LAND ROVER FREELANDER 2001 Workshop Manual
Manufacturer: LAND ROVER, Model Year: 2001, Model line: FREELANDER, Model: LAND ROVER FREELANDER 2001Pages: 1007, PDF Size: 23.47 MB
Page 461 of 1007
AUTOMATIC GEARBOX - JATCO
44-26 REPAIRS
26.Remove lower bolt securing gearbox.
27.Remove 2 upper bolts securing gearbox to
engine.
28.Release gearbox from 2 dowels.
29.Manoeuvre and lower gearbox to floor.
30.If necessary remove displaced gearbox closing
panel.31.Fit converter retaining plate and secure with
bolts.
Refit
1.Clean gearbox closing panel.
2.Ensure closing plate is in position on engine
and located on dowels.
3.Clean drive plate and ensure free from cracks
and distortion.
4.Clean gearbox to engine mating faces, dowels
and dowel holes.
5.Remove torque converter retaining plate.
6.Ensure torque converter is fully located in oil
pump drive by checking depth 'A' as illustrated.
Depth A = 27 mm.
7.Fit lifting chains to eyes and take weight of
gearbox.
8.Raise gearbox and engage with dowels. Fit
bolts securing gearbox to engine and tighten to
85 Nm (63 lbf.ft).
9.Fit bolt securing closing plate to gearbox and
tighten to 10 Nm (7.5 lbf.ft).
10.Remove lifting chains from gearbox.
11.Fit mounting bracket to gearbox and tighten
bolts to 85 Nm (63 lbf.ft).
12.Raise engine, align bracket to mounting and
tighten through bolt to 100 Nm (74 lbf.ft).
13.Remove engine support chains.
14.Align torque converter to drive plate and tighten
bolts to 45 Nm (33 lbf.ft).
15.Fit grommet to access plate.
16.Fit trunnion to selector lever, fit inner cable to
trunnion and secure outer cable to abutment
bracket.
17.Adjust selector cable.
+ AUTOMATIC GEARBOX - JATCO,
ADJUSTMENTS, Selector cable - adjust.
18.Connect gearbox harness multiplugs and fit to
clips.
19.Position earth lead to gearbox and tighten bolt
to 25 Nm (18 lbf.ft).
20.Connect intercooler hose and tighten clip.
M44 1687
M44 1686
M44 1689
Page 462 of 1007
AUTOMATIC GEARBOX - JATCO
REPAIRS 44-27
21.Fit new circlip to LH drive shaft.
22.With assistance, fit LH drive shaft to gearbox,
keep shaft square to prevent damage to oil seal
in gearbox.
23.Fit IRD.
+ INTERMEDIATE REDUCTION
DRIVE, REPAIRS, Intermediate reduction
drive (IRD) unit - Td4.
24.Fit starter motor.
+ CHARGING AND STARTING,
REPAIRS, Starter motor - Td4.
25.Fit fluid cooler.
+ AUTOMATIC GEARBOX - JATCO,
REPAIRS, Fluid cooler - Td4.
26.Fit intake ducting assembly.
+ FUEL DELIVERY SYSTEM - DIESEL,
REPAIRS, Ducting - intake assembly.
27.Connect battery earth lead.
28.Untie and close bonnet.
Fluid pan - reseal
$% 44.24.05
Remove
1.Drain gearbox fluid.
+ AUTOMATIC GEARBOX - JATCO,
ADJUSTMENTS, Gearbox fluid - drain &
refill.
2.Remove fluid cooler.
+ AUTOMATIC GEARBOX - JATCO,
REPAIRS, Fluid cooler - KV6.
3.Release multiplugs from clips attached to fluid
pan.
4.Remove 21 bolts securing fluid pan to gearbox.
5.Remove fluid pan.
Refit
1.Clean fluid pan and mating face on gearbox.
2.Apply sealant, Part No. STC 4600to contact
faces of fluid pan and gearbox.
3.Position fluid pan, fit bolts and tighten
progressively to 7 Nm (5 lbf.ft).
