NISSAN NOTE 2016 Service Repair Manual

TM-150
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F11A]
P0706 TRANSMISSION RANGE SENSOR A
P0706 TRANSMISSION RANGE SENSOR A
DTC LogicINFOID:0000000012431083
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PREPARATION BEFORE WORK
If another "DTC CONFIRMATION PROCEDURE" occurs just before, turn ignition switch OFF and wait for at
least 10 seconds, then perform the next test.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine.
2. Maintain the following conditions.
3. Shift the selector lever through entire positions from “P ” to “L”. (Hold the selector lever at each position for
35 seconds or more.)
4. Check the first trip DTC.
Is
“P0706” detected?
YES >> Go to TM-150, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000012431084
1.ADJUSTMENT OF CONTROL CABLE
Adjust control cable. Refer to TM-232, "
Inspection".
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
With CONSULT
1. Turn ignition switch ON.
2. Select “Self Diagnostic Results” in “TRANSMISSION”.
3. Touch “Erase”.
4. Perform "DTC CONFIRMATION PROCEDURE". Refer to TM-150, "
DTC Logic".
Is
“P0706” detected?
DTC Trouble diagnosis name DTC detection conditionPossible causes
P0706 Transmission Range Sensor
A Circuit Range/Performance When all of the following conditions are satis-
fied for 30 consecutive seconds:
• All range signals stay OFF
• Power supply voltage: More than 11 V
• Harness or connector
(Open circuit transmission range
switch ignition power supply/open cir-
cuit between transmission range
switch and TCM)
• Transmission range switch
• Control cable
When all of the following conditions are satis-
fied for 5 consecutive seconds:
• All range signals stay OFF
• Power supply voltage: More than 11 V
• Engine speed −
input shaft speed is more
than 200 rpm.
• Input shaft speed is more than 250 rpm.
• CVT fluid temperature: More than 20
°C
(68°F).
Accelerator pedal position : 0.0/8
Brake pedal : Depressed
Vehicle speed : 0 km/h (0 MPH)
Revision: August 2015 2016 Versa Note

cardiagn.com

P0706 TRANSMISSION RANGE SENSOR ATM-151
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
YES >> GO TO 3.
NO >> INSPECTION END
3.CHECK POWER CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect transmission range switch connector.
3. Turn ignition switch ON.
4. Check voltage between transmission range switch harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 7.
4.CHECK CIRCUIT BETWEEN TR ANSMISSION RANGE SWITCH AND TCM (PART 1)
1. Turn ignition switch OFF.
2. Disconnect TCM connector.
3. Check continuity between transmission range sw itch harness connector terminals and TCM harness con-
nector terminals.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace malfunctioning parts.
5.CHECK CIRCUIT BETWEEN TR ANSMISSION RANGE SWITCH AND TCM (PART 2)
Check continuity between tr ansmission range switch harness connector terminals and ground.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace malfunctioning parts.
6.CHECK TRANSMISSION RANGE SWITCH
Check transmission range switch. Refer to TM-152, "
Component Inspection (Transmission Range Switch)".
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-42, "Intermittent Incident".
+
−Vo l ta g e
Transmission range switch
Connector Terminal F52 4 Ground 10 – 16 V
Transmission range switch TCM
Continuity
Connector Terminal Connector Terminal
F52 2
F44 4
Existed
57
66
86
95
Transmission range switch
—Continuity
Connector Terminal
F52 2
Ground Not existed
5
6
8
9
Revision: August 2015
2016 Versa Note

