JAGUAR XFR 2010 1.G Workshop Manual

DTC Description Possible Causes Action security. Clear the DTC and retest. If the
problem persists, renew the driver door
window switch B11F6-11
Driver Folding Mirror
Motor - Circuit short to
ground
Driver folding mirror motor
circuit short circuit to ground
Mirror motor failure
Refer to the electrical circuit diagrams and
check the mirror fold circuit between the
drivers door module and the mirror
assembly. Repair as necessary B11F6-15
Driver Folding Mirror
Motor - Circuit short to
battery or open
Driver mirror heater output
circuit short circuit to power or
open circuit
Mirror motor failure
Refer to the electrical circuit diagrams and
check the mirror fold circuit between the
drivers door module and the mirror
assembly. Repair as necessary B11F7-11
Passenger Folding Mirror
Motor - Circuit short to
ground
Passenger folding mirror motor
circuit short circuit to ground
Mirror motor failure
Refer to the electrical circuit diagrams and
check the mirror fold circuit between the
passenger door module and the mirror
assembly. Repair as necessary B11F7-15
Passenger Folding Mirror
Motor - Circuit short to
battery or open
Passenger mirror heater output
circuit short circuit to power or
open circuit
Mirror motor failure
Refer to the electrical circuit diagrams and
check the mirror fold circuit between the
passenger door module and the mirror
assembly. Repair as necessary B1222-23
Master Lock/Unlock
Switch - Signal stuck
low
Master lock or unlock switch
digital input circuit - signal
stuck low
Refer to the electrical circuit diagrams and
check master lock and unlock switch digital
input circuits for short to ground, open
circuit B1A98-83
LIN Bus Circuit #1 -
Value of signal
protection calculation
incorrect
Value of signal protection
calculation incorrect
Refer to the electrical circuit diagrams and
check the LIN Bus circuit between the rear
door control unit and the Driver Door
Module. Check the connectors for integrity
and security. Clear the DTC and retest. If
the problem persists, renew the rear door
control module B1A98-86
LIN Bus Circuit #1 -
Signal invalid
Signal invalid
Refer to the electrical circuit diagrams and
check the LIN Bus circuit between the rear
door control unit and the Driver Door
Module. Check the connectors for integrity
and security. Clear the DTC and retest. If
the problem persists, renew the rear door
control module B1A98-87
LIN Bus Circuit #1 -
Missing message
Missing message
Refer to the electrical circuit diagrams and
check the LIN Bus circuit between the rear
door control unit and the Driver Door
Module. Check the connectors for integrity
and security. Clear the DTC and retest. If
the problem persists, renew the rear door
control module B1C09-11
Driver Left/Right Mirror
Motor Circuit - Circuit
short to ground
Driver mirror adjustment motor
circuit short circuit to ground
Mirror left/right motor failure
Refer to the electrical circuit diagrams and
check the mirror motor circuit between the
drivers door module and the mirror
assembly. Repair as necessary B1C09-15
Driver Left/Right Mirror
Motor Circuit - Circuit
short to battery or open
Driver mirror adjustment motor
circuit short circuit to power or
open circuit
Mirror left/right motor failure
Refer to the electrical circuit diagrams and
check the mirror motor circuit between the
drivers door module and the mirror
assembly. Repair as necessary B1C10-11
Driver Up/Down Mirror
Motor Circuit - Circuit
short to ground
Driver mirror adjustment motor
circuit short circuit to ground
Mirror motor failure
Refer to the electrical circuit diagrams and
check the mirror motor circuit between the
drivers door module and the mirror
assembly. Repair as necessary

