KIA TELLURIDE 2021 Features and Functions Guide

REMINDERS:
§ The Rear View Monitor is not a substitute for proper and safe backing-up procedures
§ The Rear View Monitor may not display every object behind the vehicle
§ Always drive carefully and use caution when backing up
See section 4 in the Owner’s Manual for more information. Images are for illustrative purposes only and may not reflect actual feature or
operation.
59
Rear View Monitor (RVM) System†6
The Rear View Monitor system is a supplemental system that displays the view behind the vehicle through the
Navigation screen* while the vehicle is in Reverse.
The Rear View Monitor activates when the:
§ Engine Start /Stop button is in the ON position
§ Gear Shift Lever is in the R (Reverse) position
P
R
N
DSHIFTL OCK
RELEASE
OTHER KEY FEATURES
OTHER KEY FE AT URE S
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLE TE
OPERATING INFORMATION AND SAFETY WARNINGS. *IF EQUIPPED
†LEG AL DISCL AIMERS ON BACK INSIDE COVER

60
Auto-Dimming Rearview Mirror
Designed to help reduce glare from a vehicle’s headlights located in the rear
and also to connect up to three electronic transmitters in one location.
REMINDER: Mirror indicator light will illuminate when automatic dimming is ON.
HomeLink® Setup - How to Sync Transmitter
If programming for the first time, begin with Step 1 (repeating this step will delete all information).
To program non-rolling and rolling code garage door openers and other devices:
1. Press and hold the left
A and center D buttons simultaneously until the indicator light C begins to
flash (to reprogram buttons, skip this step)
2. Press and hold the desired button
A, B or D and hold the button on the transmitter while it is
approximately 1 to 3 inches away from the mirror. The HomeLink® Indicator light C will flash rapidly
once the frequency signal has been successfully programmed
To finish programming rolling code garage door openers, complete these steps:
3. Locate the “learn” or “smart” button on the garage door’s motor head unit. Press and release the button
and complete Step 4 within 30 seconds
4. Firmly press and release the programmed HomeLink
® button up to three times
Operating HomeLink
®:
Press one of the programmed HomeLink
® buttons.
Erasing programmed buttons:
Press and hold the left
A and center D buttons simultaneously for approximately 20 seconds, and then
release both buttons within 30 seconds.
HomeLink® with Auto-Dimming Rearview Mirror† 13
A HomeLink® button B HomeLink® button C Indicator lightD HomeLink® button
E Glare detection sensorF Automatic dimming ONG Automatic dimming OFF
See section 4 in the Owner’s Manual for more
information.
If your garage door opener was manufactured
in 2011 or later, and you’re unable to program
your vehicle’s HomeLink
® system, you may
need to purchase a HomeLink Repeater Kit. For
more information, go to www.HomeLink.com or
call (800) 355-3515.
HOMELINK REARVIEW
MIRROR SETUP VIDEO
To view a video on your
mobile device, snap this
QR Code or visit the listed
website. Refer to page 2
for more information.
www.youtube.com/KiaFeatureVideos
QR CODE
§ You can reprogram a single HomeLink® button by repeating Step 2
§ Erasing programmed buttons will delete all trained transmitters
QUICK TIPS
OTHER KEY FEATURES
ABCDEFG
OTHER KEY
FE AT URE S
*IF EQUIPPED
†LEG AL DISCL AIMERS ON BACK INSIDE COVER

