ENGINE OVERHAUL -Oil Pump and Oil Pan11B-47
OIL PUMP AND OIL PAN
REMOVAL AND INSTALLATION
2
1
Apply engine oil on
all sliding sections
before installing.
4 56
12 13
16187 20
38
9
10 1415
1719
1139±5N•m 54±5N•m19±3N•m
36±3N•m23±3N•m 17±1N•m 10±2N•m
9±3N•m 22±4N•m 23±3N•m
19±3N•m
44±5N•m 23±3N•m
25
24232221
26272930
31
28
19±3N•m
Removal steps
1. Drain plug
"NA2. Drain plug gasket
"MA3. Oil filter
AA""LA4. Oil pan
5. Oil screen
6. Oil screen gasket
7. Baffle plate
"KA8. Oil pressure switch
9. Oil cooler bypass valve
10. Relief plug
11. Gasket
12. Relief spring
13. Relief plunger
14. Oil filter bracket
15. Oil filter bracket gasket
AB""JA16. Plug cap
17. O-ringAC""IA18. Flange bolt
"HA19. Oil pump case
20. Oil pump case gasket
21. Oil pump cover
"GA22. Oil pump driven gear
"GA23. Oil pump drive gear
"FA24. Crankshaft front oil seal
"EA25. Counter balance shaft oil seal
"DA26. Oil pump oil seal
27. Counter balance shaft, right
28. Counter balance shaft, left
AD""CA29. Counter balance shaft front bearing
AE""BA30. Counter balance shaft rear bearing,
right
AE""AA31. Counter balance shaft rear bearing,
left

ENGINE OVERHAUL -Oil Pump and Oil Pan11B-48
REMOVAL SERVICE POINTS
AA"OIL PAN REMOVAL
1. Remove the oil pan tightening bolts.
2. Tap the special tool between the oil pan and cylinder
block.
3. Tap on the edge of the special tool, slide the tool and
remove the oil pan.
AB"PLUG CAP REMOVAL
Fit the special tool (MD998162) into the notch on the plug
cap as shown in the illustration. Loosen the plug cap while
supporting with the special tool (MD998783).
AC"FLANGE BOLT REMOVAL
1. Remove the plug on the left side of the cylinder block,
and insert a Phillips driver (shaft diameter 8 mm) by 60
mm or more to stop the rotation of the counter balance
shaft left.
2. Loosen the flange bolt.
AD"COUNTER BALANCE SHAFT FRONT BEARING
REMOVAL
Pull out the counter balance shaft front bearing from the
cylinder block using the special tool.
Caution
Always remove the counter balance shaft front bearing
first. Otherwise, the counter balance shaft rear bearing
cannot be removed.MD998727
MD998162
MD998783
Plug
Phillips driver
MD998371Front bearing

ENGINE OVERHAUL -Oil Pump and Oil Pan11B-49
AE"COUNTER BALANCE SHAFT REAR BEARING
REMOVAL
1. Pull out the counter balance shaft rear bearing right from
the cylinder block using the special tool (MD998372).
2. When removing the counter balance shaft rear bearing
left, install the special tool (MB991603) onto the front
of the cylinder block, and then remove the bearing using
the special tool (MD998372).
INSTALLATION SERVICE POINTS
"AACOUNTER BALANCE SHAFT REAR BEARING
LEFT INSTALLATION
1. Install the special tool (MB991603) onto the cylinder block.
2. Set the counter balance shaft rear bearing left into the
special tool (MD998705).
NOTE
There is no oil hole on the counter balance shaft rear
bearing left.
3. Tap in the counter balance shaft rear bearing left.
"BACOUNTER BALANCE SHAFT REAR BEARING
RIGHT INSTALLATION
1. Install the guide pin onto the cylinder block.
2. Align the ratchet ball of the special tool with the oil hole,
and set the counter balance shaft rear bearing right.
MB991603
MD998372
MB991603
MD998705
MB991603
MD998705
Rear bearing
left
Guide pin
Ratchet ball
MD998705 Rear bearing right
Oil hole

ENGINE OVERHAUL -Oil Pump and Oil Pan11B-50
3. Align and insert the special tool into the guide pin, and
tap in the counter balance shaft rear bearing right.
"CACOUNTER BALANCE SHAFT FRONT BEARING
INSTALLATION
1. Remove the part for tapping in the rear bearing from
the special tool.
2. Install the guide pin onto the cylinder block.
3. Align the ratchet ball of the special tool with the oil hole,
and set the counter balance shaft front bearing.
MD998705
Guide pin
MD998705
Part for tapping in
the rear bearing
Guide pin
Ratchet ball
MD998705 Front bearing
Oil hole

ENGINE OVERHAUL -Oil Pump and Oil Pan11B-51
4. Align and insert the special tool into the guide pin, and
tap in the counter balance shaft front bearing.
"DAOIL PUMP OIL SEAL INSTALLATION
Install the oil pump oil seal using an appropriate socket wrench.
"EACOUNTER BALANCE SHAFT OIL SEAL
INSTALLATION
Install the counter balance shaft oil seal using an appropriate
socket wrench.
"FACRANKSHAFT FRONT OIL SEAL INSTALLATION
Install the crankshaft front oil seal using the special tool.
MD998705
Guide pin
Socket wrench
Oil pump case Oil seal
Socket wrench
Oil pump case
Oil seal
MD998375
Oil pump case Oil seal

