NISSAN NOTE 2016 Service Repair Manual

BRC-3
C
DE
G H
I
J
K L
M A
B
BRC
N
O P
Diagnosis Procedure ...........................................
..
128
BRAKE WARNING LAMP ............................. ..129
Component Function Check ................................ ..129
Diagnosis Procedure .............................................129
VDC OFF INDICATOR LAMP ..........................130
Component Function Check ................................ ..130
Diagnosis Procedure .............................................130
SLIP INDICATOR LAMP ..................................131
Component Function Check ................................ ..131
Diagnosis Procedure .............................................131
SYMPTOM DIAGNOSIS ............................132
VDC/TCS/ABS ................................................ ..132
Symptom Table ................................................... ..132
EXCESSIVE ABS FUNCTION OPERATION
FREQUENCY ...................................................
133
Diagnosis Procedure ........................................... ..133
UNEXPECTED PEDAL REACTION ................134
Diagnosis Procedure ........................................... ..134
THE BRAKING DISTANCE IS LONG ..............135
Diagnosis Procedure ........................................... ..135
ABS FUNCTION DOES NOT OPERATE .........136
Diagnosis Procedure ........................................... ..136
PEDAL VIBRATION OR ABS OPERATION
SOUND OCCURS ............................................
137
Diagnosis Procedure ........................................... ..137
VEHICLE JERKS DURING VDC/TCS/ABS
CONTROL ........................................................
138
Diagnosis Procedure ........................................... ..138
NORMAL OPERATING CONDITION .............139
Description ........................................................... ..139
REMOVAL AND INSTALLATION .............140
WHEEL SENSOR ............................................140
FRONT WHEEL SENSOR ..................................... ..140
FRONT WHEEL SENSOR : Exploded View .........140
FRONT WHEEL SENSOR : Removal and Instal-
lation ......................................................................
140
REAR WHEEL SENSOR ....................................... ..141
REAR WHEEL SENSOR : Exploded View ............141
REAR WHEEL SENSOR : Removal and Installa-
tion .........................................................................
141
SENSOR ROTOR ............................................143
FRONT SENSOR ROTOR ..................................... ..143
FRONT SENSOR ROTOR : Removal and Instal-
lation ......................................................................
143
REAR SENSOR ROTOR ....................................... ..143
REAR SENSOR ROTOR : Removal and Installa-
tion .........................................................................
143
ABS ACTUATOR AND ELECTRIC UNIT
(CONTROL UNIT) ...........................................
144
Exploded View .......................................................144
Removal and Installation .......................................144
VDC OFF SWITCH ..........................................146
Removal and Installation .......................................146
STEERING ANGLE SENSOR .........................147
Exploded View .......................................................147
Removal and Installation .......................................147
Revision: August 2015 2016 Versa Note

cardiagn.com

BRC-4
< PRECAUTION >[VDC/TCS/ABS]
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint Syst
em (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000012430820
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SR and SB section of
this Service Manual.
WARNING:
• To avoid rendering the SRS inopera tive, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintent ional activation of the system. For re moval of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipmen t on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harn esses can be identified by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or electri c power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers , always switch the Ignition OFF, disconnect the
battery and wait at least three minutes before performing any service.
Precaution for Brake SystemINFOID:0000000012430821
WARNING:
Clean any dust from the front brake and rear brake using a vacuum dust collector. Do not blow by
compressed air.
• Brake fluid use refer to MA-11, "
Fluids and Lubricants".
• Do not reuse drained brake fluid.
• Do not spill or splash brake fluid on painted surfaces. Brake fluid may seriously damage paint. Wipe it off
immediately and wash with water if it gets on a painted surface.
• Always confirm the specified tightening torque when installing the brake pipes.
• After pressing the brake pedal more deeply or harder t han normal driving, such as air bleeding, check each
item of brake pedal. Adjust brake pedal if it is outside the standard value.
• Do not use mineral oils such as gasoline or light oil to clean. They may damage rubber parts and cause
improper operation.
• Always loosen the brake tube flare nut with a flare nut wrench.
• Tighten the brake tube flare nut to the specified torque with a crow-
foot (A) and torque wrench (B).
• Always connect the battery terminal when moving the vehicle.
• Turn the ignition switch OFF and disconnect the ABS actuator and electric unit (control unit) harness connector or the battery negative
terminal before performing the work.
• Check that no brake fluid leakage is present after replacing the parts.
JPFIA0001ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

