UCONNECT PHONE — IF
EQUIPPED
Uconnect Phone is a voice-activated, hands-
free, in-vehicle communications system.
Uconnect Phone allows you to dial a phone
number with your mobile phone using simple
voice commands (e.g., “Call”…“Mike”…
“Work” or “Dial”…“151-1234-5555”). Your mo-
bile phone’s audio is transmitted through your
vehicle’s audio system; the system will auto-
matically mute your radio when using the
Uconnect Phone.
NOTE:
The Uconnect Phone requires a mobile
phone equipped with the Bluetooth “Hands-
Free Profile”, Version 0.96 or higher. See the
Uconnect website for supported phones.
For Uconnect Customer Support visit
UconnectPhone.com.
Uconnect Phone allows you to transfer calls
between the system and your mobile phone as
you enter or exit your vehicle and enables you
to mute the system’s microphone for private
conversation.The Uconnect Phone is driven through your
Bluetooth “Hands-Free Profile” mobile phone.
Uconnect features Bluetooth technology - the
global standard that enables different electronic
devices to connect to each other without wires
or a docking station, so Uconnect Phone works
no matter where you stow your mobile phone
(be it your purse, pocket, or briefcase), as long
as your phone is turned on and has been paired
to the vehicle’s Uconnect Phone. The Uconnect
Phone allows up to seven mobile phones to be
linked to the system. Only one linked (or paired)
mobile phone can be used with the system at a
time. The system is available in many lan-
guages.
WARNING!
Any voice commanded system should be
used only in safe driving conditions following
all applicable laws, including laws regarding
phone use. Your attention should be focused
on safely operating the vehicle. Failure to do
so may result in a collision causing serious
injury or death.Uconnect Phone Button
The radio or steering wheel con-
trols (if equipped) will contain the
two control buttons (Uconnect
Phone
button and Voice Com-
mandbutton) that will enable
you to access the system. When you push the
button you will hear the word Uconnect followed
by a BEEP. The beep is your signal to give a
command.
Voice Command Button
Actual button location may vary
with the radio. The individual but-
tons are described in the “Opera-
tion” section.
The Uconnect Phone can be used with any
Hands-Free Profile certified Bluetooth mobile
phone. See the Uconnect website for supported
phones. Refer to your mobile service provider
or the phone manufacturer for details.
The Uconnect Phone is fully integrated with the
vehicle’s audio system. The volume of the
Uconnect Phone can be adjusted either from
67

the radio volume control knob or from the
steering wheel radio control (right switch), if so
equipped.
The radio display will be used for visual prompts
from the Uconnect Phone such as “CELL” or
caller ID on certain radios.
OperationVoice commands can be used to operate the
Uconnect Phone and to navigate through the
Uconnect Phone menu structure. Voice com-
mands are required after most Uconnect Phone
prompts. You will be prompted for a specific
command and then guided through the avail-
able options.
•Prior to giving a voice command, one must
wait for the beep, which follows the “Ready”
prompt or another prompt.
•For certain operations, compound com-
mands can be used. For example, instead of
saying “Setup” and then “Pair a Device,” the
following compound command can be said:
“Pair a Bluetooth Device.”
•For each feature explanation in this section,
only the compound form of the voice com-mand is given. You can also break the com-
mands into parts and say each part of the
command when you are asked for it. For
example, you can use the compound form
voice command “Phonebook New Entry,” or
you can break the compound form command
into two voice commands: “Phonebook” and
“New Entry.” Please remember, the
Uconnect Phone works best when you talk in
a normal conversational tone, as if speaking
to someone sitting a few feet/meters away
from you.
Voice Command Tree
Refer to “Voice Tree” in this section.
Help Command
If you need assistance at any prompt, or if you
want to know your options at any prompt, say
“Help” following the beep. The Uconnect Phone
will play some of the options at any prompt if
you ask for help.
To activate the Uconnect Phone, simply push
the Phone
button and follow the audible
prompts for directions. Uconnect Phone ses-
sions begin with a push of the Phone
button
on the radio control head.Cancel Command
At any prompt, after the beep, you can say
“Cancel” and you will be returned to the main
menu. However, in a few instances the system
will take you back to the previous menu.
Pair (Link) Uconnect Phone To A Mobile
Phone
To begin using your Uconnect Phone, you must
pair your compatible Bluetooth enabled mobile
phone.
To complete the pairing process, you will need
to reference your mobile phone Owner’s
Manual. The Uconnect website may also pro-
vide detailed instructions for pairing.
The following are general phone to Uconnect
Phone pairing instructions:
1. Activate the Bluetooth on your mobile
phone.
2. Push the Phone
button to begin.
3. After the “Ready” prompt and the following
beep, say “Device Pairing.”
4. When prompted, after the beep, say “Pair a
Device” and follow the audible prompts.
68

