6518-2. Steps to take in an emergency
8
When trouble arises
RX350_U_OM48E90U Chock the tires.
Slightly loosen the wheel nuts (one
turn). For vehicles with wheel lock nuts, loosen
the wheel lock nut first.
Turn the tire jack portion by hand
until the notch of the jack is in con-
tact with the jack point. The jack point guides are located under
the rocker panel. They indicate the jack
point positions.Replacing a flat tire 1
Flat tire Wheel chock positions
Front Left-hand side Behind the rear right-hand side tire
Right-hand side Behind the rear left-hand side tire
Rear Left-hand side In front of the front right-hand side tire
Right-hand side In front of the front left-hand side tire2
3
A

652 8-2. Steps to take in an emergency
RX350_U_OM48E90U Raise the vehicle until the tire is
slightly raised off the ground.
Remove all the wheel nuts and the
tire. When resting the tire on the ground,
place the tire so that the wheel design
faces up to avoid scratching the wheel
surface. 4
5

6538-2. Steps to take in an emergency
8
When trouble arises
RX350_U_OM48E90U WA R N I N G ■
When holding a tire with Selectable Color Trim (if equipped)
■
Replacing a flat tire ●
Do not touch the disc wheels or the area around the brakes immediately after the
vehicle has been driven.
After the vehicle has been driven the disc wheels and the area around the brakes will
be extremely hot. Touching these areas with hands, feet or other body parts while
changing a tire, etc. may result in burns. ●
Failure to follow these precautions could cause the wheel nuts to loosen and the tire
to fall off, resulting in death or serious injury.
• Never use oil or grease on the wheel bolts or wheel nuts.
Oil and grease may cause the wheel nuts to be excessively tightened, leading to
bolt or disc wheel damage. In addition, the oil or grease can cause the wheel nuts
to loosen and the wheel may fall off, causing a serious accident.
Remove any oil or grease from the wheel bolts or wheel nuts.
• Have the wheel nuts tightened with a torque wrench to 76 ft•lbf (103 N•m,
10.5 kgf•m) as soon as possible after changing wheels.
• When installing a tire, only use wheel nuts that have been specifically designed for
that wheel.
• If there are any cracks or deformations in the bolt screws, nut threads or bolt holes
of the wheel, have the vehicle inspected by your Lexus dealer.■
Replacing a flat tire for vehicles with power back door
In cases such as when replacing tires, make sure to turn off the power back door main
switch (  P. 100). Failure to do so may cause the back door to operate unintentionally
if the power back door switch is accidentally touched, resulting in hands and fingers
being caught and injured.Do not hold the tire by the Selectable Color
Trim. Otherwise, the Selectable Color Trim
may be damaged or may fall off causing the tire
to drop, possibly causing injury.

654 8-2. Steps to take in an emergency
RX350_U_OM48E90U Remove any dirt or foreign matter
from the wheel contact surface. If foreign matter is on the wheel contact
surface, the wheel nuts may loosen
while the vehicle is in motion, causing
the tire to come off.
Install the spare tire and loosely
tighten each wheel nut by hand by
approximately the same amount. Tighten the wheel nuts until the tapered
portion comes into loose contact with
the disc wheel seat.
Lower the vehicle.
Firmly tighten each wheel nut two or
three times in the order shown in the
illustration. For vehicles with wheel lock nuts,
tighten the wheel lock nut last.
Tightening torque:
76 ft·lbf (103 N·m, 10.5 kgf·m)
Stow the flat tire, tire jack and all tools.Installing the spare tire 1
Disc wheel
seatTapered portion2
3
4
5

6558-2. Steps to take in an emergency
8
When trouble arises
RX350_U_OM48E90U ■
The compact spare tire ●
The compact spare tire is identified by the label “TEMPORARY USE ONLY” on the
tire sidewall.
Use the compact spare tire temporarily, and only in an emergency. ●
Make sure to check the tire inflation pressure of the compact spare tire. (  P. 6 8 0 )■
When using the compact spare tire
As the compact spare tire is not equipped wi th a tire pressure warning valve and trans-
mitter, low inflation pressure of the spare ti re will not be indicated by the tire pressure
warning system. Also, if you replace the compact spare tire after the tire pressure warn-
ing light comes on, th e light remains on.■
When the compact spare tire is equipped
When driving with the compact spare tire inst alled, the vehicle height will be different
than when driving with standard tires. ■
If you have a flat front tire on a road covered with snow or ice
Install the compact spare tire on one of the rear wheels of the vehicle. Perform the follow-
ing steps and fit tire chains to the front tires:
Replace a rear tire with the compact spare tire.
Replace the flat front tire with the tire removed from the rear of the vehicle.
Fit tire chains to the front tires. 1
2
3