DTC Description Possible Causes Action B1C10-15
Driver Up/Down Mirror
Motor Circuit - Circuit
short to battery or open
Driver mirror adjustment motor
circuit short circuit to power or
open circuit
Mirror motor failure
Refer to the electrical circuit diagrams and
check the mirror motor circuit between the
drivers door module and the mirror
assembly. Repair as necessary B1C11-11
Passenger Left/Right
Mirror Motor Circuit -
Circuit short to ground
Passenger mirror adjustment
motor circuit short circuit to
ground
Mirror motor failure
Refer to the electrical circuit diagrams and
check the mirror motor circuit between the
passenger door module and the mirror
assembly. Repair as necessary B1C11-15
Passenger Left/Right
Mirror Motor Circuit -
Circuit short to battery
or open
Passenger mirror adjustment
motor circuit short circuit to
power or open circuit
Mirror motor failure
Refer to the electrical circuit diagrams and
check the mirror motor circuit between the
passenger door module and the mirror
assembly. Repair as necessary B1C12-11
Passenger Up/Down
Mirror Motor Circuit -
Circuit short to ground
Passenger mirror adjustment
motor circuit short circuit to
ground
Mirror motor failure
Refer to the electrical circuit diagrams and
check the mirror motor circuit between the
passenger door module and the mirror
assembly. Repair as necessary B1C12-15
Passenger Up/Down
Mirror Motor Circuit -
Circuit short to battery
or open
Passenger mirror adjustment
motor circuit short circuit to
power or open circuit
Mirror motor failure
Refer to the electrical circuit diagrams and
check the mirror motor circuit between the
passenger door module and the mirror
assembly. Repair as necessary B1C13-11
Driver Up/Down Mirror
Motor Feedback Circuit -
Circuit short to ground
Driver mirror adjustment motor
circuit short circuit to ground
Mirror motor failure
Refer to the electrical circuit diagrams and
check the mirror motor circuit between the
driver door module and the mirror assembly.
Repair as necessary B1C13-15
Driver Up/Down Mirror
Motor Feedback Circuit -
Circuit short to battery
or open
Driver mirror adjustment motor
circuit short circuit to power or
open circuit
Mirror motor failure
Refer to the electrical circuit diagrams and
check the mirror motor circuit between the
driver door module and the mirror assembly.
Repair as necessary B1C14-11
Driver Left/Right Mirror
Motor Feedback Circuit -
Circuit short to ground
Driver mirror adjustment motor
circuit short circuit to ground
Mirror motor failure
Refer to the electrical circuit diagrams and
check the mirror motor circuit between the
driver door module and the mirror assembly.
Repair as necessary B1C14-15
Driver Left/Right Mirror
Motor Feedback Circuit -
Circuit short to battery
or open
Driver mirror adjustment motor
circuit short circuit to power or
open circuit
Mirror motor failure
Refer to the electrical circuit diagrams and
check the mirror motor circuit between the
driver door module and the mirror assembly.
Repair as necessary B1C15-11
Passenger Up/Down
Mirror Motor Feedback
Circuit - Circuit short to
ground
Passenger mirror adjustment
motor circuit short circuit to
ground
Mirror motor failure
Refer to the electrical circuit diagrams and
check the mirror motor circuit between the
passenger door module and the mirror
assembly. Repair as necessary B1C15-15
Passenger Up/Down
Mirror Motor Feedback
Circuit - Circuit short to
battery or open
Passenger mirror adjustment
motor circuit short circuit to
power or open circuit
Mirror motor failure
Refer to the electrical circuit diagrams and
check the mirror motor circuit between the
passenger door module and the mirror
assembly. Repair as necessary B1C16-11
Passenger Left/Right
Mirror Motor Feedback
Circuit - Circuit short to
ground
Passenger mirror adjustment
motor circuit short circuit to
ground
Mirror motor failure
Refer to the electrical circuit diagrams and
check the mirror motor circuit between the
passenger door module and the mirror
assembly. Repair as necessary B1C16-15
Passenger Left/Right
Mirror Motor Feedback
Circuit - Circuit short to
battery or open
Passenger mirror adjustment
motor circuit short circuit to
power or open circuit
Mirror motor failure
Refer to the electrical circuit diagrams and
check the mirror motor circuit between the
passenger door module and the mirror
assembly. Repair as necessary

