JAGUAR XFR 2010 1.G Workshop Manual

2. NOTE: Lubricate and install the new O-ring seals.

Torque:
M8 25 Nm M6 12 Nm



















3. NOTE: Lubricate and install the new O-ring seals.
4. Torque: 12 Nm www.JagDocs.com

6. NOTE: Tsubaki timing drive only.
Install the lower timing chain making sure the coloured
chain links align correctly with the fuel rail high-pressure
fuel pumps camshaft and crankshaft sprocket markings.

7. CAUTION: Make sure that the tensioner spring is
correctly located.


NOTE: Tsubaki timing drive only.
Torque: 21 Nm









8. NOTE: INA timing drive only.
Install the lower timing chain making sure the coloured
chain links align correctly with the fuel rail high-pressure
fuel pumps camshaft and crankshaft sprocket markings.

9. CAUTION: Make sure that the tensioner spring is
correctly located.


NOTE: INA timing drive only.
Torque: 21 Nm













10. Refer to: Oil Pan Extension (303-01C Engine - V8 5.0L Petrol, Removal and Installation).

11. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).

Engine - V8 S/C 5.0L Petrol - Timing Cover
Removal and Installation

Removal


NOTE: Removal steps in this procedure may contain installation details. Published: 12-Sep-2011

1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).


2. WARNING: Make sure to support the vehicle with axle stands.
Raise and support the vehicle.

3. Refer to: Accessory Drive Belt (303-05D Accessory Drive - V8 S/C 5.0L Petrol, Removal and Installation).

4. Refer to: Accessory Drive Belt Tensioner (303-05D Accessory Drive - V8 S/C 5.0L Petrol, Removal and Installation).

5. Refer to: Thermostat Housing - Vehicles With: Supercharger (303-03C Engine Cooling - V8 5.0L Petrol/V8 S/C 5.0L Petrol, Removal and
Installation).

6. Refer to: Valve Cover LH (303-01D Engine - V8 S/C 5.0L Petrol, Removal and Installation).

7. Refer to: Valve Cover RH (303-01D Engine - V8 S/C 5.0L Petrol, Removal and Installation).

8. Refer to: Crankshaft Pulley (303-01D Engine - V8 S/C 5.0L Petrol, Removal and Installation).


9. NOTE: Engine shown removed for clarity.

10.
















11.
12. NOTE: Engine shown removed for clarity.

















NOTE: Engine shown removed for clarity.

























NOTE: Engine shown removed for clarity. www.JagDocs.com

Installation

3. NOTE: Tighten the bolts in the indicated sequence.

Torque: 12 Nm





















4. NOTE: Tighten the bolts in the indicated sequence.
Torque: 12 Nm

5. CAUTION: Make sure that the mating faces are clean
and free of foreign material.

Apply RTV sealant WSE-M4G323-A6 (Loctite 5901G) to the
areas shown, and tighten the bolts within 7 minutes.




















6. CAUTION: Make sure that the mating faces are clean
and free of foreign material.

Install the bolts, but do not tighten fully at this stage.

7.
















8.
9.
10. NOTE: Tighten the bolts in the indicated sequence.

Torque: 12 Nm













Torque: 12 Nm
















Torque: 12 Nm
















Torque: 12 Nm
