EC-420
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
P2135 TP SENSOR
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between electric thro
ttle control actuator harness connector and ground.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair open circuit or short to ground or short to power in harness or connectors.
4.CHECK THROTTLE POSITION SENSOR INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Check the continuity between electric thro ttle control actuator harness connector and ground.
2. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair open circuit or short to ground or short to power in harness or connectors.
5.CHECK THROTTLE POSITION SENSOR
Refer to EC-420, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 7.
NO >> GO TO 6.
6.REPLACE ELECTRIC THROTTLE CONTROL ACTUATOR
Replace electric throttle control actuator. Refer to EM-28, "
Removal and Installation".
>> INSPECTION END
7.CHECK INTERMITTENT INCIDENT
Refer to GI-42, "
Intermittent Incident".
>> INSPECTION END
Component InspectionINFOID:0000000012431631
1.CHECK THROTTLE POSITION SENSOR
1. Turn ignition switch OFF.
2. Reconnect all harness connectors disconnected.
3. Perform EC-129, "
Description".
4. Turn ignition switch ON.
5. Set selector lever to D (CVT) or 1st (M/T) position.
6. Check the voltage between ECM harness connector and ground.
Electric throttle control actuator ECM
Continuity
Connector Terminal Connector Terminal
F7 4F11 36 Existed
Electric throttle control actuator ECM
Continuity
Connector Terminal Connector Terminal
F7 1
F11 33
Existed
33 4
Revision: August 2015 2016 Versa Note

cardiagn.com

EC-432
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
P219C, P219D, P219E, P219F AIR FUEL RATIO
With CONSULT
1. On CONSULT screen, select the following items in “DATA MONITOR”.
- ENG SPEED
- COOLAN TEMP/S
- B/FUEL SCHDL
- A/F IMBALNC DIAG-CPS STAT
- A/F IMBLNC DIAG-CPS CMPLT
2. Drive vehicle under the following conditions for at least 20 consecutive seconds. CAUTION:
• Always drive vehicle at a safe speed.
• This procedure must be performed by two or more persons.
NOTE:
•Keep the accelerator pedal as possible during cruising.
• Drive the vehicle at approximately 88 km/h (55MPH) allows easy diagnosis.
3. Check “A/F IMBLNC DIAG -CPS CMPLT” indication.
Is
“CMPLT” displayed?
YES >> GO TO 5.
NO >> GO TO 2.
5.PERFORM DTC CONFIRMATION PROCEDURE-3
Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-433, "Diagnosis Procedure".
NO >> INSPECTION END
6.PERFORM DTC CONFIRMATION PROCEDURE-4
With GST
1. Start the engine and warm it up to normal operating temperature.
2. Drive vehicle under the following conditions for at least 20 consecutive seconds. CAUTION:
• Always drive vehicle at a safe speed.
NOTE:
•Keep the accelerator pedal as possible during crusing.
• Drive the vehicle at approximately 88 km/h (55MPH) allows easy diagnosis.
3. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-433, "Diagnosis Procedure".
NO >> INSPECTION END
ENG SPEED 2,000 – 2,600 rpm (M/T)
1,400 – 2,000 rpm (CVT)
COOLAN TEMP/S More than 80°C (176 °F)
B/FUEL SCHDL 6 – 8 msec
Selector lever 4th or more (M/T)
D position (CVT)
A/F IMBALNC DIAG-CPS STAT PRSNT
Engine speed 2,000 – 2,600 rpm (M/T)
1,400 – 2,000 rpm (CVT)
Calculated load value 46 – 73% (M/T)
49 – 79% (CVT)
Selector lever 4th or more (M/T)
D position (CVT)
Revision: August 2015
2016 Versa Note

cardiagn.com

COOLING FANEC-441
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
COOLING FAN
Component Function CheckINFOID:0000000012431641
1.CHECK COOLING FAN FUNCTION
With CONSULT
1. Turn ignition switch ON.
2. Perform “COOLING FAN” in “A CTIVE TEST” mode with CONSULT.
3. Touch “LOW” and “Hi” on the CONSULT screen.
4. Check that cooling fan operates.
NOTE:
The cooling fan operates at high speeds even when “LOW” is selected in CONSULT “ACTIVE TEST”. (For sin-
gle connector cooling fan with M/T models)
Without CONSULT
1. Perform IPDM E/R auto active test and check cooling fan motor operation. Refer to PCS-9, "
Diagnosis
Description".
2. Check that cooling fan operates.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Refer to EC-441, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000012431642
1.CHECK COOLING FAN MOTOR CIRCUIT
1. Disconnect cooling fan motor harness connector.
2. Check the continuity between IPDM E/R harne ss connector and cooling fan motor harness connector.
CVT models
M/T models
3. Check the continuity between cooling fan relay harness connector and cooling fan motor harness connec-
tor.
CVT models
M/T models
4. Check the continuity between cooling fan motor harness connector and ground.
IPDM E/R Cooling fan motor
Continuity
Connector Terminal Connector Terminal
E43 7E
51
Existed
5E 323
IPDM E/R Cooling fan motor
Continuity
Connector Terminal Connector Terminal
E43 7
E31 2
Existed
51
Cooling fan relay Cooling fan motor
Continuity
Connector Terminal Connector Terminal
E62 5E32 4 Existed
Cooling fan relay Cooling fan motor
Continuity
Connector Terminal Connector Terminal
E62 5E31 4 Existed
Revision: August 2015 2016 Versa Note