PRECAUTIONSBRC-5
< PRECAUTION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
Precaution for Brake Control SystemINFOID:0000000012430822
• Just after starting vehicle after ignition switch is ON, brake pedal may vibrate or motor operating noise may be heard from engine compartment. This is a normal condition.
• When an error is indicated by ABS or another warning lamp, collect all necessary information from customer
(what symptoms are present under what conditions) and check for simple causes before starting diagnostic
servicing. Besides electrical system inspection, c heck brake booster operation, brake fluid level and oil
leaks.
• If tire size and type are used in an improper combinati on or brake pads are not Genuine NISSAN parts, stop-
ping distance or steering stability may deteriorate.
• ABS might be out of order or malfunctions by putting a radio (wiring inclusive), an antenna and a lead-in wire
near the control unit.
• If aftermarket parts (car stereo, CD player, etc.) have been installed, check for incidents such as harness pinches, open circuits, and improper wiring.
• VDC system may not operate normally or a VDC OFF indi cator lamp or SLIP indicator lamp may light.
- When replacing the following parts with parts other than genuine parts or making modifications: Suspension- related parts (shock absorber, spring, bushing, etc.), tire s, wheels (other than specified sizes), brake-related
parts (pad, rotor, caliper, etc.), engine-related parts (muffler, ECM, etc.) and body reinforcement-related parts
(roll bar, tower bar, etc.).
- When driving with worn or deteriorated suspension, tires and brake-related parts.
Precaution for Harness RepairINFOID:0000000012430823
• Solder the repair part, and wrap it with tape. [Twisted wire fray
must be 110 mm (4.33 in) or less.]
• Do not bypass the repair point with wire. (If it is bypassed, the turn- out point cannot be separated and the twisted wire characteristics
are lost.)
SKIB8766E
SKIB8767E
Revision: August 2015 2016 Versa Note

cardiagn.com

BRC-6
< PREPARATION >[VDC/TCS/ABS]
PREPARATION
PREPARATION
PREPARATION
Special Service ToolINFOID:0000000012430824
The actual shape of the tools may differ from those illustrated here.
Commercial Service ToolINFOID:0000000012430825
Tool number
(TechMate No.)
Tool nameDescription
KV991J0080
(J-45741)
ABS active wheel sensor tester Checking operation of ABS active wheel sen-
sors
WFIA0101E
Tool name
Description
1. Flare nut crowfoot
2. Torque wrench Tightening brake tube flare nuts

a: 10mm (0.39 in)/12mm (0.47 in)
Power Tool Loosening nuts, screws and bolts
S-NT360
PIIB1407E
Revision: August 2015 2016 Versa Note

cardiagn.com

COMPONENT PARTSBRC-7
< SYSTEM DESCRIPTION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
SYSTEM DESCRIPTION
COMPONENT PARTS
Component Parts LocationINFOID:0000000012430826
AWFIA1210ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

