NISSAN NOTE 2016 Service Repair Manual

DEF-30
< SYMPTOM DIAGNOSIS >
REAR WINDOW DEFOGGER AND DOOR MIRROR DEFOGGER DO NOT OPER-
ATE.
SYMPTOM DIAGNOSIS
REAR WINDOW DEFOGGER AND DOOR MIRROR DEFOGGER DO NOT
OPERATE.
Diagnosis ProcedureINFOID:0000000012431783
1. CHECK REAR WINDOW DEFOGGER SWITCH
Check rear window defogger switch.
Refer to DEF-20, "
Component Function Check".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning parts.
2. CHECK REAR WINDOW DEFOGGER RELAY
Check rear window defogger relay.
Refer to DEF-22, "
Component Function Check".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace the malfunctioning parts.
3. CHECK REAR WINDOW DEFOGGER POWER SUPPLY AND GROUND CIRCUIT
Check rear window defogger power supply and ground circuit.
Refer to DEF-24, "
Component Function Check".
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-42, "Intermittent Incident".
NO >> Repair or replace the malfunctioning parts.
Revision: August 2015 2016 Versa Note

cardiagn.com

REAR WINDOW DEFOGGER DOES NOT OPERATE BUT BOTH OF DOOR MIR-
ROR DEFOGGER OPERATE.
DEF-31
< SYMPTOM DIAGNOSIS >
C
DE
F
G H
I
J
K
M A
B
DEF
N
O P
REAR WINDOW DEFOGGER DOES NOT OPERATE BUT BOTH OF DOOR
MIRROR DEFOGGER OPERATE.
Diagnosis ProcedureINFOID:0000000012431784
1. CHECK REAR WINDOW DEFOGGER POWER SUPPLY AND GROUND CIRCUIT
Check rear window defogger power supply and ground circuit.
Refer to DEF-24, "
Component Function Check".
Is the inspection result normal?
YES >> Refer to GI-42, "Intermittent Incident".
NO >> Repair or replace the malfunctioning parts.
Revision: August 2015 2016 Versa Note

cardiagn.com

DEF-32
< SYMPTOM DIAGNOSIS >
BOTH DOORS MIRROR DEFOGGER DON’T OPERATE BUT REAR WINDOW
DEFOGGER OPERATES
BOTH DOORS MIRROR DEFOGGER DON’T OPERATE BUT REAR WIN-
DOW DEFOGGER OPERATES
Diagnosis ProcedureINFOID:0000000012431785
1. CHECK DOOR MIRROR DEFOGGER FUSE
Check if the following fuse in fuse block (J/B) is blown.
Is the inspection result normal?
YES >> GO TO 2.
NO >> If fuse is blown, be sure to eliminate cause of malfunction before installing new fuse.
2. CHECK BOTH DOOR MIRROR DEFOGGER
1. Check door mirror LH. Refer to DEF-26, "
Component Function Check".
2. Check door mirror RH. Refer to DEF-28, "
Component Function Check".
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-42, "Intermittent Incident".
NO >> Repair or replace the malfunctioning parts.
COMPONENT PARTS AMPEREFUSE NO.
Fuse block (J/B) 10A1
Revision: August 2015 2016 Versa Note

cardiagn.com

DRIVER SIDE DOOR MIRROR DEFOGGER DOES NOT OPERATE.DEF-33
< SYMPTOM DIAGNOSIS >
C
DE
F
G H
I
J
K
M A
B
DEF
N
O P
DRIVER SIDE DOOR MIRROR DEFOGGER DOES NOT OPERATE.
Diagnosis ProcedureINFOID:0000000012431786
1. CHECK DOOR MIRROR DEFOGGER LH
Check door mirror defogger LH.
Refer to DEF-26, "
Component Function Check".
Is the inspection result normal?
YES >> Refer to GI-42, "Intermittent Incident".
NO >> Repair or replace the malfunctioning parts.
Revision: August 2015 2016 Versa Note

