ENGINE - Servioe Adjustment ProceduresII-II
Access
cover
,-
(0 a0
<
0 0
0 0
0
101 II0221
Access cover
Screwdriver slot
3EN075
(9) Remove the air conditioning drive belt and the generator drive belt.
(10)Removle the access covers. There are easily removed by
inserting a screwdriver into the slots indicated by the raised
arrows in the timing belt cover and twisting. (1l)lnset-t
the special tool (MD998051-01)
from the pivot side
access hole and loosen the tension spacer (with a tensioner lock nut on it) 1 to 2 turn.
Next insert a 14 mm socket wrench from the slot side
access hole and loosen the tensioner lock bolt 1 to 2 turn.
(12)Turn the crankshaft clockwise by two teeth of the camshaft
sprocket.
(13)First ticjhten the timing belt tensioner installation bolt (on
the
lo&er side), and then tighten the tensioner spacer
(upper side).
Caution
Be sure to tighten the bolt (lower side) first. lf the
tensioner spacer of pivot side is tightened first, the
tensioner will rotate with it and belt tension may
becorn; loose.
(14)lnstall the access cover. The access cover may be easily
installeNd by passing the hooks between the guides and
sliding it in.
(15)lnstall the air conditioning drive belt and generator drive
belt and adjust the slack. (Refer to P.l
l-l 2.)
(16)lnstall the timing belt front upper cover.
(17)lnstall the engine mounting bracket.
(18)lnstall the spark plugs.
(19)lnstall the left side undercover panel.
TSB Revision

11-12ENGINE - Service Adjustment Procedures
DRIVE BELTS TENSION ADJUSTMENT
MllFMBBO
(1) Check that the belts are not damaged.
Power steenng
oil pump
pulley
\
W
ater
pump
pulley
I Tension
pulley/
Generator
compressor
Crankshaft
pulley pulley
We
Spindle----As.
IRESET button (2) Apply
IOON (22 Ibs.) force to the belt back midwa
y
between the pulleys as shown in the figure, measure the
deflection or, by using a belt-tension gauge, check the
belt’s tension.
Standard value:
Gauge250-500500-700400 (88)
N (Ibs.)(55-110)(110-154)
ForAKDeflection Approx. 8.05.0-5.56.0-7.0
compressor mm (in.)(.315)(.197-,217) (.236-.276)
For P/S
pump Gauge
250-500320-400470-570
N (Ibs.)(55-110)(71-88)(104-126)
Deflection 6.0-9.0
-mm (in.)(.236-,354)
NOTE
There is more than one type of belt-tension gauge (type A and
type
8, for example), so be sure to use the gauge according to
its instructions for use.
1 TSB Revision

ENGINE - Service Adjustment ProceduresII-13
TENSION ADJUSTMENT OF THE GENERATOR DRIVE
BELT
Pwot
nut
,,,\
\ // \ 01u0090
Belt tension 01A0060
-
W

ater
OiA0059
Caution
1. Before checking, turn the engine one time or more.
2.If the belt tension is too strong, it is possible that the
generator or water pump bearing is damaged.
If the b’elt tension is too weak, however, sounds of its
slipping will be heard, and the belt’s service life will be
reduced.
1.Loosen the generator pivot nut.
2. Loosen the lock bolt of the belt tension adjuster.
3. Using the adjustment bolt, adjust the belt tension to
specified.
4. Tighten the lock bolt.
5.Tighten the generator pivot nut.
6.Check the deflection or the tension of the belt; readjust if
necessary.
NOTE
Even for a new belt, the adjustment value for a used belt
should be used to make the adjustment if the belt has been
used for as long as five minutes or more.
DEFLECTION ADJUSTMENT OF POWER STEERING OIL
PUMP DRIVE BELT
1. Loosen power steering oil pump fixing bolt.
2. Move power steering pump, tension belt moderately and adjust deflection.
3. Tighten fixing bolts.
4. Run the engine one time or more.
5. Check the belt deflection. Readjust, if necessary.
TENSION ADJUSTMENT OF THE AIR CONDITIONING
COMPRESSOR DRIVE BELT
1. Loosen tension pulley fixing bolt A.
2. Adjust belt deflection with adjusting bolt B.
3. Tighten fixing bolt A.
4. Run the engine one time or more. 5. Check the belt tension. Readjust, if necessary.
NOTE
Even for a new belt, the adjustment value for a used belt
should be used to make the adjustment if the belt has been
used for as long as five minutes or more.
TSB RevisionI

