MITSUBISHI LANCER EVOLUTION 2007 Service Repair Manual

B-3
ABS
L.H. drive vehicles 198......................
R.H. drive vehicles 205......................
ACD
Vehicles without AYC
212....................
Vehicles without AYC
220....................
ACD AND AYC
L.H. drive vehicles 228......................
R.H. drive vehicles 238......................
SUPPLEMENTAL RESTRAINT SYSTEM
(SRS) AND SEAT BELT PRETENSIONER
L.H. drive vehicles 248......................
R.H. drive vehicles 250......................
IMMOBILIZER SYSTEM
L.H. drive vehicles 252......................
R.H. drive vehicles 254......................
INTERCOOLER WATER SPLAY 256........
SPARE CONNECTOR
(FOR FRONT FOG LAMP) 258............

WIRING HARNESS CONFIGURATION DIAGRAMSB-4
WIRING HARNESS CONFIGURATION DIAGRAMS
OVERALL WIRING DIAGRAM
L.H. drive vehicles
Front wiring
harness (RH)
Control wiring
harnessInstrument panel
wiring harnessRoof wiring
harnessFloor wiring
harness (RH)
Battery wiring
harnessFront wiring
harness (LH)Front door
wiring harness*Floor wiring
harness (LH)Fuel wiring
harness
Rear door
wiring harness*
NOTE
(1) This illustration shows only major wiring harness.
(2) *: also equipped at the right side.

WIRING HARNESS CONFIGURATION DIAGRAMSB-5
R.H. drive vehicles
Front wiring
harness (RH)
Control wiring
harnessInstrument panel
wiring harnessRoof wiring
harnessFloor wiring
harness (RH)
Battery wiring
harnessFront wiring
harness (LH)Front door
wiring harness*Floor wiring
harness (LH)Fuel wiring
harness
Rear door
wiring harness*

WIRING HARNESS CONFIGURATION DIAGRAMS
Connector
symbol
A
A-01
A-37
A-36
A-48
A-40
A-31
A-28A-47A-46A-45
1
Connector colour code
B:Black
Y:Yellow
L:Blue
G:Green
R:Red
BR:Brown
V:Violet
O:Orange
GR:Gray
None: Milk white
B-6
ENGINE COMPARTMENT
L.H. drive vehicles
A-01 (2-GR) Side turn signal lamp (RH)
A-02 (2-GR) Side turn signal lamp (LH)
A-03 (2-B) Wheel speed sensor (Front: LH)
A-04X (4) Spare connector (for front fog lamp relay)
A-05X (4) Horn relay
A-06X (4) Condenser fan relay (LO)
A-07X (4) Condenser fan relay (HI)
A-08X (4) No connectionA-09X (4) Radiator fan relay
A-10X (11) Front-ECU
A-11X (11) Front-ECU
A-12 (2-B) Front wiring harness (LH) and control
wiring harness combination
A-13 (8-B) Front wiring harness (LH) and control
wiring harness combination
A-16 (2-B) Headlamp (HI: LH)

WIRING HARNESS CONFIGURATION DIAGRAMS
A-02
A-25
A-03
A-04X
A-05X
A-06X
A-07X
A-08X
A-09X
A-10X
A-11X
A-12
A-13
A-43
A-39
A-44
A-21A-23A-16
14
B-7
A-21 (3-GR) Fan controller
A-23 (1-B) Horn (HI)
A-25 (1-B) Horn (LO)
A-28 (2-B) Headlamp (HI: RH)
A-31 (1) Spare connector (for front fog lamp)
A-36 (2-BR) Dual pressure switch
A-37 (2-B) Wheel speed sensor (Front: RH)
A-39 (8-B) Front combination lamp (LH)A-40 (8-B) Front combination lamp (RH)
A-43 (8-B) Front wiring harness (LH) and control
wiring harness combination
A-44 (2) Intercooler water spray motor
A-45 (2-B) Condenser fan motor
A-46 (2-GR) Condenser fan motor
A-47 (1-B) A/C compressor
A-48 (1-B) Power steering oil pressure switch

