LEXUS RX350 2016 Owners Manual
Manufacturer: LEXUS, Model Year: 2016, Model line: RX350, Model: LEXUS RX350 2016Pages: 748, PDF Size: 12.36 MB
Page 641 of 748

6418-2. Steps to take in an emergency
8
When trouble arises
RX350_U_OM48E90U Master warning light The master warning light also comes on or flashes in order to indicate that a message
is currently being displayed on the multi-information display.
Multi-information display
If any of the warning messages are show n again after the following actions have
been performed, contact your Lexus dealer.
The warning lights and warning buzzers operate as follows depending on the
content of the message. If a message in dicates the need for inspection by a
dealer, have the vehicle inspected by your Lexus dealer immediately.If a warning message is displayed The multi-information display shows warnings of system malfunctions, incor-
rectly performed operations, and messages that indicate a need for mainte-
nance. When a message is shown, perform the correction procedure
appropriate to the message.
Except F SPORT models
F SPORT models
Messages and warnings 1
2
System
warning
light Wa r n i n g b u z z e r
* Wa r n i n g
Comes
on Sounds Indicates an important situation, such
as when a system related to driving is
malfunctioning or that danger may
result if the correction procedure is not
performed
Comes on
or flashes Sounds Indicates an important situation, such
as when the systems shown on the
multi-information display may be mal-
functioning
Page 642 of 748

642 8-2. Steps to take in an emergency
RX350_U_OM48E90U * : A buzzer sounds the first time a message is shown on the multi-information display.
●
If the following messages are shown, there may be a malfunction.
Immediately stop the vehicle in a safe place and contact your Lexus dealer.
Continuing to drive the vehicle may be dangerous.
• “Braking Power Low Stop in a Safe Place See Owner’s Manual”
• “Oil Pressure Low Stop in a Safe Place See Owner’s Manual”
• “Charging System Malfunction See Owner's Manual” ●
If the following message is shown, there may be a malfunction.
Immediately have the vehicle inspected by your Lexus dealer.
• “Access System with Elec. Key Malfunction See Owner’s Manual” ●
If “Engine Coolant Temp High Stop in a Safe Place See Owner’s Manual” is
shown, following the instructions, accordingly. ( P. 668)●
If “Transmission Fluid Temp High See Owner’s Manual” is shown, the auto-
matic transmission fluid temperature may be too high.
Immediately stop the vehicle in a safe place, shift the shift lever to P with the
engine running and wait until the message is cleared.
If the message is not cleared, contact your Lexus dealer. Flashes Sounds Indicates a situation, such as when
damage to the vehicle or danger may
result
Comes
on Does not sound Indicates a condition, such as malfunc-
tion of electrical components, their
condition, or indicates the need for
maintenance
Flashes Does not sound Indicates a situation, such as when an
operation has been performed incor-
rectly, or indicates how to perform an
operation correctly
If a message instructing to refer to the Owner’s Manual is displayed System
warning
light Wa r n i n g b u z z e r
* Wa r n i n g
Page 643 of 748

6438-2. Steps to take in an emergency
8
When trouble arises
RX350_U_OM48E90U Take the appropriate actions as in structed in the message displayed.
If any of the following messages are displa yed, also refer to this Owner’s Manual.■
If “Shift to P Before Exiting Vehicle” is shown
Message is displayed when the driver’s door is opened without turning the
engine switch off with the shift lever in any position other than P.
Shift the shift lever to P. ■
If “Power Turned Off to Save Battery” is displayed
This message is displayed when the power was cut off due to the automatic
power off function.
The next time the engine is started, increase the engine speed slightly and
maintain it at that spee d for approximately 5 minutes to recharge the battery.■
If “AWD System Overheated Switching to 2WD Mode” or “AWD System
Overheated 2WD Mode Engaged” is displayed (AWD models)
This message may be displayed when driving under extremely high load con-
ditions.
Drive the vehicle at low speeds or stop the vehicle in a safe place with the
engine running until the message is cleared.
If the message is not cleared, have the vehicle inspected by your Lexus dealer.■
If “A New Key has been Registered Contact Your Dealer for Details” is dis-
played
This message will be displayed each time the driver’s door is opened when the
doors are unlocked from the outside for approximately one week after a new
electronic key has been registered.
If this message is displayed but you have not had a new electronic key regis-
tered, ask your Lexus dealer to check if an unknown electronic key (other than
those in your possession) has been registered. ■
When “Headlight System Malfunctio n Visit Your Dealer” is displayed
The following systems may be malfunct ioning. Have the vehicle inspected by
your Lexus dealer immediately. ●
The LED headlight system ●
The automatic headlight leveling system ●
Automatic High Beam (if equipped) ●
AFS (Adaptive Front-lighting System) (if equipped)Other messages displayed on the multi-information display
Page 644 of 748

