LEXUS RX350 2015 Owners Manual

6714-3. Do-it-yourself maintenance
4
Maintenance and care Engine compartment cover
■ Removing the engine compartment covers
Outside
Front

6724-3. Do-it-yourself maintenance
■ Installing the clips
NOTICE■
After installing an engine compartment cover
Make sure that the cover is securely installed in its original position.

6734-3. Do-it-yourself maintenance
4
Maintenance and care Battery cover
Removing the battery cover.
NOTICE■
When installing the battery cover
Securely install the cover over the battery. Failure to do so may cause water to enter
the engine compartment when it rains or the vehicle is washed, resulting in a mal-
function.

6744-3. Do-it-yourself maintenance
Engine oil
With the engine at operating temperat ure and turned off, check the oil
level on the dipstick.
■ Checking the engine oil
Park the vehicle on level grou nd. After warming up the engine
and turning it off, wait more th an 5 minutes for the oil to drain
back into the bottom of the engine.
Holding a rag under the end, pull
the dipstick out.
Wipe the dipstick clean.
Reinsert the dipstick fully.
Holding a rag under the end, pull the dipstick out and check the
oil level.
Low
Normal
Excessive
The shape of the dipstick may dif-
fer depending on the type of vehi-
cle or engine.
Wipe the dipstick and reinsert it fully.STEP 1
STEP 2
STEP 3
STEP 4
STEP 5
STEP 6

6754-3. Do-it-yourself maintenance
4
Maintenance and care ■ Adding engine oil
If the oil level is below or near the
low level mark, add engine oil of
the same type as th at already in the
engine.
Make sure to check th e oil type and prepare the items needed before
adding oil.
Remove the oil filler cap by turning it counterclockwise.
Add engine oil slowly, checking the dipstick.
Install the oil filler cap by turning it clockwise.Engine oil
selection  P. 8 0 9
Oil quantity
(Low  Full) 1.6 qt. (1.5 L, 1.3 Imp. qt.)
Items Clean funnel
■
Engine oil consumption
A certain amount of engine oil will be consumed while driving. In the following situ-
ations, oil consumption may increase, and engine oil may need to be refilled in
between oil maintenance intervals.
●
When the engine is new, for example di rectly after purchasing the vehicle or
after replacing the engine
●
If low quality oil or oil of an inappropriate viscosity is used
●
When driving at high engi ne speeds or with a heavy load, when towing, or when
driving while accelerating or decelerating frequently
●
When leaving the engine id ling for a long time, or when driving frequently
through heavy traffic STEP 1
STEP 2
STEP 3

6764-3. Do-it-yourself maintenance
CAUTION■
Used engine oil ●
Used engine oil contains potentially harmful contaminants which may cause skin
disorders such as inflammati on or skin cancer, so care should be taken to avoid
prolonged and repeated contact. To remove used engine oil from your skin, wash
thoroughly with soap and water.●
Dispose of used oil and filters only in a safe and acceptable manner. Do not dis-
pose of used oil and filters in househol d trash, in sewers or onto the ground.
Call your Lexus dealer, service station or auto parts store for information con-
cerning recycling or disposal.●
Do not leave used engine oil within the reach of children.
NOTICE■
To prevent serious engine damage
Check the oil level on a regular basis.■
When replacing the engine oil ●
Be careful not to spill engine oil on the vehicle components.●
Avoid overfilling, or the engine could be damaged.●
Check the oil level on the dipstick every time you refill the vehicle.●
Be sure the engine oil filler cap is properly tightened.

6774-3. Do-it-yourself maintenance
4
Maintenance and care Engine coolant
The coolant level is satisfactory if it is between the “FULL” and “LOW”
lines on the reservoir when the engine is cold.
Reservoir cap
“FULL” line
“LOW” line If the level is on or below the
“LOW” line, add coolant up to the
“FULL” line. (  P. 799)
■
Coolant selection
Only use “Toyota Super Long Life Coolant” or a similar high quality ethylene glycol
based non-silicate, non-amine, non-nitrite, and non-borate coolant with long-life
hybrid organic acid technology.
U.S.A.: “Toyota Super Long Life Coolant” is a mixture of 50% coolant and 50%
deionized water. (Minimum temperature: -31  F [-35  C])
Canada: “Toyota Super Long Life Coolant” is a mixture of 55% coolant and 45%
deionized water. (Minimum temperature: -44  F [-42  C])
For more details about coolant, contact your Lexus dealer.

6784-3. Do-it-yourself maintenance
Radiator and condenser
Check the radiator and condenser an d clear away any foreign objects.
If either of the above parts are extremely dirty or you are not sure of their
condition, have your vehicle checked by your Lexus dealer.■
If the coolant level drops within a short time after replenishing
Visually check the radiator, hoses, radiator cap, drain cock and water pump.
If you cannot find a leak, have your Lexus dealer test the cap and check for leaks in
the cooling systems.
CAUTION■
When the engine is hot
Do not remove the radiator cap.
The cooling system may be under pressure and may spray hot coolant if the cap is
removed, causing serious injuries, such as burns.
NOTICE■
When adding engine coolant
Coolant is neither plain water nor straight antifreeze. The correct mixture of water
and antifreeze must be used to provide proper lubrication, corrosion protection
and cooling. Be sure to read the antifreeze or coolant label.■
If you spill coolant
Be sure to wash it off with water to prevent damage to parts or paint.
CAUTION
■
When the engine is hot
Do not touch the radiator or condenser as they may be hot and cause serious inju-
ries, such as burns.

6794-3. Do-it-yourself maintenance
4
Maintenance and care Brake fluid
■ Checking fluid level
The brake fluid level should be
between the “MAX” and “MIN”
lines on the tank.
■ Adding fluid
Make sure to check the fluid type and prepare the necessary item. Fluid type FMVSS No.116 DOT 3 or SAE J1703
Items Clean funnel

6804-3. Do-it-yourself maintenance
■
Brake fluid can absorb moisture from the air
Excess moisture in the brake fluid can cause a dangerous loss of braking efficiency.
Use only newly opened brake fluid.
CAUTION■
When filling the reservoir
Take care because brake fluid can harm your hands or eyes and damage painted
surfaces.
If fluid gets on your hands or in your eyes, flush the affected area with clean water
immediately.
If you still experience discomfort, see a doctor.
NOTICE■
If the fluid level is low or high
It is normal for the brake fluid level to go down slightly as the brake pads wear out or
when the fluid level in the accumulator is high.
If the reservoir needs frequent re filling, may be a serious problem.
