NISSAN NOTE 2016 Service Repair Manual

DLK-12
< PREPARATION >[WITH INTELLIGENT KEY SYSTEM]
PREPARATION
Commercial Service Tools
INFOID:0000000012429964
KV48105501
(J-45295-A)
Transmitter Activation Tool • Activate TPMS transmitter IDs
• Compatible with future sensors
• Equipped with a display (KV48105501
only)
—
(J-46534)
Trim Tool Set Removing trim components
Tool number
(TechMate No.)
Tool name
Description
ALEIA0183ZZ
AWJIA0483ZZ
(TechMate No.)
Tool name
Description
(J-39565)
Engine Ear Locating the noise
(—)
Power Tool Loosening nuts, screws and bolts
SIIA0995E
PIIB1407E
Revision: August 2015
2016 Versa Note

cardiagn.com

COMPONENT PARTSDLK-13
< SYSTEM DESCRIPTION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
SYSTEM DESCRIPTION
COMPONENT PARTS
INTELLIGENT KEY SYSTEM
INTELLIGENT KEY SYSTEM : Component Parts LocationINFOID:0000000012429965
ALKIA3191ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

DLK-14
< SYSTEM DESCRIPTION >[WITH INTELLIGENT KEY SYSTEM]
COMPONENT PARTS
A. View with instrument panel assembly
removed B. View with glove box door removed C. View with front grille removed
D. View of LH door (RH similar) E. View of LH door switch (RH similar) F. View with rear bumper cover re- moved
G. View from rear of vehicle H. View with rear seat cushion removed I. View with center console removed
No. Component Function
1. Combination meter Combination meter transmits the vehicle speed sig-
nal to BCM via CAN communication.
BCM also receives the vehicle speed signal from
ABS actuator and electric uni
t (control unit) via CAN
communication. BCM compares both signals to de-
tect the vehicle speed.
Security indicator lamp is located on combination
meter.
Security indicator lamp blinks when ignition switch
is in any position other than ON to warn that NIS-
SAN VEHICLE IMMOBILIZER SYSTEM-NATS
[NVIS (NATS)] is on board.
Refer to MWI-59, "
METER SYSTEM : Combination
Meter".
2. Push-button ignition switch Push-button ignition switch has push switch inside
which detects that push-button ignition switch is
pressed, and then transmits ON/OFF signal to
BCM. BCM changes the ignition switch position with
the operation of push-button ignition switch. BCM
maintains the ignition switch position status while
push-button ignition switch is not operated.
3. BCM BCM controls INTELLIGENT KEY SYSTEM (EN-
GINE START FUNCTION), NISSAN VEHICLE IM-
MOBILIZER SYSTEM-NATS [NVIS (NATS)] and
VEHICLE SECURITY SYSTEM.
BCM performs the ID verification between BCM and
Intelligent Key when the Intelligent Key is carried
into the detection area of inside key antenna, and
push-button ignition switch is pressed. If the ID ver-
ification result is OK, ignition switch operation is
available.
Then, when the ignition switch is turned ON, BCM
performs ID verification between BCM and ECM. If
the ID verification result is OK, ECM can start en-
gine.
Refer to BCS-6, "
BODY CONTROL SYSTEM :
Component Parts Location" for detailed installation
location.
4. Main power window and door lock/unlock switch Door lock and unlock switch is integrated into the
main power window and door lock/unlock switch.
Door lock and unlock switch transmits door lock/un-
lock operation signal to BCM.
Refer to PWC-7, "
Main Power Window And Door
Lock/Unlock Switch".
5. Front door lock assembly LH Door key cylinder switch is integrated into front door
lock assembly (driver side).
Door key cylinder switch detects door LOCK/UN-
LOCK operation using mechanical key, and then
transmits the operation signal to BCM.
Refer to DLK-17, "
INTELLIGENT KEY SYSTEM :
Front Door Lock Asse
mbly (Driver Side)".
6. Rear door lock actuator LH Rear door lock actuator locks/unlocks the rear door
latch assembly.
Revision: August 2015
2016 Versa Note