61
Sunvisor† 24
Use the sunvisor to shield direct light through the front or side windows.
Slide the sunvisor out and adjust as needed.
REMINDERS:
§ Sunvisor may not shield all direct light
§ Sunvisor may impair visibility if not adjusted properly
§
Be aware of seating position when adjusting or
swinging sunvisor around to or from the front or side
windows
§
Do not operate the vehicle if the sunvisor is impairing
your visibility
OTHER KEY FEATURES
OTHER KEY FE AT URE S
See section 4 in the Owner’s Manual for more information.
Hood Release Lever and Latch
Opening the Hood:
1.
Pull the hood release lever
A to unlatch the hood
2.
In the front of the vehicle, lift the hood slightly, push the secondary latch
B to the left inside of the hood’s
center and lift the hood
Closing the Hood:
Lower the hood about halfway and then press down to securely lock in place.
REMINDERS:
§ While lowering and closing, keep hands away from under the Hood
§ Open the Hood only after turning the engine off, on a flat surface, with the gear shift in P (Park) position and setting the parking brake
§ Make sure the hood is securely closed before driving
(Located on Driver side kick panel) (Located inside of Hood’s center)
AB
B
See section 4 in the Owner’s Manual for more information.
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLE TE
OPERATING INFORMATION AND SAFETY WARNINGS. *IF EQUIPPED
†LEG AL DISCL AIMERS ON BACK INSIDE COVER

62
Fuel Cap / Malfunction Indicator (Check Engine Light)Fuel Filler Lid Release
To access the Fuel Cap, press the Fuel Filler Lid to open. Tighten for ONE
CLICK to prevent malfunction indicator
from illuminating.
To open the Fuel Filler lid:
1. Press the right edge of the Fuel Filler lid
A
2. Pull the Fuel Filler lid out to fully open B
To open the Fuel Cap, turn it counterclockwise C
REMINDER: It is normal operation
when tightening to hear one
click and then when Fuel Cap is
released, it clicks back .
REMINDER: The fuel filler lid lock will unlock /open only when driver’s side
door is unlocked .
ONE-CLICK FUEL CAP
VIDEO
To view a video on your
mobile device, snap this
QR Code or visit the listed
website. Refer to page 2
for more information.
www.youtube.com/KiaFeatureVideos
QR CODE
§ Place the Fuel Cap on the inside of the Fuel Filler Lid when fueling D
QUICK TIP
OTHER KEY FEATURES
A
BC
D
OTHER KEY
FE AT URE S
See section 4 in the Owner’s Manual
for more information.
See section 4 in the Owner’s Manual for more information.
*IF EQUIPPED

63
A
Occupant Detection System (ODS) / Passenger Airbag Off Indicator† 2 ,1 6
ODS is designed to detect the presence and position of the front passenger and is designed to adjust or turn off
airbag deployment accordingly.
Depending on the situation and type of
accident, the system may:
§ Deploy airbag (Adult)
§ Not deploy the airbag (Unoccupied)
If the system determines that the airbag
should not be deployed, the “PASSENGER AIRBAG OFF” light will illuminate
D.
REMINDER: Do not allow an adult passenger to ride in the front seat when the Passenger Airbag Indicator is illuminated OFF because the
airbag will not deploy in the event of a crash. The driver must instruct the passenger to reposition her/himself in the seat.
See section 3 in the Owner’s Manual for more information.
Seat Belts† 2 ,19
To properly fasten your safety belts:
1.
Insert the belt tongue plate
A into the buckle until it clicks
2.
Position the lap portion of the belt across your lap as LOW ON THE HIPS as possible
C. Adjust the belt
to a SNUG FIT by pulling up on the shoulder portion B
Seat Belt Retractor Locks
Retractor locks allow lap/shoulder safety belts to remain unlocked during normal vehicle operation for
freedom of movement and increased comfort.
During a STRONG STOP, SUDDEN TURN OR CERTAIN COLLISIONS, seat belt retractors will automatically
lock the belts to help reduce the risk of injury.
For more detailed information regarding your vehicle’s s afety belts, please refer to section 3 in the Owner’s Manual and the separate brochure
titled “Understanding Your S afety Belt & Supplemental Restraint System.”
REMINDER:
For maximum protection, always wear your seatbelt.
2PASSENGER
AIR BAG OFF
(Located to the right of Climate Controls, Center Panel)
2PASSENGERAIR BAG OFF
§ The seat belt warning chime operates for the driver’s seat only
QUICK TIP
SAFETY
AB
C
D
SAFETY
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLE TE
OPERATING INFORMATION AND SAFETY WARNINGS. *IF EQUIPPED
†LEG AL DISCL AIMERS ON BACK INSIDE COVER

