Install the special tool.
Special Tool(s): 303-1482






















CAUTIONS:


Apply the torque to the end of the special tool.


Make sure that the torque wrench is aligned with the
special tool as illustrated in the graphic.
Install the torque wrench to the special tool.
Torque: 35 Nm www.JagDocs.com

26. CAUTION: Make sure that the torque wrench does not
move whilst tightening the VVT bolts.

first. NOTE: Make sure to tighten the inlet VVT unit bolts
Torque: 32 Nm












27.
28.
Remove the special tool.

























Remove the special tool.

29.
30.
31.
Remove the special tool.
Special Tool(s): 303-1447















Install the special tool.
Special Tool(s): 303-1448
















CAUTION: Install the crankshaft pulley bolt with an
M16 washer to prevent damage to the crankshaft on
installation.
Torque: 50 Nm

32.
Remove the special tool.
Special Tool(s): 303-1448











33. Rotate the engine two complete turns clockwise.


34.
















35. CAUTION: Only rotate the crankshaft clockwise.
Install the special tool.
Special Tool(s): 303-1447













Install the special tool.
Special Tool(s): 303-1448

36.
37.
38.


























Remove the special tool.
Special Tool(s): 303-1448














CAUTIONS:


If the special tool cannot be installed, return to step
22 of the installation until the special tool 303-1445 is
installed correctly.


If directed to step 22, make sure that the VVT unit
retaining bolts are loosened prior to installing the special
tool(s).
Install the special tool.

Special Tool(s): 303-1445

39.
















40.
41. CAUTION: If the special tool cannot be installed, the
timing chain installation steps must be repeated.
Install the special tool.














Remove the special tool.

























Remove the special tool. www.JagDocs.com

42.
43.
Remove the special tool.
Special Tool(s): 303-1447














Torque: 10 Nm













44.
Refer to: Timing Cover (303-01C Engine - V8 5.0L Petrol, Removal and Installation).

45. Connect the battery ground cable.

Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).

Engine - V8 S/C 5.0L Petrol - Valve Cover LH
Removal and Installation Published: 11-May-2011


Removal


NOTE: Removal steps in this procedure may contain installation details.

1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).

2. Refer to: Supercharger (303-12D Intake Air Distribution and Filtering - V8 S/C 5.0L Petrol, Removal and Installation).

3. Refer to: Secondary Bulkhead Panel LH - TDV6 3.0L Diesel /V8 5.0L Petrol/V8 S/C 5.0L Petrol (501-02 Front End Body Panels, Removal and Installation).

4. Refer to: Air Cleaner Outlet Pipe LH (303-12D Intake Air Distribution and Filtering - V8 S/C 5.0L Petrol, Removal and Installation).

5. Refer to: Fuel Rail LH (303-04E Fuel Charging and Controls - V8 S/C 5.0L Petrol, Removal and Installation).

6. Torque: 10 Nm 303-1446
Valve Cover Alignment Tool Special Tool(s)

7.
Installation

1. CAUTIONS:


Use only a plastic scraper when removing the sealing
material.


Use lint free cloth.


Make sure that the mating faces are clean and free of
corrosion and foreign material.


Installation of the valve cover and tightening must be
carried out within 7 minutes of applying the sealant.
NOTES:


Some variation in the illustrations may occur, but the
essential information is always correct.


Apply two beads of silcone gasket sealant (Loctite
5901) as shown on the illustration. The application of the
sealant must be 1.5mm diameter 12mm long. Install the
valve cover immediately after applying the sealant. The
cover should be fitted directly to the head without smearing
the sealant or the seals.
To install, reverse the removal procedure.

3. NOTE: Tighten the bolts in the indicated sequence.
Torque: 13 Nm