cardiagn.com

COMPONENT PARTSDLK-15
< SYSTEM DESCRIPTION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
INTELLIGENT KEY SYSTEM : Inside Key Antenna (Instrument Center)INFOID:0000000012429966
• Inside key antenna (instrument center) detects that Intelligent Key
is within the inside detection area, and then transmits detection
status to BCM.
• Inside key antenna (instrument center) is installed in the rear of cluster lid C of instrument center.
7. Back door lock actuator Back door lock actuator locks/unlocks the back door
latch assembly.
8. Inside key antenna (instrument center) Inside key antenna (instrument center) detects
whether Intelligent Key is inside the vehicle or not,
and then transmits the signal to the BCM.
Refer to
DLK-15, "
INTELLIGENT KEY SYSTEM :
Inside Key Antenna (Instrument Center)".
9. Remote keyless entry receiver Remote keyless entry receiver receives button op-
eration signal and key ID signal of Intelligent Key,
and them transmits them to the BCM.
Refer to
DLK-17, "
INTELLIGENT KEY SYSTEM :
Remote Keyless Entry Receiver".
10. Intelligent Key warning buzzer Intelligent Key warning buzzer warns the user, who
is outside the vehicle, of operation confirmation ac-
cording to Intelligent Key operation and door re-
quest switch operation, or of an inappropriate
operation.
Refer to
DLK-17, "
INTELLIGENT KEY SYSTEM :
Intelligent Key Warning Buzzer".
11. Outside key antenna LH Outside key antenna (LH) detects whether Intelli-
gent Key is outside the vehicle or not, and then
transmits the signal to the BCM.
Refer to
DLK-16, "
INTELLIGENT KEY SYSTEM :
Outside Key Antenna (Driver Side)".
12. Door request switch Door request switch transmits door lock/unlock re-
quest signal to the BCM.
13. Door switch Door switch detects door open/close condition and
then transmits ON/OFF signal to BCM.
14. Outside key antenna (rear bumper) Outside key antenna (Rear bumper) detects wheth-
er Intelligent Key is outside the vehicle or not, and
then transmits the signal to the BCM.
Refer to
DLK-16, "
INTELLIGENT KEY SYSTEM :
Outside Key Antenna (Rear Bumper)".
15. Back door request switch Back door request switch transmits door lock/unlock
request signal to the BCM.
16. Inside key antenna (trunk room) Inside key antenna (trunk room) detects whether In-
telligent Key is inside the vehicle or not, and then
transmits the signal to the BCM.
Refer to
DLK-16, "
INTELLIGENT KEY SYSTEM :
Inside Key Antenna (Trunk Room)".
17. Inside key antenna (console) Inside key antenna (console) detects whether Intel-
ligent Key is inside the vehicle or not, and then
transmits the signal to the BCM.
Refer to
DLK-16, "
INTELLIGENT KEY SYSTEM :
Inside Key Antenna (Console)".
No.
Component Function
JMKIA8646ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

DLK-16
< SYSTEM DESCRIPTION >[WITH INTELLIGENT KEY SYSTEM]
COMPONENT PARTS
INTELLIGENT KEY SYSTEM : In side Key Antenna (Console)
INFOID:0000000012429967
• Inside key antenna (console) detects that Intelligent Key is within
the inside detection area, and then transmits detection status to
BCM.
• Inside key antenna (console) is installed underneath the center console.
INTELLIGENT KEY SYSTEM : Insi de Key Antenna (Trunk Room)INFOID:0000000012429968
• Inside key antenna (trunk room) detects that Intelligent Key is
within the inside detection area, and then transmits detection sta-
tus to BCM.
• Inside key antenna (trunk room) is installed under the rear seat cushion.
INTELLIGENT KEY SYSTEM : Outs ide Key Antenna (Rear Bumper)INFOID:0000000012429969
• Outside key antenna (rear bumper) detects that Intelligent Key is
within the outside detection area, and then transmits detection sta-
tus to BCM. Request signal is transmitted simultaneously to Intelli-
gent Key.
• Outside key antenna (rear bumper) is installed in the rear of rear bumper.
INTELLIGENT KEY SYSTEM : Ou tside Key Antenna (Driver Side)INFOID:0000000012429970
• Outside key antenna LH detects that Intelligent Key is within the
outside detection area, and then transmits detection status to
BCM. Request signal is transmitted simultaneously to Intelligent
Key.
• Outside key antenna LH is installed in front outside handle LH.
JMKIA8646ZZ
JMKIA8646ZZ
JMKIA8646ZZ
JMKIA8648ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

