DIAGNOSIS SYSTEM [ABS ACTUATOR AND ELECTRIC UNIT (CONTROL
UNIT)]
BRC-33
< SYSTEM DESCRIPTION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
× : Applicable
–: Not applicable
ACTIVE TEST MODE
CAUTION:
• Do not perform active test while driving vehicle.
• Make sure to completely bleed air from brake system.
• The active test cannot be performed with the ABS warning lamp, VDC OFF indicator lamp, SLIP indi-
cator lamp or brake warning lamp on.
• ABS warning lamp, VDC OFF indi cator lamp, SLIP indicator lamp and brake warning lamp turn on
during active test.
NOTE:
• When active test is performed while depressing the pedal, the pedal depression amount will change. This is normal.
• “TEST IS STOPPED” is displayed 10 seconds after operation start.
• After “TEST IS STOPPED” is displayed, to perform test again, touch BACK.
Test Item
ABS SOLENOID VALVE• Select “Up”, “Keep” and “Down”. Then use screen monitor to check that solenoid valve operates as shown in
the table below.
SV1
(On/Off) ––
×Suction valve 1(On/Off) status is displayed.
SV2
(On/Off) ––
×Suction valve 2 (On/Off) status is displayed.
ACCEL POS SIG
(%) ×
– ×Throttle valve open/close status judged by CAN com-
munication signal is displayed.
SIDE G-SENSOR
(m/s
2) ×
– ×Transverse acceleration detected by side G-sensor is
displayed.
STR ANGLE SIG
(deg) ×
– ×Steering angle detected by steering angle sensor is
displayed.
PRESS SENSOR
(bar) ×
– ×Brake pressure detected by pressure sensor is dis-
played.
EBD SIGNAL
(On/Off) ––
×EBD operation (On/Off) status is displayed.
ABS SIGNAL
(On/Off) ––
×ABS operation (On/Off) status is displayed.
TCS SIGNAL
(On/Off) ––
×TCS operation (On/Off) status is displayed.
VDC SIGNAL
(On/Off) ––
×VDC operation (On/Off) status is displayed.
EBD FAIL SIG
(On/Off) ––
×EBD fail signal (On/Off) status is displayed.
ABS FAIL SIG
(On/Off) ––
×ABS fail signal (On/Off) status is displayed.
TCS FAIL SIG
(On/Off) ––
×TCS fail signal (On/Off) status is displayed.
VDC FAIL SIG
(On/Off) ––
×VDC fail signal (On/Off) status is displayed.
CRANKING SIG
(On/Off) ––
×The input state of the key SW START position signal
is displayed.
FLUID LEV SW
(On/Off) ×
– ×Brake fluid level switch (On/Off) status is displayed.
Item
(Unit) Data monitor item selection
Remarks
ECU INPUT
SIGNALS MAIN
SIGNALS SELECTION
FROM MENU
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 482 of 3641
![NISSAN NOTE 2016 Service Repair Manual BRC-34
< SYSTEM DESCRIPTION >[VDC/TCS/ABS]
DIAGNOSIS SYSTEM [
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL
UNIT)]
*: On for 1 to 2 seconds after the select, and then Off.
NOTE:
A brief moment of On/Off co](/img/5/57363/w960_57363-481.png "NISSAN NOTE 2016 Service Repair Manual BRC-34
< SYSTEM DESCRIPTION >[VDC/TCS/ABS]
DIAGNOSIS SYSTEM [
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL
UNIT)]
*: On for 1 to 2 seconds after the select, and then Off.
NOTE:
A brief moment of On/Off co")
BRC-34
< SYSTEM DESCRIPTION >[VDC/TCS/ABS]
DIAGNOSIS SYSTEM [
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL
UNIT)]
*: On for 1 to 2 seconds after the select, and then Off.
NOTE:
A brief moment of On/Off condition occurs every 20 seconds after ignition switch turned ON. This is not malfunction because it is an
operation for checking.
ABS SOLENOID VALVE (ACT)
• Select “Up”, “ACT UP” and “ACT KEEP”. Then use screen monitor to check that solenoid valve operates as
shown in the table below.
*: On for 1 to 2 seconds after the select, and then Off.