cardiagn.com

TM-152
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F11A]
P0706 TRANSMISSION RANGE SENSOR A
NO >> Repair or replace malfunctioning parts.
7.CHECK CIRCUIT BETWEEN
IPDM E/R AND TRANSMISSION RANGE SWITCH
1. Disconnect IPDM E/R connector.
2. Check continuity between IPDM E/R har ness connector and transmission range switch.
Is the check result normal?
YES >> GO TO 8.
NO >> Repair or replace malfunctioning parts.
8.DETECT MALFUNCTIONING ITEMS
Check the following items:
• Open circuit or short circuit in harness between ignition switch and IPDM E/R. Refer to PG-27, "
Wiring Dia-
gram — Ignition Power Supply —".
• Short circuit in harness between IPDM E/R harne ss connector terminal 21 and transmission range switch
harness connector terminal 4.
• 10A fuse (No. 49, IPDM E/R). Refer to PG-60, "
IPDM E/R Terminal Arrangement".
• IPDM E/R
Is the check result normal?
YES >> Check intermittent incident. Refer to GI-42, "Intermittent Incident".
NO >> Repair or replace malfunctioning parts.
Component Inspection (T ransmission Range Switch)INFOID:0000000012431085
1.CHECK TRANSMISSION RANGE SWITCH
Check continuity between transmission range switch connector terminals.
Is the inspection result normal?
YES >> INSPECTION END
NO >> There is a malfunction of transmission range switch. Replace transaxle assembly. Refer to TM-
259, "Removal and Installation".
IPDM E/RTransmission range switch
Continuity
Connector Terminal Connector Terminal
E45 21F52 4 Existed
Transmission range switch
Condition Continuity
Te r m i n a l
7 – 10 Manual lever: “P” and “N” positions Existed
Other than the above
Not existed
4 – 5 Manual lever: “P
” position Existed
Other than the above Not existed
4 – 8 Manual lever: “R
” position Existed
Other than the above Not existed
4 – 9 Manual lever: “N position
Existed
Other than the above Not existed
4 – 2 Manual lever: “D
” position Existed
Other than the above Not existed
4 – 6 Manual lever: “L
” position Existed
Other than the above Not existed
Revision: August 2015 2016 Versa Note

cardiagn.com

P0711 TRANSMISSION FLUID TEMPERATURE SENSOR ATM-153
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P0711 TRANSMISSION FLUI D TEMPERATURE SENSOR A
DTC LogicINFOID:0000000012431086
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PREPARATION BEFORE WORK
If another "DTC CONFIRMATION PROCEDURE" occurs just before, turn ignition switch OFF and wait for at
least 10 seconds, then perform the next test.
>> GO TO 2.
2.INSPECTION START
Is it necessary to erase permanent DTC?
YES >> GO TO 3.
NO >> GO TO 7.
3.CHECK DTC (ECM AND TCM)
Check the DTC.
Is any DTC other than
“P0711” detected?
YES >> Check DTC detect ed item. Refer to EC-87, "DTCIndex" (ECM), TM-110, "DTC Index" (TCM).
NO >> GO TO 4.
DTC Trouble diagnosis name DTC detection conditionPossible causes
P0711 Transmission Fluid Tempera-
ture Sensor A Circuit Range/
Performance When any of 1 or 2 is satisfied:
1. Under the following diagnosis conditions,
CVT fluid temperature does not rise to
10°C (50 °F) after driving for a certain pe-
riod of time with the TCM-received fluid
temperature sensor value between −
40 °C ( −40 °F) and 9 °C (48.2 °F).
- Diagnosis condition
• Selector lever: “D” position
• Vehicle speed: 10 km/h (7 MPH) or more
• Engine speed: 450 rpm or more
• Accelerator pedal position: 1.0/8 or more
• TCM power supply voltage: More than 11 V
• CVT fluid temperature: Less than 10 °C
2. When the condition of the final judgment is satisfied after satisfying that of the pro-
visional judgment:
- Provisional judgment: All of the following conditions are satisfied within 2 seconds
after the ignition switch is turned ON.
• U0073, U0100, P0712 and P0713 are not detected.
• CAN communication is normal.
• TCM power supply voltage: More than 11
V
• The difference between CVT fluid tem-
perature and engine coolant temperature
is 37°C (98.6 °F) or more, or −27 °C ( −
16 °F) or less.
- Final judgment: When all of the following conditions are satisfied and this state is
maintained for 300 seconds:
•ECM is normal.
• Provisional judgment is satisfied. CVT fluid temperature sensor
Revision: August 2015
2016 Versa Note

