start engine.
2. Check oil pressure warning lamp and confirm it is not illumi- nated.
Is oil pressure warning lamp illuminated?
YES >> Proceed to LU-7, "Inspection".
NO >> GO TO 2.
2.CHECK INTAKE VALVE TIMING CONTROL SOLENOID VALVE
Refer to EC-179, "
Component Inspection (Intake Valve Timing Control Solenoid Valve)".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace malfunctioning intake valve timing control solenoid valve.
3.CHECK CRANKSHAFT POSITION SENSOR
Refer to EC-301, "
Component Inspection (Crankshaft Position Sensor)".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Replace crankshaft position sensor.
4.CHECK CAMSHAFT PO SITION SENSOR
Refer to EC-306, "
Component Inspection (Camshaft Position Sensor)".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Replace malfunctioning camshaft position sensor.
5.CHECK CAMSHAFT SPROCKET (SIGNAL PLATE)
Check the following.
 Accumulation of debris to the signal plate of camshaft sprocket (INT)
 Chipping signal plate of camshaft sprocket (INT)
Is the inspection result normal?
YES >> GO TO 6.
NO >> Remove debris and clean the signal plate of camshaft sprocket (INT) or replace camshaft sprocket (INT).
Refer to EM-61, "
Exploded View".
6.CHECK TIMING CHAIN INSTALLATION
Check service records for any recent repairs that may cause timing chain misaligned.
Are there any service records that may cause timing chain misaligned?
YES >> Check timing chain installation. Refer to EM-61, "Exploded View".
NO >> GO TO 7.
7.CHECK LUBRICATION CIRCUIT
Perform “Inspection of Camshaft Sprocket (INT) Oil Groove”. Refer to LU-7, "
Inspection".
PBIA8559J
JMBIA0962ZZ
Revision: 2010 May2011 QX56

P0643 SENSOR POWER SUPPLYEC-381
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P0643 SENSOR POWER SUPPLY
DTC LogicINFOID:0000000006217882
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confi rm that battery voltage is 8 V or more at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and let it idle for 1 second.
2. Check DTC.
Is DTC detected?
YES >> Go to EC-381, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006217883
1.CHECK ACCELERATOR PEDAL POSITION SENSOR 1 POWER SUPPLY CIRCUIT
1. Disconnect accelerator pedal position (APP) sensor harness connector.
2. Turn ignition switch ON.
3. Check the voltage between APP sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 6.
NO >> GO TO 2.
2.CHECK SENSOR POWER SUPPLY CIRCUIT
Check harness for short to power and short to ground, between the following terminals.
DTC No.Trouble diagnosis name
(Trouble diagnosis content) DTC detecting condition Possible cause
P0643 SENSOR POWER/CIRC
(Sensor power su
pply circuit
short) ECM detects that the voltage of
power source for sensor is ex-
cessively low or high.  Harness or connectors
(Accelerator pedal position sensor 1 circuit is shorted.)
[Camshaft position sensor (bank 2) circuit is shorted.]
[Manifold absolute pressure (MAP) sensor circuit is
shorted.]
(Throttle position sensor circuit is shorted.)
 Accelerator pedal position sensor 1
 Camshaft position sensor (bank 2)
 Manifold absolute pressure (MAP) sensor
 Throttle position sensor
APP sensor Ground Voltage (V)
Connector Terminal
E110 (Without ICC) 2 Ground Approx. 5
E67 (With ICC) 12
Revision: 2010 May2011 QX56