NOTE: Test item
Display item Display (Note)
Up Keep Down
FR RH SOL FR RH IN SOL
OffOn On
FR RH OUT SOL OffOffOn*
FR LH SOL FR LH IN SOL
OffOn On
FR LH OUT SOL OffOffOn*
RR RH SOL RR RH IN SOL
OffOnOn
RR RH OUT SOL OffOffOn*
RR LH SOL RR LH IN SOL
OffOn On
RR LH OUT SOL OffOffOn*
Test itemDisplay item Display (Note)
Up ACT UP ACT KEEP
FR RH ABS SOLENOID
(ACT) FR RH IN SOL
OffOffOff
FR RH OUT SOL OffOffOff
CV1 OffOnOn
CV2 OffOn* Off
SV1 OffOnOn
SV2 OffOn Off
FR LH ABS SOLENOID
(ACT) FR LH IN SOL
OffOffOff
FR LH OUT SOL OffOffOff
CV1 OffOnOn
CV2 OffOn* Off
SV1 OffOnOn
SV2 OffOn Off
RR RH ABS SOLENOID
(ACT) RR RH IN SOL
OffOffOff
RR RH OUT SOL OffOffOff
CV1 OffOnOn
CV2 OffOn* Off
SV1 OffOnOn
SV2 OffOn Off
RR LH ABS SOLENOID
(ACT) RR LH IN SOL
OffOffOff
RR LH OUT SOL OffOffOff
CV1 OffOnOn
CV2 OffOn* Off
SV1 OffOnOn
SV2 OffOn Off
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 483 of 3641
![NISSAN NOTE 2016 Service Repair Manual DIAGNOSIS SYSTEM [ABS ACTUATOR AND ELECTRIC UNIT (CONTROL
UNIT)]
BRC-35
< SYSTEM DESCRIPTION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
A brief moment of On/Off condition occurs every 20 secon](/img/5/57363/w960_57363-482.png "NISSAN NOTE 2016 Service Repair Manual DIAGNOSIS SYSTEM [ABS ACTUATOR AND ELECTRIC UNIT (CONTROL
UNIT)]
BRC-35
< SYSTEM DESCRIPTION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
A brief moment of On/Off condition occurs every 20 secon")
DIAGNOSIS SYSTEM [ABS ACTUATOR AND ELECTRIC UNIT (CONTROL
UNIT)]
BRC-35
< SYSTEM DESCRIPTION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
A brief moment of On/Off condition occurs every 20 seconds after ignition switch turned ON. This is not malfunction because it is an
operation for checking.
ABS MOTOR• Select “On” and “Off”. Make sure motor relay and actuator relay operates as shown in table below.
NOTE:
A brief moment of On/Off condition occurs every 20 seconds after ignition switch turned ON. This is not malfunction because it is an
operation for checking.
WORK SUPPORT
Test item Display item Display
On Off
ABS MOTOR MOTOR RELAY
OnOff
ACTUATOR RLY (Note) OnOn
Conditions Description
ST ANGLE SENSOR ADJUSTMENT Steering angle sensor neutral position adjustment can be per-
formed. Refer to
BRC-55, "
ADJUSTMENT OF STEERING AN-
GLE SENSOR NEUTRAL POSITION : Special Repair
Requirement".
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 484 of 3641
![NISSAN NOTE 2016 Service Repair Manual BRC-36
< ECU DIAGNOSIS INFORMATION >[VDC/TCS/ABS]
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
ECU DIAGNOSIS INFORMATION
ABS ACTUATOR AND ELECTRIC
UNIT (CONTROL UNIT)
Reference ValueINFOID:000000001](/img/5/57363/w960_57363-483.png "NISSAN NOTE 2016 Service Repair Manual BRC-36
< ECU DIAGNOSIS INFORMATION >[VDC/TCS/ABS]
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
ECU DIAGNOSIS INFORMATION
ABS ACTUATOR AND ELECTRIC
UNIT (CONTROL UNIT)
Reference ValueINFOID:000000001")
BRC-36
< ECU DIAGNOSIS INFORMATION >[VDC/TCS/ABS]
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
ECU DIAGNOSIS INFORMATION
ABS ACTUATOR AND ELECTRIC
UNIT (CONTROL UNIT)
Reference ValueINFOID:0000000012430843
VALUES ON THE DIAGNOSIS TOOL
CAUTION:
The display shows the control unit calculation data, so a normal value might be displayed even in the
event the output circuit (harness) is open or short-circuited.