COMPONENT PARTSDLK-17
< SYSTEM DESCRIPTION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
INTELLIGENT KEY SYSTEM : Outsi de Key Antenna (Passenger Side)INFOID:0000000012429971
• Outside key antenna RH detects that Intelligent Key is within the
outside detection area, and then transmits detection status to
BCM. Request signal is transmitted simultaneously to Intelligent
Key.
• Outside key antenna RH is installed in front outside handle RH.
INTELLIGENT KEY SYSTEM : Front Do or Lock Assembly (Driver Side)INFOID:0000000012429972
• Door lock actuator and unlock sensor are Integrated in front door
lock assembly LH.
• Door lock actuator receives lock/unlock signal from BCM, and then
locks/unlocks driver door.
• Only front door lock assembly LH integrates unlock sensor. Unlock sensor transmits lock/unlock status of LH door to BCM.
INTELLIGENT KEY SYSTEM : Remote Keyless Entry ReceiverINFOID:0000000012429973
• Remote keyless entry receiver receives button operation signal
and key ID signal of Intelligent Key, and then transmits them to
BCM.
• Remote keyless entry receiver is installed in the rear of glove box
lid.
INTELLIGENT KEY SYSTEM : Intelligent Key Warning BuzzerINFOID:0000000012429974
• Intelligent Key warning buzzer warns the user, who is outside vehi-cle, of operation confirmation according to Intelligent Key operation
and door request switch operation, or of an inappropriate opera-
tion.
• Intelligent Key warning buzzer is installed in the rear of front bumper and behind LH headlight.
JMKIA8648ZZ
JMKIA8649ZZ
JMKIA8647ZZ
JMKIA8650ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

DLK-18
< SYSTEM DESCRIPTION >[WITH INTELLIGENT KEY SYSTEM]
COMPONENT PARTS
INTELLIGENT KEY SYSTEM : Back Door Lock Assembly
INFOID:0000000012429975
• Back door lock assembly integrates door lock actuator and back door latch.
• Door lock actuator locks/unlocks the back door according to the
door lock/unlock signal from BCM.
INTELLIGENT KEY SYSTEM : Door Lock and Unlock SwitchINFOID:0000000012429976
• Door lock and unlock switch transmits door lock/unlock signaloperation to BCM.
• Door lock and unlock switch is integrated in the main power win-
dow and door lock/unlock switch and power window and door lock/
unlock switch RH.
INTELLIGENT KEY SYSTEM : Front Door Request Switch (Driver Side)INFOID:0000000012429977
• Front door request switch LH transmits door request switch signalto BCM.
• Front door request switch (LH) (1) is integrated in front outside handle LH.
INTELLIGENT KEY SYSTEM : Front Door Request Switch (Passenger Side)
INFOID:0000000012429978
• Front door request switch RH transmits door request switch signal
to BCM.
• Front door request switch RH (1) is integrated in front outside han-
dle RH.
JMKIA8651ZZ
ALKIA3203ZZ
JMKIA9353ZZ
JMKIA9353ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

COMPONENT PARTSDLK-19
< SYSTEM DESCRIPTION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
INTELLIGENT KEY SYSTEM : Door SwitchINFOID:0000000012429979
Door switch detects open/close status of door and transmits door
switch signal to BCM.
INTELLIGENT KEY SYSTEM : Back Door Request SwitchINFOID:0000000012429980
• Back door request switch transmits back door request switch sig- nal to BCM.
• Back door request switch (1) is integrated in outside handle (back
door).
JMKIA6526ZZ
ALKIA3192ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

