Mercury Villager 1996 Owner's Manuals

Electronic Sound Systems
225
[AS32520(ALL)06/95]
Using the ªPROGRAM ADVANCEº button
[AS32540(ALL)06/95]
This button has different functions depending on the audio
source. In radio mode, pressing this button will cycle through
the memory presets for the given frequency band (AM, FM1,
FM2). In the cassette mode, pressing this button will change
tape sides. During the CD operation, this button will cycle
through the discs (one button push, one disc advance).
[AS32560(ALL)06/95]
Using the ªSOURCE SELECTº button
[AS32580(ALL)06/95]
This button will cycle through all modes then begin to play. The
cycle order is as follows: AM, FM1, FM2, tape, CD (if
equipped).
[AS32600(ALL)06/95]
How to turn the speakers on and off
[AS32620(ALL)06/95]
When the rear seat controls are on, push the ªSPKRS, ON-OFFº
button to turn all speakers off. Push again to turn all speakers
on.
[AS32640(ALL)06/95]
Using headphones with the rear seat controls
[AS32660(ALL)06/95]
Two 3.5mm headphone jacks have been provided on the rear
seat controls. Plug headphones into the provided jack(s) to
operate headphones. Note that the headphones can be used only
when the speakers are off.
[AS32680(ALL)06/95]
Using the ªSEEKº button
[AS32700(ALL)06/95]
This button has different functions for each source (mode). In
radio mode, pressing ªSEEKº proceeds to the previous or next
station. In cassette mode, this button is an Automatic Music
Search (AMS), moving to the next or previous selection on the
tape. In CD mode, this button moves to the beginning of the
next or previous track.
File:10vxasn.ex
Update:Mon Jun 3 14:57:29 1996

226
[AS32720(ALL)06/95]
How to Use Your Steering Wheel Audio
Controls (If equipped)
[AS32740(ALL)06/95]
If your vehicle is equipped with steering wheel audio controls,
the controls are located on the inner right rim of the steering
wheel. These controls duplicate some of the audio functions.
[AS32760(ALL)06/95]
How to adjust volume
[AS32780(ALL)06/95]
Press the up arrow button (G) to increase the volume.
[AS32800(ALL)06/95]
Press the down arrow button (H) to decrease the volume.
[AS32820(ALL)06/95]
Using the ªNEXTº button
[AS32840(ALL)06/95]
This control has different functions for each source (mode). In
the radio mode, the radio will cycle through the memory
presets for the given frequency band. In cassette mode, the tape
advances to the next selection. In CD mode, the CD will move
to the next track on the given disc.
*
[AS35200(ALL)06/95]
Common Radio Reception Conditions
[AS35300(ALL)03/93]
Several conditions affect FM reception and can result in noise or
interference in the reception. These are:
[AS35400(ALL)03/93]
Distance/Strength
[AS35500(ALL)05/94]
The strength of the FM signal is directly related to the distance
the signal must travel. The listenable range of an average FM
signal is approximately 25 miles (40 km). Beyond this distance,
the radio is operating in a ªfringeº area and the signal becomes
weaker.
[AS35600(ALL)03/93]
Terrain
[AS35700(ALL)05/94]
The terrain (hills, mountains, tall buildings) of the area over
which the signal travels may prevent the FM signal from being
noise-free.
File:10vxasn.ex
Update:Mon Jun 3 14:57:29 1996