656 8-2. Steps to take in an emergency
RX350_U_OM48E90U WA R N I N G ■
When using the compact spare tire ●
Remember that the compact spare tire provid ed is specifically designed for use with
your vehicle. Do not use your compact spare tire on another vehicle. ●
Do not use more than one compact spare tire simultaneously. ●
Replace the compact spare tire with a standard tire as soon as possible. ●
Avoid sudden acceleration, ab rupt steering, sudden bra king and shifting operations
that cause sudden engine braking. ■
When the compact spare tire is attached
The vehicle speed may not be correctly detected, and the following systems may not
operate correctly:
Also, not only can the following system not be utilized fully, but it may even negatively
affect the drive-train components:
• AWD system (AWD models) ■
Speed limit when using the compact spare tire
Do not drive at speeds in excess of 50 mph (80 km/h) when a compact spare tire is
installed on the vehicle.
The compact spare tire is not designed for driving at high speeds. Failure to observe
this precaution may lead to an accid ent causing death or serious injury.■
After using the tools and jack
Before driving, make sure all the tools and jack are securely in place in their storage
location to reduce the possibility of personal injury during a collision or sudden brak-
ing.• ABS & Brake assist
•VSC
•TRAC
• Trailer Sway Control
•EPS
• VDIM (if equipped)
• Adaptive Variable Suspension System
(if equipped)
• Cruise control (if equipped)
• Dynamic radar cruise control (if
equipped)
• Dynamic radar cruise control with full-
speed range (if equipped)
• PCS (Pre-Collision System) (if
equipped) • LDA (Lane Departure Alert with
steering control) (if equipped)
• LKA (Lane-keeping Assist) (if
equipped)
• Automatic High Beam (if equipped)
• AFS (Adaptive Front-lighting System)
(if equipped)
• Tire pressure warning system
• Intuitive parking assist (if equipped)
• Lexus parking assist monitor (if
equipped)
• Panoramic view monitor (if equipped)
• BSM (Blind Spot Monitor) (if
equipped)
• Navigation system (if equipped)

6578-2. Steps to take in an emergency
8
When trouble arises
RX350_U_OM48E90U NOTICE ■
Be careful when driving over bumps with the compact spare tire installed on the vehi-
cle
When driving with the compact spare tire inst alled, the vehicle height will be different
than when driving with standard tires. Be careful when driving over uneven road sur-
faces, etc. ■
Driving with tire chains and the compact spare tire
Do not fit tire chains to the compact spare tire.
Tire chains may damage the vehicle body and adversely affect driving performance.■
When replacing the tires
When removing or fitting the wheels, tires or the tire pressure warning valve and trans-
mitter, contact your Lexus dealer as the tire pressure warning valve and transmitter
may be damaged if not handled correctly.

658 8-2. Steps to take in an emergency
RX350_U_OM48E90U One of the following may be the cause of the problem: ●
There may not be sufficient fuel in the vehicle’s tank.
Refuel the vehicle. ●
The engine may be flooded.
Try to restart the engine again following correct starting procedures.
(  P. 220)●
There may be a malfunction in the engine immobilizer system. (  P. 74 )
One of the following may be the cause of the problem: ●
The battery terminal connections may be loose or corroded. ●
The battery may be discharged. (  P. 6 6 5 )
The engine starting system may be malfun ctioning due to an electrical problem
such as electronic key battery depletion or a blown fuse. However, an interim
measure is available to start the engine. (  P. 6 5 9 )If the engine will not start If the engine will not start even though correct starting procedures are being
followed (  P. 220), consider each of the following points:
The engine will not start even thoug h the starter motor operates nor-
mally.
The starter motor turns over slowly , the interior lights and headlights
are dim, or the horn does not sound or sounds at a low volume.
The starter motor does not turn over

6598-2. Steps to take in an emergency
8
When trouble arises
RX350_U_OM48E90U One of the following may be the cause of the problem: ●
One or both of the battery terminals may be disconnected. ●
The battery may be discharged. (  P. 6 6 5 )●
There may be a malfunction in the steering lock system. Contact your Lexus dealer if the problem cannot be repaired, or if repair procedures
are unknown.
When the engine does not start, the following steps can be used as an interim
measure to start the engine if the engine switch is functioning normally.
T urn the engine switch to IGNITION ON mode and check that the parking
brake is set. (  P. 221, 235)
Shift the shift lever to P.
Turn the engine switch to ACCESSORY mode.
Press and hold the engine switch for about 15 seconds while depressing the
brake pedal firmly.
Even if the engine can be started using the above steps, the system may be mal-
functioning. Have the vehicle inspected by your Lexus dealer.The starter motor does not turn ove r, the interior lights and headlights
do not turn on, or the horn does not sound.
Emergency start function 1
2
3
4

660 8-2. Steps to take in an emergency
RX350_U_OM48E90U T urn the engine switch to IGNITION ON mode and check that the parking
brake is set. (  P. 221, 235)
Turn the engine switch to ACCESSORY mode.
Depress the brake pedal.
Pry the cover up with a flathead
screwdriver or equivalent tool. To prevent damage to the cover, cover
the tip of the screwdriver with a rag.
Press the shift lock override button. The shift lever can be shifted while the
button is pressedIf the shift lever cannot be shifted from P If the shift lever cannot be shifted with your foot on the brake pedal, there may
be a problem with the shift lock system (a system to prevent accidental opera-
tion of the shift lever). Have the vehicl e inspected by your Lexus dealer imme-
diately.
The following steps may be used as an emergency measure to ensure that the
shift lever can be shifted: 1
2
3
4
5
