Lexus CT200h 2013 Owner's Manual (in English)

5577-3. Do-it-yourself maintenance
CT200h_OM_OM76102E_(EE)
7
Maintenance and care
WA R N I N G
Replacing light bulbs
Be sure to stop the hybrid system and turn off the lights. Do not attempt to
replace the bulb immediately after turning off the lights.
The bulbs become very hot and may cause burns.
Do not touch the glass portion of the light bulb with bare hands. When it is
unavoidable to hold the glass portion, use and hold with a clean dry cloth to
avoid getting moisture and oils on the bulb.
Also, if the bulb is scratched or dropped, it may blow out or crack.
Fully install light bulbs and any parts used to secure them. Failure to do so
may result in heat damage, fire, or water entering the headlight unit. This may
damage the headlights or cause condensation to build up on the lens.
Do not attempt to repair or disassemble light bulbs, connectors, electric cir-
cuits or component parts.
Doing so may result in death or serious injury due to electric shock.
To prevent damage or fire
Make sure bulbs are fully seated and locked.
Check the wattage of the bulb before installing to prevent heat damage.
NOTICE
When replacing the outer foot lights
If the front window is stopping you from conducting the replace operation
properly, open the window on the side you are working on to allow you enough
space to work. Continuing the operation without giving yourself enough space
to work could lead you to scratch the vehicle.

5587-3. Do-it-yourself maintenance
CT200h_OM_OM76102E_(EE)

559
8When trouble arises
CT200h_OM_OM76102E_(EE)
8-1. Essential information
Emergency flashers........... 560
If your vehicle has to
be stopped in an
emergency....................... 561
8-2. Steps to take in an emergency
If your vehicle needs to be
towed .............................. 562
If you think something is
wrong .............................. 567
If a warning light turns on
or a warning buzzer
sounds ............................. 568
If a warning message is
displayed ......................... 575
If you have a flat tire (vehicles
with a spare tire) ............. 590
If you have a flat tire (vehicles
without a spare tire) ........ 604
If the hybrid system will not
start ................................. 619
If the electronic key does not
operate properly .............. 621
If the 12-volt battery is
discharged ....................... 623
If your vehicle overheats .. 628
If the vehicle becomes
stuck................................ 632

5608-1. Essential information
CT200h_OM_OM76102E_(EE)
Emergency flashers
Press the switch.
All the turn signal lights will flash.
To turn them off, press the switch
once again.
Emergency flashers
If the emergency flashers are used for a long time while the hybrid system is not
operating (while the “READY” indicator is not illuminated), the 12-volt battery
may discharge.
The emergency flashers are used to warn other drivers when the vehicle
has to be stopped in the road due to a breakdown, etc.

561
8 8-1. Essential information
When trouble arises
CT200h_OM_OM76102E_(EE)
If your vehicle has to be stopped in an emergency
Steadily step on the brake pedal with both feet and firmly depress it.
Do not pump the brake pedal repeatedly as this will increase the effort
required to slow the vehicle.
Shift the shift position to N.
If the shift position is shifted to N
After slowing down, stop the vehicle in a safe place by the road.
Stop the hybrid system.
If the shift position cannot be shifted to N
Keep depressing the brake pedal with both feet to reduce vehicle speed
as much as possible.
To stop the hybrid system, press
and hold the power switch for 2
consecutive seconds or more, or
press it briefly 3 times or more in
succession.
Stop the vehicle in a safe place by the road.
Only in an emergency, such as if it becomes impossible to stop the vehi-
cle in the normal way, stop the vehicle using the following procedure:
1
2
3
4
3
Press and hold for 2 seconds or
more,
4
WA R N I N G
If the hybrid system has to be turned off while driving
Power assist for the steering wheel will be lost, making the steering wheel
heavier to turn. Decelerate as much as possible before turning off the hybrid
system.
5

