NISSAN NOTE 2016 Service Repair Manual
Manufacturer: NISSAN, Model Year: 2016, Model line: NOTE, Model: NISSAN NOTE 2016Pages: 3641, PDF Size: 28.72 MB
Page 2941 of 3641
![NISSAN NOTE 2016 Service Repair Manual SEC-84
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B260F ENGINE STATUS
B260F ENGINE STATUS
DescriptionINFOID:0000000012430398
BCM receives the engine status signal from ECM via CAN communic](/img/5/57363/w960_57363-2940.png "NISSAN NOTE 2016 Service Repair Manual SEC-84
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B260F ENGINE STATUS
B260F ENGINE STATUS
DescriptionINFOID:0000000012430398
BCM receives the engine status signal from ECM via CAN communic")
SEC-84
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B260F ENGINE STATUS
B260F ENGINE STATUS
DescriptionINFOID:0000000012430398
BCM receives the engine status signal from ECM via CAN communication.
DTC LogicINFOID:0000000012430399
DTC DETECTION LOGIC
NOTE:
• If DTC B260F is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
BCS-63, "
DTC Logic".
• If DTC B260F is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to BCS-64, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON and wait 2 seconds or more.
2. Check DTC in “Self Diagnostic Result” of “BCM” using CONSULT.
Is DTC detected?
YES >> Go to SEC-84, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012430400
1.INSPECTION START
1. Turn ignition switch ON.
2. Select “Self Diagnostic Result” of “BCM” using CONSULT.
3. Touch ERASE.
4. Perform DTC CONFIRMATION PROCEDURE for DTC B260F. Refer to SEC-84, "
DTC Logic".
Is DTC detected?
YES >> GO TO 2.
NO >> Inspection End.
2.REPLACE ECM
1. Replace ECM. Refer to EC-477, "
Removal and Installation".
2. Perform “ADDITIONAL SERVICE WHEN REPLACING ECM”.
Refer to EC-125, "
Work Procedure".
>> Inspection End.
DTC No. Trouble diagnosis name DTC detecting conditionPossible cause
B260F ECM CAN COMM BCM has not yet received the engine status
signal from ECM when ignition switch is in
the ON position. • Harness or connectors
(The CAN communication line is open
or shorted.)
•ECM
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2942 of 3641
![NISSAN NOTE 2016 Service Repair Manual B261F ASCD CLUTCH SWITCHSEC-85
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
B261F ASCD CLUTCH SWITCH
DTC LogicINFOID:0000000012430401
DTC DETECTION LOGIC
N](/img/5/57363/w960_57363-2941.png "NISSAN NOTE 2016 Service Repair Manual B261F ASCD CLUTCH SWITCHSEC-85
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
B261F ASCD CLUTCH SWITCH
DTC LogicINFOID:0000000012430401
DTC DETECTION LOGIC
N")
B261F ASCD CLUTCH SWITCHSEC-85
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
B261F ASCD CLUTCH SWITCH
DTC LogicINFOID:0000000012430401
DTC DETECTION LOGIC
NOTE:
• If DTC B261F is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
BCS-63, "
DTC Logic".
• If DTC B261F is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to
BCS-64, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine.
2. Drive vehicle at a speed of 40 km/h (24.8 MPH) or more for 10 seconds.
3. Decrease the vehicle speed to below 40 km/h (24.8 MPH).
4. Repeat steps 2 and 3 twice (total of 3 times).
5. Check DTC in “Self Diagnostic Result” of “BCM” using CONSULT.
Is DTC detected?
YES >> Go to SEC-85, "Diagnosis Procedure".
NO >> Inspection End
Diagnosis ProcedureINFOID:0000000012430402
Regarding Wiring Diagram information, refer to SEC-37, "Wiring Diagram".
1.CHECK DTC OF COMBINATION METER
Check DTC in “Self Diagnostic Result ” of “METER/M&A” using CONSULT.
Refer to MWI-24, "
DTC Index".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning parts.
2.CHECK FUSE
1. Turn power switch OFF.
2. Check that the following fuse in the fuse block (J/B) is not blown.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace the blown fuse after repairing the cause of blowing.
