SEC-64
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2555 STOP LAMP
2. Disconnect stop lamp switch connector.
3. Check continuity between stop lamp switch terminals.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace stop lamp switch. Refer to
BR-20, "
Exploded View".
Stop lamp switch
ConditionContinuity
Te r m i n a l
1 2Brake pedal Not depressed
No
Depressed Yes
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2922 of 3641
![NISSAN NOTE 2016 Service Repair Manual B2556 PUSH-BUTTON IGNITION SWITCHSEC-65
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
B2556 PUSH-BUTTON IGNITION SWITCH
DTC LogicINFOID:0000000012430376
DTC](/img/5/57363/w960_57363-2921.png "NISSAN NOTE 2016 Service Repair Manual B2556 PUSH-BUTTON IGNITION SWITCHSEC-65
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
B2556 PUSH-BUTTON IGNITION SWITCH
DTC LogicINFOID:0000000012430376
DTC")
B2556 PUSH-BUTTON IGNITION SWITCHSEC-65
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
B2556 PUSH-BUTTON IGNITION SWITCH
DTC LogicINFOID:0000000012430376
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Press push-button ignition switch under the following condition.
- Brake pedal: Not depressed
2. Release push-button ignition switch and wait 100 seconds or more.
3. Check DTC in “Self Diagnostic Result” of “BCM” using CONSULT.
Is DTC detected?
YES >> Go to SEC-65, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012430377
Regarding Wiring Diagram information, refer to SEC-37, "Wiring Diagram".
1.CHECK PUSH-BUTTON IGNITION SWITCH INPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect push-button ignition switch connector.
3. Check voltage between push-button ignition switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 2.
2.CHECK PUSH-BUTTON IGNITION SWITCH CIRCUIT
1. Disconnect BCM connector and IPDM E/R connector.
2. Check continuity between push-button ignition switch harness connector and BCM harness connector.
3. Check continuity between push-button ignition switch harness connector and ground.
DTC No. Trouble diagnosis name DTC detecting conditionPossible cause
B2556 ENG START SW BCM detects the push-button ignition switch
stuck at ON for 100 seconds or more. • Harness or connectors
(Push-button ignition switch circuit is
shorted.)
• Push-button ignition switch
•BCM
(+)
(–)Voltage (V)
(Approx.)
Push-button ignition switch
Connector Terminal
M25 8GroundBattery voltage
Push-button ignition switch BCM
Continuity
Connector TerminalConnector Terminal
M25 8M98 76Yes
Push-button ignition switch GroundContinuity
Connector Terminal
M25 8 No
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2923 of 3641
![NISSAN NOTE 2016 Service Repair Manual SEC-66
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2556 PUSH-BUTTON IGNITION SWITCH
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness.
3.REPLACE BCM
1. Repla](/img/5/57363/w960_57363-2922.png "NISSAN NOTE 2016 Service Repair Manual SEC-66
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2556 PUSH-BUTTON IGNITION SWITCH
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness.
3.REPLACE BCM
1. Repla")
SEC-66
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2556 PUSH-BUTTON IGNITION SWITCH
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness.
3.REPLACE BCM
1. Replace BCM. Refer to BCS-74, "
Removal and Installation".
2. Perform initialization of BCM and registration of all Intelligent Keys using CONSULT. Refer to the CON-
SULT Immobilizer mode and follow the on-screen instructions.
>> Inspection End.
4.CHECK PUSH-BUTTON IGNITION SWITCH GROUND CIRCUIT
Check continuity between push-button ignition switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace harness.
5.CHECK PUSH-BUTTON IGNITION SWITCH
Refer to SEC-66, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Replace push-button ignition switch. Refer to SEC-115, "
Removal and Installation".
6.CHECK INTERMITTENT INCIDENT
Refer to GI-42, "
Intermittent Incident".
>> Inspection End.
