NISSAN NOTE 2016 Service Repair Manual

SEC-104
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B210E STARTER RELAY
B210E STARTER RELAY
DTC LogicINFOID:0000000012430426
DTC DETECTION LOGIC
NOTE:
• If DTC B210E is displayed with DTC U1000, first
perform the trouble diagnosis for DTC U1000. Refer to
BCS-63, "
DTC Logic".
• If DTC B210E is displayed with DTC B2605, first perform the trouble diagnosis for DTC B2605. Refer to
SEC-80, "
DTC Logic".
• When IPDM E/R power supply voltage is low (Approx. 7 - 8 V for about 1 second), the DTC B210F may be
detected.
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION
1. Turn ignition switch ON.
2. Turn ignition switch OFF and wait 1 second or more.
3. Turn ignition switch ON.
4. Perform “Self Diagnostic Result” of “IPDM E/R” using CONSULT.
Is DTC B210E displayed?
YES >> Refer to SEC-104, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012430427
Regarding Wiring Diagram information, refer to SEC-37, "Wiring Diagram".
1. PERFORM SELF DIAGNOSTIC RESULT
Perform "Self Diagnostic Result" of "IPDM E/R" using CONSULT.
Is display history of DTC B210E CRNT?
YES >> GO TO 2.
NO >> Refer to GI-42, "
Intermittent Incident".
2.CHECK STARTER CONTROL RELA Y CONTROL CIRCUITS VOLTAGE
Check voltage between IPDM E/R connectors and ground.
Is the inspection result normal?
YES >> Replace IPDM E/R. Refer to PCS-30, "Removal and Installation".
NO (WITH M/T)>>GO TO 3.
CONSULT Display DTC Detection Condition Possible Cause
STARTER RELAY OFF
[B210E] When comparing the following items, IPDM E/R
detects that starter control relay is stuck in the
OFF position for 5 second or more:
• Starter control relay signal (CAN) from BCM.
• Starter relay status signal (CAN) from BCM.
• Starter control relay an
d starter relay status
signal. (IPDM E/R input)
• Starter control relay co ntrol signal. (IPDM E/R
output) • IPDM E/R
•BCM
•Battery
IPDM E/R
GroundVo l ta g e
(Approx.)
Connector Terminal
E44 13
—Battery voltage
F42 40
Revision: August 2015 2016 Versa Note

cardiagn.com

B210E STARTER RELAYSEC-105
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
NO (WITH CVT)>>GO TO 4.
3.CHECK STARTER CONTROL RELA Y CONTROL CIRCUIT CONTINUITY
1. Disconnect IPDM E/R connector E44 and clutch interlock switch connector E34.
2. Check continuity between IPDM E/R connector E44 and clutch interlock switch connector E34.
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-74, "Removal and Installation".
NO >> Repair or replace harness or connectors.
4.CHECK STARTER CONTROL RELA Y CONTROL CIRCUIT CONTINUITY
1. Disconnect IPDM E/R connector F42 and transmission range switch connector F52.
2. Check continuity between IPDM E/R connecto r F42 and transmission range switch connector F52.
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-74, "Removal and Installation".
NO >> Repair or replace harness or connectors.
IPDM E/R Clutch interlock switch
Continuity
Connector TerminalConnector Terminal
E44 13E34 2Yes
IPDM E/R Transmission range switch
Continuity
Connector TerminalConnector Terminal
F42 40F52 10Yes
Revision: August 2015 2016 Versa Note

cardiagn.com

SEC-106
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B210F SHIFT POSITION/CLUTCH INTERLOCK SWITCH
B210F SHIFT POSITION/CLUTCH INTERLOCK SWITCH
DTC LogicINFOID:0000000012430428
DTC DETECTION LOGIC
NOTE:
If DTC B210F is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
BCS-
63, "DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Shift selector lever to the P position.
2. Turn ignition switch ON and wait 1 second or more.
3. Shift selector lever to the N position and wait 1 second or more.
4. Shift selector lever to the position other than P and N, and wait 1 second or more.
5. Check DTC in “Self Diagnostic Result” of “IPDM E/R” using CONSULT.
Is DTC detected?
YES >> Go to SEC-106, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis Procedure INFOID:0000000012430429
Regarding Wiring Diagram information, refer to SEC-37, "Wiring Diagram".
1.CHECK DTC OF BCM
Check DTC in “Self Diagnostic Result” of “BCM” using CONSULT.
Is DTC detected?
YES >> Perform the trouble diagnosis relat ed to the detected DTC. Refer to BCS-50, "DTCIndex".
NO >> GO TO 2.
2.CHECK IPDM E/R SIGNAL CIRCUIT OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R connector.
3. Disconnect transmission range switch connector.
4. Check continuity between IPDM E/R harness connector and transmission range switch harness connec- tor.
5. Check continuity between IP DM E/R harness connector and ground.
DTC No. Trouble diagnosis name DTC detecting conditionPossible cause
B210F INTRLCK/PNP SW ON IPDM E/R detects a difference between the
following signals:
• P/N position signal from transmission
range switch and P/N position signal
(CAN) from BCM . • Harness or connectors
(The CAN communication line is open
or shorted.)
• Harness or connectors (Transmission range switch circuit is
open or shorted.)
• Transmission range switch
•IPDM E/R
•BCM
IPDM E/R Transmission range switch
Continuity
Connector TerminalConnector Terminal
F42 40F52 10Yes
Revision: August 2015 2016 Versa Note