DTC No. CONSULT screen items
(Trouble diagnosis content) DTC detecting condition
Possible cause
B261F ASCD CNCL/CLTCH SW
(ASCD clutch interlock
switch) BCM detects the following status for 10 seconds
3 times:
• Clutch interlock switch input: 0 V.
• Vehicle speed: 40 km/h (24.8 MPH) or more. • Harness or connectors.
(CAN communication line is open
or shorted.)
• Harness or connectors. (Clutch interlock switch circuit is
open or shorted)
• Clutch interlock switch
• Combination meter
•BCM
Signal name Fuse No.
Ignition power supply 10 (10 A)
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2943 of 3641
![NISSAN NOTE 2016 Service Repair Manual SEC-86
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B261F ASCD CLUTCH SWITCH
3.CHECK CLUTCH INTERLOCK SWITCH POWER SUPPLY
1. Disconnect clutch interlock switch connector.
2. Turn ignition sw](/img/5/57363/w960_57363-2942.png "NISSAN NOTE 2016 Service Repair Manual SEC-86
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B261F ASCD CLUTCH SWITCH
3.CHECK CLUTCH INTERLOCK SWITCH POWER SUPPLY
1. Disconnect clutch interlock switch connector.
2. Turn ignition sw")
SEC-86
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B261F ASCD CLUTCH SWITCH
3.CHECK CLUTCH INTERLOCK SWITCH POWER SUPPLY
1. Disconnect clutch interlock switch connector.
2. Turn ignition switch ON.
3. Check voltage between clutch interlock switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace harness.
4.CHECK CLUTCH INTERLOCK SWITCH SIGNAL
1. Connect clutch interlock switch connector.
2. Check voltage between BCM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 6.
5.REPLACE BCM
1. Replace BCM. Refer to BCS-74, "
Removal and Installation".
2. Perform initialization of BCM and registration of all Intelligent Keys using CONSULT. Refer to the CON-
SULT Immobilizer mode and follow the on-screen instructions.
>> Inspection End.
6.CHECK CLUTCH INTERLOCK SWITCH CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BCM connector.
3. Check continuity between clutch interlock switch harness connector and BCM harness connector.
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair or replace harness.
7.CHECK CLUTCH INTERLOCK SWITCH
Refer to SEC-87, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 8.
NO >> Replace clutch interlock switch. Refer to CL-11, "
Exploded View".
8.CHECK INTERMITTENT INCIDENT
Refer to GI-42, "
Intermittent Incident".
(+)
(–)Voltage (V)
(Approx.)
Clutch interlock switch
Connector Terminal
E34 1GroundBattery voltage
(+)
(–)Condition Voltage
BCM
Connector Terminal
M98 101Ground Clutch pedal Released
0 V
Depressed Battery voltage
Clutch interlock switch BCM
Continuity
Connector TerminalConnector Terminal
E34 2M98 101Yes
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2944 of 3641
![NISSAN NOTE 2016 Service Repair Manual B261F ASCD CLUTCH SWITCHSEC-87
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
>> Inspection End.
Component InspectionINFOID:0000000012430403
1.CHECK CLUTCH I](/img/5/57363/w960_57363-2943.png "NISSAN NOTE 2016 Service Repair Manual B261F ASCD CLUTCH SWITCHSEC-87
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
>> Inspection End.
Component InspectionINFOID:0000000012430403
1.CHECK CLUTCH I")
B261F ASCD CLUTCH SWITCHSEC-87
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
>> Inspection End.
Component InspectionINFOID:0000000012430403
1.CHECK CLUTCH INTERLOCK SWITCH
1. Turn ignition switch OFF.
2. Disconnect clutch interlock switch connector.
3. Check continuity between clutch interlock switch terminals.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace clutch interlock switch. Refer to CL-11, "
Exploded View".