Component InspectionINFOID:0000000012430378
1.CHECK PUSH-BUTTON IGNITION SWITCH
1. Turn ignition switch OFF.
2. Disconnect push-button ignition switch connector.
3. Check continuity between push- button ignition switch terminals.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace push-button ignition switch. Refer to SEC-115, "
Removal and Installation".
Push-button ignition switch
GroundContinuity
Connector Terminal
M25 4 Yes
Push-button ignition switch
Condition Continuity
Te r m i n a l
48 Push-button ignition
switchPressed
Yes
Not pressed No
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2924 of 3641
![NISSAN NOTE 2016 Service Repair Manual B2557 VEHICLE SPEEDSEC-67
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
B2557 VEHICLE SPEED
DTC LogicINFOID:0000000012430379
DTC DETECTION LOGIC
NOTE:
• I](/img/5/57363/w960_57363-2923.png "NISSAN NOTE 2016 Service Repair Manual B2557 VEHICLE SPEEDSEC-67
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
B2557 VEHICLE SPEED
DTC LogicINFOID:0000000012430379
DTC DETECTION LOGIC
NOTE:
• I")
B2557 VEHICLE SPEEDSEC-67
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
B2557 VEHICLE SPEED
DTC LogicINFOID:0000000012430379
DTC DETECTION LOGIC
NOTE:
• If DTC B2557 is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to BCS-63, "
DTC Logic".
• If DTC B2557 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to BCS-64, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and wait 10 seconds or more.
2. Drive the vehicle at a vehicle speed of 10 km/h (6.2 MPH) or more for 10 seconds or more.
3. Check DTC in “Self Diagnostic Result” of “BCM” using CONSULT.
Is DTC detected?
YES >> Go to SEC-67, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012430380
1.CHECK DTC OF “ABS ACTUATOR A ND ELECTRIC UNIT (CONTROL UNIT)”
Check DTC in “Self Diagnostic Result” of “ABS” using CONSULT.
Is DTC detected?
YES >> Perform the trouble diagnosis related to the detected DTC. Refer to BRC-43, "DTC Index".
NO >> GO TO 2.
2.CHECK DTC OF COMBINATION METER
Check DTC in “Self Diagnostic Result ” of “METER/M&A” using CONSULT.
Is DTC detected?
YES >> Perform the trouble diagnosis related to the detected DTC. Refer to MWI-24, "DTC Index".
NO >> GO TO 3.
3.CHECK INTERMITTENT INCIDENT
Refer to GI-42, "
Intermittent Incident".
>> Inspection End.
DTC No. Trouble diagnosis name DTC detecting conditionPossible causes
B2557 VEHICLE SPEED BCM detects one of the following conditions for 10
seconds continuously:
• Vehicle speed signal from “combination meter”
is 10 km/h (6.2 MPH) or more and vehicle
speed signal from “ABS actuator and electric
unit (control unit)” is 4 km/h (2.5 MPH) or less.
• Vehicle speed signal from “combination meter” is 4 km/h (2.5 MPH) or less and vehicle speed
signal from “ABS actuator and electric unit
(control unit)” is 10 km/h (6.2 MPH) or more. • Harness or connectors
(The CAN communication line is
open or shorted.)
• Combination meter
• ABS actuator and electric unit
(control unit)
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2925 of 3641
![NISSAN NOTE 2016 Service Repair Manual SEC-68
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2601 SHIFT POSITION
B2601 SHIFT POSITION
DTC LogicINFOID:0000000012430381
DTC DETECTION LOGIC
NOTE:
• If DTC B2601 is displayed with DT](/img/5/57363/w960_57363-2924.png "NISSAN NOTE 2016 Service Repair Manual SEC-68
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2601 SHIFT POSITION
B2601 SHIFT POSITION
DTC LogicINFOID:0000000012430381
DTC DETECTION LOGIC
NOTE:
• If DTC B2601 is displayed with DT")
SEC-68
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2601 SHIFT POSITION
B2601 SHIFT POSITION
DTC LogicINFOID:0000000012430381
DTC DETECTION LOGIC
NOTE:
• If DTC B2601 is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
BCS-63, "
DTC Logic".