cardiagn.com

B210F SHIFT POSITION/CLUTCH INTERLOCK SWITCHSEC-107
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
Is the inspection result normal?
YES >> Replace IPDM E/R. Refer to PCS-30, "Removal and Installation".
NO >> Repair or replace harness.
(+)
(–)Continuity
IPDM E/R
Connector Terminal
F42 40Ground No
Revision: August 2015 2016 Versa Note

cardiagn.com

SEC-108
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2110 SHIFT POSITION/CLUTCH INTERLOCK SWITCH
B2110 SHIFT POSITION/C
LUTCH INTERLOCK SWITCH
DTC LogicINFOID:0000000012430430
DTC DETECTION LOGIC
NOTE:
If DTC B2110 is displayed with DTC U1000, first per form the trouble diagnosis for DTC U1000. Refer to BCS-
63, "DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Shift selector lever to the P position.
2. Turn ignition switch ON and wait 1 second or more.
3. Shift selector lever to the N position and wait 1 second or more.
4. Shift selector lever to the position other than P and N, and wait 1 second or more.
5. Check DTC in “Self Diagnostic Result” of “IPDM E/R” using CONSULT.
Is DTC detected?
YES >> Go to SEC-108, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis Procedure INFOID:0000000012430431
Regarding Wiring Diagram information, refer to SEC-37, "Wiring Diagram".
1.CHECK DTC OF BCM
Check DTC in “Self Diagnostic Result” of “BCM” using CONSULT.
Is DTC detected?
YES >> Perform the trouble diagnosis relat ed to the detected DTC. Refer to BCS-50, "DTCIndex".
NO >> GO TO 2.
2.CHECK IPDM E/R SIGNAL CIRCUIT OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R connector.
3. Disconnect transmission range switch connector.
4. Check continuity between IPDM E/R harness connector and transmission range switch harness connec- tor.
5. Check continuity between IP DM E/R harness connector and ground.
DTC No. Trouble diagnosis name DTC detecting conditionPossible cause
B210F INTRLCK/PNP SW OFF IPDM E/R detects a difference between the
following signals:
• P/N position signal from transmission
range switch and P/N position signal
(CAN) from BCM. • Harness or connectors
(The CAN communication line is open
or shorted.)
• Harness or connectors (Transmission range switch circuit is
open or shorted.)
• Transmission range switch
• IPDM E/R
•BCM
IPDM E/R Transmission range switch
Continuity
Connector TerminalConnector Terminal
F 424 0F 521 0Y es
Revision: August 2015 2016 Versa Note

cardiagn.com

B2110 SHIFT POSITION/CLUTCH INTERLOCK SWITCHSEC-109
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
Is the inspection result normal?
YES >> Replace IPDM E/R. Refer to PCS-30, "Removal and Installation".
NO >> Repair or replace harness.
(+)
(–)Continuity
IPDM E/R
Connector Terminal
F42 40Ground No
Revision: August 2015 2016 Versa Note

cardiagn.com

SEC-110
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
VEHICLE SECURITY INDICATOR
VEHICLE SECURITY INDICATOR
DescriptionINFOID:0000000012542522
• Vehicle security indicator is built in combination meter.
• NATS (Nissan Anti-Theft System) condition is indicated by blink or illumination of vehicle security indicator.
Component Function CheckINFOID:0000000012542523
1.CHECK FUNCTION
1. Perform “Active Test” of “THEFT IND” in the “IMMU” using CONSULT.
2. Check vehicle security indicator operation.
Is the inspection result normal?
YES >> Inspection End.
NO >> Refer to SEC-110, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000012542524
Regarding Wiring Diagram information, refer to SEC-37, "Wiring Diagram".
1.SECURITY INDICATOR LAMP ACTIVE TEST
With CONSULT
Check “THEFT IND”” in “Active Test” of “IMMU”.
Without CONSULT
1. Disconnect BCM.
2. Check voltage between BCM harness connector M97 terminal 23 and ground.
Is the inspection result normal?
YES >> Security indicator lamp is OK.
NO >> GO TO 2.
2.SECURITY INDICATOR LAMP CHECK
Check security indicator lamp condition.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace combination meter. Refer to MWI-115, "
Removal and Installation".
3.CHECK HARNESS CONTINUITY
1. Turn ignition switch OFF.
2. Disconnect BCM and security indicator lamp connector.
3. Check continuity between BCM connector M97 term inal 23 and combination meter connector M24 termi-
nal 18.
Test item Description
THEFT IND ON
Vehicle security indicator ON
OFF OFF
ConnectorTe r m i n a l s
ConditionVoltage (V)
(Approx.)
(+) (-)
M97 23Ground ON
0
OFF Battery voltage
Revision: August 2015 2016 Versa Note

