Page 621 of 748

6217-3. Do-it-yourself maintenance
7
Maintenance and care
RX350_U_OM48E90U Install the cover. Align the tabs of the cover with the
grooves and install the cover.
■
Replacing the following bulbs
If any of the lights listed below has burnt out, have it replaced by your Lexus
dealer. ●
Headlight low beams ●
Headlight high beams ●
Front turn signal lights (vehic les with triple-beam headlights)●
Parking lights and daytime running lights ●
Front fog lights ●
Cornering lights (if equipped) ●
Front side marker lights (vehicles with triple-beam headlights) ●
Side turn signal lights ●
Stop/tail lights ●
Rear turn signal light (vehic les with triple-beam headlights)●
Rear side marker lights ●
High mounted stoplight ●
License plate lights ●
Outer foot lights 5
Page 622 of 748

622 7-3. Do-it-yourself maintenance
RX350_U_OM48E90U ■
LED lights
The headlight low beams, headlight high beams, front turn signal lights (vehicles with tri-
ple-beam headlights), parking lights and dayt ime running lights, front fog lights, corner-
ing lights (if equipped), front side marker lights (vehicles with tr iple-beam headlights),
side turn signal lights, stop/t ail lights, rear turn signal lig ht (vehicles with triple-beam
headlights), rear side marker lights, high moun ted stoplight, license plate lights, and outer
foot lights consist of a number of LEDs. If an y of the LEDs has burned out, take your vehi-
cle to your Lexus dealer to have the light replaced. ■
Condensation build-up on the inside of a lens
Temporary condensation build-up on the inside of the headlight lens does not indicate a
malfunction. Contact your Lexus dealer for mo re information in the following situations:●
Large drops of water have built up on the inside of a lens.●
Water has built up inside a headlight. ■
When replacing light bulbs
P. 6 0 6
WA R N I N G ■
To p r e v e n t i n j u r y
Before performing any light bulb replacement procedure, be sure to turn the engine
switch off. Failure to do so may result in burns from hot components or a part of your
body may get caught on an operating comp onent, possibly causing serious injury.■
Replacing light bulbs ●
Turn off the lights. Do not attempt to replace the bulb immediately after turning off the
lights.
The bulbs become very hot and may cause burns. ●
Do not touch the glass portion of the light bulb with bare hands. When it is unavoid-
able to hold the glass portion, use and ho ld with a clean dry cloth to avoid getting
moisture and oils on the bulb.
Also, if the bulb is scratched or dropped, it may blow out or crack.●
Fully install light bulbs and any parts used to secure them. Failure to do so may result
in heat damage, fire, or water entering the headlight unit. This may damage the head-
lights or cause condensation to build up on the lens.●
Do not attempt to repair or disassemble the light bulbs, connectors, electric circuits
or component parts.
Doing so may result in death or se rious injury due to electric shock.■
To prevent damage or fire ●
Make sure bulbs are fully seated and locked. ●
Check the wattage of the bulb before installin g to prevent heat damage.
Page 623 of 748

623
8When trouble arises
RX350_U_OM48E90U 8-1. Essential information
Emergency flashers .................. 624
If your vehicle has to be
stopped in an
emergency................................. 625
8-2. Steps to take in an
emergency
If your vehicle needs to be
towed ........................................... 626
If you think something is
wrong ........................................... 632
Fuel pump shut off
system .......................................... 633
If a warning light turns
on or a warning buzzer
sounds.......................................... 634
If a warning message is
displayed.......................................641
If you have a flat tire................... 646
If the engine will not start ........658
If the shift lever cannot be
shifted from P............................660
If the electronic key does
not operate properly ...............661
If the vehicle battery is
discharged ................................. 665
If your vehicle overheats .........668
If the vehicle becomes
stuck ............................................... 671
Page 624 of 748

624
RX350_U_OM48E90U 8-1. Essential information
Press the switch. All the turn signal lights will flash. To turn
them off, press the switch once again.
■
Emergency flashers
If the emergency flashers are used for a long time while the engine is not operating, the
battery may discharge.
Emergency flashers The emergency flashers are used to warn other drivers when the vehicle has
to be stopped in the road due to a breakdown, etc.
Page 625 of 748

6258-1. Essential information
8
When trouble arises
RX350_U_OM48E90U Steadily step on the brake pedal with both feet and firmly depress it.Do not pump the brake pedal repeatedly as this will increase the effort required to
slow the vehicle.
Shift the shift lever to N.
If the shift lever is shifted to N
After slowing down, stop the vehicle in a safe place by the road.
Stop the engine.
If the shift lever cannot be shifted to N
Keep depressing the brake pedal with both feet to reduce vehicle speed as
much as possible.
To stop the engine, press and hold
the engine switch for 2 consecutive
seconds or more, or press it briefly 3
times or more in succession.
Stop the vehicle in a safe place by the road.If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in
the normal way, stop the vehicl e using the following procedure:1
2
3
4
3
Press and hold for 2 seconds or more,
or press briefly 3 times or more4
WA R N I N G ■
If the engine has to be turned off while driving
Power assist for the brakes and steering wheel will be lost, making the brake pedal
harder to depress and the steering wheel heavier to turn. Decelerate as much as possi-
ble before turning off the engine. 5
Page 626 of 748