• If DTC B2601 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to BCS-64, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Shift the selector lever to the P position.
2. Turn ignition switch ON and wait 2 seconds or more.
3. Shift the selector lever to any position other than P and wait 2 seconds or more.
4. Check DTC in “Self Diagnostic Result” of “BCM” using CONSULT.
Is DTC detected?
YES >> Go to SEC-68, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012430382
Regarding Wiring Diagram information, refer to SEC-37, "Wiring Diagram".
1.CHECK CVT SHIFT SELECTOR CIRCUIT (BCM)
1. Turn ignition switch OFF.
2. Disconnect CVT shift selector (park position switch) connector.
3. Disconnect BCM connector.
4. Check continuity between CVT shift selector (p ark position switch) harness connector and BCM harness
connector.
5. Check continuity between CVT shift selector (park position switch) harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace harness.
DTC No. Trouble diagnosis name DTC detecting conditionPossible cause
B2601 SHIFT P SIGNAL When there is a difference between P range
signal from CVT shift selector (park position
switch) and P position signal from IPDM E/R
(CAN). • Harness or connectors
(CAN communication line is open or
shorted.)
• Harness or connectors [CVT shift selector (park position
switch) circuit is open or shorted.]
• IPDM E/R
•BCM
CVT shift selector (park position switch) BCM
Continuity
Connector TerminalConnector Terminal
M38 8M97 37Yes
CVT shift selector (park position switch) GroundContinuity
Connector Terminal
M38 8 No
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2926 of 3641
![NISSAN NOTE 2016 Service Repair Manual B2601 SHIFT POSITIONSEC-69
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
2.CHECK CVT SHIFT SELECTOR CIRCUIT (IPDM E/R)
1. Disconnect IPDM E/R connector.
2.](/img/5/57363/w960_57363-2925.png "NISSAN NOTE 2016 Service Repair Manual B2601 SHIFT POSITIONSEC-69
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
2.CHECK CVT SHIFT SELECTOR CIRCUIT (IPDM E/R)
1. Disconnect IPDM E/R connector.
2.")
B2601 SHIFT POSITIONSEC-69
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
2.CHECK CVT SHIFT SELECTOR CIRCUIT (IPDM E/R)
1. Disconnect IPDM E/R connector.
2. Check continuity between CVT shift selector (par k position switch) harness connector and IPDM E/R har-
ness connector.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness.
3.REPLACE BCM
1. Replace BCM. Refer to BCS-74, "
Removal and Installation".
2. Perform initialization of BCM and registration of al l Intelligent Keys using CONSULT. Refer to the CON-
SULT Immobilizer mode and follow the on-screen instructions.
3. Perform DTC CONFIRMATION PROCEDURE for DTC B2601. Refer to SEC-68, "
DTC Logic".
Is DTC B2601 detected again?
YES >> Replace IPDM E/R. Refer to PCS-30, "Removal and Installation".
NO >> Inspection End.
CVT shift selector (park position switch) IPDM E/R
Continuity
Connector TerminalConnector Terminal
M38 8E47 80Yes
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2927 of 3641
![NISSAN NOTE 2016 Service Repair Manual SEC-70
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2602 SHIFT POSITION
B2602 SHIFT POSITION
DTC LogicINFOID:0000000012430383
DTC DETECTION LOGIC
NOTE:
• If DTC B2602 is displayed with DT](/img/5/57363/w960_57363-2926.png "NISSAN NOTE 2016 Service Repair Manual SEC-70
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2602 SHIFT POSITION
B2602 SHIFT POSITION
DTC LogicINFOID:0000000012430383
DTC DETECTION LOGIC
NOTE:
• If DTC B2602 is displayed with DT")
SEC-70
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2602 SHIFT POSITION
B2602 SHIFT POSITION
DTC LogicINFOID:0000000012430383
DTC DETECTION LOGIC
NOTE:
• If DTC B2602 is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
BCS-63, "
DTC Logic".
• If DTC B2602 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to BCS-64, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine.