644 8-2. Steps to take in an emergency
RX350_U_OM48E90U ■
If “Forward Camera System Unavailable” or “Forward Camera System
Unavailable Clean Windshield ” is displayed (if equipped)
The following systems may be suspended until the problem shown in the mes-
sage is resolved. ●
PCS (Pre-Collision System) ●
LKA (Lane-Keeping Assist) ●
LDA (Lane Departure Alert with steering control) ●
Dynamic radar cruise control with full-speed range ●
Dynamic radar cruise control ●
Automatic High Beam■
If “Oil Maintenance Required Soon” is shown
Indicates that the engine oil is schedule d to be changed. (The indicator will not
work properly unless the message has been reset.)
Check the engine oil, and change if ne cessary. After changing the engine oil,
the message should be reset. ( P. 5 7 7 )■
If “Oil Maintenance Required” is shown
Indicates that the engine oil should be changed. (After the engine oil is
changed and the message has been reset.)
Check and change the engine oil, and o il filter by your Lexus dealer. After
changing the engine oil, the message should be reset. ( P. 5 7 7 )■
If “Maintenance Required Soon” is displayed (U.S.A. only)
Indicates that all maintenance according to the driven distance on the mainte-
nance schedule
* should be performed soon.
Comes on approximately 4500 miles (7200 km) after the message has been
reset.
If necessary, perform maintenance. Pl ease reset the message after the main-
tenance is performed. ( P. 565)
* : Refer to the separate “Scheduled Mainte nance” or “Owner’s Manual Supplement”
for the maintenance interval applicable to your vehicle.
Page 645 of 748

6458-2. Steps to take in an emergency
8
When trouble arises
RX350_U_OM48E90U ■
If “Maintenance Required Visit Your Dealer” is displayed (U.S.A. only)
Indicates that all maintenance is required to correspond to the driven distance
on the maintenance schedule
* .
Comes on approximately 5000 miles (8000 km) after the message has
been reset.
(The indicator will not wo rk properly unless the message has been reset.)
Perform the necessary maintenance. Please reset the message after the main-
tenance is performed. ( P. 565)
* : Refer to the separate “Scheduled Mainte nance” or “Owner’s Manual Supplement”
for the maintenance interval applicable to your vehicle. ■
System warning lights
The master warning light does not come on or flash in the following cases. Instead, a sep-
arate system warning light will come on al ong with a message shown on the multi-infor-
mation display. ●
“Antilock Brake System Malfunction Visit Your Dealer”:
The ABS warning light comes on. ( P. 6 3 4 )●
“Charging System Malfunction See Ow ner’s Manual” (F SPORT models):
The charging system warning light comes on. ( P. 6 3 4 )■
Warning buzzer
P. 6 3 8
NOTICE ■
“High Power Consumption Partial Limit On AC/Heater Operation” is frequently
shown
There is a possible malfunction relating to the charging system or the battery may be
deteriorating. Have the vehicle inspected by your Lexus dealer.
Page 646 of 748

