4.2.5 Map Settings
You can fine-tune the appearance of the Map screen, adjust the map view to your
needs, show or suppress 3D buildings, and manage Place visibility settings (which
Places to show on the map).
The map is always shown on the screen so that you can see the effect when you
change a setting. Scroll the screen downward to display the setting behind the lower
part of the screen.
Button Description
When this button is selected, the map view mode can
be changed.
•
: Displays things such as actual construction
sites three dimensionally on the map.
•
: The map is rotated so that the direction of
travel is displayed in the upward direction.
•
: The map is displayed so that north is up
regardless of the direction of travel.
Adjust the basic zoom and tilt levels to your needs.
Three levels are available.
During route guidance in any map view mode, the
function for zooming in on approaching intersections
turns on/off automatically.
Show or hide 3D city models, 3D artistic or block
representation of all city building data containing
actual building sizes and positions on the map.
NAV-12AVUAE.indb 812015/02/20 15:09:16

82
ButtonDescription
When enabled, the map zooms out to show an
overview of the surrounding area if the next route
event (maneuver) is far away. The system goes back
to the normal map view when you approach the next
event.
Select which Places to show on the map while
navigating. Too many Places make the map crowded,
so it is a good idea to show as few as possible. You
have the following possibilities:
•
Select the checkbox to show or hide the Place
category.
•
Select the name of the Place category to open the list
of its subcategories.
NAV-12AVUAE.indb 822015/02/20 15:09:16

83
1
2
3
4
5
6
4.2.6 Visual Guidance settings
Adjust how the software helps you navigate with different kinds of route related
information on the Map screen.
ButtonDescription
Whenever adequate information is available, lane
information similar to the real ones on road signs
above the road is displayed at the top of the map.
You can turn this feature on or off.
If you are approaching a highway/freeway exit or
a complex intersection and the needed information
exists, the map is replaced with a 3D view of the
junction. You can turn this feature on or let the map
be displayed for the whole route.
When entering tunnels, the surface roads and
buildings can be disturbing. This feature shows a
generic picture of a tunnel instead of the map. A top-
down overview of the tunnel and remaining distance
are also displayed.
NAV-12AVUAE.indb 832015/02/20 15:09:16

84
5 Glossary
Active route
The currently navigated route. Whenever a destination is set, the route is active until
you delete it or reach your destination. See also: Route.
City
Center
The city center is not the geometric center of the city but an arbitrary point the
map creators have chosen. In cities and villages, it is usually the most important
intersection; in larger cities, it is one of the important intersections.
Color
theme
The navigation system has different color themes for daytime and nighttime which
can be selected as desired.
One daytime scheme and one nighttime scheme is always selected for the map and
for the menus.
The navigation system uses them when it switches from day to night and back.
GPS
accuracy
Several factors have impact on the deviation between your real position and the one
given by the GPS device. For example, signal delay in the ionosphere or reflecting
objects near the GPS device have a different and varying impact on how accurately
the GPS device can calculate your position.
NAV-12AVUAE.indb 842015/02/20 15:09:16

85
1
2
3
4
5
6
5 Glossary
Active route
The currently navigated route. Whenever a destination is set, the route is active until
you delete it or reach your destination. See also: Route.
City Center
The city center is not the geometric center of the city but an arbitrary point the
map creators have chosen. In cities and villages, it is usually the most important
intersection; in larger cities, it is one of the important intersections.
Color theme
The navigation system has different color themes for daytime and nighttime which
can be selected as desired.
One daytime scheme and one nighttime scheme is always selected for the map and
for the menus.
The navigation system uses them when it switches from day to night and back.
GPS accuracy
Several factors have impact on the deviation between your real position and the one
given by the GPS device. For example, signal delay in the ionosphere or reflecting
objects near the GPS device have a different and varying impact on how accurately
the GPS device can calculate your position.
Map
The navigation system works with digital maps which are not simply the
computerized versions of traditional paper maps. Similarly to paper road maps, the
2D mode of digital maps show you streets, roads, and elevation by colors.
In 3D mode, you can see the altitude differences, for example valleys and
mountains, elevated roads, and in selected cities 3D landmarks and 3D buildings are
also displayed.
You can use digital maps interactively: you can zoom in and out (increase or
decrease the scale), you can tilt them up and down, and rotate them left and right. In
GPS-supported navigation, digital maps facilitate route planning.
North-up
map orientation
In North-up mode the map is rotated so its top always faces North. This is the
orientation for example in Find on Map.
Road
Safety Camera
This function is not available in some countries and regions.
Special alert points for speed, red light or bus lane cameras. Dif ferent data sources
are available. You can configure the navigation system to warn you when you
approach one of these cameras.
Detecting the location of Road Safety Cameras is prohibited in certain countries.
It is the sole responsibility of the driver to check whether this feature can be used
during the trip.
The software is capable of showing and warning for more than just cameras. V

arious
other types of proximity alert points like school zones and railway crossings are also
available.
Route

A sequence of maneuvers (for example, turns and roundabouts) to reach the
destination. The route contains one start point and one or more destinations.
T

rack-up
map orientation
In Track-up mode the map is rotated so its top always points in the current driving
direction.

