EM-20
< PERIODIC MAINTENANCE >[HR16DE]
AIR CLEANER FILTER
2. Remove the air cleaner filter (1) from the air cleaner body.
INSTALLATION
Installation is in the reverse order of removal.
NOTE:
Check that the air cleaner filter is securely placed in the air cleaner body.
JSBIA1093ZZ
Revision: August 2015
2016 Versa Note
cardiagn.com
Page 1022 of 3641
![NISSAN NOTE 2016 Service Repair Manual SPARK PLUGEM-21
< PERIODIC MAINTENANCE > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
SPARK PLUG
Exploded ViewINFOID:0000000012431699
Removal and InstallationINFOID:0000000012431700
REMOVAL
1. Remove igni NISSAN NOTE 2016 Service Repair Manual SPARK PLUGEM-21
< PERIODIC MAINTENANCE > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
SPARK PLUG
Exploded ViewINFOID:0000000012431699
Removal and InstallationINFOID:0000000012431700
REMOVAL
1. Remove igni](/img/5/57363/w960_57363-1021.png)
SPARK PLUGEM-21
< PERIODIC MAINTENANCE > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
SPARK PLUG
Exploded ViewINFOID:0000000012431699
Removal and InstallationINFOID:0000000012431700
REMOVAL
1. Remove ignition coil. Refer to
EM-48, "Removal and Installation".
CAUTION:
Do not drop or shock ignition coil.
2. Remove spark plug using a suitable tool.
CAUTION:
Do not drop or shock spark plug.
INSPECTION AFTER REMOVAL
• If the spark plug tip is covered with carbon, a spark plug cleaner may be used.
CAUTION:
1. Ignition coil 2. Spark plug3. Rocker cover
Front
AWBIA1599ZZ
Diameter (a) : 14 mm (0.55 in)
JPBIA0030ZZ
Cleaner air pressure : Less than 588 kPa (6 kg/cm2, 85 psi)
Cleaning time : Less than 20 seconds
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 1023 of 3641
![NISSAN NOTE 2016 Service Repair Manual EM-22
< PERIODIC MAINTENANCE >[HR16DE]
SPARK PLUG
Do not use a wire brush for cleaning.
• Checking and adjusting spark plug gap is not required between change intervals. Do not adjust the gap; repla NISSAN NOTE 2016 Service Repair Manual EM-22
< PERIODIC MAINTENANCE >[HR16DE]
SPARK PLUG
Do not use a wire brush for cleaning.
• Checking and adjusting spark plug gap is not required between change intervals. Do not adjust the gap; repla](/img/5/57363/w960_57363-1022.png)
EM-22
< PERIODIC MAINTENANCE >[HR16DE]
SPARK PLUG
Do not use a wire brush for cleaning.
• Checking and adjusting spark plug gap is not required between change intervals. Do not adjust the gap; replace the spark plug as
necessary if out of specification.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
Do not drop or shock the spark plug.
*: Always check with the Parts Department for the latest parts information.
CAUTION:
Always tighten the spark plug to specified torque to align the orie ntation of electrodes. The ground
electrode of a genuine spark plug is positioned in the area of maximum ignitability by tightening to the
specified torque. When replacing spark plugs, use genuine spark pl ugs of which the ground electrode
is adjusted.
NOTE:
SMA773C
SMA806CA
Make NGK
Standard type* PLZKAR6A-11
Gap (nominal) 1.1 mm (0.043 in)
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 1024 of 3641
![NISSAN NOTE 2016 Service Repair Manual SPARK PLUGEM-23
< PERIODIC MAINTENANCE > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
The ground electrode of the spark plug is positioned in the area of maximum ignitability to improve combustion
eficien NISSAN NOTE 2016 Service Repair Manual SPARK PLUGEM-23
< PERIODIC MAINTENANCE > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
The ground electrode of the spark plug is positioned in the area of maximum ignitability to improve combustion
eficien](/img/5/57363/w960_57363-1023.png)
SPARK PLUGEM-23
< PERIODIC MAINTENANCE > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
The ground electrode of the spark plug is positioned in the area of maximum ignitability to improve combustion
eficiency in the cylinder, reduce CO2 (carbon
dioxide) emission and improve fuel economy.
