NISSAN NOTE 2016 Service Repair Manual

DLK-122
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
IGN OFF INTERLOCK DOOR UNLOCK FUNCTION DOES NOT OPERATE
IGN OFF INTERLOCK DOOR UNLOCK
FUNCTION DOES NOT OPERATE
Diagnosis ProcedureINFOID:0000000012430072
1.CHECK AUTOMATIC LOCK/UNLOCK SELECT SETTING IN WORK SUPPORT
1. Select “DOOR LOCK” of “BCM” using CONSULT.
2. Select “AUTOMATIC LOCK/UNLOCK SELECT” in “Work support”.
3. Check “AUTOMATIC LOCK/UNLOCK SE LECT” setting in “Work support”.
Refer to BCS-18, "
DOOR LOCK : CONSULT Func tion (BCM - DOOR LOCK)".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Set “Unlock Only” or “Lock/Unlock” in “AUTOMATIC LOCK/UNLOCK SELECT”.
2.CHECK AUTOMATIC DOOR UNLOCK SELECT SETTING IN WORK SUPPORT
1. Select “DOOR LOCK” of “BCM” using CONSULT.
2. Select “AUTOMATIC DOOR UNLOCK SELECT” in “Work support”.
3. Check “AUTOMATIC DOOR UNLOCK SE LECT” setting in “Work support”.
Refer to BCS-18, "
DOOR LOCK : CONSULT Func tion (BCM - DOOR LOCK)".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Set “MODE 1” or “MODE 3” in “AUTOMATIC DOOR UNLOCK SELECT”.
3.REPLACE BCM
1. Replace BCM. Refer to BCS-74, "
Removal and Installation".
2. Confirm the operation after replacement.
Is the result normal?
YES >> Inspection End.
NO >> Check intermittent incident. Refer to GI-42, "
Intermittent Incident".
Revision: August 2015 2016 Versa Note

cardiagn.com

HAZARD AND BUZZER REMINDER DOES NOT OPERATEDLK-123
< SYMPTOM DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
HAZARD AND BUZZER REMI NDER DOES NOT OPERATE
Diagnosis ProcedureINFOID:0000000012430073
1.CHECK HAZARD ANSWER BACK SETTING IN WORK SUPPORT
1. Select “INTELLIGENT KEY” of “BCM” using CONSULT.
2. Select “HAZARD ANSWER BACK” in “Work support”.
3. Check the “HAZARD ANSWER BA CK” setting in “Work support”.
Refer to BCS-22, "
INTELLIGENT KEY : CONSULT Function (BCM - INTELLIGENT KEY)".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Set the “Lock Only”, “Unlock Only” or “Lock/Unlock” in “HAZARD ANSWER BACK”.
2.CHECK ANS BACK I-KEY LOCK SETTING IN WORK SUPPORT
1. Select “INTELLIGENT KEY” of “BCM” using CONSULT.
2. Select “ANS BACK I-KE Y LOCK” in “Work support.
3. Check the “ANS BACK I-KEY LOCK” setting in “Work support”. Refer to BCS-22, "
INTELLIGENT KEY : CONSULT Function (BCM - INTELLIGENT KEY)".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Set the “Horn Chirp” or “Buzzer” in “ANS BACK I-KEY LOCK”.
3.CHECK ANS BACK I-KEY UNLOCK SETTING IN WORK SUPPORT
1. Select “INTELLIGENT KEY” of “BCM” using CONSULT.
2. Select “ANS BACK I-KEY UNLOCK” in “Work support”.
3. Check the “ANS BACK I-KEY UNLOCK” setting in “Work support”. Refer to BCS-22, "
INTELLIGENT KEY : CONSULT Function (BCM - INTELLIGENT KEY)".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Set the “On” in “ANS BACK I-KEY UNLOCK”.
4.CHECK HAZARD FUNCTION
Check hazard function.
Refer to DLK-101, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace the malfunctioning parts.
5.CHECK INTELLIGENT KEY WARNING BUZZER
Check Intelligent Key warning buzzer.
Refer to DLK-102, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace the malfunctioning parts.
6.REPLACE BCM
1. Replace BCM. Refer to BCS-74, "
Removal and Installation".
2. Confirm the operation after replacement.
Is the result normal?
YES >> Inspection End.
NO >> Check intermittent incident. Refer to GI-42, "
Intermittent Incident".
Revision: August 2015 2016 Versa Note