This is the default orientation in 3D map view mode.
Vehicle
marker
The current position is indicated by a blue arrow on the map. The direction the blue
arrow is pointed indicates the current heading.
NAV-12AVUAE.indb 852015/02/20 15:09:16

86
6 End-User Terms
The data (“Data”) is provided for your personal, internal use only and not for resale.
It is protected by copyright, and is subject to the following terms and conditions
which are agreed to by you, on the one hand, and [CLIENT] (“[CLIENT]”) and its
licensors (including their licensors and suppliers) on the other hand.
© 200X NAVTEQ [Insert any applicable copyright notices as required for the
country-specific Data being used]. All rights reserved.
The Data for areas of Canada includes information taken with permission from
Canadian authorities, including: © Her Majesty the Queen in Right of Canada, ©
Queen's Printer for Ontario, © Canada Post Corporation, GeoBase
®, © Department
of Natural Resources Canada.
NAVTEQ holds a non-exclusive license from the United States Postal Service
® to
publish and sell ZIP+4® information.
©United States Postal Service
® 200X. Prices are not established, controlled or
approved by the United States Postal Service®. The following trademarks and
registrations are owned by the USPS: United States Postal Service, USPS, and
ZIP+4.
Terms
and Conditions
Personal Use Only. You agree to use this Data together with [insert name of
CLIENT’

s authorized Application] for the solely personal, non-commercial
purposes for which you were licensed, and not for service bureau, time-sharing
or other similar purposes. Accordingly, but subject to the restrictions set forth
in the following paragraphs, you may copy this Data only as necessary for your
personal use to (i) view it, and (ii) save it, provided that you do not remove any
copyright notices that appear and do not modify the Data in any way . You agree
not to otherwise reproduce, copy, modify, decompile, disassemble, create any
derivative works of, or reverse engineer any portion of this Data, and may not
transfer or distribute it in any form, for any purpose, except to the extent permitted
by mandatory laws.
NAV-12AVUAE.indb 862015/02/20 15:09:16

87
1
2
3
4
5
6
6 End-User Terms
The data (“Data”) is provided for your personal, internal use only and not for resale.
It is protected by copyright, and is subject to the following terms and conditions
which are agreed to by you, on the one hand, and [CLIENT] (“[CLIENT]”) and its
licensors (including their licensors and suppliers) on the other hand.
© 200X NAVTEQ [Insert any applicable copyright notices as required for the
country-specific Data being used]. All rights reserved.
The Data for areas of Canada includes information taken with permission from
Canadian authorities, including: © Her Majesty the Queen in Right of Canada, ©
Queen's Printer for Ontario, © Canada Post Corporation, GeoBase
®, © Department
of Natural Resources Canada.
NAVTEQ holds a non-exclusive license from the United States Postal Service
® to
publish and sell ZIP+4® information.
©United States Postal Service
® 200X. Prices are not established, controlled or
approved by the United States Postal Service®. The following trademarks and
registrations are owned by the USPS: United States Postal Service, USPS, and
ZIP+4.
Terms and Conditions
Personal Use Only. You agree to use this Data together with [insert name of
CLIENT’s authorized Application] for the solely personal, non-commercial
purposes for which you were licensed, and not for service bureau, time-sharing
or other similar purposes. Accordingly, but subject to the restrictions set forth
in the following paragraphs, you may copy this Data only as necessary for your
personal use to (i) view it, and (ii) save it, provided that you do not remove any
copyright notices that appear and do not modify the Data in any way . You agree
not to otherwise reproduce, copy, modify, decompile, disassemble, create any
derivative works of, or reverse engineer any portion of this Data, and may not
transfer or distribute it in any form, for any purpose, except to the extent permitted
by mandatory laws.
Restrictions. Except where you have been specifically licensed to do so by
[CLIENT], and without limiting the preceding paragraph, you may not (a) use this
Data with any products, systems, or applications installed or otherwise connected
to or in communication with vehicles, capable of vehicle navigation, positioning,
dispatch, real time route guidance, fleet management or similar applications; or (b)
with or in communication with any positioning devices or any mobile or wireless-
connected electronic or computer devices, including without limitation cellular
phones, palmtop and handheld computers, pagers, and personal digital assistants or
PDAs.
Warning. The Data may contain inaccurate or incomplete information due to the
passage of time, changing circumstances, sources used and the nature of collecting
comprehensive geographic data, any of which may lead to incorrect results.
No Warranty. This Data is provided to you “as is,” and you agree to use it at your
own risk. [CLIENT] and its licensors (and their licensors and suppliers) make no
guarantees, representations or warranties of any kind, express or implied, arising
by law or otherwise, including but not limited to, content, quality , accuracy,
completeness, effectiveness, reliability, fitness for a particular purpose, usefulness,
use or results to be obtained from this Data, or that the Data or server will be
uninterrupted or error-free.
Disclaimer of Warranty: [CLIENT] AND ITS LICENSORS (INCLUDING THEIR
LICENSORS AND SUPPLIERS) DISCLAIM ANY WARRANTIES, EXPRESS
OR IMPLIED, OF QUALITY, PERFORMANCE, MERCHANTABILITY,
FITNESS FOR A PARTICULAR PURPOSE OR NON-INFRINGEMENT. Some
States, Territories and Countries do not allow certain warranty exclusions, so to that
extent the above exclusion may not apply to you.
NAV-12AVUAE.indb 872015/02/20 15:09:16