1. Ground electrode of spark plug A. Top view B. Air-fuel mixture flow
C. Poor ignitability region
JPBIA5996GB
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 1025 of 3641
![NISSAN NOTE 2016 Service Repair Manual EM-24
< REMOVAL AND INSTALLATION >[HR16DE]
DRIVE BELT IDLER PULLEY
REMOVAL AND INSTALLATION
DRIVE BELT IDLER PULLEY
Exploded ViewINFOID:0000000012431701
Removal and InstallationINFOID:0000000012431702 NISSAN NOTE 2016 Service Repair Manual EM-24
< REMOVAL AND INSTALLATION >[HR16DE]
DRIVE BELT IDLER PULLEY
REMOVAL AND INSTALLATION
DRIVE BELT IDLER PULLEY
Exploded ViewINFOID:0000000012431701
Removal and InstallationINFOID:0000000012431702](/img/5/57363/w960_57363-1024.png)
EM-24
< REMOVAL AND INSTALLATION >[HR16DE]
DRIVE BELT IDLER PULLEY
REMOVAL AND INSTALLATION
DRIVE BELT IDLER PULLEY
Exploded ViewINFOID:0000000012431701
Removal and InstallationINFOID:0000000012431702
REMOVAL
1. Remove drive belt. Refer to
EM-16, "Removal and Installation".
2. Remove the lock nut, and then remove the plate, tensioner idler pulley, and washer.
3. Remove the center shaft together with the spacer and the adjusting bolt.
INSTALLATION
1. Insert the center shaft (1) into the slide groove of the spacer (2).
Fully screw in the adjusting bolt (3) in the belt loosening direc-
tion ( ).
• At that time, place the flange (a) of the adjusting bolt and theseat (b) of the center shaft on the spacer.
2. Place each surface (c/d) of the spacer on the generator bracket. Install the washer, tensioner idler pulley, and plate, and then
temporarily tighten the lock nut.
1. Generator bracket 2. Tensioner bolt 3. Spacer
4. Adjusting bolt 5. Plate 6. Tensioner idler pulley
7. Washer Front
AWBIA1618ZZ
Lock nut
(Temporary tightening): 4.4 N·m (0.45 kg-m, 39 in-lb)
PBIC3885E
Revision: August 2015
2016 Versa Note
cardiagn.com
Page 1026 of 3641
![NISSAN NOTE 2016 Service Repair Manual DRIVE BELT IDLER PULLEYEM-25
< REMOVAL AND INSTALLATION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
3. Installation of remaining components is in the reverse order of removal.
Revision: August 2015
201 NISSAN NOTE 2016 Service Repair Manual DRIVE BELT IDLER PULLEYEM-25
< REMOVAL AND INSTALLATION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
3. Installation of remaining components is in the reverse order of removal.
Revision: August 2015
201](/img/5/57363/w960_57363-1025.png)
DRIVE BELT IDLER PULLEYEM-25
< REMOVAL AND INSTALLATION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
3. Installation of remaining components is in the reverse order of removal.
Revision: August 2015
2016 Versa Note
cardiagn.com
Page 1027 of 3641
![NISSAN NOTE 2016 Service Repair Manual EM-26
< REMOVAL AND INSTALLATION >[HR16DE]
AIR CLEANER AND AIR DUCT
AIR CLEANER AND AIR DUCT
Exploded ViewINFOID:0000000012431703
Removal and InstallationINFOID:0000000012431704
REMOVAL
NOTE:
Mass air NISSAN NOTE 2016 Service Repair Manual EM-26
< REMOVAL AND INSTALLATION >[HR16DE]
AIR CLEANER AND AIR DUCT
AIR CLEANER AND AIR DUCT
Exploded ViewINFOID:0000000012431703
Removal and InstallationINFOID:0000000012431704
REMOVAL
NOTE:
Mass air](/img/5/57363/w960_57363-1026.png)
EM-26
< REMOVAL AND INSTALLATION >[HR16DE]
AIR CLEANER AND AIR DUCT
AIR CLEANER AND AIR DUCT
Exploded ViewINFOID:0000000012431703
Removal and InstallationINFOID:0000000012431704
REMOVAL
NOTE:
Mass air flow sensor is removable as an assembly with the air cleaner cover.
1. Remove air duct (inlet) from the air cleaner body.
2. Disconnect PCV hose from the air duct.
3. Remove the air duct (between air cleaner case and electric throttle control actuator).
• Add matching marks if necessary for easier installation.
4. Remove air cleaner assembly with the following steps:
a. Disconnect the mass air flow sensor harness connector.
b. Remove the air cleaner body bolts.
c. Pull up on the air cleaner assembly to disengage it from the grommet and remove the air cleaner assem- bly.
CAUTION:
• Do not shock the mass air flow sensor.
• Do not disassemble the mass air flow sensor.
• Do not touch the sensor of the mass air flow sensor.
INSPECTION AFTER REMOVAL
1. Air cleaner cover 2. Mass air flow sensor 3. Gasket
4. Clamp 5. Air duct 6. Clamp
7. Hose 8. Clamp 9. Grommet
10. Grommet insert 11. Grommet 12. Grommet insert
13. Air duct inlet 14. Air cleaner body 15. Air cleaner filter
A. To electric throttle control actuator B. To rocker cover
AWBIA2082ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 1028 of 3641
![NISSAN NOTE 2016 Service Repair Manual AIR CLEANER AND AIR DUCTEM-27
< REMOVAL AND INSTALLATION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
Inspect air duct (inlet) and air duct for cracks, tears, or breaks.