4.Secure multiplugs to clips.
5.Fit fluid cooler.
+ AUTOMATIC GEARBOX - JATCO,
REPAIRS, Fluid cooler - KV6.
6.Fill gearbox with fluid.
+ AUTOMATIC GEARBOX - JATCO,
ADJUSTMENTS, Gearbox fluid - drain &
refill.
Page 463 of 1007
AUTOMATIC GEARBOX - JATCO
44-28 REPAIRS
Fluid cooler - air blast - Td4 (hot
climates)
$% 44.24.09
Remove
1.Disconnect battery earth lead.
2.Remove front bumper.
+ EXTERIOR FITTINGS, REPAIRS,
Bumper - assembly - front - up to 04MY.
3.Remove combined fan and thermostat
multiplug from harness.
4.Remove harness multiplug from mounting
bracket.
5.Remove nut securing multiplug mounting
bracket, move bracket aside.
6.Position container beneath gearbox cooler
hoses to contain fluid spillage.7.Disconnect cooler quick release hoses.
CAUTION: Before disconnecting or
removing components, ensure the
immediate area around joint faces and
connections are clean. Plug open
connections to prevent contamination.
8.Remove 3 bolts securing air blast cooler
assembly to chassis and move aside.
M37 1754
Page 464 of 1007
AUTOMATIC GEARBOX - JATCO
REPAIRS 44-29
9.Remove 2 scrivets, release cooler ducting from
hooks and move aside.
10.Remove 5 bolts securing fan cowl to cooler
matrix and move aside.
11.Remove 4 nuts securing fan motor to cowl and
move aside.
NOTE: Do not carry out further dismantling if
component is removed for access only.12.Remove cooler pipe union nuts and move pipes
aside.
CAUTION: To prevent damage to
components, use two spanners when
loosening or tightening unions.
13.Remove and discard 'O' rings.
Refit
1.Fit new 'O' rings to oil cooler pipes.
2.Fit pipes to cooler matrix, align and tighten
union nuts to 25 Nm (18 lbf.ft).
3.Position fan cowl to cooler matrix, fit bolts and
tighten to 5 Nm (3.5 lbf.ft).
4.Position fan motor to cowl, fit nuts and tighten
to 5 Nm (3.5 lbf.ft).
5.Fit cooler duct and secure with scrivets.
6.Fit air blast cooler assembly, fit bolts and
tighten upper bolt to 5 Nm (3.5 lbf.ft). Lower
bolts should be tightened to 10 Nm (7.5 lbf.ft).
7.Ensure connections are clean, then fit and
secure flexible hoses.
8.Fit multiplug mounting bracket and tighten nut
to 10 Nm (7.5 lbf.ft).
9.Connect harness multiplug, fit multiplug to
mounting bracket.
10.Fit front bumper.
+ EXTERIOR FITTINGS, REPAIRS,
Bumper - assembly - front - up to 04MY.
11.Connect battery earth lead.
Page 465 of 1007
AUTOMATIC GEARBOX - JATCO
44-30 REPAIRS
Fluid cooler - Td4
$% 44.24.10
Remove
1.Disconnect battery earth lead.
2.Remove underbelly panel.
+ EXTERIOR FITTINGS, REPAIRS,
Panel - underbelly.
3.Position container to collect coolant spillage.
4.Release 2 clips and disconnect coolant hoses
from fluid cooler.
5.Position container to collect fluid spillage.
6.Disconnect 2 fluid cooler hose unions and
discard 'O' rings.
7.Remove 3 bolts securing fluid cooler bracket.
8.Remove fluid cooler.Refit
1.Clean cooler mounting points.
2.Position fluid cooler to mounting, fit bolts,
tighten 2 bolts to 45 Nm (33 lbf.ft) and
remaining bolt to 25 Nm (18 lbf.ft).
3.Connect coolant hoses and secure with clips.
4.Lubricate new 'O' rings with clean transmission
fluid and fit to fluid cooler hoses.
