KIA CARNIVAL 2007 Workshop Manual

4.Install the new seatback cover.(Refer to BD group)
5. Install the seat assembly, then connect the Side Airbag (SAB) harness connector.
6. Recline and slide the front seat forward fully, make sure the harness wires are not pinched or interfering with other
parts.
7. Reconnect the battery negative cable.
8. After installing the Side Airbag (SAB), confirm proper system operation:
a. Turn the ignition switch ON; the SRS indicator light should be turned on for about six seconds and then go off.

Seat Belt Pretensioner (BPT)

2007 > 2.7L V6 GASOLINE >
DESCRIPTION
The Seat Belt Pretensioners (BPT) are installed inside Center Pillar (LH & RH). When a vehicle crashes with a certain
degree of frontal impact, the pretensioner seat belt helps to reduce the severity of injury to the front seat occupants by
retracting the seat belt webbing. This prevents the front occupants from thrusting forward and hitting the steering
wheel or the instrument panel when the vehicle crashes.
Never attempt to measure the circuit resistance of the Seat Belt Pretensioner (BPT) even if you are using the
specified tester. If the circuit resistance is measured with a tester, the pretensioner will be ignited accidentally.
This will result in serious personal injury.

2007 > 2.7L V6 GASOLINE >
components

2007 > 2.7L V6 GASOLINE >
REMOVAL
1.Disconnect the battery negative cable, and wait for at least three minutes before beginning work.
2. Remove the door scuff trim. (Refer to BD group)
3. Remove the center pillar trim. (Refer to BD group)
4. Remove the lower anchor bolt.
5. Remove the upper anchor bolt.
6. Loosen the Seat Belt Pretensioner mounting bolts and remove the Seat Belt Pretensioner.
7.Disconnect the Seat Belt Pretensioner connector.
INSTALLATION
1.Disconnect the negative ( - ) cable from battery and wait for at least three minutes.
2. Remove ignition key from the vehicle.
3. Connect the Seat Belt Pretensioner connector.
4. Install the Seat Belt Pretensioner (BPT) with bolts.
Tightening Torque (Seat Belt Anchor Bolt)
: 4.0 ~ 5.5 kgf.m (39.2 ~ 53.9 Nm, 28.9 ~ 39.8 lb.ft)
5. Install the upper and lower anchor bolts.
Tightening Torque (Seat Belt Anchor Bolt)
: 4.0 ~ 5.5 kgf.m (39.2 ~ 53.9 Nm, 28.9 ~ 39.8 lb.ft)
6. Install the center pillar trim and door scuff trim.
7. Reconnect the negative battery cable.
8. After installing the Seat Belt Pretensioner (BPT), confirm proper system operation:
a. Turn the ignition switch ON; the SRS indicator light should be turned on for about six seconds and then go off.

Seat Belt Buckle Pretensioner

2007 > 2.7L V6 GASOLINE >
DESCRIPTION
The Seat Belt Buckle Pretensioners (BUPT) are installed in the right side of the driver seat and the left side of the
passenger seat. When a vehicle crashes with a certain degree of frontal impact, the seat belt buckle pretensioner
helps to reduce the severity of injury to the front seat occupants by retracting the seat belt buckle. This prevents the
front occupants from thrusting forward and hitting the steering wheel or the instrument panel when the vehicle crashes.
Never attempt to measure the circuit resistance of the Seat Belt Buckle Pretensioner (BUPT) even if you are
using the specified tester. If the circuit resistance is measured with a tester, the pretensioner will be ignited
accidentally. This will result in serious personal injury.

2007 > 2.7L V6 GASOLINE >
components

2007 > 2.7L V6 GASOLINE >
REMOVAL
1.Disconnect the battery negative cable, and wait for at least three minutes before beginning work.
2. Remove the front seat assembly. (Refer to BD group)
3. Loosen the Seat Belt Buckle Pretensioner mounting bolt and remove the Seat Belt Buckle Pretensioner.
INSTALLATION
1.Disconnect the battery negative cable and wait for at least three minutes.
2. Remove the ignition key from the vehicle.
3. Install the Seat Belt Buckle Pretensioner (BUPT) with the bolt.
Tightening torque
: 4.0 ~ 5.5 kgf.m (39.2 ~ 53.9 Nm, 28.9 ~ 39.8 lb.ft)
4. Install the front seat assembly.
a.Ensure that the harness is installed and routed properly to prevent damage to the wiring.
5. Reconnect the battery negative cable.
6. After installing the Seat Belt Buckle Pretensioner (BUPT), confirm proper system operation:
a. Turn the ignition switch ON; the SRS indicator light should be turned on for about six seconds and then go off.