DTC Description Possible Causes Action B1C39-29
Key Lock Switch - Signal
invalid
Key lock switch signal invalid,
stuck/jammed
Switch held for longer than 20
seconds
Key lock switch circuit short to
ground (where connected)
Key lock switch failure
Central Junction Box fault
Refer to the electrical circuit diagrams and
the key lock switch circuit. Clear the DTC
and retest. If no other DTCs are present,
ignore this fault. If the DTC returns, suspect
an internal fault with the Central Junction
Box. Refer to the warranty policy and
procedures manual if a module is suspect B1D06-11
Left Turn Indicator -
Circuit short to ground
Left turn signal short circuit to
ground
Refer to the electrical circuit diagrams and
check left turn signal for short circuit to
ground B1D06-15
Left Turn Indicator -
Circuit short to battery
or open
Left turn signal short circuit to
power
Left turn signal high resistance,
open circuit
Refer to the electrical circuit diagrams and
check left turn signal for short circuit high
resistance, open circuit B1D07-11
Right Turn Indicator -
Circuit short to ground
Right turn signal short circuit to
ground
Refer to the electrical circuit diagrams and
check right turn signal for short circuit to
ground B1D07-15
Right Turn Indicator -
Circuit short to battery
or open
Right turn signal circuit short
circuit to power
Right turn signal circuit high
resistance, open circuit
Refer to the electrical circuit diagrams and
check right turn signal for short circuit high
resistance, open circuit B1D17-11 Battery Backed Sounder
- Circuit short to ground
Battery backed sounder
inclination sensor control circuit
- short to ground
Refer to the electrical circuit diagrams and
check battery backed sounder inclination
sensor control circuit for short to ground B1D18-11
Volumetric Sensor -
Circuit short to ground
Intrusion sensor module supply
circuit - short to ground
Carry out any pinpoint tests associated with
this DTC using the manufacturer approved
diagnostic system. Refer to the electrical
circuit diagrams and check intrusion sensor
module supply circuit for short to ground B1D97-96 Tilt Sensor - Component
internal failure
Component internal failure
Suspect the battery backed sounder, check
and install a new battery backed sounder as
required C1B14-11
Sensor Supply #1 -
Circuit short to ground
Short to ground
Refer to the electrical circuit diagrams and
test window sensor supply circuit for short
to ground C1B14-15
Sensor Supply #1 -
Circuit short to battery
or open
Short to power or open circuit
Refer to the electrical circuit diagrams and
test window sensor supply circuit for short
to power or open circuit C1B15-11 Sensor Supply Voltage A
- Circuit short to ground
Position sensor supply circuit
short to ground
Position sensor fault
Refer to the electrical circuit diagrams and
check the position sensor supply circuit
between the rear door module and the
window motor. If the problem persists,
renew the window motor C1B15-15 Sensor Supply Voltage A
- Circuit short to battery
or open
Position sensor supply circuit
short to power or open circuit
Position sensor fault
Refer to the electrical circuit diagrams and
check the position sensor supply circuit
between the rear door module and the
window motor. If the problem persists,
renew the window motor P1624-13
Anti-Theft System -
Circuit open
RJB anti-theft signal circuit -
open circuit
Refer to the electrical circuit diagrams and
check RJB anti-theft signal circuit for open
circuit