Clutch interlock switch
ConditionContinuity
Terminal
1 2Clutch pedal Not depressed
No
Depressed Yes
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2945 of 3641
![NISSAN NOTE 2016 Service Repair Manual SEC-88
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2620 PARK/NEUTRAL POSITION SWITCH
B2620 PARK/NEUTRAL POSITION SWITCH
DTC LogicINFOID:0000000012430404
NOTE:
• If DTC B2620 is displayed](/img/5/57363/w960_57363-2944.png "NISSAN NOTE 2016 Service Repair Manual SEC-88
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2620 PARK/NEUTRAL POSITION SWITCH
B2620 PARK/NEUTRAL POSITION SWITCH
DTC LogicINFOID:0000000012430404
NOTE:
• If DTC B2620 is displayed")
SEC-88
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2620 PARK/NEUTRAL POSITION SWITCH
B2620 PARK/NEUTRAL POSITION SWITCH
DTC LogicINFOID:0000000012430404
NOTE:
• If DTC B2620 is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
BCS-63, "
DTC Logic".
• If DTC B2620 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to BCS-64, "
DTC Logic".
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine.
2. Drive vehicle at a speed of 40 km/h (24.8 MPH) or more for 10 seconds.
3. Decrease the vehicle speed to below 40 km/h (24.8 MPH).
4. Repeat steps 2 and 3 twice (total of 3 times).
5. Check DTC in “Self Diagnostic Result” of “BCM” using CONSULT.
Is DTC detected?
YES >> Go to SEC-88, "Diagnosis Procedure".
NO >> Inspection End
Diagnosis ProcedureINFOID:0000000012430405
Regarding Wiring Diagram information, refer to SEC-37, "Wiring Diagram".
1.CHECK DTC OF COMBINATION METER
Check DTC in “Self Diagnostic Result” of “METER/M&A” using CONSULT.
Refer to MWI-24, "
DTC Index".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning parts.
2.CHECK FUSE
1. Turn power switch OFF.
2. Check that the following fuse in the fuse block (J/B) is not blown.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace the blown fuse after repairing the cause of blowing.
DTC No. CONSULT screen items
(Trouble diagnosis content) DTC detecting condition
Possible cause
B2620 NEUTRAL SW
(Neutral switch) BCM detects the following status for 10 sec-
onds 3 times:
• Park/neutral position switch input: Battery
voltage
• Vehicle speed: 40 km/h (24.8 MPH) or more. • Harness or connector
(CAN communication line is open
or shorted.)
• Harness or connector (Park/neutral position switch circuit
is open or shorted.)
• Park/neutral position switch
• Combination meter
•BCM
Signal name Fuse No.
Ignition power supply 3 (10 A)
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2946 of 3641
![NISSAN NOTE 2016 Service Repair Manual B2620 PARK/NEUTRAL POSITION SWITCHSEC-89
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
3.CHECK PARK/NEUTRAL POSITION SWITCH POWER SUPPLY
1. Turn ignition s](/img/5/57363/w960_57363-2945.png "NISSAN NOTE 2016 Service Repair Manual B2620 PARK/NEUTRAL POSITION SWITCHSEC-89
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
3.CHECK PARK/NEUTRAL POSITION SWITCH POWER SUPPLY
1. Turn ignition s")
B2620 PARK/NEUTRAL POSITION SWITCHSEC-89
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
3.CHECK PARK/NEUTRAL POSITION SWITCH POWER SUPPLY
1. Turn ignition switch OFF.
2. Disconnect park/neutral position switch connector.
3. Turn ignition switch ON.
4. Check voltage between park/neutral pos ition switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace harness.
4.CHECK PARK/NEUTRAL POSITION SWITCH INPUT SIGNAL
1. Turn ignition switch OFF.
2. Connect park/neutral position switch connector.
3. Turn ignition switch ON.
4. Check voltage between BCM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 6.
5.REPLACE BCM
1. Replace BCM. Refer to BCS-74, "
Removal and Installation".
2. Perform initialization of BCM and registration of al l Intelligent Keys using CONSULT. Refer to the CON-
SULT Immobilizer mode and follow the on-screen instructions.
>> Inspection End.
6.CHECK PARK/NEUTRAL POSITION SWITCH SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect park/neutral position switch connector.