cardiagn.com

VEHICLE SECURITY INDICATORSEC-111
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
4. Check continuity between BCM connector M97 terminal 23 and ground.
Is the inspection result normal?
YES >> Check the following: • 10A fuse No. 8, located in fuse block (J/B)
• Harness for open or short between security indicator lamp and fuse.
NO >> Repair or replace harness.
BCM Combination meter
Continuity
Connector TerminalConnector Terminal
M97 23M24 18Yes
BCM GroundContinuity
Connector Terminal
M97 23 No
Revision: August 2015 2016 Versa Note

cardiagn.com

SEC-112
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
ENGINE DOES NOT START WHEN INTELLI
GENT KEY IS INSIDE OF VEHICLE
SYMPTOM DIAGNOSIS
ENGINE DOES NOT START WHEN INTELLIGENT KEY IS INSIDE OF VE-
HICLE
DescriptionINFOID:0000000012430432
Engine does not start when push-button ignition swit ch is pressed while carrying Intelligent Key.
NOTE:
• Check that vehicle is under the condition shown in “Conditions of vehicle” before starting diagnosis, and check each symptom.
• The engine start function, door lock function, power di stribution system, and NATS-IVIS/NVIS in the Intelli-
gent Key system are closely related to each other regarding control. The vehicle security function can oper-
ate only when the door lock and power dist ribution system are operating normally.
Conditions of Vehicle (Operating Conditions)
• “ENGINE START BY I-KEY” setting in “Work suppor t” in “INTELLIGENT KEY” of “BCM” is ON.
• One or more of Intelligent Keys with registered Intelligent Key ID is in the vehicle.
Diagnosis ProcedureINFOID:0000000012430433
1.PERFORM WORK SUPPORT
Perform “INSIDE ANT DIAGNOSIS” in “Work Support” of “INTELLIGENT KEY” of “BCM” using CONSULT.
Refer to BCS-22, "
INTELLIGENT KEY : CONSULT Func tion (BCM - INTELLIGENT KEY)".
>> GO TO 2.
2.PERFORM SELF-DIAGNOSIS RESULT
Select “Self Diagnostic Result” mode of “BCM”, and check whether or not DTC of inside key antenna is
detected.
Is DTC detected?
YES >> Perform the trouble diagnosis for detected DTC. Refer to BCS-50, "DTCIndex".
NO >> GO TO 3.
3.CHECK PUSH-BUTTON IGNITION SWITCH
Check push-button ignition switch.
Refer to SEC-66, "
Component Inspection".
Is the operation normal?
YES >> GO TO 4.
NO >> Repair or replace malfunctioning parts.
4.CONFIRM THE OPERATION
Confirm the operation again.
Is the inspection normal?
YES >> Check intermittent incident. Refer to GI-42, "Intermittent Incident".
NO >> GO TO 1.
Revision: August 2015 2016 Versa Note

cardiagn.com

SECURITY INDICATOR LAMP DOES NOT TURN ON OR BLINKSEC-113
< SYMPTOM DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
SECURITY INDICATOR LAMP DOES NOT TURN ON OR BLINK
DescriptionINFOID:0000000012430434
Security indicator lamp does not blink when power supply position is other than the ON position.
NOTE:
• Before performing the diagnosis, perform “Work Flow”. Refer to SEC-46, "
Work Flow".
• Check that vehicle is under the condition shown in “Conditions of vehicle” before starting diagnosis, and check each symptom.
Conditions of Vehicle (Operating Conditions)
Power supply position is other than the ON position.
Diagnosis ProcedureINFOID:0000000012430435
1.CHECK SECURITY INDICATOR LAMP
Check security indicator lamp.
Refer to SEC-110, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning parts.
2.CONFIRM THE OPERATION
Confirm the operation again.
Is the result normal?
YES >> Check intermittent incident. Refer to GI-42, "Intermittent Incident".
NO >> GO TO 1.
Revision: August 2015 2016 Versa Note

cardiagn.com