cardiagn.com

TM-154
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F11A]
P0711 TRANSMISSION FLUID
TEMPERATURE SENSOR A
4.PERFORM DTC CONFIRMATION PROCEDURE (PART 1)
TESTING CONDITION:
• While performing the following procedure, do not add fuel.
• Before performing the followin g procedure, check that fuel level is between 1/4 and 4/4.
• Before performing the following procedure, confirm that battery voltage is 11 V or more at idle.
With CONSULT
1. Move the vehicle to a cool place.
NOTE:
Cool the vehicle in an environment of ambient air temperature between −10° C (14° F) and 35 °C (95 °F).
2. Turn ignition switch OFF and leave the vehicle for 12 hours.
CAUTION:
Never turn ignition switch ON during this procedure.
NOTE:
The vehicle must be cooled with the food open.
3. Turn ignition switch ON. CAUTION:
Never start the engine.
4. Select “Data Monitor” in “TRANSMISSION”.
5. Select “FLUID TEMP”.
6. Record CVT fluid temperature.
7. Start engine and let it idle for 5 minutes or more. CAUTION:
Never turn ignition switch OFF during idling.
8. Check 1st trip DTC.
With GST
1. Move the vehicle to a cool place. NOTE:
Cool the vehicle in an environment of ambient air temperature between −10° C (14° F) and 35 °C (95 °F).
2. Turn ignition switch OFF and leave the vehicle for 12 hours. CAUTION:
Never turn ignition switch ON during this procedure.
NOTE:
The vehicle must be cooled with the food open.
3. Start engine and let it idle for 5 minutes or more. CAUTION:
Never turn ignition switch OFF during idling.
4. Check 1st trip DTC.
Is
“P0711” detected?
YES >> Go to TM-156, "Diagnosis Procedure".
NO-1 (With CONSULT)>>GO TO 5.
NO-2 (With GST)>>GO TO 6.
5.CHECK CVT FLUID TEMPERATURE
With CONSULT
1. Select “Data Monitor” in “TRANSMISSION”.
2. Select “FLUID TEMP”.
Is the value of
“FLUID TEMP” 10°C (50°F) or more?
YES >> INSPECTION END
NO >> GO TO 6.
6.PERFORM DTC CONFIRMATION PROCEDURE (PART 2)
With CONSULT
1. Drive the vehicle for the total minutes specified in the Driving time column below with the following condi-
tions satisfied.
Selector lever : “D” position
Accelerator pedal position : 1.0/8 or more
Vehicle speed : 10 km/h (7 MPH) or more
Revision: August 2015 2016 Versa Note

cardiagn.com

P0711 TRANSMISSION FLUID TEMPERATURE SENSOR ATM-155
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
2. Stop the vehicle.
3. Check the first trip DTC. With GST
1. Drive the vehicle and maintain the following conditions for 18 minutes or more.
2. Stop the vehicle.
3. Check the first trip DTC.
Is
“P0711” detected?
YES >> Go to TM-156, "Diagnosis Procedure".
NO >> INSPECTION END
7.PERFORM DTC CONFIRMATION PROCEDURE
With CONSULT
1. Turn ignition switch OFF and cool the engine.
2. Turn ignition switch ON. CAUTION:
Never start the engine.
3. Select “Data Monitor” in “TRANSMISSION”.
4. Select “FLUID TEMP”.
5. Record CVT fluid temperature.
6. Start the engine and wait for at least 2 minutes.
7. Drive the vehicle for the total minutes specified in the Driving time column below with the following condi- tions satisfied.
8. Stop the vehicle.
9. Check the first trip DTC. With GST
1. Turn ignition switch OFF and cool the engine.
2. Start the engine and wait for at least 2 minutes.
3. Drive the vehicle and maintain the following conditions for 18 minutes or more.
CVT fluid temperature before engine start Driving time
− 40 °C ( −40 °F) – −31 °C ( −23.8 °F) 18 minutes or more
− 30 °C ( −22 °F) – −21 °C ( −5.8 °F) 16 minutes or more
− 20 °C ( −4°F) – −11 °C ( −12.2 °F) 13 minutes or more
− 10 °C (14 °F) – −1 °C (30.2 °F) 9 minutes or more
0 °C (32 °F) – 9 °C (48.2 °F) 6 minutes or more
Selector lever : “D” position
Accelerator pedal position : 1.0/8 or more
Vehicle speed : 10 km/h (7 MPH) or more
Selector lever : “D” position
Accelerator pedal position : 1.0/8 or more
Vehicle speed : 10 km/h (7 MPH) or more
CVT fluid temperature before engine start Driving time
− 40 °C ( −40 °F) – −31 °C ( −23.8 °F) 18 minutes or more
− 30 °C ( −22 °F) – −21 °C ( −5.8 °F) 16 minutes or more
− 20 °C ( −4°F) – −11 °C ( −12.2 °F) 13 minutes or more
− 10 °C (14 °F) – −1 °C (30.2 °F) 9 minutes or more
0 °C (32 °F) – 9 °C (48.2 °F) 6 minutes or more
Other than the above — (Go to “8.CHECK CVT FLU-
ID TEMPERATURE SENSOR”)
Revision: August 2015
2016 Versa Note