DTC Description Possible Causes Action P254F-13
Engine Hood Switch
Circuit/Open - Circuit
open
Hood ajar switch signal circuit -
open circuit
Refer to the electrical circuit diagrams and
check hood ajar switch signal circuit for open
circuit U0010-00
Medium Speed CAN
Communication Bus - No
sub type information
Medium speed CAN
communication Bus
Carry out network integrity test using
manufacturer approved diagnostic system.
Refer to electrical circuit diagrams and test
Medium speed CAN network for open, short
circuit and high resistance U0140-00
Lost Communication
With CJB - No sub type
information
Logged when subscribed CAN
message missing from CJB
Refer to the electrical circuit diagrams and
test power and ground supplies to Central
Junction Box. Check CAN network between
Driver Door Module and Central Junction
Box. Carry out network integrity test using
manufacturer approved diagnostic system U0208-00
Lost Communication
With Driver Seat Module
(DSM) - No sub type
information
Missing message
Refer to the electrical circuit diagrams and
test power and ground supplies to Driver
Seat Module. Check CAN network between
Driver Door Module and Driver Seat Module.
Carry out network integrity test using
manufacturer approved diagnostic system U0300-00
Internal Control Module
Software Incompatibility
- No sub type
information
Car configuration file mismatch
with vehicle specification
NOTE: After updating the car configuration
file, set the ignition to on and wait 30 seconds
before clearing the DTCs

Using the manufacturer approved diagnostic
system, check and up-date the car
configuration file as necessary U2002-24
Switch - Signal stuck
high
Signal stuck high
Clear DTC and re-test. If DTC remains,
install a new passenger side window switch U2004-24
Auxiliary Switch Pack -
Signal stuck high
Signal stuck high
Left or right rear door local
switch pressed for longer than
20 seconds
Switch circuit short to ground or
power
Refer to the electrical circuit diagrams and
check the left and right door switch circuits U2010-11
Switch Illumination -
Circuit short to ground
Switch illumination circuit short
to ground
Refer to electrical circuit diagrams and check
the switch illumination circuit U2012-08
Car Configuration
Parameter(s) - Bus
signal/message failures
Bus signal/message failures
Cycle the ignition status and re-test. If DTC
remains, re-configure the RJB using the
manufacturer approved diagnostic system U2013-24
Switch Pack - Signal
stuck high
Signal stuck high
Clear DTC and re-test. If DTC remains,
install a new driver side window switch pack U2014-44
Control Module
Hardware - Data
memory failure
Data Memory Failure
Install a new DDM/PDM, Refer to the
warranty policy and procedures manual if a
module is suspect U2100-00
Initial Configuration Not
Complete - No sub type
information
Driver/passenger door module is
not configured correctly
Re-configure the DDM/PDM using the
manufacturer approved diagnostic system U2101-00
Control Module
Configuration
Incompatible - No sub
type information
Car configuration file mismatch
with vehicle specification
Re-configure the module using the
manufacturer approved diagnostic system.
Check the configuration of the Car
Configuration File (CCF)

DTC Description Possible Causes Action U3003-62
Battery Voltage - Signal
compare failure
Mis-match of battery voltage, of
2 volts or lower, between
DDM/PDM and RJB
Check vehicle battery and charging system.
Refer to the relevant section in the
workshop manual. Refer to the electrical
circuit diagrams and check the power and
ground supply circuits to both modules www.JagDocs.com

Body Panels, Removal and Installation).

2. Remove the engine compartment brace.














3. Remove the secondary bulkhead LH panel.
For additional information, refer to: Secondary Bulkhead Panel LH - 3.0L NA V6 - AJ27 (501-02 Front End Body Panels, Removal and Installation).
4. Remove the pedestrian protection actuator.
Reposition the pedestrian protection hood actuator.

5. Release the pedestrian protection actuator bracket.
6. Remove the anti-theft alarm horn.














Installation

1. Install is the reverse of removal.
Tighten to 7 Nm.

Published: 11-May-2011
Anti-Theft - Passive - Anti-Theft - Passive - Component Location
Description and Operation
Component Location










































Item Description 1 CJB (central junction box) 2 Radio frequency receiver 3 RJB (rear junction box) 4 Keyless vehicle module 5 Low frequency antennae (3 off) 6 Start control module www.JagDocs.com