646 8-2. Steps to take in an emergency
RX350_U_OM48E90U ●
Stop the vehicle on a hard, flat surface. ●
Set the parking brake. ●
Shift the shift lever to P. ●
Stop the engine. ●
Turn on the emergency flashers. ( P. 6 2 4 )If you have a flat tire Your vehicle is equipped with a spare ti re. The flat tire can be replaced with
the spare tire.
For details about tires: P. 5 8 4WA R N I N G ■
If you have a flat tire
Do not continue driving with a flat tire.
Driving even a short distance with a flat ti re can damage the tire and the wheel beyond
repair, which could result in an accident.
Before jacking up the vehicle
Page 647 of 748

6478-2. Steps to take in an emergency
8
When trouble arises
RX350_U_OM48E90U
Vehicles without a towing eyelet
* : Documentation relating to the wheel lock key, such as the registration and I.D. card, is
inside the glove box.Location of the spare tire, jack and tools
Jack handle
Wheel nut wrench
Spare tire Wheel lock key
* (if equipped)
Jack1
2
3 4
5
Page 648 of 748

648 8-2. Steps to take in an emergency
RX350_U_OM48E90U
Vehicles with a towing eyelet
Jack handle
Wheel nut wrench
Spare tire Jack
Towing eyeletWA R N I N G ■
Using the tire jack
Observe the following precautions.
Improper use of the tire jack may cause the vehicle to suddenly fall off the jack, leading
to death or serious injury. ●
Do not use the tire jack for any purpose ot her than replacing tires or installing and
removing tire chains. ●
Only use the tire jack that comes with this vehicle for replacing a flat tire.
Do not use it on other vehicles, and do not use other tire jacks for replacing tires on
this vehicle. ●
Put the jack properly in its jack point. ●
Do not put any part of your body under the vehicle while it is supported by the jack.●
Do not start the engine or drive the vehicle while the vehicle is supported by the jack. ●
Do not raise the vehicle while someone is inside. ●
When raising the vehicle, do not pu t an object on or under the jack.●
Do not raise the vehicle to a height greater than that required to replace the tire. ●
Use a jack stand if it is necessary to get under the vehicle. ●
When lowering the vehicle, make sure that there is no-one near the vehicle. If there
are people nearby, warn them vocally before lowering. 1
2
3 4
5
Page 649 of 748

6498-2. Steps to take in an emergency
8
When trouble arises
RX350_U_OM48E90U When replacing tires on a vehicle with wheel lock nuts, use the following proce-
dures to remove and install the wheel lock nuts. The wheel lock key is stored in
the tray inside the luggage compartment. Always return the wheel lock key to its
original position after use, so that it does not get lost.■
Removal
For ease of removal, the wheel lock nut should always be the first one loos-
ened.
Place the wheel lock key on top of the wheel lock nut, turning until the
wheel lock key and wheel lock nut patterns engage.
Place the wheel nut wrench on the wheel lock key, and while applying pres-
sure on the wheel lock key, loosen the wheel lock nut.■
Installation
For ease of installation, the wheel lock nut should always be the last one tight-
ened.
By hand, install a wheel lock nut on each wheel.
Place the wheel lock key on top of the wheel lock nut, turning until the
wheel lock key and wheel lock nut patterns engage.
Place the wheel nut wrench on the wheel lock key, and while applying pres-
sure on the wheel lock key, tighten the wheel lock nut to the recommended
torque.Wheel lock nut (if equipped)
NOTICE
Do not use an impact wrench. Using an impact wrench may cause permanent damage
to wheel lock nut and wheel lock key. If in doubt about wheel lock application, contact
your Lexus dealer. 1
2
1
2
3
Page 650 of 748

650 8-2. Steps to take in an emergency
RX350_U_OM48E90U Secure the deck board using the hook. ( P. 5 2 1 )
Disengage the hook and take out
the jack. Remove the wheel nut wrench and then
the jack
Secure the deck board using the hook. ( P. 5 2 1 )
Loosen the center fastener that
secures the spare tire.Taking out the jack 1
2
Taking out the spare tire 1
2
WA R N I N G ■
When storing the spare tire
Be careful not to catch fingers or other body parts between the spare tire and the body
of the vehicle.