Electronic Sound Systems
227
*
[AS35900(ALL)01/95]
If there is a building or large structure between the antenna and
station, some of the signal ªbendsº around the building, but
certain spots receive almost no signal. Moving out of the
ªshadowº of the structure will allow the station to return to
normal.
[AS36000(ALL)05/95]
This condition exists when the radio waves are reflected off
objects or structures; the reflected signal cancels the normal
signal, causing the antenna to pick up noise and distortion.
Cancellation effects are most prominent in metropolitan areas,
but also can becomes quite severe in hilly terrain and depressed
roadways.
[AS36100(ALL)03/93]
To minimize the effects of these conditions, a stereo/mono
blend circuit has been incorporated into this system. This feature
automatically switches a weak stereo signal to a clearer
monaural signal, which improves the quality of reception.
*
[AS36200(ALL)01/95]
Several sources of static are normal conditions on AM
frequencies. These can be caused by power lines, electric fences,
traffic lights and thunderstorms.
*
[AS36300(ALL)01/95]
Another reception phenomenon isStrong Signal Capture and
Overload. This can occur when listening to a weak station and
when passing another broadcast tower. The close station may
capture the more distant station, although the displayed
frequency does not change. While passing the tower, the station
may switch back and forth a few times before returning to the
original station.
*
[AS36400(ALL)01/95]
When several broadcast towers are present (common in
metropolitan areas) several stations may overload the receiver,
resulting in considerable station changing, mixing and
distortion.
*
[AS36500(ALL)01/95]
Automatic gain control circuitry for both AM and FM bands has
been incorporated into this system to reduce strong signal
capture and overload.
File:10vxasn.ex
Update:Mon Jun 3 14:57:29 1996

228
%*
[AS36600(ALL)08/89]
All About Radio Frequencies
[AS36700(ALL)06/95]
The Federal Communications Commission (FCC) and the
Canadian Radio and Telecommunications Commission (CRTC)
establish the frequencies that AM and FM radio stations may
use for their broadcasts. The allowable frequencies are: AM: 530,
540...1700, 1710 kHz in 10 kHz steps; FM: 87.9, 88.1...107.7, 107.9
MHz in 0.2 MHz steps.
[AS36800(ALL)03/93]
Not all frequencies will be assigned to a given area. This radio
will tune to each of these frequencies using manual tuning and
no fine tuning is necessary as radio stations may not use other
frequencies.
[AS36900(ALL)03/93]
Some FM radio stations advertise a ªrounded-offº frequency
which is not the frequency on which they actually broadcast.
For example, a radio station that is assigned a frequency of 98.7
MHz may call itself ªRadio 99º even though 99.0 MHz is not an
allowable FM broadcast frequency.
*
[AS37000(ALL)01/95]
Important Warranty and Service Information
*
[AS37050(ALL)01/95]
About Your Warranty
[AS37100(ALL)03/93]
Your sound system is warranted for three years. Consult your
vehicle warranty booklet for further information.
*
[AS37150(ALL)01/95]
Servicing Your Audio System
[AS37200(ALL)03/93]
At Ford Audio, we stand behind our audio systems with a
comprehensive service and repair program. If anything should
go wrong with your Ford Audio System, return to your dealer
for service. There is a nationwide network of qualified Ford
authorized repair centers to service your problem.
File:10vxasn.ex
Update:Mon Jun 3 14:57:29 1996

229
Driving Your Villager
%*[DR01000(ALL)01/93]Automatic Transaxle Operation
*[DR01100(ALL)01/95]Putting Your Vehicle in Gear
*[DR01200(ALL)04/95]Your vehicle's gearshift lever is on the steering column. The
OVERDRIVE OFF/ON button is located on the end of the
gearshift lever. You can put the gearshift lever in any one of
several positions.
[DR01300(ALL)06/95]
10-1/2 pica art:0040163-F
The steering column gearshift lever positions
*[DR01400(ALL)05/95]RWARNING
Hold the brake pedal down while you move the gearshift
lever from position to position. If you do not hold the
brake pedal down, your vehicle may move unexpectedly
and injure someone.
*[DR01500(ALL)01/93]Once you place the gearshift lever securely into position,
gradually release the brake pedal and use the accelerator as
necessary.
File:11vxdrn.ex
Update:Tue Jun 4 11:42:50 1996

