Body MITSUBISHI LANCER 2005 Repair Manual

HOOD
BODY42-4
HOOD
REMOVAL AND INSTALLATIONM1421001600561
Post-installation Operation
•Adjustment of Clearance Around Hood (Refer to P.42-3).
•Adjustment of Alignment of Hood Stepped Portion and
Hood Striker (Refer to P.42-3).
•Adjustment of Hood Height (Refer to P.42-3).
AC304739
1 1
22
44
5 6 73 8
910
AD9.0 ± 2.0 N·m21 ± 4 N·m 11 ± 2 N·m21 ± 4 N·m
Removal
1. Hood bumper
2. Hood latch
3. Hood weatherstrip
Hood lock release cable removal
steps
4. Hood lock release handle
5. Hood lock release cableHood and hood hinge removal
steps
6. Hood insulator
7. Hood weatherstrip
•Washer hose (Refer to GROUP 51,
Windshield wiper and washer
P.51-23.)
8. Hood
9. Hood support rod
10. Hood hinge

FENDER
BODY42-5
FENDER
SPECIAL TOOLM1421000600256
AC300865
Note
: Clip positions
Section A – A
AC
Clip
A
A
6 8
6 8
Clip positions
Tool Number Name Use
MB990784 Ornament remover Side turn-signal lamp removal
MB990784

FENDER
BODY42-6
FENDER
REMOVAL AND INSTALLATIONM1421001900302
Pre-removal and Post-installation Operation
•Front Bumper Removal and Installation (Refer to GROUP
51, Front Bumper P.51-2.)
•Front Deck Garnish Removal and Installation (Refer to
GROUP 51, Windshield Wiper and Washer P.51-23.)
•Side Air Dam Removal and Installation side air dam> (Refer to GROUP 51, Side Air Dam
P.51-15.)
AC300491
AC304753
AC303863
Clip Section A – A
AB
A A
123
3 4
Note
: Clip positions
Removal steps
1. Splash shield
<> >>A<<2. Side turn-signal lamp3. Delta outer garnish
4. FenderRemoval steps (Continued)

FENDER
BODY42-7
REMOVAL SERVICE POINT
<> SIDE TURN-SIGNAL LAMP
REMOVAL
Use special tool ornament remover (MB990784) to
prize out the tab from the fender, and remove the
side turn signal light.
INSTALLATION SERVICE POINT
>>A<< SIDE TURN-SIGNAL LAMP
INSTALLATION
Engage the claw with the fender panel, and install
the side turn-signal lamp.
AC005980AC005980
Front of vehicle
Side turn-signal light
MB990784
ABAC005719
Fender panelHook
Claw
Fender panel
: Front of vehicle
AE

FUEL FILLER LID
BODY42-8
FUEL FILLER LID
REMOVAL AND INSTALLATIONM1421002500277
Pre-removal and Post-installation Operation
•Rear Seat Removal and Installation (Refer to GROUP
52A, Rear Seat P.52A-28.)
•Front Scuff Plate (Driver's Seat Side), Rear Scuff Plate
(Driver's Side), Centre Pillar Lower Trim (Driver's Side),
Quarter Trim (Driver's Side) Removal and Installation
(Refer to GROUP 52A, Trims P.52A-11.)
18M0109W0570AQ
AC005996
AC005973
3
54
3
2 1
5.0 ± 1.0 N·m
AC
Fuel filler lid height and clearance
adjustment
Removal steps
1. Fuel filler lid panel assembly
2. Clip
3. Fuel filler lid hook assembly4. Fuel filler lid lock release cable
5. Fuel filler lid lock release handleRemoval steps (Continued)

STRUT TOWER BAR
BODY42-9
STRUT TOWER BAR
REMOVAL AND INSTALLATIONM1421005600091
WINDOW GLASS
ADHESIVEM1422000500081
SPECIAL TOOLSM1422000600293
AC304680AB
Strut tower bar44 ± 5 N·m
Item Specified adhesive
Windshield 3M ATD Part No.8609 Super Fast Urethane Auto Glass
Sealant or equivalent
3M ATD Part No.8608 Super Fast Urethane Primer or
equivalent Rear window glass
Quarter window glass
Tailgate window glass
Tool Number Name Use
MB990480 Glass holder Removal and installation of window glass
MB990784 Ornament remover Removal of rear window lower moulding
MB990480
MB990784

WINDOW GLASS
BODY42-10
WINDOW REPAIRM1422005600027
The windshield, rear window glass, quarter window
glass and tailgate window glass are attached by an
urethane-base adhesive to the window frame. This
adhesive provides improved glass holding and
sealing, and also gives body openings a greater
structural strength.
ITEMS
HANDLING OF AUTO WINDOW SEALER
Keep the sealant in a cool place, not exposed to the
direct rays of the sun. Do not place any heavy article
on the sealant nor press it, otherwise it will become
deformed. Avoid storing the sealant for more than 6
months, because it will lose its sealing effect.
BODY PINCH-WELD FLANGE SERVICING
Before servicing the body pinch-weld flange, remove
old adhesive completely. If the flange requires
painting, bake it after painting is completed. Name Remark
Adhesive 3M ATD Part No.8609 Super Fast Urethane Auto Glass Sealant or
equivalent
Primer 3M ATD Part No.8608 Super Fast Urethane Primer or equivalent
Spacers Available as service part
Dam Available as service part
Anti-rust solvent (or Tectyl
506T.Valvoline Oil Company)For rust prevention
Isopropyl alcohol For grease removal from bonded surface
Steel piano wire Dia. × length... 0.6mm × 1m For cutting adhesive
Glass adhesive knife For cutting adhesive
Adhesive gun For pressing-out adhesive

