D-1
CORROSION
PROTECTION
CONTENTS
BODY SEALING LOCATIONS 2............
FLOOR 2...................................
UPPER BODY 2............................
SIDE BODY 2.............................
UNDERCOAT APPLICATION LOCATIONS 5...

CORROSION PROTECTION -Body Sealing LocationsD-2
BODY SEALING LOCATIONS
NOTES REGARDING REPAIR WORK
In places where the sealant can be directly seen on surfaces such as the drip rails, pillars, or clinch,
and where the appearance of the paint surface is important, apply sealant or wipe away sealant after
application to make the amount of sealant even. Be careful not to cover the drain hole.
▄▄▄(bold
dotted line) indicates the application location at the back.
FLOOR
2
1
3
4
UPPER BODY
2
22
6
5
7
SIDE BODY
11
12
9
8
10

CORROSION PROTECTION -Body Sealing Locations
12
34
56
78
D-3

CORROSION PROTECTION -Body Sealing Locations
910
1112
HoodFront door
Rear doorTrunk lid
D-4

CORROSION PROTECTION -Undercoat Application LocationsD-5
UNDERCOAT APPLICATION LOCATIONS
In order to provide resistance to rust, corrosion, chipping, and vibration, an undercoat is applied to certain
areas of the underbody.
After completing body repairs, restore this undercoat if necessary.
* Mark the areas indicated with asterisks to make sure no undercoat adheres to these areas.
:Undercoat (Film thicknessof at least 0.5 mm)
*
* *
*
*

NOTES

E-1
SYNTHETIC-RESIN
PARTS
CONTENTS
LOCATION OF SYNTHETIC-RESIN PARTS 2..

SYNTHETIC-RESIN PARTS -Location of Synthetic-resin PartsE-2
LOCATION OF SYNTHETIC-RESIN PARTS
The following shows the main locations of synthetic-resin parts.
1
1
17
27 28
25
297
18 23
19
2416 9
222
26
101 21 5
14
1315
12
11
20 46
83
3031
24

SYNTHETIC-RESIN PARTS -Location of Synthetic-resin PartsE-3
No.Part numberMaterialAbbreviation of
materialHeat-resistant
temperature (_C)
1
2Outside mirror
Rear spoilerAcrylonitrile
Butadiene styreneABS80
3Roof antennaAcrylonitrile
Ethylene butadieneAES90
4HeadlampPolycarbonatePC120
5
6
7Front bumper bezel
Rear door outside handle
Front door outside handlePolycarbonate +
Acrylonitrile butadiene styrenePC + ABS125 - 135
8Splash shieldPolyethylenePE100
9
10
11
12
13
14
15
16
17
18
19
20Oil cooler duct
Instrument panel
Front pillar trim
Inside rear view mirror
Centre pillar trim
Rear pillar trim
Rear door trim
Rear end trim
Rear scuff plate
Rear console box
Front scuff plate
Cowl side trimPolypropylenePP80
21
22
23
24Front bumper extension
Front bumper face
License plate garnish
Front door trimRubber denatured polypropylenePP + E/P80
25Rear bumper faceWith talc added rubber denatured
polypropylenePP + E/P - TD
(HMPP)80 - 100
26Side sill extensionWith 20% talc added rubber dena-
tured polypropylenePP + E/P - TD20
(HMPP)11 0
27Center pillar trim lowerWith 10 % talc added polypropylenePP - TD10
(PPF)110 - 120
28
29Front deck garnish
Floor consoleWith 20 % talc added polypropylenePP - TD20
(PPF)120 - 130
30Hood inlet upper garnishPolyphenylene ether + PolyamidePPE+PA
(PA/PPO)185
31Roof drip moldingPolyvinyl chloridePVC80
NOTE
1. If the new material symbols designated by the ISO differ from the old symbols, both are given, with
the old symbols enclosed in brackets.
ISO: (International Standardization Organization)
2. A slash (/) in the material symbol indicates that two different materials compose a 2-layer construction.
A plus sign (+) indicates that the two different materials are mixed.
3. The material symbols for synthetic-resin parts are embossed on parts in hidden places.