Replace air duct (inlet) and air NISSAN NOTE 2016 Service Repair Manual AIR CLEANER AND AIR DUCTEM-27
< REMOVAL AND INSTALLATION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
Inspect air duct (inlet) and air duct for cracks, tears, or breaks.
Replace air duct (inlet) and air](/img/5/57363/w960_57363-1027.png)
AIR CLEANER AND AIR DUCTEM-27
< REMOVAL AND INSTALLATION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
Inspect air duct (inlet) and air duct for cracks, tears, or breaks.
Replace air duct (inlet) and air duct if necessary.
INSTALLATION
Installation is in the reverse order of removal.
NOTE:
Align marks, attach each joint and screw clamps firmly.
Revision: August 2015
2016 Versa Note
cardiagn.com
Page 1029 of 3641
![NISSAN NOTE 2016 Service Repair Manual EM-28
< REMOVAL AND INSTALLATION >[HR16DE]
INTAKE MANIFOLD
INTAKE MANIFOLD
Exploded ViewINFOID:0000000012431705
Removal and InstallationINFOID:0000000012431706
REMOVAL
NOTE:
When removing components s NISSAN NOTE 2016 Service Repair Manual EM-28
< REMOVAL AND INSTALLATION >[HR16DE]
INTAKE MANIFOLD
INTAKE MANIFOLD
Exploded ViewINFOID:0000000012431705
Removal and InstallationINFOID:0000000012431706
REMOVAL
NOTE:
When removing components s](/img/5/57363/w960_57363-1028.png)
EM-28
< REMOVAL AND INSTALLATION >[HR16DE]
INTAKE MANIFOLD
INTAKE MANIFOLD
Exploded ViewINFOID:0000000012431705
Removal and InstallationINFOID:0000000012431706
REMOVAL
NOTE:
When removing components such as hoses, tubes/lines, etc.
, cap or plug openings to prevent fluid from spill-
ing.
1. Remove air duct (inlet), air duct and air cleaner. Refer to EM-26, "
Removal and Installation".
2. Disconnect water hoses from the electr ic throttle actuator (if necessary).
CAUTION:
• Perform this step when the engine is cold.
• Do not spill engine coolant on the drive belt.
3. Remove electric throttle control actuator. CAUTION:
• Handle carefully to avoid any shock to electric throttle control actuator.
• Do not disassemble electric throttle control actuator.
4. Disconnect EVAP purge control solenoid valve har ness connector and vacuum hose from EVAP purge
control solenoid valve.
CAUTION:
1. EVAP canister purge volume control
solenoid valve 2. Hose clamp
3. Vacuum hose
4. PCV hose 5. Hose clamp6. Intake manifold gasket
7. Intake manifold 8. Electric throttle control actuator 9. Electric throttle control actuator
gasket
10. EVAP service port A. To air ductB. To centralized under-floor piping
C. To air duct D. To brake boosterE. To PCV valve in rocker cover
Front
AWBIA1602ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 1030 of 3641
![NISSAN NOTE 2016 Service Repair Manual INTAKE MANIFOLDEM-29
< REMOVAL AND INSTALLATION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
Handle EVAP canister purge volume control
solenoid valve carefully and avoid impacts.
5. Disconnect vacuum h NISSAN NOTE 2016 Service Repair Manual INTAKE MANIFOLDEM-29
< REMOVAL AND INSTALLATION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
Handle EVAP canister purge volume control
solenoid valve carefully and avoid impacts.
5. Disconnect vacuum h](/img/5/57363/w960_57363-1029.png)
INTAKE MANIFOLDEM-29
< REMOVAL AND INSTALLATION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
Handle EVAP canister purge volume control
solenoid valve carefully and avoid impacts.
5. Disconnect vacuum hose for brake booster from intake manifold.
6. Remove intake manifold bolts (A) at the rocker cover.
7. Loosen bolts in reverse order as shown. CAUTION:
Cover engine openings to avoid entry of foreign materials.
8. Remove intake manifold and intake manifold gasket.
9. Remove EVAP purge control solenoid valve from intake manifold (if necessary). CAUTION:
Handle EVAP canister purge volume control solenoid valve carefully and avoid impacts.
INSTALLATION
Installation is in the reverse order of removal.
Intake Manifold
1. Install the new intake manifold gasket to the intake manifold.
• Align the protrusions used for checking gasket installation con-dition with the clearance grooves (A) of the intake manifold
groove.
CAUTION:
Do not reuse the intake manifold gasket.
NOTE:
New gasket for electric throttle control actuator can be installed
when the electric throttle control actuator is installed.
2. Place the intake manifold into position. CAUTION:
Check that the oil level gauge guide is not detached from the securing clip of the water inlet due to
interference of intake manifold.
AWBIA1620ZZ
AWBIA1576ZZ
JSBIA1220ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