TELLURIDE NORMAL MAINTENANCE SCHEDULE
‡ If equipped.
A. See the Owner’s Manual for complete maintenance schedule.
B. And, if necessary, adjust, correct, clean or replace.
C. If TOP TIER detergent gasoline is not available, one bottle of
additive is recommended. Additives are available from your
authorized Kia dealer along with information on how to use
them. Do not mix other additives.
D. Both the fuel filter & fuel tank air filter are generally
considered to be maintenance free, depending on fuel quality
being used. However, periodic inspection is recommended. If
your vehicle is having issues like fuel flow restriction, power
surging, loss of power, difficulty starting, etc., replace the
fuel filter immediately and consult an authorized Kia dealer
for service.
E. Transfer case oil and rear axle oil should be changed anytime
they have been submerged in water. F.
Inspect for excessive tappet noise and/or engine vibration and
adjust if necessary.
G. The drive belt should be replaced when cracks occur or
tension is reduced excessively.
See the Owner’s Manu al for more details and complete
maintenance information, including severe maintenance
schedule. Warranty may be voided if maintenance schedule is
not followed. P
=Perform
R =Replace
I =Inspect
B
§ Check your Maintenance Schedule or schedule an
appointment with a dealer using your UVO link account by
logging into your Kia Access with UVO App or your account
on https://owners.Kia.com ( Vehicles equipped with UVO link
only – See page 45 for setup information)
QUICK TIP
64
MAINTENANCE
(up to 60,000 miles)AMAINTENANCE INTERVALS (MILES)
MAINTENANCE ITEMS 7, 5 0 0
15,000 22,500 30,000 3 7, 5 0 045,000 52,50060,000
Add fuel additives
CP PPPPPPP
Rotate tires PPPPPPPP
Engine oil and oil filter RRRRRRRR
Climate control air filter RRRRRRRR
Battery condition IIIIIIII
Brake lines, hoses and connections IIIIIIII
Brake discs and pads IIIIIIII
Vacuum hose IIIIIIII
Steering gear rack, linkage & boots IIIIIIII
Suspension ball joints and mounting bolts IIIIIIII
Air conditioner compressor/refrigerant IIIIIIII
Tire (pressure and tread wear) IIIIIIII
Bolts/nuts on chassis and body IIIIIIII
Exhaust system IIIIIIII
Air cleaner filter IIIR IIIR
Brake fluid IIIIIIII
Parking brake IIIIIIII
Drive shafts and boots IIII
Fuel tank air filte r