230
[DR01600(ALL)09/93]Shift-lock Safety Feature
[DR01700(ALL)04/95]Your vehicle has a special shift-lock safety feature which
prevents you from shifting out of P (Park) without the brake
pedal depressed. To shift the transaxle out of the P (Park)
position, the ignition must be in the ON position and your foot
must be pressing on the brake pedal.
*[DR01800(ALL)04/95]If the shift lever cannot be moved from the P (Park) position
with the brake pedal depressed:
*[DR01900(ALL)01/93]1.Shut the engine off and remove the ignition key.
*[DR02000(ALL)01/93]2.Apply the parking brake.
*[DR02100(ALL)01/93]3.Reinsert the ignition key and turn it clockwise to the first
position (OFF).
*[DR02200(ALL)04/95]4.Depress the brake pedal, move the gearshift lever to N
(Neutral) and start the engine.
*[DR02290(ALL)06/95]If you need to shift out of P (Park) by using the alternate
procedure described above, it is possible that a fuse has blown
and that your brakelamps may also not be functional. Please
refer to the chapter titledServicing Your Villagerin this Owner
Guide for instructions on checking and replacing fuses.
*[DR02300(ALL)05/95]R WARNING
DO NOT DRIVE YOUR VEHICLE UNTIL YOU VERIFY
THAT THE BRAKELAMPS ARE WORKING.
%*[DR02500(ALL)06/92]Backing Up
*[DR02600(ALL)06/95]Before shifting into or out of R (Reverse), you should always
come to a complete stop.
File:11vxdrn.ex
Update:Tue Jun 4 11:42:50 1996

Driving Your Villager
231
*
[DR02700(ALL)01/95]
Driving
[DR03000(ALL)06/95]
When to use D (Overdrive)
[DR03100(ALL)01/93]
Overdrive is the normal driving position. When the gearshift
lever is placed in (D) Overdrive, and the Overdrive Off button
has not been pressed, the vehicle will automatically upshift to
second, third and fourth gears. The transaxle will shift into the
correct gear when the right speed is reached.
%*
[DR03200(ALL)06/95]
When to use D (Drive Ð with the Overdrive Off button
activated)
[DR03300(ALL)06/95]
You will notice that there is only one drive position on your
gearshift selection indicator (instead of Drive and Overdrive).
You will find a button labeled OVERDRIVE OFF/ON located on
the gearshift lever. Push in the button on the end of the lever
and the O/D OFF light in the instrument cluster will illuminate.
With the O/D OFF light illuminated, the transaxle will operate
in first, second and third gears and will not shift into fourth
gear. Operating in Drive (O/D OFF) provides more engine
braking than Overdrive for descending hills, or city driving.
[DR03400(ALL)06/95]
6 pica art:0040164-C
The OVERDRIVE OFF/ON button
*
[DR03500(ALL)09/93]
To return the transaxle to the normal Overdrive operation, press
the OVERDRIVE OFF/ON button again. Use this button to
select Overdrive or Overdrive Off whenever you drive your
vehicle.
[DR03600(ALL)02/95]
NOTE: Overdrive will not engage until the engine has fully
warmed up.
File:11vxdrn.ex
Update:Tue Jun 4 11:42:50 1996