WIRING HARNESS CONFIGURATION DIAGRAMS
Connector
symbol
A
A-01
A-37
A-36
A-34
A-48
A-40
A-31
A-28
A-47A-46A-45
Connector colour code
B:Black
Y:Yellow
L:Blue
G:Green
R:Red
BR:Brown
V:Violet
O:Orange
GR:Gray
None: Milk white
1
B-8
ENGINE COMPARTMENT
R.H. drive vehicles
A-01 (2-GR) Side turn signal lamp (RH)
A-02 (2-GR) Side turn signal lamp (LH)
A-03 (2-B) Wheel speed sensor (Front: LH)
A-04X (4) Spare connector (for front fog lamp relay)
A-05X (4) Horn relay
A-06X (4) Condenser fan relay (LO)
A-07X (4) Condenser fan relay (HI)
A-08X (4) No connectionA-09X (4) Radiator fan relay
A-10X (11) Front-ECU
A-11X (11) Front-ECU
A-12 (2-B) Front wiring harness (LH) and control
wiring harness combination
A-16 (2-B) Headlamp (HI: LH)
A-21 (3-GR) Fan controller

WIRING HARNESS CONFIGURATION DIAGRAMS
A-02
A-25
A-03
A-04X
A-05X
A-06X
A-07X
A-08X
A-09X
A-10X
A-11X
A-12
A-39
A-44
A-16
A-21A-23
14
B-9
A-23 (1-B) Horn (HI)
A-25 (1-B) Horn (LO)
A-28 (2-B) Headlamp (HI: RH)
A-31 (1) Spare connector (for front fog lamp)
A-34 (2) No connection
A-36 (2-BR) Dual pressure switch
A-37 (2-B) Wheel speed sensor (Front: RH)
A-39 (8-B) Front combination lamp (LH)A-40 (8-B) Front combination lamp (RH)
A-44 (2) Intercooler water spray motor
A-45 (2-B) Condenser fan motor
A-46 (2-GR) Condenser fan motor
A-47 (1-B) A/C compressor
A-48 (1-B) Power steering oil pressure switch

WIRING HARNESS CONFIGURATION DIAGRAMS
Connector
symbol
-01
thru
-37
B
B-37
B-34
B-23
B-01B-27B-26
Earth cable
B-21B-22
Connector colour code
B:Black
Y:Yellow
L:Blue
G:Green
R:Red
BR:Brown
V:Violet
O:Orange
GR:Gray
None: Milk white
B-10
ENGINE AND TRANSMISSION
L.H. drive vehicles
B-01 (5-GR) Windshield wiper motor
B-02 (4-B) Throttle position sensor
B-03 (3-B) Vehicle speed sensor
B-04 (2-GR) Brake fluid level switch
B-05X (1) Engine speed detection connector
B-06X (5) No connection
B-07X (4) No connectionB-08X (4) No connection
B-09X (4) No connection
B-10X (4) No connection
B-11X (4) Engine control relay
B-12X (4) A/C compressor relay
B-14 (10-B) Control wiring harness and battery wiring
harness combination

WIRING HARNESS CONFIGURATION DIAGRAMS
B-25
B-18
B-24B-02B-04
B-05X
B-06X
B-07X
B-08X
B-09X
B-10X
B-11X
B-12X
B-14
B-03
B-36
B-19B-20B-31
4
11
12
B-11
B-18 (1) Starter
B-19 (1-B) Starter
B-20 (1-B) Oil pressure switch
B-21 (1) Alternator
B-22 (4-GR) Alternator
B-23 (2-B) Purge control solenoid valve
B-24 (2-B) Injector 4B-25 (2-B) Injector 3
B-26 (2-B) Injector 2
B-27 (2-B) Injector 1
B-31 (7-B) Air flow sensor
B-34 (4-B) Oxygen sensor
B-36 (2-GR) Waste gate solenoid valve
B-37 (2-B) Fuel pressure solenoid valve

WIRING HARNESS CONFIGURATION DIAGRAMS
Connector
symbol
-108
thru
-142
BEarth cable
B-123B-138B-139B-140B-141
B-119
B-121
B-122B-112B-142
Connector colour code
B:Black
Y:Yellow
L:Blue
G:Green
R:Red
BR:Brown
V:Violet
O:Orange
GR:Gray
None: Milk white
B-12
L.H. drive vehicles
B-108 (2-B) Back-up lamp switch
B-110 (1-B) Engine coolant temperature gauge unit
B-112 (2-BR) EGR solenoid valve
B-114 (3-GR) Ignition coil 1B-115 (6-B) Idle speed control servo
B-116 (3-B) Camshaft position sensor
B-118 (2-B) Engine coolant temperature sensor
B-119 (3-GR) Ignition coil 2