Monitor item Display content Data monitor
Condition Reference value in
normal operation
FR LH SENSOR Wheel speed 0 [km/h, mph]
Vehicle stopped
Nearly matches the speed meter display
(± 10% or less) Vehicle running
(Note 1)
FR RH SENSOR Wheel speed 0 [km/h, mph]
Vehicle stopped
Nearly matches the speed meter display
(± 10% or less) Vehicle running
(Note 1)
RR LH SENSOR Wheel speed 0 [km/h, mph]
Vehicle stopped
Nearly matches the speed meter display
(± 10% or less) Vehicle running
(Note 1)
RR RH SENSOR Wheel speed 0 [km/h, mph]
Vehicle stopped
Nearly matches the speed meter display
(± 10% or less) Vehicle running
(Note 1)
FR RH IN SOL Operation status of all solenoid valves Actuator (solenoid valve) is active (“AC-
TIVE TEST” with CONSULT) or actuator
relay is inactive (in fail-safe mode)
On
When the actuator (solenoid valve) is not
active and actuator relay is active (igni-
tion switch ON) Off
FR RH OUT SOL Operation status of all solenoid valves Actuator (solenoid valve) is active (“AC-
TIVE TEST” with CONSULT) or actuator
relay is inactive (in fail-safe mode)
On
When the actuator (solenoid valve) is not
active and actuator relay is active (igni-
tion switch ON) Off
FR LH IN SOL Operation status of all solenoid valves Actuator (solenoid valve) is active (“AC-
TIVE TEST” with CONSULT) or actuator
relay is inactive (in fail-safe mode)
On
When the actuator (solenoid valve) is not
active and actuator relay is active (igni-
tion switch ON) Off
FR LH OUT SOL Operation status of all solenoid valves Actuator (solenoid valve) is active (“AC-
TIVE TEST” with CONSULT) or actuator
relay is inactive (in fail-safe mode)
On
When the actuator (solenoid valve) is not
active and actuator relay is active (igni-
tion switch ON) Off
RR RH IN SOL Operation status of all solenoid valves Actuator (solenoid valve) is active (“AC-
TIVE TEST” with CONSULT) or actuator
relay is inactive (in fail-safe mode)
On
When the actuator (solenoid valve) is not
active and actuator relay is active (igni-
tion switch ON) Off
Revision: August 2015
2016 Versa Note
cardiagn.com
Page 485 of 3641
![NISSAN NOTE 2016 Service Repair Manual ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)BRC-37
< ECU DIAGNOSIS INFORMATION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
RR RH OUT SOL Operation status of all solenoid valves Actuator (solen](/img/5/57363/w960_57363-484.png "NISSAN NOTE 2016 Service Repair Manual ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)BRC-37
< ECU DIAGNOSIS INFORMATION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
RR RH OUT SOL Operation status of all solenoid valves Actuator (solen")
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)BRC-37
< ECU DIAGNOSIS INFORMATION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
RR RH OUT SOL Operation status of all solenoid valves Actuator (solenoid valve) is active (“AC-
TIVE TEST” with CONSULT) or actuator
relay is inactive (in fail-safe mode)
On
When the actuator (solenoid valve) is not
active and actuator relay is active (igni-
tion switch ON) Off
RR LH IN SOL Operation status of all solenoid valves Actuator (solenoid valve) is active (“AC-
TIVE TEST” with CONSULT) or actuator
relay is inactive (in fail-safe mode)
On
When the actuator (solenoid valve) is not
active and actuator relay is active (igni-
tion switch ON) Off
RR LH OUT SOL Operation status of all solenoid valves Actuator (solenoid valve) is active (“AC-
TIVE TEST” with CONSULT) or actuator
relay is inactive (in fail-safe mode)
On
When the actuator (solenoid valve) is not
active and actuator relay is active (igni-
tion switch ON) Off
EBD WARN LAMP EBD warning lamp
(Note 2) When EBD warning lamp is ON
On
When EBD warning lamp is OFF Off
STOP LAMP SW Brake pedal operation When brake pedal is depressed
On
When brake pedal is not depressed Off
MOTOR RELAY Motor and motor relay operation When the motor relay and motor are op-
erating
On
When the motor relay and motor are not
operating Off
ACTUATOR RLY Actuator relay operation When the actuator relay is operating
On
When the actuator relay is not operating Off
ABS WARN LAMP ABS warning lamp