cardiagn.com

TM-156
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F11A]
P0711 TRANSMISSION FLUID
TEMPERATURE SENSOR A
4. Stop the vehicle.
CAUTION:
Never turn ignition switch OFF
5. Check the first trip DTC.
Is
“P0711” detected?
YES >> Go to TM-156, "Diagnosis Procedure".
NO >> GO TO 8.
8.CHECK CVT FLUID TE MPERATURE SENSOR
1. Turn ignition switch OFF.
2. Disconnect CVT unit connector.
3. Check resistance between CVT unit connector terminals.
Is the inspection result normal?
YES >> INSPECTION END
NO >> There is a malfunction of CVT fluid temperat ure sensor. Replace control valve. Refer to TM-259,
"Removal and Installation".
Diagnosis ProcedureINFOID:0000000012431087
1.CHECK CVT FLUID TEMPERATURE SENSOR
1. Turn ignition switch OFF.
2. Disconnect CVT unit connector.
3. Check CVT fluid temperature sensor. Refer to TM-156, "
Component Inspection (CVT Fluid Temperature
Sensor)".
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-42, "Intermittent Incident".
NO >> Repair or replace malfunctioning parts.
Component Inspection (CVT Fluid Temperature Sensor) INFOID:0000000012431088
1.CHECK CVT FLUID TE MPERATURE SENSOR
Check resistance between CVT unit connector terminals.
Is the inspection result normal?
YES >> INSPECTION END
NO >> There is a malfunction of CVT fluid temperatur e sensor. Replace control valve assembly. Refer to
TM-242, "
Removal and Installation".
Selector lever : “D” position
Accelerator pedal position : 1.0/8 or more
Vehicle speed : 10 km/h (7 MPH) or more
CVT unit Condition Resistance
(Approx.)
Te r m i n a l
12 – 18 CVT fluid temperature: 20
°C (68 °F) 6.5 kΩ
CVT fluid temperature: 50 °C (122 °F) 2.2 k Ω
CVT fluid temperature: 80 °C (176 °F) 0.87 k Ω
CVT unit
Condition Resistance
(Approx.)
Te r m i n a l
12 – 18 CVT fluid temperature: 20
°C (68 °C) 6.5 kΩ
CVT fluid temperature: 50 °C (122 °C) 2.2 k Ω
CVT fluid temperature: 80 °C (176 °C) 0.87 k Ω
Revision: August 2015 2016 Versa Note