5.Connect hoses to fluid cooler and tighten
unions to 18 Nm (13 lbf.ft).
6.Top-up gearbox fluid level.
+ MAINTENANCE, MAINTENANCE,
Automatic Gearbox – JATCO.
7.Connect battery earth lead.
8.Refill cooling system.
+ COOLING SYSTEM - Td4,
ADJUSTMENTS, Coolant - drain and refill.
9.Fit underbelly panel.
+ EXTERIOR FITTINGS, REPAIRS,
Panel - underbelly.
Page 466 of 1007
AUTOMATIC GEARBOX - JATCO
REPAIRS 44-31
Fluid cooler - KV6
$% 44.24.10
Remove
1.Remove underbelly panel.
+ EXTERIOR FITTINGS, REPAIRS,
Panel - underbelly.
2.Position container to collect fluid spillage.
WARNING: Observe due care when draining
gearbox fluid as the fluid can be very hot.
3.Disconnect 2 fluid cooler hose unions and
discard 'O' rings.
CAUTION: Always fit plugs to open
connections to prevent contamination.
4.Position container to collect coolant spillage.
5.Release 2 clips and disconnect coolant hoses
from fluid cooler.
CAUTION: Always fit plugs to open
connections to prevent contamination.
6.Remove 2 bolts securing fluid cooler.
7.Remove fluid cooler.Refit
1.Position fluid cooler to mounting bracket, fit
bolts and tighten to 25 Nm (18 lbf.ft).
2.Connect coolant hoses and secure with clips.
3.Lubricate new 'O' rings with clean transmission
fluid and fit 'O' rings to fluid cooler hoses.
+ CAPACITIES, FLUIDS,
LUBRICANTS AND SEALANTS,
Lubrication.
4.Connect hoses to fluid cooler and tighten
unions to 18 Nm (13 lbf.ft).
5.Refill cooling system.
+ COOLING SYSTEM - K SERIES KV6,
ADJUSTMENTS, Coolant - drain and refill.
6.Top-up gearbox fluid level.
+ MAINTENANCE, MAINTENANCE,
Automatic Gearbox – JATCO.
7.Fit underbelly panel.
+ EXTERIOR FITTINGS, REPAIRS,
Panel - underbelly.
Page 467 of 1007
AUTOMATIC GEARBOX - JATCO
44-32 REPAIRS
Hose - fluid cooler
$% 44.24.13
This procedure is identical for both feed and return
hoses.
Remove
1.Remove underbelly panel.
+ EXTERIOR FITTINGS, REPAIRS,
Panel - underbelly.
2.Position container to collect fluid spillage.
WARNING: Observe due care when draining
gearbox fluid as the fluid can be very hot.
3.Disconnect hose from fluid cooler and discard
'O' ring.
CAUTION: Always fit plugs to open
connections to prevent contamination.
4.Loosen union and remove hose from gearbox.
5.Remove and discard 'O' ring.Refit
1.Wipe union and pipe ends using a lint free cloth.
2.Lubricate new 'O' ring with clean transmission
fluid and fit 'O' ring to hose.
+ CAPACITIES, FLUIDS,
LUBRICANTS AND SEALANTS,
Lubrication.
3.Position hose to fluid cooler but do not fully
tighten union.
4.Position hose to gearbox and tighten union to
18 Nm (13 lbf.ft).
5.Tighten fluid cooler hose union to 18 Nm (13
lbf.ft).
6.Top-up gearbox fluid level.
+ MAINTENANCE, MAINTENANCE,
Automatic Gearbox – JATCO.
7.Fit underbelly panel.
+ EXTERIOR FITTINGS, REPAIRS,
Panel - underbelly.
8.Remove container.
M44 1639
Page 468 of 1007
DRIVESHAFTS
REPAIRS 47-1
DRIV ESHAFTS REPAIRS
Shaft with both joints - LH
$% 47.10.01
Remove
1.Disconnect battery earth lead.
2.Raise front of vehicle.