88
Disclaimer of Liability: [CLIENT] AND ITS LICENSORS (INCLUDING
THEIR LICENSORS AND SUPPLIERS) SHALL NOT BE LIABLE TO YOU:
IN RESPECT OF ANY CLAIM, DEMAND OR ACTION, IRRESPECTIVE OF
THE NATURE OF THE CAUSE OF THE CLAIM, DEMAND OR ACTION
ALLEGING ANY LOSS, INJURY OR DAMAGES, DIRECT OR INDIRECT,
WHICH MAY RESULT FROM THE USE OR POSSESSION OF THE
INFORMATION; OR FOR ANY LOSS OF PROFIT, REVENUE, CONTRACTS
OR SAVINGS, OR ANY OTHER DIRECT, INDIRECT, INCIDENTAL,
SPECIAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF YOUR USE
OF OR INABILITY TO USE THIS INFORMATION, ANY DEFECT IN THE
INFORMATION, OR THE BREACH OF THESE TERMS OR CONDITIONS,
WHETHER IN AN ACTION IN CONTRACT OR TORT OR BASED ON A
WARRANTY, EVEN IF [CLIENT] OR ITS LICENSORS HAVE BEEN ADVISED
OF THE POSSIBILITY OF SUCH DAMAGES. Some States, Territories and
Countries do not allow certain liability exclusions or damages limitations, so to that
extent the above may not apply to you.
Export Control. You agree not to export from anywhere any part of the Data
provided to you or any direct product thereof except in compliance with, and
with all licenses and approvals required under, applicable export laws, rules and
regulations.
Entire Agreement. These terms and conditions constitute the entire agreement
between [CLIENT] (and its licensors, including their licensors and suppliers) and
you pertaining to the subject matter hereof, and supersedes in their entirety any and
all written or oral agreements previously existing between us with respect to such
subject matter.
Governing Law. The above terms and conditions shall be governed by the laws of
the State of Illinois [insert “Netherlands” where European NAVTEQ Data is used],
without giving effect to (i) its conflict of laws provisions, or (ii) the United Nations
Convention for Contracts for the International Sale of Goods, which is explicitly
excluded. You agree to submit to the jurisdiction of the State of Illinois [insert “The
Netherlands” where European NAVTEQ Data is used] for any and all disputes,
claims and actions arising from or in connection with the Data provided to you
hereunder.
NAV-12AVUAE.indb 882015/02/20 15:09:16

89
1
2
3
4
5
6
Government End Users. If the Data is being acquired by or on behalf of the United
States government or any other entity seeking or applying rights similar to those
customarily claimed by the United States government, this Data is a “commercial
item” as that term is defined at 48 C.F.R. (“FAR”) 2.101, is licensed in accordance
with these End-User Terms, and each copy of Data delivered or otherwise furnished
shall be marked and embedded as appropriate with the following “Notice of Use,”
and shall be treated in accordance with such Notice:
NOTICE
OF USE
CONTRACTOR (MANUFACTURER/SUPPLIER) NAME: NA
VTEQ
CONTRACTOR (MANUFACTURER/SUPPLIER) ADDRESS: 425 West Randolph
Street, Chicago, Illinois 60606

This Data is a commercial item as defined in FAR 2.101 and is subject to these End-
User Terms under which this Data was provided.
© 200X NAVTEQ – All rights reserved.
If the Contracting Officer, federal government agency, or any federal official refuses
to use the legend provided herein, the Contracting Officer, federal government
agency, or any federal official must notify NAVTEQ prior to seeking additional or
alternative rights in the Data.
NAV-12AVUAE.indb 892015/02/20 15:09:16

NAV-12AVUAE.indb 902015/02/20 15:09:16