cardiagn.com

P0712 TRANSMISSION FLUID TEMPERATURE SENSOR ATM-157
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P0712 TRANSMISSION FLUI D TEMPERATURE SENSOR A
DTC LogicINFOID:0000000012431089
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PREPARATION BEFORE WORK
If another "DTC CONFIRMATION PROCEDURE" occurs just before, turn ignition switch OFF and wait for at
least 10 seconds, then perform the next test.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine and wait for 10 seconds or more.
2. Check the first trip DTC.
Is
“P0712” detected?
YES >> Go to TM-157, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000012431090
1.CHECK CIRCUIT BETWEE N TCM AND CVT UNIT
1. Turn ignition switch OFF.
2. Disconnect TCM connector and CVT unit connector.
3. Check continuity between TCM harness connector terminal and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace malfunctioning part.
2.CHECK CVT FLUID TEMPERATURE SENSOR
Check CVT fluid temperature sensor. Refer to TM-157, "
Component Inspection (CVT Fluid Temperature Sen-
sor)".
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-42, "Intermittent Incident".
NO >> Repair or replace malfunctioning parts.
Component Inspection (CVT Fluid Temperature Sensor) INFOID:0000000012431091
1.CHECK CVT FLUID TEMPERATURE SENSOR
Check resistance between CVT unit connector terminals.
DTC Trouble diagnosis name DTC detection conditionPossible causes
P0712 Transmission Fluid Tempera-
ture Sensor A Circuit Low The CVT fluid temperature identified by the
TCM is 180
°C (356 °F) or more continuously
for 5 seconds or more under the following di-
agnosis conditions:
• Diagnosis conditions
- Ignition switch: ON
- TCM power supply voltage: More than 11 V • Harness or connector
(CVT fluid temperature sensor circuit is
shorted to ground)
• CVT fluid temperature sensor
TCM —Continuity
Connector Terminal
F44 12Ground Not existed
Revision: August 2015 2016 Versa Note

cardiagn.com

TM-158
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F11A]
P0712 TRANSMISSION FLUID
TEMPERATURE SENSOR A
Is the inspection result normal?
YES >> INSPECTION END
NO >> There is a malfunction of CVT fluid temperatur e sensor. Replace control valve assembly. Refer to
TM-242, "
Removal and Installation".
CVT unit Condition Resistance
(Approx.)
Te r m i n a l
12 – 18 CVT fluid temperature: 20
°C (68 °C) 6.5 kΩ
CVT fluid temperature: 50 °C (122 °C) 2.2 k Ω
CVT fluid temperature: 80 °C (176 °C) 0.87 k Ω
Revision: August 2015 2016 Versa Note

cardiagn.com

P0713 TRANSMISSION FLUID TEMPERATURE SENSOR ATM-159
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P0713 TRANSMISSION FLUI D TEMPERATURE SENSOR A
DTC LogicINFOID:0000000012431092
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PREPARATION BEFORE WORK
If another "DTC CONFIRMATION PROCEDURE" occurs just before, turn ignition switch OFF and wait for at
least 10 seconds, then perform the next test.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine.
2. Maintain the following condition for 10 seconds or more.
3. Stop the vehicle.
4. Check the first trip DTC.
Is
“P0713” detected?
YES >> Go to TM-159, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000012431093
1.CHECK CIRCUIT BETWEEN TC M AND CVT UNIT (PART 1)
1. Turn ignition switch OFF.
2. Disconnect TCM connector and CVT unit connector.
3. Check continuity between TCM harness connector terminals and CVT unit harness connector terminals.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace malfunctioning part.
2.CHECK CIRCUIT BETWEEN TC M AND CVT UNIT (PART 2)
1. Turn ignition switch ON.
2. Check voltage between TCM harness connector terminal and ground.
DTC Trouble diagnosis name DTC detection conditionPossible causes
P0713 Transmission Fluid Tempera-
ture Sensor A Circuit High The CVT fluid temperature identified by the
TCM is
−40 °C (− 40°F) or less continuously for
5 seconds or more under the following diagno-
sis conditions:
• Diagnosis conditions
- Ignition switch: ON
- Vehicle speed: More than 10 km/h (7 MPH)
- TCM power supply voltage: More than 11 V • Harness or connector
(CVT fluid temperature sensor circuit is
open or shorted to power supply)
• CVT fluid temperature sensor
Vehicle speed : 20 km/h (12 MPH) or more
TCM CVT unit
Continuity
Connector Terminal Connector Terminal
F44 12
F46 12
Existed
11 1 8
Revision: August 2015 2016 Versa Note

cardiagn.com