You will be asked to say a four-digit Personal
Identification Number (PIN), which you will later
need to enter into your mobile phone. You can
enter any four-digit PIN. You will not need to
remember this PIN after the initial pairing pro-
cess.
For identification purposes, you will be
prompted to give the Uconnect Phone a name
for your mobile phone. Each mobile phone that
is paired should be given a unique phone name.
You will then be asked to give your mobile
phone a priority level between one and seven,
with one being the highest priority. You can pair
up to seven mobile phones to your Uconnect
Phone. However, at any given time, only one
mobile phone can be in use, connected to your
Uconnect System. The priority allows the
Uconnect Phone to know which mobile phone
to use if multiple mobile phones are in the
vehicle at the same time. For example, if priority
three and priority five phones are present in the
vehicle, the Uconnect Phone will use the priority
three mobile phone when you make a call. You
can select to use a lower priority mobile phone
at any time (refer to “Advanced Phone Connec-
tivity” in this section).Dial By Saying A Number
•Push the Phone
button to begin.
•After the “Ready” prompt and the following
beep, say “Dial.”
•The system will prompt you to say the num-
ber you want to call.
•For example, you can say “151-1234-5555.”
•The Uconnect Phone will confirm the phone
number and then dial. The number will ap-
pear in the display of certain radios.
Call By Saying A Name
•Push the Phone
button to begin.
•After the “Ready” prompt and the following
beep, say “Call.”
•The system will prompt you to say the name
of the person you want to call.
•After the “Ready” prompt and the following
beep, say the name of the person you want
to call. For example, you can say “John Doe,”
where John Doe is a previously stored name
entry in the Uconnect phonebook or down-
loaded phonebook. To learn how to store aname in the phonebook, refer to “Add Names
to Your Uconnect Phonebook.”
•The Uconnect system will confirm the name
and then dial the corresponding phone num-
ber, which may appear in the display of
certain radios.
Phonebook Download — Automatic
Phonebook Transfer From Mobile Phone
If equipped and specifically supported by your
phone, Uconnect Phone automatically down-
loads names (text names) and number entries
from your mobile phone’s phonebook. Specific
Bluetooth Phones with Phone Book Access
Profile may support this feature. See Uconnect
website for supported phones.
•To call a name from the Uconnect Phone-
book or downloaded Phonebook, follow the
procedure in “Call by Saying a Name” sec-
tion.
•Automatic download and update, if sup-
ported, begins as soon as the Bluetooth
wireless phone connection is made to the
Uconnect Phone, for example, after you start
the vehicle.
69

•A maximum of 2,000 entries per phone will
be downloaded and updated every time a
phone is connected to the Uconnect Phone.
•Depending on the maximum number of en-
tries downloaded, there may be a short delay
before the latest downloaded names can be
used. Until then, if available, the previously
downloaded phonebook is available for use.
•Only the phonebook of the currently con-
nected mobile phone is accessible.
•Either the mobile phone’s phonebook or the
mobile phone’s SIM card phonebook is
downloaded.
•This downloaded phonebook cannot be ed-
ited or deleted on the Uconnect Phone.
These can only be edited on the mobile
phone. The changes are transferred and
updated to Uconnect Phone on the next
phone connection.
Add Names To Your Uconnect Phonebook
NOTE:
Adding names to the Uconnect Phonebook
is recommended when the vehicle is not in
motion.To add names to the Uconnect phonebook
using Voice Commands:
1. Push the Phone
button to begin.
2. After the “Ready” prompt and the following
beep, say “Phonebook New Entry.”
3. When prompted, say the name of the new
entry. Use of long names helps the Voice
Command and it is recommended. For ex-
ample, say “Robert Smith” or “Robert” in-
stead of “Bob.”
4. When prompted, enter the number designa-
tion (e.g., “Home,” “Work,” “Mobile,” or
“Other”). This will allow you to store multiple
numbers for each phonebook entry, if de-
sired.
5. When prompted, recite the phone number
for the phonebook entry that you are adding.
After you are finished adding an entry into the
phonebook, you will be given the opportunity to
add more phone numbers to the current entry or
to return to the main menu.The Uconnect Phone will allow you to enter up
to 32 names in the phonebook with each name
having up to four associated phone numbers
and designations. Each language has a sepa-
rate 32 name phonebook accessible only in that
language. In addition, if equipped and sup-
ported by your phone, Uconnect Phone auto-
matically downloads your mobile phone’s
phonebook.
Edit Uconnect Phonebook Entries
NOTE:
Editing phonebook entries is recommended
when the vehicle is not in motion. Automatic
downloaded phonebook entries cannot be
deleted or edited.
•Push the Phone
button to begin.
•After the “Ready” prompt and the following
beep, say “Phonebook Edit.”
•You will then be asked for the name of the
phonebook entry that you wish to edit.
•Next, choose the number designation (home,
work, mobile, or other) that you wish to edit.
70