cardiagn.com

DLK-124
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
KEY REMINDER FUNCTION DOES NOT OPERATE
KEY REMINDER FUNCTION DOES NOT OPERATE
Diagnosis ProcedureINFOID:0000000012430074
1.CHECK ANTI KEY LOCK IN F
UNCTI SETTING IN WORK SUPPORT
1. Select “INTELLIGENT KEY” of “BCM” using CONSULT.
2. Select “ANTI KEY LOCK IN FUNCTI” in “Work support”.
3. Check “ANTI KEY LOCK IN FUNCTI” setting in “Work support”.
Refer to BCS-22, "
INTELLIGENT KEY : CONSULT Func tion (BCM - INTELLIGENT KEY)".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Set “On” in “ANTI KEY LOCK IN FUNCTI”.
2.CHECK DOOR SWITCH
Check door switch.
Refer to DLK-98, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace the malfunctioning parts.
3.CHECK INSIDE KEY ANTENNA
Check inside key antenna.
• Instrument center: Refer to DLK-65, "
DTC Logic".
• Console: Refer to DLK-67, "
DTC Logic".
• Trunk room: Refer to DLK-69, "
DTC Logic".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace the malfunctioning parts.
4.CHECK UNLOCK SENSOR
Check unlock sensor.
Refer to DLK-92, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace the malfunctioning parts.
5.REPLACE BCM
1. Replace BCM. Refer to BCS-74, "
Removal and Installation".
2. Confirm the operation after replacement.
Is the result normal?
YES >> Inspection End.
NO >> Check intermittent incident. Refer to GI-42, "
Intermittent Incident".
Revision: August 2015 2016 Versa Note

cardiagn.com

OFF POSITION WARNING DOES NOT OPERATEDLK-125
< SYMPTOM DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
OFF POSITION WARNIN G DOES NOT OPERATE
Diagnosis ProcedureINFOID:0000000012430075
1.CHECK DTC WITH BCM
Check that DTC is not detected with BCM.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Perform trouble diagnosis relevant to DTC indicated.
2.CHECK DTC WITH COMBINATION METER
Check that DTC is not detected with combination meter.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Perform trouble diagnosis relevant to DTC indicated.
3.CHECK DOOR SWITCH
Check front door switch LH.
Refer to DLK-98, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace the malfunctioning parts.
4.CHECK COMBINATION METER BUZZER
Check combination meter buzzer.
Refer to DLK-78, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace the malfunctioning parts.
5.CHECK INTELLIGENT KEY WARNING BUZZER
Check Intelligent Key warning buzzer.
Refer to DLK-102, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace the malfunctioning parts.
6.REPLACE BCM
1. Replace BCM. Refer to BCS-74, "
Removal and Installation".
2. Confirm the operation after replacement.
Is the result normal?
YES >> Inspection End.
NO >> Check intermittent incident. Refer to GI-42, "
Intermittent Incident".
Revision: August 2015 2016 Versa Note

cardiagn.com

DLK-126
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
P POSITION WARNING DOES NOT OPERATE
P POSITION WARNING DOES NOT OPERATE
Diagnosis ProcedureINFOID:0000000012430076
1.CHECK DTC WITH BCM
Check that DTC is not detected with BCM.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Perform trouble diagnosis relevant to DTC indicated.
2.CHECK DTC WITH COMBINATION METER
Check that DTC is not detected with combination meter.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Perform trouble diagnosis relevant to DTC indicated.
3.CHECK INTELLIGENT KEY WARNING BUZZER
Check Intelligent Key warning buzzer.
Refer to DLK-102, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace the malfunctioning parts.
4.CHECK COMBINATION METER BUZZER
Check combination meter buzzer.
Refer to DLK-78, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace the malfunctioning parts.
5.CHECK DOOR SWITCH
Check front door switch LH.
Refer to DLK-98, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace the malfunctioning parts.
6.CHECK KEY WARNING LAMP
Check key warning lamp.
Refer to DLK-105, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair or replace the malfunctioning parts.
7.CHECK SHIFT P WARNING LAMP
Check shift P warning lamp.
Refer to D L K - 111 , "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 8.
NO >> Repair or replace the malfunctioning parts.
8.REPLACE BCM
1. Replace BCM. Refer to BCS-74, "
Removal and Installation".
2. Confirm the operation after replacement.
Is the result normal?
YES >> Inspection End.
Revision: August 2015 2016 Versa Note

cardiagn.com

P POSITION WARNING DOES NOT OPERATEDLK-127
< SYMPTOM DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
NO >> Check intermittent incident. Refer to GI-42, "Intermittent Incident".
Revision: August 2015 2016 Versa Note