BRC-8
< SYSTEM DESCRIPTION >[VDC/TCS/ABS]
COMPONENT PARTS
Component Description
INFOID:0000000012430827
ABS Actuator and Electric Unit (Control Unit)INFOID:0000000012430828
Electric unit (control unit) is integrated with actuator and comprehensively controls VDC function, TCS func-
tion, ABS function and EBD function.
ELECTRIC UNIT (CONTROL UNIT)
• Brake fluid pressure is controlled according to signals from each sensor.
• If malfunction is detected, the system enters fail-safe mode.
ACTUATOR
The following components are integrated with ABS actuator:
Pump
Returns the brake fluid reserved in reservoir to master cylinder by reducing pressure.
Motor
Activates the pump according to signals from ABS actuator and electric unit (control unit).
Motor Relay
Operates the motor ON/OFF according to signals fr om ABS actuator and electric unit (control unit).
Actuator Relay (Main Relay)
Operates each valve ON/OFF according to signals fr om ABS actuator and electric unit (control unit).
ABS IN Valve
A. View with steering wheel and spiral
cable removed B. Left side of instrument panel C. Left side of engine compartment
D. Left side of engine compartment E. Right side of engine compartment F. Left front wheel assembly
G. Near brake pedal area H. Left side of instrument panel I. Center of front seats (view with cen-
ter console removed)
J. Left rear wheel assembly
ALFIA0482ZZ
Component Reference/Function
1 Steering angle sensor BRC-9, "
Steering Angle Sensor"
2 VDC OFF switchBRC-10, "VDC OFF Switch"
3 IPDM E/RPCS-4, "Component Parts Location"
4 Brake fluid level switchBRC-10, "Brake Fluid Level Switch"
5 ABS actuator and electric unit (control unit)BRC-8, "ABS Actuator and Electric Unit (Control Unit)"
6 Front wheel sensorBRC-9, "Wheel Sensor and Sensor Rotor"
7 Stop lamp switchBRC-9, "Sto p La mp Sw itc h"
8 Combination meter (type A)MWI-9, "METER SYSTEM : Combination Meter"
9 Combination meter (type B)MWI-9, "METER SYSTEM : Combination Meter"
10 Parking brake switch BRC-10, "Parking Brake Switch"
11. Rear wheel sensor BRC-9, "Wheel Sensor and Sensor Rotor"
Revision: August 2015 2016 Versa Note

cardiagn.com

COMPONENT PARTSBRC-9
< SYSTEM DESCRIPTION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
Switches the fluid pressure line to increase or hold according to signals from control unit.
ABS OUT Valve
Switches the fluid pressure line to increase, hold or decrease according to signals from control unit.
Cut Valve 1, Cut Valve 2
Shuts off the ordinary brake line from master cylinder, when VDC function and TCS function are activated.
Suction Valve 1, Suction Valve 2
Supplies the brake fluid from master cylinder to the pump, when VDC function and TCS function are activated.
Return Check Valve
Returns the brake fluid from brake caliper and wheel cyli nder to master cylinder by bypassing orifice of each
valve when brake is released.
Reservoir
Temporarily reserves the brake fluid drained from brake caliper, so that pressure efficiently decreases when
decreasing pressure of brake caliper and wheel cylinder.
Yaw rate/side/decel G sensor
Calculates the following information that affects the v ehicle, and transmits a signal to ABS actuator and elec-
tric unit (control unit) via communication lines:
• Vehicle rotation angular velocity (yaw rate signal)
• Vehicle lateral acceleration (side G signal) and longitudinal acceleration (decel G signal)
Pressure Sensor
Detects the brake fluid pressure and transmits signal to ABS actuator and electric unit (control unit).
Wheel Sensor and Sensor RotorINFOID:0000000012430829
NOTE:
• Wheel sensor of front wheel is installed on steering knuckle.
• Sensor rotor of front wheel is integrated in wheel hub assembly.
• Wheel sensor of rear wheel is installed on back plate of rear brake.
• Sensor rotor of rear wheel is installed on rear brake drum.
• Never measure resistance and voltage value using a tester because sensor is active sensor.
• Downsize and weight reduction is aimed. IC for detection portion
and magnet for sensor rotor are adopted.
• Power supply is supplied to detection portion so that magnetic field
line is read. Magnetic field that is detected is converted to current
signal.
• When sensor rotor rotates, magnetic field changes. Magnetic field
change is converted to current signals (rectangular wave) and is
transmitted to ABS actuator and electric unit (control unit). Change
of magnetic field is pr oportional to wheel speed.
Stop Lamp SwitchINFOID:0000000012430830
Detects the operation status of brake pedal and transmits converted electric signal to ABS actuator and elec-
tric unit (control unit).
Steering Angle SensorINFOID:0000000012430831
Detects the following information and transmits steering angle signal to ABS actuator and electric unit (control
unit) via CAN communication:
• Steering wheel rotation amount
• Steering wheel rotation angular velocity
• Steering wheel rotation direction
JPFIC0131GB
Revision: August 2015 2016 Versa Note