•When prompted, recite the new phone num-
ber for the phonebook entry that you are
editing.
After you are finished editing an entry in the
phonebook, you will be given the opportunity to
edit another entry in the phonebook, call the
number you just edited, or return to the main
menu.
“Phonebook Edit” can be used to add another
phone number to a name entry that already
exists in the phonebook. For example, the entry
John Doe may have a mobile and a home
number, but you can add “John Doe’s” work
number later using the “Phonebook Edit” fea-
ture.
Delete Uconnect Phonebook Entry
NOTE:
Editing phonebook entries is recommended
when the vehicle is not in motion.
To delete a Uconnect phonebook entry using
Voice Commands:
1. Push the Phone
button to begin.2. After the “Ready” prompt and the following
beep, say “Phonebook Delete.”
3. After you enter the Phonebook Delete menu,
you will then be asked for the name of the
entry that you wish to delete. You can either
say the name of a phonebook entry that you
wish to delete or you can say “List Names” to
hear a list of the entries in the phonebook
from which you choose. To select one of the
entries from the list, push the Voice Com-
mand
button while the Uconnect Phone
is playing the desired entry and say “Delete.”
4. After you enter the name, the Uconnect
Phone will ask you which designation you
wish to delete: home, work, mobile, other, or
all. Say the designation you wish to delete.
•Note that only the phonebook entry in the
current language is deleted.
NOTE:
Automatic downloaded phonebook entries
cannot be deleted or edited.Delete/Erase “All” Uconnect Phonebook
Entries
To delete, or erase ALL Uconnect phonebook
entries using Voice Command:
1. Push the Phone
button to begin.
2. After the “Ready” prompt and the following
beep, say “Phonebook Erase All.”
•The Uconnect Phone will ask you to verify
that you wish to delete all the entries from
the phonebook.
3. After confirmation, the phonebook entries
will be deleted.
NOTE:
•Only the phonebook in the current lan-
guage is deleted.
•Automatic downloaded phonebook en-
tries cannot be deleted or edited.
List All Names In The Uconnect
Phonebook
To hear a list of ALL names in the Uconnect
phonebook using Voice Commands:
1. Push the Phone
button to begin.
71

2. After the “Ready” prompt and the following
beep, say “Phonebook List Names.”
•The Uconnect Phone will play the names
of all the phonebook entries, including the
downloaded phonebook entries, if avail-
able.
3. To call one of the names in the list, push the
Voice Command
button during the play-
ing of the desired name, and say “Call.”
NOTE:
The user can also exercise “Edit” or “De-
lete” operations at this point.
4. The Uconnect Phone will then prompt you as
to the number designation you wish to call.
•The selected number will be dialed.
Phone Call FeaturesThe following features can be accessed through
the Uconnect Phone if the feature(s) are avail-
able on your mobile service plan. For example,
if your mobile service plan provides three-way
calling, this feature can be accessed through
the Uconnect Phone. Check with your mobile
service provider for the features that you have.Answer Or Reject An Incoming Call — No
Call Currently In Progress
When you receive a call on your mobile phone,
the Uconnect Phone will interrupt the vehicle
audio system, if on, and will ask if you would like
to answer the call.
•Push the Phone
button to accept the call.
•To reject the call, push and hold the Phone
button until you hear a single beep, indi-
cating that the incoming call was rejected.
Answer Or Reject An Incoming Call — Call
Currently In Progress
If a call is currently in progress and you have
another incoming call, you will hear the same
network tones for call waiting that you normally
hear when using your mobile phone.
•
Push the Phonebutton to place the current
call on hold and answer the incoming call.
NOTE:
The Uconnect Phone compatible phones in
the market today do not support rejecting an
incoming call when another call is in prog-
ress. Therefore, the user can only answer an
incoming call or ignore it.Making A Second Call While Current Call Is
In Progress
To make a second call while you are currently
on a call, push the Voice Command
button
and say “Dial” or “Call” followed by the phone
number or phonebook entry you wish to call.
The first call will be on hold while the second call
is in progress. To go back to the first call, refer to
“Toggling Between Calls” in this section. To
combine two calls, refer to “Conference Call” in
this section.
Place/Retrieve A Call From Hold
To put a call on hold:
1. Push the Phone
button until you hear a
single beep.
•This indicates that the call is on hold.
•To bring the call back from hold, push and
hold the Phone
button until you hear a
single beep.
Toggling Between Calls
If two calls are in progress (one active and one
on hold), push the Phone
button until you
hear a single beep, indicating that the active
72