(Note 2) When ABS warning lamp is ON
On
When ABS warning lamp is OFF Off
OFF LAMP VDC OFF indicator lamp
(Note 2) When VDC OFF indicator lamp is ON
On
When VDC OFF indicator lamp is OFF Off
OFF SW VDC OFF switch When VDC OFF switch is in ON
On
When VDC OFF switch is in OFF Off
SLIP/VDC LAMP SLIP indicator lamp
(Note 2) When SLIP indicator lamp is ON
On
When SLIP indicator lamp is OFF Off
BATTERY VOLT Battery voltage supplied
to the ABS actuator
and electric unit (control unit) Ignition switch ON
10 – 16 V
GEAR Manual mode gear position determined by
TCM 1st gear
2nd gear
3rd gear
4th gear
5th gear 1
2
3
4
5
SLCT LVR POSI Selector lever position. Vehicle stoppedN/P
ENGINE SPEED With engine runn ingWhen engine running RPM
YAW RATE SEN Yaw rate detected by yaw rate/side G sensor When vehicle stop
Approx. 0 d/s
When vehicle turning -75 to 75 d/s
R POSI SIG Transmission range switch signal ON/OFF
condition CVT shift position = R position
On
CVT shift position = other than R position Off
Monitor item
Display content Data monitor
Condition Reference value in
normal operation
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 486 of 3641
![NISSAN NOTE 2016 Service Repair Manual BRC-38
< ECU DIAGNOSIS INFORMATION >[VDC/TCS/ABS]
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
N POSI SIGTransmission range switch signal ON/OFF
condition CVT shift position = N position
On
CVT shif](/img/5/57363/w960_57363-485.png "NISSAN NOTE 2016 Service Repair Manual BRC-38
< ECU DIAGNOSIS INFORMATION >[VDC/TCS/ABS]
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
N POSI SIGTransmission range switch signal ON/OFF
condition CVT shift position = N position
On
CVT shif")
BRC-38
< ECU DIAGNOSIS INFORMATION >[VDC/TCS/ABS]
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
N POSI SIGTransmission range switch signal ON/OFF
condition CVT shift position = N position
On
CVT shift position = other than N position Off
P POSI SIG Transmission range switch signal ON/OFF
condition CVT shift position = P position
On
CVT shift position = other than P position Off
CV1 ABS actuator cut valve 1 When the cut valve is active
On
When the cut valve is inactive Off
CV2 ABS actuator cut valve 2 When the cut valve is active
On
When the cut valve is inactive Off
SV1 ABS actuator suction valve When the suction valve is active
On
When the suction valve is inactive Off
SV2 ABS actuator suction valve 2 When the suction valve is active
On
When the suction valve is inactive Off
ACCEL POS SIG Throttle actuator opening/closing is dis-
played (linked with accelerator pedal) Accelerator pedal not depressed (ignition
switch is ON)
0 %
Depress accelerator pedal (ignition
switch is ON) 0 - 100 %
SIDE G-SENSOR Transverse G detected by side G sensor Vehicle stopped
Approx. 0 m/s
2
Vehicle turning rightNegative value
(m/s2)
Vehicle turning left Positive value
(m/s
2)
STR ANGLE SIG Steering angle detected by steering angle
sensor Straight-ahead
Approx. 0°
Steering wheel turned –720 to 720°
PRESS SENSOR Brake fluid pressure detected by pressure
sensor With ignition switch turned ON and brake
pedal released
Approx. 0 bar
With ignition switch turned ON and brake
pedal depressed –40 to 300 bar
EBD SIGNAL EBD operation EBD is active
On
EBD is inactive Off
ABS SIGNAL ABS operation ABS is active
On
ABS is inactive Off
TCS SIGNAL TCS operation TCS is active
On
TCS is inactive Off
VDC SIGNAL VDC operation VDC is active
On
VDC is inactive Off
EBD FAIL SIG EBD fail-safe signal In EBD fail-safe
On
EBD is normal Off
ABS FAIL SIG ABS fail-safe signal In ABS fail-safe
On
ABS is normal Off
TCS FAIL SIG TCS fail-safe signal In TCS fail-safe
On
TCS is normal Off
VDC FAIL SIG VDC fail-safe signal In VDC fail-safe
On
VDC is normal Off
Monitor item
Display content Data monitor
Condition Reference value in
normal operation
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 487 of 3641
![NISSAN NOTE 2016 Service Repair Manual ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)BRC-39
< ECU DIAGNOSIS INFORMATION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
Note 1: Confirm tire pressure is normal.