cardiagn.com

EC-442
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
COOLING FAN
CVT models
M/T models
5. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair open circuit or short to ground or short to power in harness or connectors.
2.CHECK COOLING FAN RELAY CIRCUIT
1. Disconnect cooling fan relay harness connector.
2. Disconnect IPDM E/R harness connector.
3. Check the continuity between IPDM E/R harnes s connector and cooling fan relay harness connector.
4. Check the continuity between cooling fan relay harness connector and ground.
5. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair open circuit or short to ground or short to power in harness or connectors.
3.CHECK COOLING FAN RELAY
Refer to EC-443, "
Component Inspection (Cooling Fan Relay)".
YES or NO
YES >> GO TO 4.
NO >> Replace cooling fan relay.
4.CHECK COOLING FAN MOTOR
Refer to EC-443, "
Component Inspection (Cooling Fan Motor)".
YES or NO
YES >> GO TO 5.
NO >> Replace cooling fan motor. Refer to CO-16, "
Exploded View".
5.CHECK INTERMITTENT INCIDENT
Perform GI-42, "
Intermittent Incident".
YES or NO
YES >> Replace IPDM E/R. Refer to PCS-30, "Removal and Installation".
NO >> Repair or replace harness or connector.
Cooling fan motor Ground Continuity
Connector Terminal
E5 2Ground Existed
Cooling fan motor Ground Continuity
Connector Terminal
E31 3Ground Existed
IPDM E/R Cooling fan relay
Continuity
Connector Terminal Connector Terminal
E46 65
E62 1
Existed
59 2
Cooling fan relay Ground Continuity
Connector Terminal
E62 3Ground Existed
Revision: August 2015 2016 Versa Note

cardiagn.com

COOLING FANEC-443
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Component Inspection (Cooling Fan Motor)INFOID:0000000012431643
1.CHECK COOLING FAN MOTOR
1. Turn ignition switch OFF.
2. Disconnect cooling fan motor harness connector.
3. Supply cooling fan motor terminals with battery voltage and check operation.
CVT models
M/T models
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace cooling fan motor. Refer to CO-16, "
Exploded View".
Component Inspection (Cooling Fan Relay)INFOID:0000000012431644
1.CHECK COOLING FAN RELAY
1. Turn ignition switch OFF.
2. Remove cooling fan relay.
3. Check continuity between cooling fan relay terminals under the following conditions.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace cooling fan relay.
Cooling fan motor Operation
Connector +
−
terminals
E5 1 2 Cooling fan motor operates
E32 3 4
Cooling fan motor Operation
Connector +
−
terminals
E31 23
Cooling fan motor operates
14
Cooling fan relay ConditionsContinuity
terminals
35 12 V direct current supply between
terminals 1 and 2
Existed
No current supply Not existed
JSBIA0671ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

EC-478
< SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
Idle SpeedINFOID:0000000012431675
*: Under the following conditions
• A/C switch: OFF
• Electric load: OFF (Lights, heater fan & rear window defogger)
• Steering wheel: Kept in straight-ahead position
Ignition TimingINFOID:0000000012431676
*: Under the following conditions
• A/C switch: OFF
• Electric load: OFF (Lights, heater fan & rear window defogger)
• Steering wheel: Kept in straight-ahead position
Calculated Load ValueINFOID:0000000012431677
Mass Air Flow SensorINFOID:0000000012431678
*: Engine is warmed up to normal operating temperature and running under no load.Transmission Condition Specification
CVT No load* (in P or N position) 650 ± 50 rpm
M/T No load* (in Neutral position) 650 ± 50 rpm
Transmission ConditionSpecification
CVT No load* (in P or N position) 4 ± 5 °BTDC
M/T No load* (in Neutral position) 10 ± 5°BTDC
Condition Specification (Using CONSULT or GST)
At idle 10 – 35%
At 2,500 rpm 10 – 35%
Supply voltageBattery voltage (11 – 14 V)
Output voltage at idle 0.8 – 1.3 V*
Mass air flow (Using CONSULT or GST) 0.8 – 4.0 g/s at idle*
2.0 – 10.0 g/s at 2,500 rpm*
Revision: August 2015 2016 Versa Note