and hold status of the two calls have switched.
Only one call can be placed on hold at a time.
Conference Call
When two calls are in progress (one active and
one on hold):
1. Push and hold the Phone
button until you
hear a double beep, indicating that the two
calls have been joined into one conference
call.
Three-Way Calling
To initiate three-way calling, push the Voice
Command
button while a call is in progress,
and make a second phone call, as described
under “Making a Second Call While Current Call
is in Progress.” After the second call has estab-
lished, push and hold the Phone
button until
you hear a double beep, indicating that the two
calls have been joined into one conference call.
Call Termination
To end a call in progress:
1. Momentarily push the Phone
button.
•Only the active call(s) will be terminated
and if there is a call on hold, it will become
the new active call. If the active call isterminated by the phone far end, a call on
hold may not become active automatically.
This is cell phone-dependent.
2. To bring the call back from hold, push and
hold the Phone
button until you hear a
single beep.
Redial
To redial the last number called from your
mobile phone using Voice Command:
1. Push the Phone
button to begin.
2. After the “Ready” prompt and the following
beep, say “Redial.”
•The Uconnect Phone will call the last num-
ber that was dialed from your mobile
phone.
NOTE:
This may not be the last number dialed from
the Uconnect Phone.
Call Continuation
Call continuation is the progression of a phone
call on the Uconnect Phone after the vehicle
ignition has been switched to OFF. Call continu-ation functionality available on the vehicle can
be any one of three types:
1. After the ignition is switched to OFF, a call
can continue on the Uconnect Phone either
until the call ends, or until the vehicle battery
condition dictates cessation of the call on the
Uconnect Phone and transfer of the call to
the mobile phone.
2. After the ignition is cycled to OFF, a call can
continue on the Uconnect Phone for a cer-
tain duration, after which the call is automati-
cally transferred from the Uconnect Phone to
the mobile phone.
3. An active call is automatically transferred to
the mobile phone after the ignition is cycled
to OFF.
Uconnect Phone Features
Language Selection
To change the language that the Uconnect
Phone is using:
•Push the Phone
button to begin.
73

•After the “Ready” prompt and the following
beep, say the name of the language you wish
to switch to (English, Dutch, French, Ger-
man, Italian, or Spanish, if so equipped).
•Continue to follow the system prompts to
complete the language selection.
After selecting one of the languages, all
prompts and voice commands will be in that
language.
Emergency Assistance
If you are in an emergency and the mobile
phone is reachable:
•Pick up the phone and manually dial the
emergency number for your area.
If the phone is not reachable and the Uconnect
Phone is operational, you may reach the emer-
gency number as follows:
•Push the Phone
button to begin.
•After the “Ready” prompt and the following
beep, say “Emergency” and the Uconnect
Phone will instruct the paired mobile phone
to call the emergency number.NOTE:
•The default number is 112. The number
dialed may not be applicable with the
available mobile service and area.
•If supported, this number may be pro-
grammable on some systems. To do this,
push the Phone
button and say
“Setup,” followed by “Emergency.”
•The Uconnect Phone does slightly lower
your chances of successfully making a
phone call as to that for the mobile phone
directly.
WARNING!
To use your Uconnect Phone System in an
emergency, your mobile phone must be:
•Turned on.
•Paired to the Uconnect System.
•Have network coverage.
Breakdown Service — If Equipped
If you need Breakdown service:
1. Push the Phone
button to begin.2. After the “Ready” prompt and the following
beep, say “Breakdown service.”
NOTE:
The Breakdown service number has to be
setup before using. To setup, push the
Phone
button and say “Setup, Break-
down Service” and follow prompts.
Paging
To learn how to page, refer to “Working with
Automated Systems.” Paging works properly
except for pagers of certain companies, which
time out a little too soon to work properly with
the Uconnect Phone.
Voice Mail Calling
To learn how to access your voice mail, refer to
“Working with Automated Systems.”
Working With Automated Systems
This method is used in instances where one
generally has to push numbers on the mobile
phone keypad while navigating through an au-
tomated telephone system.
You can use your Uconnect Phone to access a
voice mail system or an automated service,
such as a paging service or automated cus-
74