WARNING: Do not work on or under a
vehicle supported only by a jack. Always
support the vehicle on safety stands.
3.Remove road wheel.
4.Remove underbelly panel.
+ EXTERIOR FITTINGS, REPAIRS,
Panel - underbelly.
5.Remove 3 bolts and remove splash shield.
6.Release stake from drive shaft nut.
7.With assistant depressing the brake pedal,
remove and discard the drive shaft nut.8.Remove clip securing brake hose and release
hose from damper bracket.
9.Release ABS sensor harness and brake hose
from damper.
10.Release ABS sensor from hub.
11.Remove 2 bolts securing brake caliper to hub.
Release caliper from hub and tie aside.
CAUTION: Do not allow caliper to hang on
brake hose.
Page 469 of 1007
DRIVESHAFTS
47-2 REPAIRS
12.Remove 2 bolts securing damper to hub.
13.Release hub from damper.
14.Release drive shaft from hub.
15.Position container to catch oil spillage
16.Secure LRT-54-026 to drive shaft inboard joint.
Using a lever, release drive shaft from gearbox.
17.Remove drive shaft.
CAUTION: Care must be taken not to
damage oil seal when removing drive shaft
from gearbox
18.Remove and discard circlip from drive shaft.Refit
1.Inspect gearbox seal for signs of wear or
damage.
2.Wipe drive shaft ends, gearbox oil seal and
hub.
3.Lubricate oil seal running surfaces.
4.Fit new circlip to drive shaft.
5.Fit drive shaft ensuring circlip is fully engaged.
CAUTION: Drive shaft must be fitted with
care to prevent damage to gearbox oil seal.
6.Position drive shaft in hub.
7.Fit new hub nut but do not tighten at this stage.
8.Fit hub to damper, fit nuts and bolts and tighten
to 205 Nm (150 lbf.ft).
9.Position caliper to brake disc fit bolts and
tighten to 100 Nm (74 lbf.ft).
10.Clean ABS sensor and mating face.
11.Lubricate ABS sensor with anti-seize grease.
12.Fit ABS sensor .
CAUTION: Ensure ABS sensor is fully
located into hub, so that sensor touches
reluctor ring.
13.Position ABS harness and brake hose in
bracket and secure with clip.
14.Fit splash shield and secure with bolts.
15.Tighten front hub nut to 400 Nm (295 lbf.ft).
16.Stake front hub nut.
17.Fit road wheel(s) and tighten nuts to 115 Nm
(85 lbf.ft).
18.Check and top up oil level as required.
+ MAINTENANCE, MAINTENANCE,
Manual Gearbox – PG1.
+ MAINTENANCE, MAINTENANCE,
Manual Gearbox – GETRAG.
+ MAINTENANCE, MAINTENANCE,
Automatic Gearbox – JATCO.
19.Fit underbelly panel.
+ EXTERIOR FITTINGS, REPAIRS,
Panel - underbelly.
20.Remove stands and lower vehicle.
21.Connect battery earth lead.
Page 470 of 1007
DRIVESHAFTS
REPAIRS 47-3
Shaft with both joints - RH
$% 47.10.02
Remove
1.Disconnect battery earth lead.
2.Raise front of vehicle.
WARNING: Do not work on or under a
vehicle supported only by a jack. Always
support the vehicle on safety stands.
3.Remove road wheel.
4.Remove underbelly panel.
+ EXTERIOR FITTINGS, REPAIRS,
Panel - underbelly.
5.Remove 3 bolts securing RH splash shield to
body and remove shield.
6.Release stake from drive shaft nut.
7.With assistant depressing the brake pedal,
remove and discard the drive shaft nut.8.Remove clip securing brake hose and release
hose from damper bracket.
9.Release ABS sensor harness and brake hose
from damper.
10.Release ABS sensor from hub.
11.Remove 2 bolts securing brake caliper to hub.
Release caliper from hub and tie aside.
CAUTION: Do not allow caliper to hang on
brake hose.