232
*
[DR03700(ALL)02/95]
The transaxle will be in the ªoverdrive onº mode when the
vehicle is started even if the O/D OFF mode was selected when
the vehicle was last shut off.
[DR03800(ALL)04/94]
If your vehicle is on an extremely slippery surface, the
Electronic Transaxle Control Module may receive a signal
indicating a rapid increase or decrease in wheel speed. If the
module detects this condition, it will limit the transaxle
operation to Third gear and Reverse. This reduces tire slippage
and protects the transaxle. The transaxle will operate normally
in Reverse, but will lack power during acceleration in Drive. If
this happens, stop your vehicle as soon as possible and turn the
ignition off for 3 seconds. Restart the vehicle. If the condition
still exists, contact your dealer as soon as possible.
*
[DR03900(ALL)04/95]
NOTE: If the O/D OFF indicator light is flashing on and off
repeatedly when the vehicle is started, there is a
transaxle electronic system malfunction. Contact your
dealer as soon as possible.
*
[DR04000(ALL)06/95]
When to use 2 (Second)
[DR04100(ALL)01/93]
Use Second (2) when driving on slippery roads or to provide
additional engine braking on downgrades. This position
provides Second gear operation only. Do not exceed 68 mph
(110 km/h) in this position.
*
[DR04200(ALL)06/95]
When to use 1 (First)
[DR04300(ALL)01/93]
Use First (1) to provide maximum engine braking on steep
downgrades. Upshifts from First can be made by manually
shifting to Second (2) or Overdrive (D). First (1) gear provides
only first gear operation. If you select First while driving at
higher speeds, the transaxle will shift to Second (2), and then
shift back to First (1) after the vehicle decelerates to the proper
speed. Do not exceed 35 mph (56 km/h) in this position.
File:11vxdrn.ex
Update:Tue Jun 4 11:42:50 1996

Driving Your Villager
233
[DR04320(ALL)06/95]
N (Neutral)
*
[DR04340(ALL)06/95]
In N (Neutral), the wheels of the transaxle are not locked. Your
vehicle will roll freely, even on the slightest incline, unless the
parking brake or brakes are on.
*
[DR04400(ALL)06/92]
Parking
*
[DR04500(ALL)06/95]
Always come to a complete stop before you shift into P (Park).
This position locks the transaxle and prevents the front wheels
from turning. To securely latch the gearshift in the P (Park)
position, pull it toward you, push it completely
counterclockwise against the stop, and then push it toward the
instrument panel.
[DR04600(ALL)01/93]
The gearshift is securely latched in Park (P) if you cannot rotate
it in a clockwise direction without lifting it toward you.
*
[DR04700(ALL)06/95]
RWARNING
Always set the parking brake fully and make sure the
gearshift is securely latched in P (Park).
*
[DR04800(ALL)06/95]
RWARNING
Never leave your vehicle unattended while it is running.
*
[DR05000(ALL)06/94]
Forced Downshifts
[DR05100(ALL)01/93]
To gain extra acceleration in Drive (D) (when passing another
vehicle) push the accelerator to the floor. The transaxle will
automatically downshift to the appropriate gear - third, second
or first.
File:11vxdrn.ex
Update:Tue Jun 4 11:42:50 1996

234
*
[DR05700(ALL)01/95]
Steering Your Vehicle
*
[DR05800(ALL)01/93]
Your vehicle has power steering. Power steering uses energy
from the engine to help steer your vehicle.
%*
[DR05850(ALL)04/95]
If the amount of effort needed to steer your vehicle changes at a
constant vehicle speed, have the power steering system checked.
If the power steering system breaks down (or if the engine is
turned off), you can steer the vehicle manually but it takes more
effort.
*
[DR05900(ALL)01/93]
Never hold the steering wheel in the extreme right or left
position for more than five seconds if the engine is running.
This can damage the power steering pump.
*
[DR06100(ALL)01/93]
NOTE: After any severe impact such as striking large
potholes, sliding into curbs on icy roads, or a collision
involving the front end, have the front suspension
and steering checked for possible damage.
*
[DR06200(ALL)03/95]
Brakes
*
[DR06300(ALL)01/93]
When the foot (service) brake pedal is depressed, the
high-mount brake lamp should illuminate.
*
[DR06400(ALL)01/93]
Front Disc Brakes
[DR06500(ALL)01/93]
The front disc brakes are self-adjusting. They do not require
service other than periodic lubrication of the caliper slide rails
and inspection for pad wear.
*
[DR06600(ALL)10/94]
Rear Drum Brakes
*
[DR06700(ALL)01/93]
The rear drum brakes are self-adjusting. Automatic adjustment
occurs through normal use of the brakes.
File:11vxdrn.ex
Update:Tue Jun 4 11:42:50 1996