II-14ENGINE - Ennine AssemblvENGINE
ASSEMBLY

(8 VALVE>
REMOVAL AND INSTALLATION
Pre-removal Operationl Eliminating fuel pressure in fuel line
(Refer to GROUP 13-On-Vehicle Inspection
of MFI Components.)
*Removal of the Hood (Refer to GROUP
42-Hood.)*Draining of the Coolant
(Refer to GROUP OO-Maintenance Service.)
*Removal of the Transaxle Assembly
(Refer to GROUP 22,
23-Transaxle.)*Removal of the Radiator(Refer to GROUP 14-Radiator.)
I IPost-installation Operation*Installation of the Radiator
(Refer to GROUP 14-Radiator.)*Installation of the Transaxle Assembly (Refer to GROUP 22, 23-Transaxle.)*Refilling of the Coolant(Refer to GROUP 00-Maintenance Servic
l Installation of the Hood
(Refer to GROUP
42-Hood.)
:e.) :1989
models>
-6
Nm-4 ft.lbs./
4-6 Nm3-4 ft.lbs.
cl990 models>
128
3-4 ftlbs. MllSA-A
<1991,1992 models>
1-6 Nm5-4 ft.lbs.
1-6 Nm1-4 ft.lbs.\
OlAO625
\,,OlA0647
1 TSB Revision

ENGINE - Engine Assembly11-15
35-4

5
25-33 35-45 Nm
25-33
ft.lbs.
24
35-45 N
m
25-33
ft.lbs.
23-2
7
250166309
I23
:l;nbs.
50-65 Nm
36-47 ft.lbs.
dv--iu wm: ’22-29 ft.lbs. \ d.(,(I3L i‘9
50-65 Nm*Cb36-47 ft.lbs.* -
Removal steps
1. Connection for accelerator cable(Refer to GROUP
13-Service Adjustment
Procedures.)
2. Connection for heater hose
3. Connection for brake booster vacuum
hose
4. Connection for fuel high pressure hose 5. O-ring
6. Connection for fuel return hose
7. Connection for vacuum hose
8. Connection for oxygen sensor
9. Connection for engine coolant temperature gauge unit
10. Connection for engine coolant
temperature sensor
11. Connection for
ISC12. Connection for injector13. Connection for EGR temperature sensor (California vehicles only)
14. Connection for ignition power transistor
15. Connection for condenser
16. Connection for TPS
17. Connection for idle speed control motor
position sensor
18. Connection for distributor
30-40 Nm
\22-29 ft.lbs.
bO-50 Nm29- 36 ft.lbs.
19. Connection for crankshaft position sensor
20. Connection for ground cable
21. Control wiring harness
22. Connection for generator
23. Connection for oil pressure switch
dae I)* 24. Power steering oil pump 27. Gasket
28. Clamp of pressure hose (Power steering) and high pressure hose (Air conditioning)
29. Engine mount bracket
30. Self locking nut
,** *+ 31. Engine assembly
IdOTEf-or tightening locations indicated by the * symbol. firsttighten temporarily, and then make the final tightenrng wrth?he entire werght of the engine applied to the vehicle body.
TSB Revision1

11-16ENGINE - Engine Assembly
SERVICE POINTS OF REMOVAL
Ml 1SBBC
24. REMOVAL OF POWER STEERING OIL PUMP
Remove the oil pump (with the hose attached).
NOTE
Suspend the removed oil pump (by using wire or similar
material) at a place where no damage will be caused
during removal/installation of the engine assembly.
25. REMOVAL OF AIR CONDITIONING COMPRESSOR
Disconnect the
connection of the air conditioning compres-
sor, and then remove the compressor (with the hose at-
tached) from the compressor bracket.
NOTE
Suspend the removed air conditioning compressor (by using wire or similar material) at a place where no damage
will be caused during removal/installation of the engine as-
sembly.
29. REMOVAL OF ENGINE MOUNT BRACKET
(1) Attach wire or similar material to the engine hook, and then suspend (to the extent that there is no slackness
of the wire) by using a chain block or similar arrange-
ment.
(2) Remove the engine mount bracket.
31. REMOVAL OF ENGINE ASSEMBLY
(1) Check to be sure that all cables, hoses, harness connectors, etc. are disconnected from the engine.
(2) Lift the chain block slowly to remove the engine assembly upward from the engine compartment
.
SERVICE POINTS OF INSTALLATION
MllSDAX
31. INSTALLATION OF ENGINE ASSEMBLY
Install the engine assembly. When doing so, check
carefully to be sure that all pipes and hoses are con- nected, and that none are twisted, damaged, etc.
25. INSTALLATION OF AIR CONDITIONING
COMPRESSORI24. POWER STEERING OIL PUMP
Adjust belt tension. (Refer to
P. 1 1-l 2.)
TSB Revision