3. Disconnect BCM connector.
4. Check continuity between park/neutral position switch harness connector and BCM harness connector.
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair or replace harness.
7.CHECK PARK/NEUTRAL POSITION SWITCH
Refer to SEC-90, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 8.
NO >> Replace park/neutral position switch. Refer to TM-19, "
Removal and Installation".
(+)
(–)Voltage (V)
(Approx.)
Park/neutral position switch
Connector Terminal
F24 2GroundBattery voltage
(+)
(–)Condition Voltage
BCM
Connector Terminal
M98 102Ground Shift lever Neutral position
Battery voltage
Except neutral position 0 V
Park/neutral position switch BCM
Continuity
Connector TerminalConnector Terminal
F24 3M98 102Yes
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2947 of 3641
![NISSAN NOTE 2016 Service Repair Manual SEC-90
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2620 PARK/NEUTRAL POSITION SWITCH
8.CHECK INTERMITTENT INCIDENT
Refer to GI-42, "
Intermittent Incident".
>> Inspection End.
Component I](/img/5/57363/w960_57363-2946.png "NISSAN NOTE 2016 Service Repair Manual SEC-90
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2620 PARK/NEUTRAL POSITION SWITCH
8.CHECK INTERMITTENT INCIDENT
Refer to GI-42, \"
Intermittent Incident\".
>> Inspection End.
Component I")
SEC-90
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2620 PARK/NEUTRAL POSITION SWITCH
8.CHECK INTERMITTENT INCIDENT
Refer to GI-42, "
Intermittent Incident".
>> Inspection End.
Component InspectionINFOID:0000000012430406
1.CHECK PARK/NEUTRAL POSITION SWITCH
1. Turn ignition switch OFF.
2. Disconnect park/neutral position switch connector.
3. Check continuity between park/ neutral position switch terminals.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace park/neutral position switch. Refer to TM-19, "
Removal and Installation".
Park/neutral position switch
ConditionContinuity
Te r m i n a l
2 3Shift lever Neutral position
Yes
Except neutral position No
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2948 of 3641
![NISSAN NOTE 2016 Service Repair Manual B26E8 CLUTCH INTERLOCK SWITCHSEC-91
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
B26E8 CLUTCH INTERLOCK SWITCH
DTC LogicINFOID:0000000012430407
DTC DETECTI](/img/5/57363/w960_57363-2947.png "NISSAN NOTE 2016 Service Repair Manual B26E8 CLUTCH INTERLOCK SWITCHSEC-91
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
B26E8 CLUTCH INTERLOCK SWITCH
DTC LogicINFOID:0000000012430407
DTC DETECTI")
B26E8 CLUTCH INTERLOCK SWITCHSEC-91
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
B26E8 CLUTCH INTERLOCK SWITCH
DTC LogicINFOID:0000000012430407
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE 1
1. Turn ignition switch ON.
2. Wait 2 seconds or more under the following conditions.
- Shift lever: In the neutral position.
- Clutch pedal: Depressed
3. Check DTC in “Self Diagnostic Result” of “BCM” using CONSULT.
Is DTC detected?
YES >> Go to SEC-91, "Diagnosis Procedure".
NO >> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE 2
1. Release clutch pedal and wait 2 seconds or more.
2. Check DTC in “Self Diagnostic Result” of “BCM” using CONSULT.
Is DTC detected?
YES >> Go to SEC-91, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012430408
Regarding Wiring Diagram information, refer to SEC-37, "Wiring Diagram".
1.CHECK DTC OF COMBINATION METER
Check DTC in “Self Diagnostic Result ” of “METER/M&A” using CONSULT.
Refer to MWI-24, "
DTC Index".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning parts.
2.CHECK FUSE
1. Turn power switch OFF.
2. Check that the following fuse in the fuse block (J/B) is not blown.
Is the inspection result normal?
DTC No. CONSULT screen items
(Trouble diagnosis content) DTC detecting condition
Possible cause
B26E8 CLUTCH SW
(Clutch switch) BCM detects the following conditions for 2
seconds or more:
• Clutch pedal position switch: ON
(Clutch pedal is released.)