cardiagn.com

DLK-128
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
ACC WARNING DOES NOT OPERATE
ACC WARNING DOES NOT OPERATE
Diagnosis ProcedureINFOID:0000000012430077
1.CHECK DTC WITH BCM
Check that DTC is not detected with BCM.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Perform trouble diagnosis relevant to DTC indicated.
2.CHECK DTC WITH COMBINATION METER
Check that DTC is not detected with combination meter.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Perform trouble diagnosis relevant to DTC indicated.
3.CHECK COMBINATION METER BUZZER
Check combination meter buzzer.
Refer to DLK-78, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace the malfunctioning parts.
4.REPLACE BCM
1. Replace BCM. Refer to BCS-74, "
Removal and Installation".
2. Confirm the operation after replacement.
Is the result normal?
YES >> Inspection End.
NO >> Check intermittent incident. Refer to GI-42, "
Intermittent Incident".
Revision: August 2015 2016 Versa Note

cardiagn.com

TAKE AWAY WARNING DOES NOT OPERATEDLK-129
< SYMPTOM DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
TAKE AWAY WARNING DOES NOT OPERATE
Diagnosis ProcedureINFOID:0000000012430078
1.CHECK DTC WITH BCM
Check that DTC is not detected with BCM.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Perform trouble diagnosis relevant to DTC indicated.
2.CHECK DTC WITH COMBINATION METER
Check that DTC is not detected with combination meter.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Perform trouble diagnosis relevant to DTC indicated.
3.CHECK INSIDE KEY ANTENNA
Check inside key antenna.
• Instrument center: Refer to DLK-65, "
DTC Logic".
• Console: Refer to DLK-67, "
DTC Logic".
• Trunk room: Refer to DLK-69, "
DTC Logic".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace the malfunctioning parts.
4.CHECK DOOR SWITCH
Check door switch.
Refer to DLK-98, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace the malfunctioning parts.
5.CHECK COMBINATION METER BUZZER
Check combination meter buzzer.
Refer to DLK-78, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace the malfunctioning parts.
6.CHECK INTELLIGENT KEY WARNING BUZZER
Check Intelligent Key warning buzzer.
Refer to DLK-102, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair or replace the malfunctioning parts.
7.CHECK KEY WARNING LAMP
Check key warning lamp.
Refer to DLK-105, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 8.
NO >> Repair or replace the malfunctioning parts.
8.REPLACE BCM
1. Replace BCM. Refer to BCS-74, "
Removal and Installation".
2. Confirm the operation after replacement.
Revision: August 2015 2016 Versa Note

cardiagn.com

DLK-130
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
TAKE AWAY WARNING DOES NOT OPERATE
Is the result normal?
YES >> Inspection End.
NO >> Check intermittent incident. Refer to
GI-42, "
Intermittent Incident".
Revision: August 2015 2016 Versa Note

cardiagn.com

INTELLIGENT KEY LOW BATTERY WARNING DOES NOT OPERATE
DLK-131
< SYMPTOM DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
INTELLIGENT KEY LOW BATTERY WARNING DOES NOT OPERATE
Diagnosis ProcedureINFOID:0000000012430079
1.CHECK DTC WITH BCM
Check that DTC is not detected with BCM.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Perform trouble diagnosis relevant to DTC indicated.
2.CHECK DTC WITH COMBINATION METER
Check that DTC is not detected with combination meter.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Perform trouble diagnosis relevant to DTC indicated.
3.CHECK LO- BATT OF KEY FOB WARN SETTING IN WORK SUPPORT
1. Select “INTELLIGENT KEY” of BCM.
2. Select “LO- BATT OF KEY FOB WARN” in “Work support”.
3. Check “LO- BATT OF KEY FOB WARN” setting in “Work support”. Refer to BCS-22, "
INTELLIGENT KEY : CONSULT Function (BCM - INTELLIGENT KEY)".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Set “ON” in “LO- BATT OF KEY FOB WARN”.
4.CHECK INTELLIGENT KEY
Check Intelligent Key.
Refer to DLK-104, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace the malfunctioning parts.
5.CHECK INSIDE KEY ANTENNA
Check inside key antenna.
• Instrument center: Refer to DLK-65, "
DTC Logic".
• Console: Refer to DLK-67, "
DTC Logic".
• Trunk room: Refer to DLK-69, "
DTC Logic".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace the malfunctioning parts.
6.CHECK KEY WARNING LAMP
Check key warning lamp.
Refer to DLK-105, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair or replace the malfunctioning parts.
7.REPLACE BCM
1. Replace BCM. Refer to BCS-74, "
Removal and Installation".
2. Confirm the operation after replacement.
Is the result normal?
YES >> Inspection End.
NO >> Check intermittent incident. Refer to GI-42, "
Intermittent Incident".
Revision: August 2015 2016 Versa Note

cardiagn.com