2. Drive vehicle at a speed of 4 km/h (2.5 MPH) or more for 10 seconds or more.
3. Check DTC in “Self Diagnostic Result” of “BCM” using CONSULT.
Is DTC detected?
YES >> Go to SEC-70, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012430384
Regarding Wiring Diagram information, refer to SEC-37, "Wiring Diagram".
1.CHECK DTC OF ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
Check DTC in “Self Diagnostic Re sult” of “ABS” using CONSULT.
Is DTC detected?
YES >> Perform the trouble diagnosis relat ed to the detected DTC. Refer to BRC-43, "DTC Index".
NO >> GO TO 2.
2.CHECK DTC OF COMBINATION METER
Check DTC in “Self Diagnostic Result” of “METER/M&A” using CONSULT.
Is DTC detected?
YES >> Perform the trouble diagnosis relat ed to the detected DTC. Refer to MWI-24, "DTC Index".
NO >> GO TO 3.
3.CHECK CVT SHIFT SELECTOR POWER SUPPLY
1. Turn ignition switch OFF.
2. Disconnect CVT shift selector (park position switch) connector.
3. Check voltage between CVT shift selector (park position switch) harness connector and ground.
DTC No. Trouble diagnosis name DTC detecting conditionPossible cause
B2602 SHIFT P DIAG BCM detects the following status for 10 seconds:
• Selector lever is in the P position.
• Vehicle speed is 4 km/h (2.5 MPH) or more.
• Ignition switch is in the ON position. • Harness or connectors
(The CAN communication line is
open or shorted.)
• Harness or connectors [CVT shift selector (park position
switch) circuit is open or shorted.]
• CVT shift selector (park position switch)
• Combination meter
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2928 of 3641
![NISSAN NOTE 2016 Service Repair Manual B2602 SHIFT POSITIONSEC-71
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
Is the inspection result normal?
YES >> GO TO 6.
NO >> GO TO 4.
4.CHECK CVT SHIFT S](/img/5/57363/w960_57363-2927.png "NISSAN NOTE 2016 Service Repair Manual B2602 SHIFT POSITIONSEC-71
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
Is the inspection result normal?
YES >> GO TO 6.
NO >> GO TO 4.
4.CHECK CVT SHIFT S")
B2602 SHIFT POSITIONSEC-71
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
Is the inspection result normal?
YES >> GO TO 6.
NO >> GO TO 4.
4.CHECK CVT SHIFT SELECTOR POWER SUPPLY CIRCUIT
1. Disconnect BCM connector.
2. Check continuity between CVT shift selector (park position switch) harness connector and BCM harness connector.
3. Check continuity between CVT shift selector (park position switch) harness connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace harness.
5.REPLACE BCM
1. Replace BCM. Refer to PCS-30, "
Removal and Installation".
2. Perform initialization of BCM and registration of al l Intelligent Keys using CONSULT. Refer to the CON-
SULT Immobilizer mode and follow the on-screen instructions.
>> Inspection End.
6.CHECK CVT SHIFT SELECTOR CIRCUIT
1. Disconnect BCM connector and IPDM E/R connector.
2. Check continuity between CVT shift selector (park position switch) harness connector and BCM harness connector.
3. Check continuity between CVT shift selector (park position switch) harness connector and ground.
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair or replace harness.
7.CHECK CVT SHIFT SELECTOR (PARK POSITION SWITCH)
Refer to SEC-72, "
Component Inspection".
Is the inspection result normal?
(+)
(–)Voltage (V)
(Approx.)
CVT shift selector (park position switch)
Connector Terminal
M38 7GroundBattery voltage
CVT shift selector (park position switch) BCM
Continuity
Connector TerminalConnector Terminal
M38 7M98 104Yes
CVT shift selector (park position switch) GroundContinuity
Connector Terminal
M38 7 No
CVT shift selector (park position switch) BCM
Continuity
Connector TerminalConnector Terminal
M38 8M97 37Yes
CVT shift selector (park position switch) GroundContinuity
Connector Terminal
M38 8 No
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2929 of 3641
![NISSAN NOTE 2016 Service Repair Manual SEC-72
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2602 SHIFT POSITION
YES >> GO TO 8.