cardiagn.com

CO-4
< SYSTEM DESCRIPTION >[HR16DE]
DESCRIPTION
SYSTEM DESCRIPTION
DESCRIPTION
Engine Cooling SystemINFOID:0000000012432130
M/T models
CVT models
JSBIA1096GB
JSBIA1297GB
Revision: August 2015 2016 Versa Note

cardiagn.com

DESCRIPTIONCO-5
< SYSTEM DESCRIPTION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
CO
NP
O
Engine Cooling System SchematicINFOID:0000000012432131
M/T models
CVT models
AWBIA1141GB
AWBIA1142GB
Revision: August 2015 2016 Versa Note

cardiagn.com

RADIATORCO-13
< REMOVAL AND INSTALLATION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
CO
NP
O
REMOVAL AND INSTALLATION
RADIATOR
Exploded ViewINFOID:0000000012432139
Removal and InstallationINFOID:0000000012432140
REMOVAL
WARNING:
Do not remove the radiator cap when the engine is
hot. Serious burns could occur from high-pressure
engine coolant escaping from the radi ator. Wrap a thick cloth around the radiator cap. Slowly turn it a
quarter of a turn to release built-up pressure. Carefu lly remove radiator cap by turning it all the way.
NOTE:
When removing components such as hoses, tubes/lines, etc. , cap or plug openings to prevent fluid from spill-
ing.
1. Reservoir tank hose 2. Reservoir tank cap 3. Reservoir tank
4. Mounting rubber (lower) 5. O-ring6. Drain plug
7. Radiator 8. Cooling fan assembly 9. Clamp
10. Radiator hose (lower) 11. Clamp12. Oil cooler hose
13. Radiator hose to water outlet (upper) 14. Radiator cap adapter 15. Radiator cap
16. Radiator cap adapter bracket 17. Clamp 18. Radiator hose (upper) to radiator
19. Mounting rubber (upper) 20. CVT cooler hose 21. Clamp
21. Clamp 22. Clamp23. CVT cooler hose
24. Clamp A. To water inletB. To water outlet
C. To oil cooler
AWBIA2770ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

CO-14
< REMOVAL AND INSTALLATION >[HR16DE]
RADIATOR
1. Drain engine coolant. Refer to
CO-8, "Draining Engine Coolant".
CAUTION:
• Perform this step when the engine is cold.
• Do not spill engine coolant on drive belt.
2. Remove air duct (inlet). Refer to EM-26, "
Removal and Installation".
3. Disconnect battery negative terminal. Refer to PG-70, "
Removal and Installation (Battery)".
4. Remove radiator hose (lower).
5. Remove radiator hose (upper) from water outlet.
6. Remove the front under cover. Refer to EXT-39, "
FRONT UNDER COVER : Removal and Installation".
7. Remove the front grille. Refer to EXT-32, "
Removal and Installation".
8. Disconnect reservoir tank hose, and remove reservoir tank.
9. Disconnect harness connector from fan motor, and move harness aside.
10. Remove radiator core support (upper). Refer to DLK-144, "
RADIATOR CORE SUPPORT UPPER :
Removal and Installation".
11. Remove the condenser bolts and place aside. Refer to HA-31, "
CONDENSER : Removal and Installa-
tion".
12. Remove radiator hose (upper) from radiator.
13. Remove cooling fan assembly. Refer to CO-16, "
Removal and Installation".
CAUTION:
Be careful not to damage or scratch the radiator.
14. Disconnect CVT cooler lines.
15. Remove the radiator from bottom of the vehicle. CAUTION:
When removing, do not damage or scrat ch radiator core or A/C condenser.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
Do not reuse O-ring.
• Insert the radiator hose (1) all the way to the stopper (2) or by 33 mm (1.30 in) (hose without a stopper) as
shown.
• The correct orientation of the hose clamps are as shown.
*: Refer to the illustrations for the specific position for each hose clamp tab. 1. Radiator hose
2. Stopper
A. Radiator side B. Engine side
JPBIA4294GB
Radiator hoseHose endPaint mark
Position of hose clamp*
Radiator hose (upper) Radiator side
UpperA
Engine side UpperB
Radiator hose (lower) Radiator side
LowerC
Engine side UpperD
Revision: August 2015 2016 Versa Note

cardiagn.com