cardiagn.com

DEF-34
< SYMPTOM DIAGNOSIS >
PASSENGER SIDE DOOR MIRROR DEFOGGER DOES NOT OPERATE.
PASSENGER SIDE DOOR MIRROR DEFOGGER DOES NOT OPERATE.
Diagnosis ProcedureINFOID:0000000012431787
1. CHECK DOOR MIRROR DEFOGGER RH
Check door mirror defogger RH.
Refer to DEF-28, "
Component Function Check".
Is the inspection result normal?
YES >> Refer to GI-42, "Intermittent Incident".
NO >> Repair or replace the malfunctioning parts.
Revision: August 2015 2016 Versa Note

cardiagn.com

REAR WINDOW DEFOGGER SWITCH DOES NOT LIGHT, BUT REAR WINDOW
DEFOGGER OPERATES
DEF-35
< SYMPTOM DIAGNOSIS >
C
DE
F
G H
I
J
K
M A
B
DEF
N
O P
REAR WINDOW DEFOGGER SWITCH DOES NOT LIGHT, BUT REAR WIN-
DOW DEFOGGER OPERATES
Diagnosis ProcedureINFOID:0000000012431788
1. CHECK FRONT AIR CONTROL (R EAR WINDOW DEFOGGER SWITCH)
Check that the front air control (rear window defogger switch) is operating normally.
Is the inspection result normal?
YES >> Refer to GI-42, "Intermittent Incident".
NO >> Refer to DEF-20, "
Diagnosis Procedure".
Revision: August 2015 2016 Versa Note

cardiagn.com

DEF-36
< REMOVAL AND INSTALLATION >
FILAMENT
REMOVAL AND INSTALLATION
FILAMENT
Inspection and RepairINFOID:0000000012431789
INSPECTION
1. When measuring voltage, wrap tin foil around the top of the neg-ative probe. Then press the foil against the wire with your finger.
2. Attach probe circuit tester (in Volt range) to middle portion of each filament.
3. If a filament is burned out, circuit tester registers 0 or battery voltage.
4. To locate burned out point, move probe to left and right along fil- ament. Test needle will swing abruptly when probe passes the
point.
REPAIR
REPAIR EQUIPMENT
• Conductive silver composition (Dupont No. 4817 or equivalent)
SEL122R
SEL263
SEL265
Revision: August 2015 2016 Versa Note

cardiagn.com

FILAMENTDEF-37
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
K
M A
B
DEF
N
O P
• Ruler 30 cm (11.8 in) long
• Drawing pen
• Heat gun
• Alcohol
• Cloth
REPAIRING PROCEDURE
1. Wipe broken heat wire and its surrounding area clean with a cloth dampened in alcohol.
2. Apply a small amount of conductive silver composition to tip of drawing pen.
NOTE:
Shake silver composition container before use.
3. Place ruler on glass along broken line. Deposit conductive silver composition on break with drawing pen. Slightly overlap existing
heat wire on both sides [preferably 5 mm (0.20 in)] of the break.
4. After repair has been completed, check repaired wire for conti- nuity. This check should be conducted 10 minutes after silver
composition is deposited.
CAUTION:
Do not touch repaired area wh ile test is being conducted.
5. Apply a constant stream of hot air directly to the repaired area for approximately 20 minutes with a heat gun. A minimum dis-
tance of 3 cm (1.2 in) should be kept between repaired area and
hot air outlet.
NOTE:
If a heat gun is not available, let the repaired area dry for 24
hours.
PIIA0215E
SEL012D
SEL013D
Revision: August 2015 2016 Versa Note

cardiagn.com

DEF-38
< REMOVAL AND INSTALLATION >
CONDENSER
CONDENSER
Removal and InstallationINFOID:0000000012431790
REMOVAL
1. Remove back door inner finisher. Refer to INT-36, "BACK DOOR INNER FINISHER : Removal and Instal-
lation".
2. Disconnect the harness connectors (B), from the condenser (1). : Front
3. Remove the condenser bolt (A) and the condenser (1).
INSTALLATION
Installation is in the reverse order of removal.
ALLIA1295ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com