Driving while distracted is dangerous and should be avoided. Drivers should remain attentive to driving and always exercise caution when using the
steering-wheel-mounted controls while driving.
Driving while distracted can result in a loss of vehicle control that may lead to an accident, severe personal injury and death. The driver’s primary
responsibility is in the safe and legal operation of a vehicle, and any handheld devices, other equipment or vehicle systems which take the driver’s eyes,
attention and focus away from the safe operation of a vehicle or that are not permissible by law should never be used during operation of the vehicle.
Safety Features: No system, no matter how advanced, can compensate for all driver error and/or driving conditions. Always drive safely. 1. UVO link: Purchase/lease of certain 2020 and newer Kia vehicles with UVO link includes a complimentary 1-year subscription starting from new vehicle retail sale/
lease date as recorded by the dealer. After your complimentary 1-year UVO link subscription expires, continued access to the full suite of UVO link available on your
Kia will require a paid subscription at the then current subscription rate or your use of certain UVO link features may immediately terminate. Use of UVO is subject to
agreement to the UVO Privacy Policy (available at https://owners.kia.com/us/en/privacy-policy.html.html) and Terms of Service (available at https://owners.kia.com/
us/en/terms-of-service.html.html). UVO link is transferable to subsequent owner during the original UVO link service term. Only use UVO link when safe to do so. Kia
Access with UVO link App is available from the Apple
® App Store® or Google Play™. Kia Motors America, Inc. reserves the right to change or discontinue UVO link at
any time without prior notification or incurring any future obligation. Message and data rates may apply. Cellular and GPS coverage is required to use most features.
UVO link features may vary by model, model year, and trim level. Features, specifications, and fees are subject to change. For more on details and limitations, visit
https://owners.kia.com or your authorized Kia dealer. Apple and App Store are registered trademarks of Apple Inc. Google and logos are trademarks of Google, LLC.
2. Airbags: For maximum protection, always wear your seat belt.
3. Android Auto
™: Android Auto is a trademark of Google, Inc. Android™ is a
registered trademark of Google, Inc. Distracted driving can result in a loss
of vehicle control. Never use a handheld device or vehicle system that takes
your focus away from safe vehicle operation.
4. Apple CarPlay
®: Apple® and Apple CarPlay® are trademarks of Apple, Inc.,
registered in the U.S. and other countries. Apple CarPlay® runs on your
smartphone cellular data service. Normal data rates will apply.
5. Bluetooth
® Wireless Technology: The Bluetooth® word mark and logos are
registered trademarks owned by Bluetooth SIG Inc., and any such marks by
Kia is pursuant to license. A Bluetooth
® enabled cell phone is required to use
Bluetooth® wireless technology.
6. Driver Assist Features – Forward Collision-Avoidance Assist (FCA) /
Forward Collision Warning (FCW), Blind-Spot Collision-Avoidance
Assist (BCA), Blind-Spot View Monitor (BVM) System, Rear Cross-
Traffic Collision-Avoidance Assist (RCCA), Lane Keeping Assist (LKA)
/ Lane Departure Warning (LDW), Lane Follow Assist (LFA) System,
Rear View Monitor System, Reverse Parking Aid Function, Parking
Distance Warning-Reverse/Forward, Smart Cruise Control (SCC) with
Stop & Go, Safe Exit Assist (SEA) System , Rear Occupant Alert (ROA)
with Ultrasonic Sensors, Highway Driving Assist (HDA) System, Leading
Vehicle Departure Alert (LVDA): These features are not substitutes for safe
driving, and may not detect all objects surrounding vehicle. Always drive
safely and use caution.
7.
Driver Attention Warning (DAW): Driver Attention Warning is not a substitute
for safe driving and may not detect all instances of inattentive driving
practices. Failure to pay attention to travel conditions and vehicle operation
could result in loss of vehicle control. Always drive safely and use caution.
8. Electronic Stability Control (ESC) / Traction Control System (TCS) /
Hill-start Assist Control (HAC): No system, no matter how advanced, can
compensate for all driver error and/or driving conditions. Always drive safely.
9. Engine Start/Stop Button with Smart Key: Always come to a complete stop
before turning the engine on or off. However, if you have an emergency while
the vehicle is in motion and must turn the engine off, you can turn the engine
off to the ACC position by pressing the Start/Stop button for more than 3
seconds or 3 times in succession. If the vehicle is still moving, you can restart
the engine by pressing the Start/Stop button with the shift lever in Neu\
tral (N).
With the engine off, hydraulic power assist for steering and braking will be
disabled and the vehicle will be more difficult to control.
10. Front Seat Headrest Adjustment: Never attempt to adjust headrests when
vehicle is in motion.
11. Google Play
™ Store is a trademark of Google, Inc. ©2019 Google Inc. All
rights reserved. Google and the Google Logo are registered trademarks of
Google Inc.
12. Head-Up Display (HUD): Failure to pay attention to travel conditions and
vehicle operation could result in loss of vehicle control. Always drive safely
and use caution.
13. HomeLink
®: Homelink® is a registered trademark of Gentex Corporation.
14. iPhone®: iPhone is a registered trademark of Apple Inc. Distracted driving
can result in a loss of vehicle control. Never use a handheld device or vehicle
system that takes your focus away from safe vehicle operation.
15. Navigation: Distracted driving can result in a loss of vehicle control. When
operating a vehicle, never use a vehicle system that takes your focus away
from safe vehicle operation. Navigation is for information purposes only, and
Kia does not make any warranties about the accuracy of the information.
16. Occupant Detection System (ODS): Kia vehicles use a number of different
ODS types that vary by model.
17. Roadside Assist: 24-hour Enhanced Roadside Assistance is a service plan
provided by Kia Motors America, Inc. Certain limitations apply. Coverage
details are available in the Kia Warranty and Consumer Information Manual.
For access to Enhanced Roadside Assistance, a connected mobile phone via
Bluetooth
® within the cellular service coverage area is required.
18. Seat adjustments: Reclining the passenger seats can reduce the
effectiveness of the safety restraint system and may lead to additional injury
in an accident.
19. Seat belts: For maximum protection, always wear your seatbelt.
20. Seat warmers: Use extreme caution when using the seat warmers to avoid
burns. Refer to the Owner’s Manual for more information.
21. SiriusXM
®: SiriusXM Satellite Radio, SiriusXM Traffic and SiriusXM Travel
Link each require a subscription sold separately, or as a package, by SiriusXM
Radio Inc. If you decide to continue your service at the end of your
trial subscription, the plan you choose will automatically renew and
bill at then-current rates until you call 1-866-635-2349 to cancel. See
SiriusXM Customer Agreement for complete terms at www.siriusxm.
com. Other fees and taxes will apply. All fees and programming are subject
to change. Not all vehicles or devices are capable of receiving all services
offered by SiriusXM. Data displays and individual product availability vary
by vehicle hardware. Current information and features may not be available
in all locations, or on all receivers. Weather Forecast, Current Conditions
may not be available in all locations. Images above are for representative
purposes only and are not real products. For actual features and images of
real products, consult the vehicle manufacturer. SiriusXM is not responsible
for any errors or inaccuracies in the data services or their use in the vehicle.
Travel Link Stocks displays current price and daily delta of around 7,000
actively reported securities traded on the NYSE
®, NASDAQ® and AMEX®. The
service is delayed approximately 20 minutes. SiriusXM satellite service is
available only to those at least 18 years of age in the 48 contiguous USA,
DC, and Puerto Rico (with coverage limitations). SiriusXM Internet Radio
service is available throughout our satellite service area and in AK and HI.
©2020 SiriusXM Radio Inc. Sirius, XM and all related marks and logos are
trademarks of SiriusXM Radio Inc.
22. Smart Power LIftgate: Driving with the liftgate open may be unlawful and
can draw dangerous exhaust fumes into your vehicle.
23. Steering-wheel-mounted controls: Driving while distracted is dangerous
and should be avoided. Remain attentive to driving and be cautious when
using steering-wheel-mounted controls while driving.
24. Sunvisors: Sunvisor may not shield all direct light. Do not operate the vehicle
if sunvisor is impairing your visibility.
25. Tilt/Telescoping Steering Wheel: Never attempt to adjust steering wheel
position when vehicle is in motion.
26. Tire Pressure Monitoring System (TPMS): Even with Tire Pressure
Monitoring System, check tire pressure on a regular basis.
LEGAL DISCLAIMERS