WINDOW GLASS
BODY42-11
WINDOW GLASS INSTALLATION
Cleaning of adhesion surface
Cut off the residual adhesive until the
thickness is less than 2 mm. clean the
adhesion surface with isopropyl alcohol,
and let dry for 3 minutes or more.Cleaning of adhesion surface
Completely cut off all of the residual
adhesive. clean the adhesive surface
with isopropyl alcohol, and let dry for
3 minutes or more.Cleaning of adhesion surface
Clean off any dirt adhering to the adhesion
surface with isopropyl alcohol, and let dry
for 3 minutes or more.
Attaching of dual lock fastener
Attach the dual lock fastener to set
the positions for the glass to be installed.
Gluing of window dam, window spacer, dual lock fastener and glass stopper
Glue the window dam, window spacer, dual lock fastener and glass stopper to the glass,
following the standard position all the way around the inside edge of the glass.
Application of primer
Apply the primer to the adhesion surface
of the body, and let dry for 3 minutes or
more.Application of primer
Apply sufficient primer evenly to the adhesion surface so that there is no patchiness.
After application, let dry for 3 to 30 minutes.
Application of adhesive
Within 30 minutes after applying the primer , apply the adhesive evenly all the way around
the inside edge of the glass.
Installing the glass
After applying the adhedive, lighty press the glass evenly so that it adheres
completely.
Cleaning
After removing excess adhesive from the body or glass with a spatula, etc.
clean off with isopropyl alcohol.
Checking for water leaks
Carry out a shower test to check that no water will leaks through.Replace the glass
Reusing the glass
Window glass installation procedure
Body side
Window glass side
AC300393

WINDOW GLASS
BODY42-12
WINDSHIELD
REMOVAL AND INSTALLATIONM1422001000313
Pre-removal and Post-installation Operation
•Front Deck Garnish Removal and Installation (Refer to
GROUP 51,Windshield Wiper and Washer P.51-23.)
•Inside Rear View Mirror Removal and Installation (Refer
to GROUP 52A, Inside Rear View Mirror P.52A-23.)
•Front Pillar Trim Removal and Installation (Refer to
GROUP 52A, Trims P.52A-11.)
•Headlining Removal and Installation (Refer to GROUP
52A, Headlining P.52A-21.)
AC006003
X0111AUX0112AU
Y0496AU
12
3 4
6
1 11 3
N
N
N
N
N
AC Y0495AU
A
A
BB
C
C Ceramic line
Seal line
Seal line
Ceramic line
MarkMark
Apply the primer and
adhesive along the
fictitious lines (seal line)
between each of
the marks.
Seal line centre
Primer Section A – A Section B – BSeal line
centre
Primer
Section C – C
Seal line
centre
Primer
5N
5N
Units: mm
Adhesive: 3M ATD Part No. 8609 Super Fast Urethane Auto Glass Sealant or equivalent and
3M ATD Part No. 8608 Super Fast Urethane Primer or equivalent
16
1613

WINDOW GLASS
BODY42-13
REMOVAL SERVICE POINT
<> WINDSHIELD REMOVAL
1. To protect the body (paint surface), apply cloth
tape to all body areas around the installed
windshield.
2. Make mating marks on the windshield and body.
3. Using piano wire.
(1) Using a sharp-point drill, make a hole in the
windshield adhesive.
(2) Pass the piano wire from the inside of the
vehicle through the hole.
CAUTION
Do not let the piano wire touch the edge of the
windshield.
(3) Pull the piano wire alternately from the inside
and outside along the windshield to cut the
adhesive.
CAUTION
Inserting the glass adhesive knife too deeply into
windshield adhesive may damage windshield.
4. Using glass adhesive knife
Keep glass adhesive knife at right angles with the
windshield edge, and put the blade at windshield
edge and surface. Then cut away adhesive along
the windshield edge.
5. Use special tool glass holder (MB990480) to
remove the windshield.
CAUTION•
Removal steps
•Roof drip moulding (Refer to GROUP
51, Moulding P.51-10.)
<> >>B<<1. Windshield
>>A<<2. Windshield moulding
>>A<<3. Window dam
>>A<<4. Glass stopper
>>A<<5. Spacer
>>A<<6. Windshield spacerRemoval steps (Continued)
ACX00474
AB
AC002060
AC207478
Glass adhesive knife
AD
ACX00475
AB
MB990480
ACX00476
AB
