Engine JAGUAR XFR 2010 1.G Workshop Manual

Engine - V8 S/C 5.0L Petrol - Lower Timing Cover
Removal and Installation Published: 19-Dec-2011


Removal

1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).


2. WARNING: Make sure to support the vehicle with axle stands.
Raise and support the vehicle.

3. Refer to: Crankshaft Pulley (303-01D Engine - V8 S/C 5.0L Petrol, Removal and Installation).

4.
5. 303-1433
Lower Timing Cover Alignment tool Special Tool(s) www.JagDocs.com

7. NOTE: Install the bolt finger tight before final
tightening.
Torque: 40 Nm












8. Torque: 40 Nm













9. Refer to: Crankshaft Pulley (303-01D Engine - V8 S/C 5.0L Petrol, Removal and Installation).

10. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).


11. CAUTION: Make sure that the vehicle is left for 5 minutes from
filling with oil and that the engine oil level is reading at least minimum
(by following Steps 14-18), before starting the engine.

Fill the engine with oil - for filling values on vehicles without
supercharger:

Refer to: Specifications (303-01C Engine - V8 5.0L Petrol, Specifications).
Fill the engine with oil - for filling values on vehicles with
supercharger:

Refer to: Specifications (303-01D Engine - V8 S/C 5.0L Petrol, Specifications).
Clean any residual engine oil from the oil filler cap area.


12. CAUTION: Make sure that the vehicle has been left for 5 minutes
from filling with oil.
Follow the Steps 14-18 before starting the engine.

13.
Start the engine and allow to run for 10 minutes, stop the
engine.

Check for leaks.

14. CAUTIONS:


Make sure that the selector lever and the gearshift mechanism are
in the park (P) position.


Make sure that the hood is open.
Turn the ignition on.

15.
Scroll through the trip menu to access the engine oil
level display. www.JagDocs.com

16.
17.
Press the cruise control cancel button twice within 2
seconds.
























The message center display will revert to the normal
display in the trip computer.
Scroll through the trip menu to access the engine oil
level display.
Check that the oil level display shows an oil level
reading.
Only after having started and run the engine for 10
minutes (as indicated in Step 13), switch off the
engine, then stabilizing for 10 minutes, take a
reading from the oil level display and, if necessary
top up with engine oil.





















18. NOTE: If instructed to follow Steps 14-18 in a previous step, return
to Step 13 and continue the procedure.
Turn the ignition off.

19. Allow 10 minutes for the engine oil level to stabilize if there has been
additional oil top up.

20.
NOTE: The following steps are to update the average
oil level value.
Turn the ignition on.
Press and hold the cruise control cancel button for
more than 2 seconds.














21.
The message center display will revert to the normal display in
the trip computer.

22. Turn the ignition off.

23. Turn the ignition on.

24.
Scroll through the trip menu to access the engine oil
level display.
Make sure that the average oil level value has now
been updated.





















25. Refer to: Air Deflector (501-02 Front End Body Panels, Removal and Installation).

Engine - V8 S/C 5.0L Petrol - Valves
Removal and Installation

Removal Published: 10-Jul-2013

1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).


2. WARNING: Do not work on or under a vehicle supported only by a jack.
Always support the vehicle on safety stands.
Raise and support the vehicle.

3. Refer to: Cylinder Head LH (303-01D Engine - V8 S/C 5.0L Petrol, Removal and Installation).

4. Refer to: Cylinder Head RH (303-01D Engine - V8 S/C 5.0L Petrol, Removal and Installation).

5.

Engine - V8 S/C 5.0L Petrol - Engine
Removal Published: 19-Nov-2013


NOTES:


Some variation in the illustrations may occur, but the essential information is always correct.


If a new engine is to be installed, remove the intake manifold to access the top transmission retaining bolts.

1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).


2. WARNING: Make sure to support the vehicle with axle stands.
Raise and support the vehicle.

3. Refer to: Cowl Vent Screen (501-02 Front End Body Panels, Removal and Installation).

4. Refer to: Air Cleaner LH (303-12C Intake Air Distribution and Filtering - V8 5.0L Petrol, Removal and Installation).

5. Refer to: Air Cleaner RH (303-12C Intake Air Distribution and Filtering - V8 5.0L Petrol, Removal and Installation).

6. Refer to: Cooling System Partial Draining, Filling and Bleeding - V8 S/C 5.0L Petrol (303-03C Engine Cooling - V8 5.0L Petrol/V8 S/C 5.0L Petrol, General Procedures).

7. Refer to: Air Conditioning (A/C) System Recovery, Evacuation and Charging (412-00 Climate Control System - General Information, General Procedures).

8. Refer to: Hood (501-02 Front End Body Panels, Removal and Installation).

9. Refer to: Cooling Fan Motor and Shroud - Vehicles With: Supercharger (303-03C Engine Cooling - V8 5.0L Petrol/V8 S/C 5.0L Petrol, Removal
and Installation).

10. Refer to: Transmission - V8 5.0L Petrol/V8 S/C 5.0L Petrol (307-01B Automatic Transmission/Transaxle - TDV6 3.0L Diesel /V8 5.0L Petrol/V8
S/C 5.0L Petrol, Installation). 303-1435
Engine Lifting Brackets Rear Special Tool(s)

38.
39.



















NOTE: This step requires the aid of another technician.

Using a suitable tool, remove the engine. www.JagDocs.com

Engine - V8 S/C 5.0L Petrol - Engine
Installation

NOTES:


Some variation in the illustrations may occur, but the essential information is always correct. Published: 19-Nov-2013

If a new engine is to be installed, remove the intake manifold to access the top transmission retaining bolts.


1. NOTE: This step requires the aid of another technician.
Install the engine assembly.





















2. Torque: 45 Nm

Petrol (211-02 Power Steering, Removal and Installation).
28. Refer to: Secondary Bulkhead Panel LH - TDV6 3.0L Diesel /V8 5.0L Petrol/V8 S/C 5.0L Petrol (501-02 Front End Body Panels, Removal and Installation).

29. Refer to: Secondary Bulkhead Panel RH - TDV6 3.0L Diesel /V8 5.0L Petrol/V8 S/C 5.0L Petrol (501-02 Front End Body Panels, Removal and Installation).

30. Refer to: Transmission - V8 5.0L Petrol/V8 S/C 5.0L Petrol (307-01B Automatic Transmission/Transaxle - TDV6 3.0L Diesel /V8 5.0L Petrol/V8
S/C 5.0L Petrol, Installation).

31. Refer to: Cooling Fan Motor and Shroud - Vehicles With: Supercharger (303-03C Engine Cooling - V8 5.0L Petrol/V8 S/C 5.0L Petrol, Removal
and Installation).

32. Refer to: Hood (501-02 Front End Body Panels, Removal and Installation).

33. Refer to: Air Conditioning (A/C) System Recovery, Evacuation and