5628-2. Steps to take in an emergency
CT200h_OM_OM76102E_(EE)
If your vehicle needs to be towed
In the following situations, it is not possible to be towed by another vehi-
cle using cable or chain, as the front wheels may be locked due to the
parking lock. Contact any authorized Lexus dealer or repairer, or another
duly qualified and equipped professional or a commercial towing service.
There is a malfunction in the P position control system. (P. 581)
There is a malfunction in the immobilizer system. (P. 87)
There is a malfunction in the smart entry & start system. (P. 622)
The 12-volt battery is discharged. (P. 624)
If towing is necessary, we recommend having your vehicle towed by any
authorized Lexus dealer or repairer, or another duly qualified and
equipped professional or a commercial towing service, using a lift-type
truck or flat bed truck.
Use a safety chain system for all towing, and abide by all state/provincial
and local laws.
If towing your vehicle with a wheel-lift type truck from the front, the
vehicle’s rear wheels and axles must be in good conditions. (P. 563,
566)
If they are damaged, use a towing dolly or flatbed truck.
Situations when it is not possible to be towed by another vehicle

5638-2. Steps to take in an emergency
CT200h_OM_OM76102E_(EE)
8
When trouble arises
The following may indicate a problem with your hybrid transmission.
Contact any authorized Lexus dealer or repairer, or another duly qualified
and equipped professional before towing.
The hybrid warning message shows on and the vehicle does not move.
The vehicle makes an abnormal sound.
Do not tow with a sling-type truck
to prevent body damage.
Situations needs to contact dealers before towing
Towing with a sling-type truck
Towing with a wheel-lift type truck
From the frontFrom the rear
Release the parking brake. Use a towing dolly under the front
wheels.

5648-2. Steps to take in an emergency
CT200h_OM_OM76102E_(EE)
If your Lexus is transported by a
flat bed truck, it should be tied
down at the locations shown in the
illustration.
If you use chains or cables to tie
down your vehicle, the angles
shaded in black must be 45.
Do not overly tighten the tie downs
or the vehicle may be damaged.
If a tow truck is not available in an emergency, your vehicle may be tem-
porarily towed using a cable or chain secured to the emergency towing
eyelet(s). This should only be attempted on hard surfaced roads for short
distances at under 30 km/h (18 mph).
A driver must be in the vehicle to steer and operate the brakes. The vehi-
cle’s wheels, drive train, axles, steering and brakes must be in good con-
dition.
Using a flat bed truck
Emergency towing

5658-2. Steps to take in an emergency
CT200h_OM_OM76102E_(EE)
8
When trouble arises
Take out the towing eyelet. (P. 592, 606)
Remove the eyelet cover using a
flathead screwdriver.
To protect the bodywork, place a rag
between the screwdriver and the
vehicle body as shown in the illus-
tration.
Insert the towing eyelet into the
hole and tighten partially by
hand.
Tighten down the towing eyelet
securely using a wheel nut
wrench.
Securely attach a cable or chain to the towing eyelet.
Take care not to damage the vehicle body.
Enter the vehicle being towed and start the hybrid system.
If the hybrid system does not start, turn the power switch to ON mode.
Shift the shift position to N and release the parking brake.
Installing towing eyelets
1
2
3
4
5
6
7

5668-2. Steps to take in an emergency
CT200h_OM_OM76102E_(EE)
Wheel nut wrench
Wheel nut wrench is installed in luggage compartment. (P. 592, 606)
WA R N I N G
Observe the following precautions.
Failure to do so may result in death or serious injury.
When transporting the vehicle
While towing
When towing using a rope, avoid sudden starts, etc. which place excessive
stress on the towing hook and rope.
The towing hook or rope may become damaged, broken debris may hit people
and cause serious damage.
Do not turn the power switch off.
This may lead to an accident as the front wheels will be locked by the parking
lock.
Installing towing eyelets to the vehicle
Make sure that towing eyelets are installed securely.
If not securely installed, towing eyelets may come loose during towing.
NOTICE
To prevent damage to the vehicle when towing using a wheel-lift type truck
When raising the vehicle, ensure adequate ground clearance for towing at the
opposite end of the raised vehicle. Without adequate clearance, the vehicle
could be damaged while being towed.
To prevent body damage when towing with a sling-type truck
Do not tow with a sling-type truck, either from the front or rear.
Be sure to transport the vehicle with the
front wheels raised or with all four wheels
raised off the ground. If the vehicle is
towed with the front wheels contacting the
ground, the drivetrain and related parts
may be damaged or electricity generated
by the operation of the motor may cause a
fire to occur depending on the nature of the
damage or malfunction.