Note 2: On and off timing for](/img/5/57363/w960_57363-486.png "NISSAN NOTE 2016 Service Repair Manual ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)BRC-39
< ECU DIAGNOSIS INFORMATION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
Note 1: Confirm tire pressure is normal.
Note 2: On and off timing for")
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)BRC-39
< ECU DIAGNOSIS INFORMATION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
Note 1: Confirm tire pressure is normal.
Note 2: On and off timing for warning lamps and indicator lamps.
•Refer to BRC-22, "
VDC/TCS/ABS : VDC Function".
•Refer to BRC-24, "
VDC/TCS/ABS : TCS Function".
•Refer to BRC-26, "
VDC/TCS/ABS : ABS Function".
•Refer to BRC-27, "
VDC/TCS/ABS : EBD Function".
Fail-safeINFOID:0000000012430844
VDC AND TCS FUNCTIONS
VDC warning lamp in combination meter turns ON when a malfunction occurs in system [ABS actuator and
electric unit (control unit)]. The control is su spended for VDC and TCS functions. However, ABS and EBD
functions operate normally.
ABS FUNCTION
ABS warning lamp and SLIP indicator lamp in combination meter turn ON when a malfunction occurs in sys-
tem [ABS actuator and electric unit (control unit)]. The control is suspended for VDC, TCS and ABS functions.
However, EBD functions operate normally.
EBD FUNCTION
ABS warning lamp, brake warning lamp and SLIP indicator lamp in combination meter turn ON when a mal-
function occurs in system [ABS actuator and electric unit (control unit)]. The control is suspended for VDC,
TCS, ABS and EBD functions.
CRANKING SIG Crank operation Crank is active
On
Crank is inactive Off
FLUID LEV SW Brake fluid level switch When brake fluid level switch ON
On
When brake fluid level switch OFF Off
Monitor item
Display content Data monitor
Condition Reference value in
normal operation
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 488 of 3641
![NISSAN NOTE 2016 Service Repair Manual BRC-40
< ECU DIAGNOSIS INFORMATION >[VDC/TCS/ABS]
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
DTC
Malfunction detected condition Fail-safe condition
C1101 When an open circuit is detected in rear RH](/img/5/57363/w960_57363-487.png "NISSAN NOTE 2016 Service Repair Manual BRC-40
< ECU DIAGNOSIS INFORMATION >[VDC/TCS/ABS]
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
DTC
Malfunction detected condition Fail-safe condition
C1101 When an open circuit is detected in rear RH")
BRC-40
< ECU DIAGNOSIS INFORMATION >[VDC/TCS/ABS]
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
DTC
Malfunction detected condition Fail-safe condition
C1101 When an open circuit is detected in rear RH wheel sensor circuit.
The following functions are sus-
pended:
•VDC
•ABS
• EBD (only when both rear wheels are malfunctioning)
C1102 When an open circuit is detected in rear LH wheel sensor circuit.
C1103 When an open circuit is detected in front RH wheel sensor circuit.
C1104 When an open circuit is detected in front LH wheel sensor circuit.
C1105
• When a short circuit is detected in rear RH wheel sensor circuit.
• When power supply voltage of rear RH wheel sensor is in following state:
- Rear RH wheel sensor power supply voltage: 7.2 V
≥ Rear RH wheel sensor pow-
er supply voltage
• When distance between rear RH wheel sensor and rear RH wheel sensor rotor is large.