ENGINE OVERHAUL -Oil Pump and Oil Pan11B-52
"GAOIL PUMP DRIVE GEAR/OIL PUMP DRIVEN
GEAR INSTALLATION
Apply sufficient engine oil onto the gears, align the match
marks, and assemble.
"HAOIL PUMP CASE INSTALLATION
1. Install the special tool onto the front end of the crankshaft,
and apply a light coat of engine oil onto the periphery
of the guide. If an oil seal is installed on the oil pump
case, always use a guide.
2. Install the oil pump case through the new oil pump case
gasket, and temporarily tighten the bolts other than the
oil filter bracket tightening bolt.
3. Install the oil filter bracket through the oil filter bracket
gasket, and temporarily tighten with the bolt.
4. Tighten the oil pump case at the specified torque 23
±3N•m, and the oil filter bracket at the specified torque
19±3N•m.
"IAFLANGE BOLT INSTALLATION
1. Insert a Phillips driver (shaft diameter 8 mm) by 60 mm
or more into the hole on the left side of the cylinder block
to stop the rotation of the counter balance shaft left.
2. Tighten the flange bolt at the specified torque 36±3
N•m.
Match marks
MD998285
Counter balance
shaft left
Counter balance
shaft right
MD998285
Phillips driver

ENGINE OVERHAUL -Oil Pump and Oil Pan11B-53
"JAPLUG CAP INSTALLATION
1. Install a new O-ring onto the oil pump case.
2. Lightly tighten the plug cap by hand.
3. As shown in the illustration, fit the special tool (MD998162)
into the notch on the plug cap, and while supporting with
the special tool (MD998783), tighten the plug cap at the
specified torque 23±3N•m.
"KAOIL PRESSURE SWITCH INSTALLATION
Sealant
Specified sealant:
3M
TMAAD Part No. 8672 or equivalent
Caution
(1) Make sure that the sealant does not protrude to the
end of the threads.
(2) Do not tighten too far.
"LAOIL PAN INSTALLATION
1. Clean the surface of the cylinder block and oil pan onto
which gasket is to be applied.
2. Squeeze out form-in-place gasket at a 4 mm width, and
apply onto the entire periphery of the oil pan flange.
Form-in-place gasket
Specified gasket:
Mitsubishi Genuine Part No. MD970389 or
equivalent
3. Note that the lengths of the bolts shown in the illustration
differ, so take care when installing.
MD998162
MD998783
Bolt hole section Groove
Timing belt side
M6×8

ENGINE OVERHAUL -Oil Pump and Oil Pan11B-54
"MADRAIN PLUG GASKET INSTALLATION
Replace the gasket with a new part, and install at the direction
shown in the illustration.
Caution
Incorrect installation direction will lead to oil leaks.
"NAOIL FILTER INSTALLATION
1. Clean the installation surface on the cylinder block side.
2. Apply engine oil on the O-ring for the oil filter.
3. Screw in the oil filter, and tighten approx. 3/4 of a rotation
(approx. 14±2N•m) from where the O-ring contacts
the installation surface.
INSPECTION
1. COUNTER BALANCE SHAFT
(1) Make sure that the oil hole is not clogged.
(2) Check the journal (bearing section) for seizure or
damage, and check the state of contact with the
bearings. If any faults are found, replace the counter
balance shaft, bearing or oil pump case assembly.
2. OIL COOLER BYPASS VALVE
(1) The valve must move smoothly.
(2) The L dimension must be at the standard value at
a constant temperature, constant humidity state.
Standard value: 34.5 mm
(3) The protruded dimensions must be at the standard
value after submerging into 100_C oil.
Standard value: 40 mm
Drain plug
Oil pan
Oil pan side Gasket
Bracket side
L
Valve

ENGINE OVERHAUL -Oil Pump and Oil Pan11B-55
3. OIL PUMP
(1) Assemble the drive gear and driven gear into the
oil pump case.
(2) Inspect the side clearance with a thickness gauge.
Standard value:
Drive gear 0.08 - 0.14 mm
Driven gear 0.06 - 0.12 mm

ENGINE OVERHAUL -Piston and Connecting Rod11B-56
PISTON AND CONNECTING ROD
REMOVAL AND INSTALLATION
20±2N•m+90_-94_
2
1
Apply engine oil on
all sliding sections
before installing.
4
56
12 7
3 8
910
11
Removal steps
"GA1. Connecting rod cap nut
AA""FA2. Connecting rod cap
"EA3. Connecting rod bearing
"DA4. Piston connecting rod
5. Connecting rod bearing
"CA6. Piston ring No. 1"CA7. Piston ring No. 2
"BA8. Oil ring
AB""AA9. Piston pin
10. Piston
11. Connecting rod
12. Bolt