NO >> Replace CVT shift selector. Refer to
TM-231, "
Removal and Installation".
8.CHECK INTERMITTENT](/img/5/57363/w960_57363-2928.png "NISSAN NOTE 2016 Service Repair Manual SEC-72
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2602 SHIFT POSITION
YES >> GO TO 8.
NO >> Replace CVT shift selector. Refer to
TM-231, \"
Removal and Installation\".
8.CHECK INTERMITTENT")
SEC-72
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2602 SHIFT POSITION
YES >> GO TO 8.
NO >> Replace CVT shift selector. Refer to
TM-231, "
Removal and Installation".
8.CHECK INTERMITTENT INCIDENT
Refer to GI-42, "
Intermittent Incident".
>> Inspection End.
Component InspectionINFOID:0000000012430385
1.CHECK CVT SHIFT SELECTOR (PARK POSITION SWITCH)
1. Turn ignition switch OFF.
2. Disconnect CVT shift selector connector.
3. Check continuity between CVT shift se lector (park position switch) terminals.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace CVT shift selector. Refer to TM-231, "
Removal and Installation".
CVT shift selector (park position switch)
ConditionContinuity
Terminal
78 Selector lever: P positionSelector button: Released
No
Selector button: Pressed Ye s
Selector lever: Other than P position
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2930 of 3641
![NISSAN NOTE 2016 Service Repair Manual B2603 SHIFT POSITIONSEC-73
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
B2603 SHIFT POSITION
DTC LogicINFOID:0000000012430386
DTC DETECTION LOGIC
NOTE:
•](/img/5/57363/w960_57363-2929.png "NISSAN NOTE 2016 Service Repair Manual B2603 SHIFT POSITIONSEC-73
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
B2603 SHIFT POSITION
DTC LogicINFOID:0000000012430386
DTC DETECTION LOGIC
NOTE:
•")
B2603 SHIFT POSITIONSEC-73
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
B2603 SHIFT POSITION
DTC LogicINFOID:0000000012430386
DTC DETECTION LOGIC
NOTE:
• If DTC B2603 is displayed with DTC B2601, first perform the trouble diagnosis for DTC B2601. Refer to SEC-68, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE 1
1. Shift the selector lever to the P position.
2. Turn ignition switch ON and wait 1 second or more.
3. Check DTC in “Self Diagnostic Result” of “BCM” using CONSULT.
Is DTC detected?
YES >> Go to SEC-73, "Diagnosis Procedure".
NO >> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE 2
1. Shift the selector lever to the position other than P and N, and wait 1 second or more.
2. Check DTC in “Self Diagnostic Result” of “BCM” using CONSULT.
Is DTC detected?
YES >> Go to SEC-73, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012430387
Regarding Wiring Diagram information, refer to SEC-37, "Wiring Diagram".
1.INSPECTION START
Perform inspection in accordance with procedure that confirms DTC.
Which procedure confirms DTC?
DTC confirmation procedure 1>>GO TO 2.
DTC confirmation procedure 2>>GO TO 8.
2.CHECK FUSE
1. Turn power switch OFF.
2. Check that the following fuse in IPDM E/R is not blown.
Is the inspection result normal?
DTC No. Trouble diagnosis name DTC detecting conditionPossible causes
B2603 SHIFT POSITION BCM detects the following status when ignition
switch is in the ON position:
• Transmission range switch signal: approx. 0
V.
• CVT shift selector (park position switch) sig- nal: approx. 0 V. • Harness or connector
[CVT shift selector (park position
switch) circuit is open or shorted.]
• Harness or connectors (Transmission range switch circuit is
open or shorted.)
• CVT shift selector (park position switch)
• Transmission range switch
•BCM
Signal name Fuse No.
Ignition power supply 49 (10 A)
Revision: August 2015 2016 Versa Note
cardiagn.com