Sales Consultant:
Sales Manager:
Customer:
Date:
Date:
Date:
TELLURIDE CUSTOMER DELIVERY CHECKLIST
Smart Cruise Control (SCC)
with Stop & Go* – page 20 Demonstrate operation
Key Feature Walkthrough
During Delivery
Multimedia USB Ports, Power Outlets
& USB Charger Ports – page 28
Blind-Spot Collision-Avoidance Assist
(BCA) – page 17
Clock Setup – page 28
Electronic Parking Brake (EPB) / Auto Hold* - pages 34-35
Engine S tar t / S top Button – page 27
Head-Up Display (HUD)* – page 10
Sunroof Operation – page 58
Parking Distance Warning - Reverse/Forward* – page 33
Passenger Air Bag Off Indicator –
page 63
Front Seat Headrest Adjustment* –
page 49
Seat Warmers/ Ventilated Seats –
page 48
Smart Key – page 56
Sunvisor – page 61
Tire Pressure Monitoring System
( TPMS) – page 9
Explain first service process and schedule first service appointment
Tour Parts & Service departments, introduce staff and explain value
of Kia Parts and Service
Review recommended maintenance schedule and maintenance
requirements to validate warranty
Review business hours
Review the Kia 10-year/100,000-mile warranty program
Ensure 100% satisfaction with sales and delivery process and no
problems with the vehicle
Confirm time and best contact number for initial dealer follow-up
Bluetooth® Wireless
Technology – pages 40-41 Demonstrate operation