cardiagn.com

BRC-10
< SYSTEM DESCRIPTION >[VDC/TCS/ABS]
COMPONENT PARTS
VDC OFF Switch
INFOID:0000000012430832
• Non-operational status or standby status of VDC and TCS functions can be selected using VDC OFF switch.
VDC OFF indicator lamp indicates the operation stat us of function. (ON: Non-operational status, OFF:
Standby status)
• VDC OFF indicator lamp turns OFF (standby status) when the engine is started again after it is stopped once
while VDC OFF indicator lamp is ON (non-operational status).
Brake Fluid Level SwitchINFOID:0000000012430833
Detects the brake fluid level in reservoir tank and transmi ts converted electric signal from combination meter to
ABS actuator and electric unit (control unit) via CAN communication.
Parking Brake SwitchINFOID:0000000012430834
Detects the operation status of parking brake switch and transmits converted electric signal from combination
meter to ABS actuator and electric unit (control unit) via CAN communication.
Revision: August 2015 2016 Versa Note

cardiagn.com

SYSTEMBRC-11
< SYSTEM DESCRIPTION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
SYSTEM
VDC/TCS/ABS
VDC/TCS/ABS : System DiagramINFOID:0000000012430835
VDC/TCS/ABS : Syst em DescriptionINFOID:0000000012430836
• The system switches fluid pressure of each brake caliper and each wheel cylinder to increase, to hold, or to
decrease according to signals from control unit in ABS actuator and electric unit (control unit). This control
system is applied to VDC, TCS, ABS and EBD functions.
• Fail-safe function is available for each function and is activated by each function when system malfunction
occurs.
INPUT SIGNAL AND OUTPUT SIGNAL
Major signal transmission between each unit via communication lines is shown in the following table.
ALFIA0331GB
Revision: August 2015 2016 Versa Note

cardiagn.com

BRC-12
< SYSTEM DESCRIPTION >[VDC/TCS/ABS]
SYSTEM
VALVE OPERATION (VDC AND TCS FUNCTIONS)
The control unit built in the ABS actuator and electric unit (control unit) controls fluid pressure of the brake cal-
ipers by operating each valve.
VDC and TCS Functions are Operating (Pressure Increases)
Component
Signal description
Steering angle sensor Transmits the steering angle sensor signal to ABS actuator and electric unit (control unit) via
CAN communication.
ECM Transmits the following signals to ABS actuator and electric unit (control unit) via CAN commu-
nication:
• Accelerator pedal position signal
• Engine speed signal
• Target throttle position signal
TCM Transmits the current gear position signal to ABS actuator and electric unit (control unit) via
CAN communication.
Combination meter Transmits the following signals to ABS actuator and electric unit (control unit) via CAN commu-
nication:
• Brake fluid level switch signal
• Parking brake switch signal
Receives the following signals fr
om ABS actuator and electric un it (control unit) via CAN com-
munication:
• ABS warning lamp signal
• Brake warning lamp signal
• VDC OFF indicator lamp signal
• SLIP indicator lamp signal
JSFIA0670GB
Name Not activated Pressure increases
Cut valve 1 Power supply is not supplied (open) Power supply is supplied (close)
Cut valve 2 Power supply is not supplied (open) Power supply is supplied (close)
Suction valve 1 Power supply is not supplied (close) Power supply is supplied (open)
Suction valve 2 Power supply is not supplied (close) Power supply is supplied (open)
ABS IN valve Power supply is not supplied (open) Power supply is not supplied (open)
Revision: August 2015 2016 Versa Note

cardiagn.com