• Clutch interlock switch: ON (Clutch pedal is depressed.) • Harness or connector
(Clutch interlock switch circuit is
open or shorted.)
• Harness or connector
(Clutch pedal position switch circuit
is open or shorted.)
• Clutch interlock switch
• Clutch pedal position switch
•BCM
Signal name Fuse No.
Ignition power supply 10 (10 A)
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2949 of 3641
![NISSAN NOTE 2016 Service Repair Manual SEC-92
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B26E8 CLUTCH INTERLOCK SWITCH
YES >> GO TO 3.
NO >> Replace the blown fuse after repairing the cause of blowing.
3.CHECK CLUTCH INTERLOCK](/img/5/57363/w960_57363-2948.png "NISSAN NOTE 2016 Service Repair Manual SEC-92
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B26E8 CLUTCH INTERLOCK SWITCH
YES >> GO TO 3.
NO >> Replace the blown fuse after repairing the cause of blowing.
3.CHECK CLUTCH INTERLOCK")
SEC-92
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B26E8 CLUTCH INTERLOCK SWITCH
YES >> GO TO 3.
NO >> Replace the blown fuse after repairing the cause of blowing.
3.CHECK CLUTCH INTERLOCK SWITCH POWER SUPPLY
1. Disconnect clutch interlock switch connector.
2. Turn ignition switch ON.
3. Check voltage between clutch interlock switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace harness.
4.CHECK CLUTCH INTERLOCK SWITCH SIGNAL
1. Connect clutch interlock switch connector.
2. Check voltage between BCM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 6.
5.REPLACE BCM
1. Replace BCM. Refer to BCS-74, "
Removal and Installation".
2. Perform initialization of BCM and registration of all Intelligent Keys using CONSULT. Refer to the CON-
SULT Immobilizer mode and follow the on-screen instructions.
>> Inspection End.
6.CHECK CLUTCH INTERLOCK SWITCH CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BCM connector.
3. Check continuity between clutch interlock switch harness connector and BCM harness connector.
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair or replace harness.
7.CHECK CLUTCH INTERLOCK SWITCH
Refer to SEC-93, "
Component Inspection (Clutch Interlock Switch)".
Is the inspection result normal?
YES >> GO TO 8.
NO >> Replace clutch interlock switch. Refer to CL-11, "
Exploded View".
8.CHECK INTERMITTENT INCIDENT
(+)
(–)Voltage (V)
(Approx.)
Clutch interlock switch
Connector Terminal
E34 1GroundBattery voltage
(+)
(–)Condition Voltage
BCM
Connector Terminal
M98 101Ground Clutch pedal Released
0 V
Depressed Battery voltage
Clutch interlock switch BCM
Continuity
Connector TerminalConnector Terminal
E34 2M98 101Yes
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2950 of 3641
![NISSAN NOTE 2016 Service Repair Manual B26E8 CLUTCH INTERLOCK SWITCHSEC-93
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
Refer to GI-42, "Intermittent Incident".
>> Inspection End.
Component Ins](/img/5/57363/w960_57363-2949.png "NISSAN NOTE 2016 Service Repair Manual B26E8 CLUTCH INTERLOCK SWITCHSEC-93
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
Refer to GI-42, \"Intermittent Incident\".
>> Inspection End.
Component Ins")
B26E8 CLUTCH INTERLOCK SWITCHSEC-93
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
Refer to GI-42, "Intermittent Incident".
>> Inspection End.
Component Inspection (Clutch Interlock Switch)INFOID:0000000012430409
1.CHECK CLUTCH INTERLOCK SWITCH
1. Turn ignition switch OFF.
2. Disconnect clutch interlock switch connector.
3. Check continuity between clutch interlock switch terminals.
.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace clutch interlock switch. Refer to CL-11, "
Exploded View".
Clutch interlock switch
Condition Continuity
Te r m i n a l
1 2 Clutch pedal Depressed Yes
Not depressed No
Revision: August 2015
2016 Versa Note
cardiagn.com