Auto-Dimming Rearview Mirror
with HomeLink® – page 6 0
Front & Rear Windshield
Wipers & Washers – page 39
CRUISE
MODE
CRUISE
CANCEL
RES
OK SET
CRUISE
CANCEL
RES
OK SET
MODECRUISE
CANCEL
RES
OK SET
MODE
CANCEL
RES
OK SET
MODECRUISE
CANCEL
RES
OK SET
CRUISE
CANCEL
RES
OK SET
CRUISE
MODECRUISE
CANCEL
RES
OK SET
CRUISE
CANCEL
RES
OK SET
MODE CRUISE
CANCEL
RES
OK SET
MODE
CANCEL
RES
OK SET
MODECRUISE
CANCEL
RES
OK SET
CRUISE
CANCEL
RES
OK SET
HI
LO
OFF
*IF EQUIPPED

SHIFT
LOCK
RELEASEP•R•N•D•
+
•-
AUTOOFFA/CSYNC888ADS OFFAUTO888AUTO888
TELLURIDE CUSTOMER DELIVERY CHECKLIST
Confirm “Good Battery” with battery tester
Verify all tire pressures are to spec (see driver’s door label) LF LR RF RR
Verify proper operation of Smart Key* lock /unlock
Ensure floormats are snapped into place (if applicable)
Verify vehicle is clean (interior and exterior), in good condition, free of chips and scratches
Ensure all key documents are in the vehicle (Owner’s Manual, Warranty and Consumer Information booklet, Tire Warranty
booklet, Features & Functions Guide and any supplemental audio/video/navigation user’s guides)
Automatic Transmission /
Manual Shift Mode* – page 32
Automatic Climate Control – page 30 Demonstrate Air Flow Modes, Defog and Defrosting Windshield Fan Speed.
UVO link* – pages 46 For further system operation, refer to the Car Infotainment System Quick Reference Guide.
UVO link Activation – page 45
UVO Assistance – page 45
UVO link with Navigation System* – page 47 For further system operation, refer to the Car Infotainment
System Quick Reference Guide.
Android Auto™ / Apple CarPlay® Setup – page 44
Before Delivery
Key Feature Walkthrough
Owner’s Name: ____________________________________ VIN:
Mileage: __________________ Dealership Name: ______________________
Sales Consultant: _________________________________ Date: __________
MAP RADIO
N AV MEDIASEEK<
SETUPL
MAP RADIO
N AV MEDIASEEK<
SETUPL
MAP RADIO
N AV MEDIASEEK<
SETUPL
RADIO
MEDIA
SEEK
TRACKHOME
PHONE
SETUP

© 2020 Kia Motors America, Inc. All rights reserved. Part Number: ON210-PS-004