DLK-20
< SYSTEM DESCRIPTION >[WITH INTELLIGENT KEY SYSTEM]
SYSTEM (POWER DOOR LOCK SYSTEM)
SYSTEM (POWER DOOR LOCK SYSTEM)
System DiagramINFOID:0000000012429981
System DescriptionINFOID:0000000012429982
DOOR LOCK FUNCTION
• The door lock and unlock switch LH is built into the main power window and door lock/unlock switch.
• The door lock and unlock switch RH is built into
the power window and door lock/unlock switch RH.
• Interlocked with the locking operation of door lock and unlock switch, door lock actuators of all doors are
locked.
• Interlocked with the unlocking operation of door lock and unlock switch, door lock actuators of all doors are
unlocked.
Door Key Cylinder
• With the door key inserted in the door key cylinder on driver side, turning it to “LOCK”, will lock door lock actuator of all doors.
• With the door key inserted in the door key cylinder on driver side, turning it to “UNLOCK” onc\
e unlocks the driver side door lock actuator; turning it to “UNLOCK” again within 60 seconds after the first unlock operation
unlocks all of the other doors. - (SELECTIVE UNLOCK OPERATION)
Selective unlock operation mode can be changed using “A UTO LOCK SET” in “Work support”. Refer to BCS-
18, "DOOR LOCK : CONSULT Function (BCM - DOOR LOCK)".
AUTOMATIC DOOR LOCKS (LOCK OPERATION)
The automatic door locks function is the function that locks all doors linked with the vehicle speed or shift posi-
tion.
Vehicle Speed Sensing Auto Door Lock*1
All doors are locked when the vehicle speed reaches 24 km/h (15 MPH) or more.
BCM outputs the lock signal to all door lock actuators when it detects that the ignition switch is turned ON, all
doors are closed and the vehicle speed received from the combination meter via CAN communication
becomes 24 km/h (15 MPH) or more.
If a door is opened and closed at any time during one ignition cycle (OFF → ON), even after initial auto door
lock operation has taken place, the BCM will relock al l doors when the vehicle speed reaches 24 km/h (15
MPH) or more again.
ALKIA2288GB
Input SingleFunction Actuator
Door lock/unlock switch Door lock/unlock signal Door lock function
• Each door lock actuator
Door key cylinder switch
Each door switch
Door open/close signal
Key reminder function
Combination meter Warning buzzer signal
Vehicle speed signal
Automatic door lock/unlock
function
Revision: August 2015
2016 Versa Note

cardiagn.com

SYSTEM (POWER DOOR LOCK SYSTEM)DLK-21
< SYSTEM DESCRIPTION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
Setting change of Automatic Door Locks (LOCK) Function
The LOCK operation setting of the aut
omatic door locks function can be changed.
With CONSULT
The ON/OFF switching of the automatic door locks (LOCK) function and the type selection of the automatic
door locks (LOCK) function can be performed at the “Work support” setting. Refer to BCS-18, "
DOOR LOCK :
CONSULT Function (BCM - DOOR LOCK)".
Without CONSULT
The automatic door locks (LOCK) function can be switched ON/OFF by performing the following operation:
1. Close all doors. (door switch OFF)
2. Push the ignition switch to the ON position.
3. Press and hold the door lock and unlock switch for 5 seconds or more in the lock direction within 20 sec- onds after turning the ignition switch ON.
4. The switching is completed when the hazard lamp blinks.
5. The ignition switch must be turned OFF and ON again between each setting change.
AUTOMATIC DOOR LOCKS (UNLOCK OPERATION)
The automatic door locks (UNLOCK) function is the func tion that unlocks all doors linked with the key position
or shift position.
IGN OFF Interlo ck Door Unlock*1
All doors are unlocked when the power supply position is changed from ON to OFF.
BCM outputs the unlock signal to all door lock actuator s when it detects that the power supply position is
changed from ignition switch ON to OFF.
Setting change of Automatic Door Locks (UNLOCK) Function
The UNLOCK operation setting of the automatic door locks function can be changed.
With CONSULT
The ON/OFF switching of the automatic door locks (UNL OCK) function and the type selection of the automatic
door locks (UNLOCK) function can be performed at the “Work support” setting. Refer to BCS-18, "
DOOR
LOCK : CONSULT Function (BCM - DOOR LOCK)".
Without CONSULT
The automatic door locks (UNLOCK) function can be sw itched ON/OFF by performing the following operation:
1. Close all doors. (door switch OFF)
2. Place the ignition switch in the ON position.
3. Press and hold the door lock and unlock switch for 5 seconds or more in the unlock direction within 20 seconds after turning the power supply position ON.
4. The switching is completed when the hazard lamp blinks.
5. The ignition switch must be turned OFF and ON again between each setting change.
*1: This function is set to ON before delivery.
OFF → ON : 2 blinks
ON → OFF : 1 blink
OFF → ON : 2 blinks
ON → OFF : 1 blink
Revision: August 2015 2016 Versa Note

cardiagn.com