626
RX350_U_OM48E90U 8-2. Steps to take in an emergency
The following may indicate a problem with your transmission. Contact your
Lexus dealer or commercial towing service before towing. ( P. 6 3 0 )●
The engine is running but the vehicle dose not move. ●
The vehicle makes an abnormal sound.
Do not tow with a sling-type truck to
prevent body damage.If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your
Lexus dealer or commercial towing se rvice, using a wheel-lift type truck or
flatbed truck.
Use a safety chain system for all towing, and abide by all state/provincial and
local laws.
2WD models: If towing your vehicle with a wheel-lift type truck from the front,
the vehicle’s rear wheels and axles must be in good conditions. ( P. 6 2 7 , 6 3 0 )
If they are damaged, use a towing dolly or flatbed truck.
AWD models: If towing your vehicle with a wheel-lift type truck, use a towing
dolly. ( P. 6 2 7 , 6 3 0 )
Situations when it is necessary to contact dealers before towing
Towing with a sling-type truck
Page 627 of 748

6278-2. Steps to take in an emergency
8
When trouble arises
RX350_U_OM48E90U Towing with a wheel-lift type truck
From the front (2WD models)
From the front (AWD models)
Release the parking brake. Use a towing dolly under the rear
wheels.
From the rear
Use a towing dolly under the front
wheels.
Page 628 of 748

628 8-2. Steps to take in an emergency
RX350_U_OM48E90U If your vehicle is transported by a flat-
bed truck, it should be tied down at the
locations shown in the illustration.
If you use chains or cables to tie down
your vehicle, the angles shaded in black
must be 45 .
Do not overly tighten the tie downs or
the vehicle may be damaged.
If a tow truck is not available in an emergency, your vehicle may be temporarily
towed using cables or chains secured to the emergency towing eyelets. This
should only be attempted on hard surf aced roads for at most 50 miles (80 km)
at under 18 mph (30 km/h).
A driver must be in the vehicle to steer and operate the brakes. The vehicle’s
wheels, drive train, axles, steering an d brakes must be in good condition.Using a flatbed truck Front
Emergency towing (vehicles with towing eyelets)
Page 629 of 748

6298-2. Steps to take in an emergency
8
When trouble arises
RX350_U_OM48E90U Take out the towing eyelet. ( P. 6 4 7 )
Remove the eyelet cover.
Insert the towing eyelet into the hole
and tighten partially by hand.
Tighten down the towing eyelet
securely using a wheel nut wrench
or hard metal bar.
Securely attach cables or chains to the towing eyelet.
Take care not to damage the vehicle body.
Enter the vehicle being towed and start the engine.
If the engine does not start, turn th e engine switch to IGNITION ON mode.
Shift the shift lever to N and release the parking brake.
When the shift lever cannot be shifted: P. 6 6 0Emergency towing procedure (vehicles with a towing eyelet) 1
2
3
4
5
6
7
Page 630 of 748

630 8-2. Steps to take in an emergency
RX350_U_OM48E90U ■
While towing
If the engine is not running, the power assist for the brakes and steering will not function,
marking steering and braking more difficult. ■
Wheel nut wrench
Wheel nut wrench is installed in luggage compartment. ( P. 6 4 7 )
WA R N I N G
Observe the following precautions.
Failure to do so may result in death or serious injury. ■
When towing the vehicle
2WD models
AW D m o d e l s
■
While towing ●
When towing using cables or chains, avoid sudden starts, etc. which place excessive
stress on the towing eyelets, cables or chains. The towing eyelets, cables or chains
may become damaged, broken debris may hit people, and cause serious damage. ●
Do not turn the engine switch off.
There is a possibility that the steering wheel is locked and cannot be operated.■
Installing towing eyelets to the vehicle
Make sure that towing eyelets are installed securely.
If not securely installed, towing ey elets may come loose during towing.Be sure to transport the vehicle with the front
wheels raised or with all four wheels raised off
the ground. If the vehicle is towed with the front
wheels contacting the ground, the drivetrain
and related parts may be damaged.
Be sure to transport the vehicle with all four
wheels raised off the ground. If the vehicle is
towed with the tires contacting the ground, the
drivetrain or related parts may be damaged,
the vehicle may fly off the truck.