• When installation of rear RH wheel sensor or rear RH wheel sensor rotor is not normal.
C1106 • When a short circuit is detected in rear LH wheel sensor circuit.
• When power supply voltage of rear LH wheel sensor is in following state:
- Rear LH wheel sensor power supply voltage: 7.2 V
≥ Rear LH wheel sensor power
supply voltage
• When distance between rear LH wheel sensor and rear LH wheel sensor rotor is
large.
• When installation of rear LH wheel sensor or rear LH wheel sensor rotor is not nor- mal.
C1107 • When a short circuit is detected in front RH wheel sensor circuit.
• When power supply voltage of front RH wheel sensor is in following state:
- Front RH wheel sensor power supply voltage: 7.2 V
≥ Front RH wheel sensor
power supply voltage
• When distance between front RH wheel sensor and front RH wheel sensor rotor is large.
• When installation of front RH wheel sensor or front RH wheel sensor rotor is not
normal.
C1108 • When a short circuit is detected in front LH wheel sensor circuit.
• When power supply voltage of front LH wheel sensor is in following state:
- Front LH wheel sensor power supply voltage: 7.2 V
≥ Front LH wheel sensor pow-
er supply voltage
• When distance between front LH wheel sensor and front LH wheel sensor rotor is large.
• When installation of front LH wheel sensor or front LH wheel sensor rotor is not normal.
C1109 • When ignition power supply voltage is in following state:
- Ignition power supply voltage: 10 V
≥ Ignition power supply voltage.
- Ignition power supply voltage: 16 V ≤ Ignition power supply voltage. The following functions are sus-
pended:
•VDC
•TCS
•ABS
•EBD
C 111 0
When there is an internal malfunction in the ABS actuator and electric unit (control
unit).
C 1111 W h e n a m a l f u n c t i o n i s d e t e c t e d i n m o t o r o r m o t o r r e l a y. The following functions are sus-
pended:
•VDC
•TCS
•ABS
C 111 5 When difference in wheel speed between any wheel and others is detected when
the vehicle is driven, because of installation of tires other than specified. The following functions are sus-
pended:
•VDC
•TCS
•ABS
•EBD
C1116 When stop lamp switch signal is not input when brake pedal operates. The following functions are sus-
pended:
•VDC
•TCS
Revision: August 2015
2016 Versa Note
cardiagn.com
Page 489 of 3641
![NISSAN NOTE 2016 Service Repair Manual ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)BRC-41
< ECU DIAGNOSIS INFORMATION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
C1120 When a malfunction is detec ted in front LH ABS IN valve.
The fo](/img/5/57363/w960_57363-488.png "NISSAN NOTE 2016 Service Repair Manual ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)BRC-41
< ECU DIAGNOSIS INFORMATION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
C1120 When a malfunction is detec ted in front LH ABS IN valve.
The fo")
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)BRC-41
< ECU DIAGNOSIS INFORMATION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
C1120 When a malfunction is detec ted in front LH ABS IN valve.
The following functions are sus-
pended:
•VDC
•TCS
• ABS
• EBD
C1121 When a malfunction is detected in front LH ABS OUT valve.
C1122 When a malfunction is detected in front RH ABS IN valve.
C1123 When a malfunction is det
ected in front RH ABS OUT valve.
C1124 When a malfunction is detected in rear LH ABS IN valve.
C1125 When a malfunction is detected in rear LH ABS OUT valve.
C1126 When a malfunction is det ected in rear RH ABS IN valve.
C1127 When a malfunction is detected in rear RH ABS OUT valve.
C1130 When a malfunction is detected in ECM system. The following functions are sus-
pended:
•VDC
•TCS
C1140 When a malfunction is detected in actuator relay. The following functions are sus-
pended:
•VDC
•TCS
• ABS
• EBD
C1142 When a malfunction is detected in VDC pressure sensor.
The following functions are sus-
pended:
•VDC
•TCS
C1143 When a malfunction is detected in steering angle sensor.
C1144 When neutral position adjustment of steering angle sensor is not complete.
C1145
When a malfunction is detected in yaw rate signal, or signal line of yaw rate/side/
decel G sensor is open or shorted.
C1146 When a malfunction is detected in side G signal, or signal line of yaw rate/side/decel
G sensor is open or shorted.