tomer service line. Some services require im-
mediate response selection. In some instances,
that may be too quick for use of the Uconnect
Phone.
When calling a number with your Uconnect
Phone that normally requires you to enter in a
touch-tone sequence on your mobile phone
keypad, you can push the Voice Command
button and say the sequence you wish to
enter, followed by the word “Send.” For ex-
ample, if required to enter your PIN followed
with a pound, (3746#),youcanpush the
Voice Command
button and say, “3746#
Send.” Saying a number, or sequence of num-
bers, followed by “Send,” is also to be used for
navigating through an automated customer ser-
vice center menu structure, and to leave a
number on a pager.
You can also send stored Uconnect phonebook
entries as tones for fast and easy access to
voice mail and pager entries. To use this fea-
ture, dial the number you wish to call and then
push the Voice Command
button and say
“Send.” The system will prompt you to enter the
name or number and say the name of the
phonebook entry you wish to send. TheUconnect Phone will then send the correspond-
ing phone number associated with the phone-
book entry, as tones over the phone.
NOTE:
•You may not hear all of the tones due to
mobile phone network configurations.
This is normal.
•Some paging and voice mail systems
have system time out settings that are too
short and may not allow the use of this
feature.
Barge In — Overriding Prompts
The “Voice Command” button can be used
when you wish to skip part of a prompt and
issue your voice command immediately. For
example, if a prompt is asking “Would you like to
pair a phone, clear a...,” you could push the
Voice Command
button and say, “Pair a
Phone” to select that option without having to
listen to the rest of the voice prompt.Turning Confirmation Prompts ON/OFF
Turning confirmation prompts off will stop the
system from confirming your choices (e.g., the
Uconnect Phone will not repeat a phone num-
ber before you dial it).
1. Push the Phone
button to begin.
2. After the “Ready” prompt and the following
beep, say one of the following:
•“Setup Confirmation Prompts On”
•“Setup Confirmation Prompts Off”
Phone And Network Status Indicators
If available on the radio and/or on a premium
display such as the instrument panel cluster,
and supported by your mobile phone, the
Uconnect Phone will provide notification to in-
form you of your phone and network status
when you are attempting to make a phone call
using Uconnect Phone. The status is given for
network signal strength, phone battery strength,
etc.
75

Dialing Using The Mobile Phone Keypad
You can dial a phone number with your mobile
phone keypad and still use the Uconnect Phone
(while dialing via the mobile phone keypad, the
user must exercise caution and take precau-
tionary safety measures). By dialing a number
with your paired Bluetooth mobile phone, the
audio will be played through your vehicle’s
audio system. The Uconnect Phone will work
the same as if you dial the number using Voice
Command.
NOTE:
Certain brands of mobile phones do not
send the dial ring to the Uconnect Phone to
play it on the vehicle audio system, so you
will not hear it. Under this situation, after
successfully dialing a number the user may
feel that the call did not go through even
though the call is in progress. Once your call
is answered, you will hear the audio.
Mute/Un-Mute (Mute ON/OFF)
When you mute the Uconnect Phone, you will
still be able to hear the conversation comingfrom the other party, but the other party will not
be able to hear you. To mute the Uconnect
Phone:
•Push the Voice Command
button.
•Following the beep, say “Mute.”
To un-mute the Uconnect Phone:
•Push the Voice Command
button.
•Following the beep, say “Mute off.”
Advanced Phone Connectivity
Transfer Call To And From Mobile Phone
The Uconnect Phone allows ongoing calls to be
transferred from your mobile phone to the
Uconnect Phone without terminating the call.
To transfer an ongoing call from your Uconnect
Phone paired mobile phone to the Uconnect
Phone or vice versa using Voice Command:
1. Push the Voice Command
button and
say “Transfer Call.”Connect Or Disconnect Link Between The
Uconnect Phone And Mobile Phone
Your mobile phone can be paired with many
different electronic devices, but can only be
actively “connected” with one electronic device
at a time.
If you would like to connect or disconnect the
Bluetooth connection between your mobile
phone and the Uconnect Phone System, follow
the instructions described in your mobile phone
User’s Manual.
List Paired Mobile Phone Names
•Push the Phone
button to begin.
•After the “Ready” prompt and the following
beep, say “Setup Phone Pairing.”
•When prompted, say “List Phones.”
•The Uconnect Phone will play the phone
names of all paired mobile phones in order
from the highest to the lowest priority. To
“Select” or “Delete” a paired phone being
announced, push the Voice Command
button and say “Select” or “Delete.” Also,
see the next two sections for an alternate
way to “Select” or “Delete” a paired phone.
76