ENGINE -- Engine Assembly
ENGINE ASSEMBLY
REMOVAL AND INSTALLATION
II-17
Pre-removal Operation@Eliminating Fuel Pressure in Fuel Line (Refer to GROUP 13-Service Adjustment Proce-
dures.)
l Removal of the Hood
(Refer to GROUP
42-Hood.)l Draining of the Engine Coolant
(Refer to GROUP 00-Maintenance Service)
l Removal of the Transaxle (Refer to GROUP
22,23-Transaxle.)l Removal of the Radiator(Refer to GROUP 14-Radiator.)
Fuel rail
603AOO70
Engine oil
Post-installation Operationl Installation of the Radiator (Refer to GROUP 14-Radiator.)l Installation of the Transaxle(Refer to GROUP 22, 23-Transaxle.)l Refilling of the Engine Coolant
(Refer to GROUP 00-Maintenance Service.)
l Installation of the Hood (Refer to GROUP
42-Hood.)
4-6 Nm3-F ft.lbs.
I6m
Removal steps
1. Vacuum hose connection
2. Brake booster vacuum hose connection
3. Heater hose connection (cylinder head
-heater unit)
4. Heater hose connection (Heater unit +water inlet pipe)
5. Fuel high pressure hose connection
6. O-ring
7. Fuel return hose connection
8. Accelerator cable connection
9. Engine coolant temperature gauge unit connector
OlA0676 10. Engine coolant temperature sensor
connector
II. Oxyqen
sensor connector
12. Distributor connector
13. Condenser
connector
14. TPS connector
15.
IAC connector
16. Injector connector
17. Air conditioning compressor connector
18. Control harness
1 TSBRevisionI

11-18
ENGINE - Engine Assembly
35-45 Nm 35-45 Nm
25-33
ft.lbs.I
35-45 Nm/ 25-33 ft.lbs.
23-27,‘17-20
Lf+gPf--
2001A0671
36-47 ft.lbs. 40-5o’Nm
29-36
ft.lbs.
Removal steps
19. Connection for generator
20. Connection for oil pressure switch+e l a21 Power steering oil pump (Refer toP.ll-16.)+e .422. Air conditioning compressor (Refer to
P.l 1-16.)23. Self-locking nuts
24. Gasket -
l *
25. Clamp of pressure hose (Power steering)
and high pressure hose (Air conditioning)
26. Engine mount bracket (Refer to P.l l-l 6.)
27. Self locking nut
+* l C28. Engine assembly (Refer to P.l I-16.) 60-80
Nm43-58 ft.lbs.
OlAO670
1 TSB Revision

ENGINE - Camshaft and Camshaft Oil SealII-19
CAMSHAFT AND CAMSHAFT OIL SEAL <8
VALVE>MllZA-A
REMOVAL AND INSTALLATION
v--
5-7 Nm
4-5 ft.lbs.
0
0 I‘
‘p4
Sealant:
3M ATD Part No. 8660
or eauivalent 20-27
Nm 14-20
ftlbs.
80-100
Nm
58-72
ftlbs.
Romnval ztrms. . . . . . ..P-w.---r-1. Connection for spark plug cables
and hioh
tension cable 3
nictrihl ,+r-,rL. U,illl lYUI”l
(Refer
to GROUP 16-Ignition System.)
3. timing belt
(Refer to P.l I-34.)4. Connection for breather hose
5. Connection for P.C.V. hose6. Accelerator cable bracket
7. Rocker cover
8. Semi-circular packing
9 Camshaft sorocket01A0316 _.
__... -..- -rLL IO Oil sea
l
+e s< ii: Rocker arm and shaft assembly,+ 12. Camshaft
TSB Revision

II-20ENGINE - Camshaft and Camshaft Oil Seal
MD998443-011
6EN245
Oil seal
MD998307-01 1
MD99
CaAshaft6ENOlZ
SERVICE POINTS OF REMOVALMllZBAE
11. REMOVAL OF ROCKER ARM AND SHAFr ASSEMBLY
Before removing the rocker arm and shaft assembly, use
the special tool to ensure that the auto-lash adjuster
doesn’t fall out.
Caution
Do not disassemble the rocker arm and shaft assembly.
SERVICE POINTS OF INSTALLATIONMllZOAG
12. INSTALLATION OF CAMSHAFT
Install in the cylinder head after applying a coat of engine
oil to the camshaft journal and cams.
11. INSTALLATION OF ROCKER ARM AND SHAFT ASSEM-
BLY
(1) Place the rocker arm and shaft assembly on the cylinder head and tighten the bearing cap bolt.
(2) Remove the special tool.
10. INSTALLATION OF OIL SEAL
(1) Install special tool, camshaft oil sea) guide, to the end
of the camshaft and apply engine oil to the outer
surface of special tool.
(2) Using special tool, camshaft oil seal installer, press-in
the oil seal.
TSB Revision1