C1153 When ABS actuator and electric
unit (control unit) is malfunctioning. (Pressure in-
crease is too much or too little.) The following functions are sus-
pended:
•VDC
•TCS
• ABS
C1154 Transmission
range switch signal or communica tion line between the ABS actuator
and electric unit (control unit) and TCM is open or shorted. The following functions are sus-
pended:
•VDC
•TCS
• ABS
C1155 When brake fluid level low signal is detected. The following functions are sus-
pended:
•VDC
•TCS
C1164 When a malfunction is detected in cut valve 1. The following functions are sus-
pended:
•VDC
•TCS
• ABS
• EBD
C1165 When a malfunction is detected in cut valve 2.
C1166 When a malfunction is detected in suction valve 1.
C1167 When a malfunction is detected in suction valve 2.
C1170 When the informatio
n in ABS actuator and electric unit (control unit) is not the same.The following functions are sus-
pended:
•VDC
•TCS
• ABS
DTC
Malfunction detected condition Fail-safe condition
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 490 of 3641
![NISSAN NOTE 2016 Service Repair Manual BRC-42
< ECU DIAGNOSIS INFORMATION >[VDC/TCS/ABS]
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
DTC Inspection Priority Chart
INFOID:0000000012430845
When multiple DTCs are displayed simultaneously, c](/img/5/57363/w960_57363-489.png "NISSAN NOTE 2016 Service Repair Manual BRC-42
< ECU DIAGNOSIS INFORMATION >[VDC/TCS/ABS]
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
DTC Inspection Priority Chart
INFOID:0000000012430845
When multiple DTCs are displayed simultaneously, c")
BRC-42
< ECU DIAGNOSIS INFORMATION >[VDC/TCS/ABS]
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
DTC Inspection Priority Chart
INFOID:0000000012430845
When multiple DTCs are displayed simultaneously, check each one using the following priority list.
U1000 When CAN communication signal is not continuously transmitted or received for 2
seconds or more.
The following functions are sus-
pended:
•VDC
•TCS
U1002
When ABS actuator and electric unit (control unit) is not transmitting or receiving
CAN communication signal for 2 seconds or less.
U1010 When detecting error during the initial diagnosis of CAN controller of ABS actuator
and electric unit (control unit)
DTC
Malfunction detected condition Fail-safe condition
PriorityDetected item (DTC)
1 • U1000 CAN COMM CIRCUIT
• U1002 SYSTEM COMM(CAN)
• U1010 CAN CONTROLLER CIRCUIT
2 • C1110 CONTROLLER FAILURE
• C1153 EMERGENCY BRAKE
• C1170 VARIANT CODING
3 • C1130 ENGINE SIGNAL 1
• C1144 ST ANG SEN SIGNAL
4 • C1109 BATTERY VOLTAGE [ABNORMAL]
• C 1111 P U M P M O T O R
•C1140 ACTUATOR RLY
5 • C1101 RR RH SENSOR-1
• C1102 RR LH SENSOR-1
• C1103 FR RH SENSOR-1
• C1104 FR LH SENSOR-1
• C1105 RR RH SENSOR-2
• C1106 RR LH SENSOR-2
• C1107 FR RH SENSOR-2
• C1108 FR LH SENSOR-2
• C1115 ABS SENSOR [ABNORMAL SIGNAL]
• C1116 STOP LAMP SW
• C1120 FR LH IN ABS SOL
• C1121 FR LH OUT ABS SOL
• C1122 FR RH IN ABS SOL
• C1123 FR RH OUT ABS SOL
• C1124 RR LH IN ABS SOL
• C1125 RR LH OUT ABS SOL
• C1126 RR RH IN ABS SOL
• C1127 RR RH OUT ABS SOL
• C1142 PRESS SEN CIRCUIT
• C1143 ST ANG SEN CIRCUIT
• C1145 YAW RATE SENSOR
• C1146 SIDE G-SEN CIRCUIT
• C1154 PNP POSI SIG
•C1164 CV1
•C1165 CV2
•C1166 SV1
•C1167 SV2
6 • C1155 BR FLUID LEVEL LOW
Revision: August 2015 2016 Versa Note
cardiagn.com
